812. Instrument cluster
2
Instrument cluster
4RUNNER (U)_(OM35B37U)
Tachometer
Displays the engine speed in revolutions per minute
Engine coolant temperature gauge
Displays the engine coolant temperature
Shift position and shift range
Displays the selected shift position or selected shift range (→P. 201)
Fuel gauge
Displays the quantity of fuel remaining in the tank
Speedometer
Displays the vehicle speed
Odometer/trip meter display change button
Switches the trip information.
Multi-information display
Presents the driver with a variety of vehicle data →P. 8 3
Gauges and meters
The displayed content may differ depending on the type of
meter.
1
2
3
4
5
6
7

832. Instrument cluster
2
Instrument cluster
4RUNNER (U)_(OM35B37U)
The multi-information display presents the driver with a variety of driv-
ing-related data.
*1: If equipped
*2: Vehicles with a navigation system
■
Switching the display
Items displayed can be
switched by pressing the dis-
play change button.
■Odometer
Displays the total distance the vehicle has been driven.
Multi-information display
Display contents
Driving monitor ( →P. 84)
Warning messages
( → P. 426)
Multi-terrain Se lect messages
*1
(→ P. 260)
Eco Driving Indicator Zone Dis-
play ( →P. 8 7 ) Outside temperature display
(
→ P. 314)
Trip information
Ice indicator ( →P. 314)
Compass*2 ( → P. 85)
Multi-terrain Select display
*1
( → P. 256)
Trip information
1
2
3
4
5
6
7
8
9

872. Instrument cluster
2
Instrument cluster
4RUNNER (U)_(OM35B37U)
●Items that can be changed
*: The default setting varies according to countries.
■Eco Driving Indicator
Eco Driving Indicator Light will not operate in the following conditions:
●The shift lever is in anything other than D.
● The vehicle speed is approximately 80 mph (130 km/h) or higher.
■ When disconnecting and reco nnecting battery terminals
The following information data will be reset:
● Trip meter
● Elapsed time
● Average fuel consumption
If the trip meter was displayed last, the odometer will be displayed after reset-
ting.
FunctionDefault settingCustomized setting
Language EnglishFrench
Spanish
Units “miles”
*“km (L/100km)”
“ECO LAMP” (Eco
Driving Indicator Light)ON (Self-lighting)OFF
Eco Driving Indicator Light
During Eco-friendly acceleration (Eco
driving), Eco Driving Indicator Light will
turn on.
Eco Driving Indicator Zone Display
Suggests Zone of Eco driving with cur-
rent Eco driving ratio based on acceler-
ation.
Zone of Eco driving
Eco driving ratio based on acceleration
If the vehicle exceeds Zone of Eco driv-
ing, the right side of Eco Driving Indica-
tor Zone Display will blink and Eco
Driving Indicator Light will turn off.1
2
3
4

522Alphabetical index
4RUNNER (U)_(OM35B37U)
License plate lights ................. 208Light switch ........................... 208
Replacing light bulbs............. 402
Wattage ................................ 473
Light bulbs
Replacing .............................. 391
Wattage ................................ 473
Lights
Fog light switch ..................... 214
Front Interior light.................. 298
Headlight switch.................... 208
Interior lights list .................... 297
Luggage compartment lights ................................... 117
Personal lights ...................... 298
Rear interior light .................. 298
Replacing light bulbs............. 391
Turn signal lever ................... 206
Vanity lights .......................... 312
Wattage ................................ 473
Limited slip differential ........... 264
Load capacity........................... 175
Lock steering column ........................... 194, 198
Luggage compartment features .................................. 307
Maintenance Do-it-yourself maintenance ... 350
General maintenance ........... 346
Maintenance data ................. 462
Maintenance requirements ... 344
Resetting the message indicating maintenance is
required .............................. 345
Malfunction indicator lamp ..... 417
Manual air conditioning system .................................... 282
Master warning light................ 426 Meter ........................................... 81
Indicators ................................ 79
Instrument panel light
control .................................. 82
Meters..................................... 81
Multi-information display ......... 83
Warning lights ......................... 77
Mirrors
Inside rear view mirror .......... 142
Outside rear view mirror defoggers ................... 284, 290
Outside rear view mirrors ..... 144
Vanity mirrors ....................... 312
Moon roof ................................. 154
Door lock linked moon roof operation ........... 156
Jam protection function ........ 155
Operation .............................. 154
Multi Terrain ABS .................... 263
Multi-information display.......... 83 Customizing vehicle features ................................ 86
Driving monitor ....................... 84
Switching the display .............. 84
Trip information....................... 83
Warning message................. 426
Multi-terrain Select .................. 256
Navigation system
*
Noise from under vehicle ........... 8
Odometer ................................... 81
Off-road precaution s ............... 276
Oil Engine oil .............................. 356
Opener Back door ............................. 116
Hood ..................................... 353
M
N
O
