15Pictorial index
4RUNNER (U)_(OM35B37U)
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 369
Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . P. 472
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 272
Checking/rotation/tire pressure warning system . . . . . . . . . P. 369
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 433
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 353
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 353
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 465
Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 457
Headlights/daytime running lights . . . . . . . . . . . . . . . . . . . . P. 208
Front side marker lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 208
Front turn signal/parking lights . . . . . . . . . . . . . . . . . . . . . . P. 208
Fog lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 214
Turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 206
Stop/tail lights/rear side marker lights . . . . . . . . . . . . . . . . P. 208
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 208
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 201
6
7
Light bulbs of the exterior lights for driving
(Replacing method: P. 389, Wattages: P. 473)
*: Vehicles with a smart key system
8
9
10
11
12
13
14
15

2064-2. Driving procedures
4RUNNER (U)_(OM35B37U)
The lever will return to its original position after operation.
Right turn
Lane change to the right (push
and hold the lever partway)
The right hand signals will flash
until you release the lever.
Lane change to the left (push
and hold the lever partway)
The left hand signals will flash until
you release the lever.
Left turn
■ Turn signals can be operated when
Vehicles without a smart key system
The engine switch is in the “ON” position.
Vehicles with a smart key system
The engine switch is in IGNITION ON mode.
■ If the indicator flashes faster than usual
Check that a light bulb in the front or rear turn signal lights has not burned
out.
Turn signal lever
Operating instructions
1
2
3
4

3906-3. Do-it-yourself maintenance
4RUNNER (U)_(OM35B37U)■
Front
■Rear
Bulb locations
Headlight low beam
Headlight high beam/day-
time running light
Fog light
Front turn signal/parking
light
Front side marker light1
2
3
4
5
Rear turn signal light
Back-up light
License plate light1
2
3

4006-3. Do-it-yourself maintenance
4RUNNER (U)_(OM35B37U)■
Rear turn signal lights
Open the back door and
remove the cover.
To prevent damage to the vehi-
cle, cover the tip of the screw-
driver with a rag.
Turn the bulb base counter-
clockwise.
Remove the light bulb.
When installing, reve rse the steps listed.
1
2
3
4

4036-3. Do-it-yourself maintenance
6
Maintenance and care
4RUNNER (U)_(OM35B37U)■
Replacing the following bulbs
If any of the lights listed below
has burnt out, have it replaced by
your Toyota dealer.
● Fog light (right side)
● Side turn signal lights
● Stop/tail lights
● Rear side marker lights
● High mounted stoplight
● Outer foot lights (if equipped)
■LED light bulbs
The side turn signal lights, stop/tail lights, rear side marker lights, \
high
mounted stoplight and outer foot lights consist of a number of LEDs. If any
LEDs burn out, take your vehicle to your Toyota dealer to have the light
replaced.
■ Condensation build-up on the inside of the lens
Temporary condensation build-up on the inside of the lens does not indicate a
malfunction. Contact your Toyota dealer for more information in the following
situations:
●Large drops of water have built up on the inside of the lens.
● Water has built up inside the lens.
CAUTION
■Replacing light bulbs
● Turn off the lights. Do not attempt to replace the bulb immediately after
turning off the lights.
The bulbs become very hot and may cause burns.
● Do not touch the glass portion of the light bulb with bare hands. When it is
unavoidable to hold the glass portion, use and hold with a clean dry cloth
to avoid getting moisture and oils on the bulb.
Also, if the bulb is scratched or dropped, it may blow out or crack.
● Fully install light bulbs and any parts used to secure them. Failure to do so
may result in heat damage, fire, or water entering the headlight unit. This
may damage the headlights or cause condensation to build up on the lens.
■ To prevent damage or fire
● Make sure bulbs are fully seated and locked.
● Check the wattage of the bulb before installing to prevent heat damage.

4738-1. Specifications
8
Vehicle specifications
4RUNNER (U)_(OM35B37U)
Light bulbs
Light bulbsBulb No.WTy p e
Exterior
HeadlightsLow beam
High beam and daytime run-
ning lights
⎯
900555
60A
B
Front turn signal and parking
lights7444NA28/8E
Front side marker lights⎯5D
Fog lights⎯19C
Rear turn signal lights⎯21E
Back-up lights⎯16D
License plate lights⎯5D
Interior
Front personal/ front interior
lights⎯5D
Rear interior light⎯8F
Vanity lights⎯8D
Door courtesy lights1685D
Luggage compartment lights⎯8F
A: H11 halogen bulbs
B: HB3 halogen bulbs
C: H16 halogen bulbs D: Wedge base bulbs (clear)
E: Wedge base bulbs (amber) F: Double end bulbs

520Alphabetical index
4RUNNER (U)_(OM35B37U)
EngineACCESSORY mode ............. 197
Compartment ........................ 354
Engine switch................ 193, 196
Hood ..................................... 353
How to start the
engine......................... 193, 196
Identification number ............ 463
If the engine will not start ...... 448
Ignition switch (engine switch) ........... 193, 196
Overheating .......................... 457
Engine coolant ......................... 359 Capacity ................................ 468
Checking ............................... 359
Preparing and checking before winter....................... 272
Engine coolant temperature gauge........................................ 81
Engine immobilizer system ...... 70
Engine oil ................................. 356
Capacity ................................ 465
Checking ............................... 356
Preparing and checking before winter....................... 272
Engine switch .................. 193, 196
Event data recorder (EDR) ........ 10
Flat tire...................................... 433
Floor mats .................................. 26
Fluid Automatic transmission......... 471
Brake .................................... 471
Power steering ...................... 472
Washer ................................. 367
Fog lights ................................. 214 Replacing light bulbs............. 389
Switch ................................... 214
Wattage ................................ 473
Four-wheel drive
system ............................ 235, 239 Front passenger occupant
classification system .............. 46
Front personal lights............... 298
Front seats ............................... 120 Adjustment............................ 120
Cleaning ............................... 341
Correct driving posture ........... 28
Driving position memory ....... 133
Head restraints ..................... 137
Seat heaters ......................... 295
Seat position memory ........... 133
Seat ventilators ..................... 295
Front side marker lights ......... 208 Light switch ........................... 208
Replacing light bulbs ............ 396
Wattage ................................ 473
Front turn signal lights ........... 206
Replacing light bulbs ............ 394
Turn signal lever ................... 206
Wattage ................................ 473
Fuel ........................................... 222 Capacity................................ 464
Fuel gauge.............................. 81
Fuel pump shut off system ... 416
Information............................ 474
Refueling .............................. 222
Type.............................. 222, 464
Warning light......................... 419
Fuel filler door ......................... 222 Refueling .............................. 222
Fuel pump shut off system..... 416
Fuses ........................................ 386
Garage door opener ................ 324
Gauges ....................................... 81
Glove box ................................. 301
Grocery bag hooks.................. 310
F
G

521Alphabetical index
4RUNNER (U)_(OM35B37U)
Head restraints ........................ 137
Headlights ................................ 208Light switch ........................... 208
Replacing light bulbs ................... 391, 393, 403
Wattage ................................ 473
Heaters
Air conditioning system ....... ................. 282, 288
Outside rear view
mirrors ....................... 284, 290
Seat heaters ......................... 295
Hill-start assist control............ 264
Hood ......................................... 353
Hooks Cargo hooks ......................... 307
Cargo net hooks ................... 308
Grocery bag hooks ............... 310
Retaining hooks (floor mat)..... 26
Horn .......................................... 140
I/M test ...................................... 349
Identification Engine................................... 463
Vehicle .................................. 463
Ignition switch (engine switch) .............. 193, 196
Illuminated entry system ........ 299
Immobilizer system ................... 70
Indicators ................................... 79
Initialization Maintenance ......................... 345
Moon roof.............................. 156
Power back window .............. 152
Power windows ..................... 148
Inside rear view mirror ............ 142
Instrument panel light
control ...................................... 82
Interior lights............................ 297
Intuitive parking assist............ 229 Jack
Vehicle-equipped jack .......... 433
Jack handle .............................. 437
Jam protection function Moon roof ............................. 155
Power back window .............. 152
Power windows..................... 147
KDSS ........................................ 264
Keyless entry ........................... 104 Smart key system ................. 104
Wireless remote control .......... 97
Keys ............................................ 90 Battery-saving function ......... 107
Electronic key ......................... 90
Engine switch ............... 193, 196
If the electronic key
does not operate
properly .............................. 451
Key number plate ................... 90
Keyless entry .......................... 97
Mechanical key ....................... 92
Replacing the battery............ 383
Warning buzzer .................... 106
Wireless remote control
key........................................ 97
Knee airbags .............................. 35
LATCH anchors ......................... 59
Lever Auxiliary catch lever.............. 353
Hood lock release lever ........ 353
Shift lever.............................. 201
Turn signal lever ................... 206
Wiper lever ................... 216, 219
H
I
J
K
L
