2017 SUBARU BRZ trunk

TABLE OF CONTENTSIndex
2
1-1. Key information
Keys ..................................... 22
1-2. Opening, closing and
locking the doors and
trunk lid
Keyless access with push
button start system ............. 25
Remote keyless entry
system ................................ 38
Doors.................................... 43
Trunk lid ............................... 46
1-3. Adjustable components
(seats, mirrors, steering
wheel)
Front seats ........................... 53
Rear seats ............................ 56
Head restraints ..................... 58
Seatbelts .............................. 60
Steering wheel ..................... 67
Anti-glare inside rear view
mirror .................................. 68
Outside rear view mirrors ..... 69
1-4. Opening and closing
the windows
Power windows .................... 72
1-5. Refueling
Opening the fuel tank cap .... 761-6. Security system
Engine immobilizer
system ................................ 80
Theft prevention labels
(U.S.A.) ............................... 84
Alarm .................................... 85
1-7. Safety information
Correct driving posture ......... 89
SRS airbag
(Supplemental Restraint
System airbag) ................... 91
Front passenger occupant
detection system .............. 129
Child restraint systems ....... 139
Installing child restraints ..... 143
2-1. Driving procedures
Driving the vehicle .............. 154
Push-button ignition
switch ............................... 169
Engine (ignition)
switch ............................... 178
Automatic transmission ...... 181
Manual Transmission ......... 188
Turn signal lever ................. 191
Parking brake ..................... 192
Horn .................................... 193
1Before driving
2When driving

7
Tires
●Rotation
●Replacement
●Inflation pressure
●Information
P. 350
P. 431
P. 357
P. 480
Rear window defogger P. 292
Trunk lid P. 46
Doors P. 43
Fuel filler lid P. 76
Turn signal lights
P. 191
Rear side marker lights P. 228

: If equipped
License plate lights P. 228
Tail lights/stop lights P. 228
Towing eyelet
P. 393
Towing eyelet
P. 393
Rear view camera P. 242
Stop lights

14
C
Instrument panel light control dial
P. 196
Trunk lid opener P. 46
Pictorial indexInstrument panel

Before driving1
21
1-1. Key information
Keys ................................... 22
1-2. Opening, closing and
locking the doors and
trunk lid
Keyless access with push
button start system .......... 25
Remote keyless
entry system .................... 38
Doors ................................. 43
Trunk lid ............................. 46
1-3. Adjustable components
(seats, mirrors,
steering wheel)
Front seats ......................... 53
Rear seats.......................... 56
Head restraints................... 58
Seatbelts ............................ 60
Steering wheel ................... 67
Anti-glare inside rear
view mirror ....................... 68
Outside rear view
mirrors.............................. 691-4. Opening and closing
the windows
Power windows .................. 72
1-5. Refueling
Opening the fuel tank
cap ................................... 76
1-6. Security system
Engine immobilizer
system ............................. 80
Theft prevention labels
(U.S.A.) ............................ 84
Alarm.................................. 85
1-7. Safety information
Correct driving posture....... 89
SRS airbag (Supplemental
Restraint System
airbag) .............................. 91
Front passenger occupant
detection system ............ 129
Child restraint systems..... 139
Installing child
restraints ........................ 143

23 1-1. Key information
1
Before driving
Using the mechanical key (vehicles with a keyless access with
push button start system)
To take out the mechanical key,
push the release knob and take
the key out.
After using the mechanical key,
store it in the access key. Carry
the mechanical key together with
the access key. If the access key
battery is depleted or the “keyless
access” entry function does not
operate properly, you will need
the mechanical key.
(oP. 449)
■When required to leave the vehicle’s key with a parking attendant
Turn the trunk lid opener main switch off as circumstances demand.
(oP. 4 7 )
On vehicles without a keyless access with push button start system, provide
the attendant with the valet key.
On vehicles with a keyless access with push button start system, remove the
mechanical key for your own use and provide the attendant with the access
key only.
■Key number plate
Keep the plate in a safe place, not in the vehicle. In the event that a key
(without a keyless access with push button start system) or mechanical key
(with a keyless access with push button start system) is lost, a new key can
be made at your SUBARU dealer using the key number plate. (oP. 448)
■When riding in an aircraft
When bringing a key with remote keyless entry system onto an aircraft,
make sure you do not press any buttons on the key while inside the aircraft
cabin. If you are carrying the key in your bag etc., ensure that the buttons
are not likely to be pressed accidentally. Pressing a button may cause the
key to emit radio waves that could interfere with the operation of the aircraft.

25
1
Before driving
1-2. Opening, closing and locking the doors and trunk lid
Keyless access with push button start system
The following operations can be performed simply by carrying the
access key on your person, for example in your pocket.
(The driver should always carry the access key.)
Unlocks and locks the doors (oP. 2 6 )
Unlocks the trunk lid (
oP. 2 6 )
Starts the engine (
oP. 1 6 9 )
Access key
Access key
Access key

: If equipped

26 1-2. Opening, closing and locking the doors and trunk lid
Unlocking and locking the doors
Grip the driver’s door handle to
unlock the door. Grip the passen-
ger’s door handle to unlock all
the doors.
Make sure to touch the sensor on
the back of the handle.
The doors cannot be unlocked for
3 seconds after the door is
locked.
Touch the lock sensor (the
indentation on the side of the
door handle) to lock the doors.
Check that the door is securely
locked.
Unlocking the trunk lid
Press the button to unlock the
trunk lid.

27 1-2. Opening, closing and locking the doors and trunk lid
1
Before driving
Antenna location and effective range
■Antenna location
Antennas outside the cabin
Antennas inside the cabin
Antenna outside the trunk
Antenna inside the trunk
