4197-2. Steps to take in an emergency
7
When trouble arises
4RUNNER (U)_(OM35B37U)
(Flashes rapidly)
Low speed four-wheel drive indicator light (if
equipped) Indicates a malfunction in the four-wheel drive system
→ Have the vehicle inspected by your Toyota dealer
immediately.
(Flashes rapidly)
Center differential lock indicator light (if equipped) Indicates a malfunction in the four-wheel drive system
→ Have the vehicle inspected by your Toyota dealer
immediately.
(Flashes contin- uously)
Multi-terrain Select indi cator light (if equipped)
Indicates a malfunction in the Multi-terrain Select sys-
tem
→ Have the vehicle inspected by your Toyota dealer
immediately.
Power steering warning light Indicates a malfunction in the power steering system
→ Have the vehicle inspected by your Toyota dealer
immediately.
Unengaged “Park” warning light (if equipped) Indicates a malfunction in the transmission “Park”
mechanism.
→ Have the vehicle inspected by your Toyota dealer
immediately.
KDSS warning light (if equipped) Indicates a malfunction in KDSS
→ Have the vehicle inspected by your Toyota dealer
immediately.
(Flashes)
Automatic running boards indicator light (if
equipped)
Indicates a malfunction in Automatic running boards
→ Have the vehicle inspected by your Toyota dealer
immediately.
Open door warning light (warning buzzer)*2
Indicates that a door is not fully closed
→ Check that all the doors are closed.
Low fuel level warning light
Indicates remaining fuel is approximately 3.5 gal. (13.1
L, 2.9 Imp. gal.) or less
→ Refuel the vehicle.
Warning lightWarning light/Details/Actions

4728-1. Specifications
4RUNNER (U)_(OM35B37U)
Chassis lubrication
Propeller shafts
SpiderLithium base chassis grease, NLGI No.2
Slide yoke
Molybdenum-disulfide lithium base chas-
sis grease, NLGI No.2 or lithium base
chassis grease, NLGI No.2
Steering
Free playLess than 1.2 in. (30 mm)
Power steering fluid typeAutomatic transmission fluid DEXRON® II
or III
Tires and wheels
Tire sizeP265/70R17 113S, P245/60R20 107H
Tire inflation pressure
(Recommended cold tire
inflation pressure)
Front:
32 psi (220 kPa, 2.2 kgf/cm2 or bar)
Rear:
32 psi (220 kPa, 2.2 kgf/cm
2 or bar)
Spare:
32 psi (220 kPa, 2.2 kgf/cm
2 or bar)
Wheel size17 × 7J, 17 × 7 1/2J, 20 × 7J
Wheel nut torque
Steel wheels:
83 ft•lbf (112 N•m, 11.4 kgf•m)
Aluminum wheels:
76 ft•lbf (103 N•m, 10.5 kgf•m)

4838-1. Specifications
8
Vehicle specifications
4RUNNER (U)_(OM35B37U)
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure
Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressureThe maximum cold inflated pressure to which
a tire may be inflated, shown on the sidewall
of the tire
Recommended infla-
tion pressureCold tire inflation pressure recommended by a
manufacturer
Accessory weight
The combined weight (in excess of those stan-
dard items which may be replaced) of auto-
matic transmission, power steering, power
brakes, power windows, power seats, radio
and heater, to the extent that these items are
available as factory-installed equipment
(whether installed or not)
Curb weight
The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight
The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant
weight150 lb. (68 kg) times the number of occupants
specified in the second column of Table 1
*
that follows
Occupant distributionDistribution of occupants in a vehicle as speci-
fied in the third column of Table 1
* below

514What to do if... (Troubleshooting)
4RUNNER (U)_(OM35B37U)
●Vehicles without a smart key system:
It is locked to prevent theft of the vehicle if the key is pulled from the engine
switch. (→P. 194)
●Vehicles with a smart key system:
It is locked automatically to prevent theft of the vehicle. ( →P. 199)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. ( →P. 146)
●The auto power off function will be operated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a period of
time. ( →P. 198)
The steering wheel cannot be turned after the engine is
stopped
The windows do not open or close by operating the power
window switches
The engine switch is tu rned off automatically
(vehicles with a smart key system)

520Alphabetical index
4RUNNER (U)_(OM35B37U)
EngineACCESSORY mode ............. 197
Compartment ........................ 354
Engine switch................ 193, 196
Hood ..................................... 353
How to start the
engine......................... 193, 196
Identification number ............ 463
If the engine will not start ...... 448
Ignition switch (engine switch) ........... 193, 196
Overheating .......................... 457
Engine coolant ......................... 359 Capacity ................................ 468
Checking ............................... 359
Preparing and checking before winter....................... 272
Engine coolant temperature gauge........................................ 81
Engine immobilizer system ...... 70
Engine oil ................................. 356
Capacity ................................ 465
Checking ............................... 356
Preparing and checking before winter....................... 272
Engine switch .................. 193, 196
Event data recorder (EDR) ........ 10
Flat tire...................................... 433
Floor mats .................................. 26
Fluid Automatic transmission......... 471
Brake .................................... 471
Power steering ...................... 472
Washer ................................. 367
Fog lights ................................. 214 Replacing light bulbs............. 389
Switch ................................... 214
Wattage ................................ 473
Four-wheel drive
system ............................ 235, 239 Front passenger occupant
classification system .............. 46
Front personal lights............... 298
Front seats ............................... 120 Adjustment............................ 120
Cleaning ............................... 341
Correct driving posture ........... 28
Driving position memory ....... 133
Head restraints ..................... 137
Seat heaters ......................... 295
Seat position memory ........... 133
Seat ventilators ..................... 295
Front side marker lights ......... 208 Light switch ........................... 208
Replacing light bulbs ............ 396
Wattage ................................ 473
Front turn signal lights ........... 206
Replacing light bulbs ............ 394
Turn signal lever ................... 206
Wattage ................................ 473
Fuel ........................................... 222 Capacity................................ 464
Fuel gauge.............................. 81
Fuel pump shut off system ... 416
Information............................ 474
Refueling .............................. 222
Type.............................. 222, 464
Warning light......................... 419
Fuel filler door ......................... 222 Refueling .............................. 222
Fuel pump shut off system..... 416
Fuses ........................................ 386
Garage door opener ................ 324
Gauges ....................................... 81
Glove box ................................. 301
Grocery bag hooks.................. 310
F
G

523Alphabetical index
4RUNNER (U)_(OM35B37U)
Outer foot lights....................... 297
Outside rear view mirrors ....... 144Adjusting and folding ............ 144
Outside rear view mirror defoggers ......... 284, 290
Outside temperature display .................................... 314
Overhead console ................... 304
Overheating, Engine................ 457
Parking brake ........................... 207 Operation .............................. 207
Parking brake engaged
warning buzzer ................... 417
Parking lights ........................... 208
Light switch ........................... 208
Replacing light bulbs............. 394
Wattage ................................ 473
Pen holder ................................ 305
Personal lights ......................... 298
Power back window ................ 150 Jam protection function......... 152
Operation .............................. 150
Power outlets ................... 315, 320
Power steering
Fluid ...................................... 363
Warning light ......................... 419
Power windows........................ 146
Door lock linked window operation ............... 148
Jam protection function......... 147
Operation .............................. 146
Window lock switch............... 146 Radiator .................................... 360
Rear differential lock
system.................................... 247
Rear seats
Adjustment............................ 123
Folding down ........ 125, 127, 129
Rear step bumper .................... 116
Rear turn signal lights ............ 206
Replacing light bulbs ............ 400
Turn signal lever ................... 206
Wattage ................................ 473
Rear view mirror Inside rear view mirror .......... 142
Outside rear view mirrors ..... 144
Rear view monitor system
*
Rear window ............................ 150
Rear window defoggers....................... 284, 290
Rear window wiper .................. 219
Refueling .................................. 222
Capacity................................ 464
Fuel types ............................. 464
Opening the fuel tank cap..... 224
Replacing Fuses .................................... 386
Key battery ........................... 383
Light bulbs ............................ 389
Tires...................................... 433
Reporting safety defects
for U.S. owners...................... 498
Resetting the message indicating maintenance
is required.............................. 345
Roof luggage carrier ............... 170
P
R
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

526Alphabetical index
4RUNNER (U)_(OM35B37U)
Tools ......................................... 434
Top tether strap ......................... 66
Total load capacity .................. 175
TowingDinghy towing ....................... 192
Emergency towing ................ 411
Trailer towing ........................ 176
TRAC (Traction Control) ......... 263
Trailer Sway Control................ 263
Transmission ........................... 201
Trip information ......................... 83
Trip meters ................................. 81
Turn signal lights..................... 206 Replacing light bulbs..... 394, 400
Turn signal lever ................... 206
Wattage ................................ 473
USB port
*
Valet key ..................................... 90
Vanity lights ............................. 312 Wattage ................................ 473
Vanity mirrors .......................... 312
Vehicle data recordings .............. 9
Vehicle identification number ................................... 463
Vehicle Stability Control (VSC) ...................................... 263
Ventilators
(seat ventilators) ................... 295
VSC (Vehicle Stabilit y Control) .... 263 Warning buzzers
Brake system ....... ................. 417
Downshifting ......................... 204
Intuitive parking assist .......... 229
Key reminder ........ 194, 421, 429
Open door............................. 419
Open moon roof reminder. ... 421
Seat belt reminder ................ 420
Warning lights ........................... 77 ABS ...................................... 418
Automatic running boards
indicator light ...................... 419
Brake system ....... ................. 417
Center differential lock indicator light ...................... 419
Charging system................... 417
Cruise control ....................... 418
Four-wheel drive indicator light ...................... 418
KDSS .................................... 419
Low engine oil pressure........ 417
Low fuel level ........................ 419
Low speed four-wheel drive indicator light ...................... 419
Malfunction indicator lamp .... 417
Master warning light ..... 420, 426
Multi-terrain Select indicator light ...................... 419
Open door............................. 419
Power steering...................... 419
Rear differential lock indicator light ...................... 418
Seat belt reminder light......... 420
Slip indicator ......................... 418
SRS ...................................... 418
Tire pressure ........................ 420
Unengaged “Park” ................ 419
U
V
W
