54 1-3. Adjustable components (seats, mirrors, steering wheel)
■Getting out of the rear seats
Pull the seatback fold strap.
The seatback will fold forward.
Front passenger seat only: The
seat can be slid forward and
backward.
■After getting in or out of the rear seats
Return the seatback to the upright position until the seat locks.
Front passenger seat only: The seat will lock in position at the point where
the seatback reaches the upright position.
■Seat dust cover
Always remove the seat dust cover that may be attached at the time of pur-
chase before using the seat.
WARNING
■Seat adjustment
●To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.

56
1-3. Adjustable components (seats, mirrors, steering wheel)
Rear seats
■Seat dust cover
Always remove the seat dust cover that may be attached at the time of pur-
chase before using the seat. The seatbacks of the rear seats can be folded down.
Pull the both left and right
seatback lock release straps
in the trunk lid to fold down the
seatback.
To return the seatbacks to its
original position, lift it up until it
locks.

59 1-3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
■Adjusting the height of the head restraints
WARNING
■Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.
●Use the head restraints designed for each respective seat.
●Adjust the head restraints to the correct position at all times.
●After adjusting the head restraints, push down on them and make sure
they are locked in position.
●Do not drive with the head restraints removed.
Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.

66 1-3. Adjustable components (seats, mirrors, steering wheel)
WARNING
■Seatbelt damage and wear
●Do not damage the seatbelts by allowing the belt, plate, or buckle to be
jammed in the door.
●Inspect the seatbelt system periodically. Check for cuts, fraying, and loose
parts. Replace a damaged seatbelt immediately. Damaged seatbelts can-
not protect an occupant from death or serious injury.
●Ensure that the belt and plate are locked and the belt is not twisted.
If the seatbelt does not function correctly, immediately contact your
SUBARU dealer.
●Replace the seat assembly, including the belts, if your vehicle has been
involved in a serious accident, even if there's no obvious damage.
●Do not attempt to install, remove, modify, disassemble or dispose of the
seatbelts. Have any necessary repairs carried out by your SUBARU
dealer. Inappropriate handling of the pretensioner may prevent it from
operating properly, resulting in death or serious injury.
■When using the seatbelt guide
●Always make sure that the belt is not twisted, and runs freely through the
guide.
●Regardless of whether the guide is used or not, always secure the seatbelt
guide button.
●Do not hang from or pull the guide forcefully.
■Before using the rear seatbelts
●Always make sure that the seatbelt is
not caught in the seatback or twisted in
one of the hooks that secure the seat-
back. Failure to do so may cause the
seatbelt to not be fastened correctly or
to become ineffective in a collision,
resulting in serious injury.

138 1-7. Safety information
WARNING
■Front passenger occupant detection system precautions
●Never install a rearward facing child seat in the front passenger’s seat
even if the front passenger’s SRS frontal airbag is deactivated. Be sure to
install it in the rear seat in a correct manner. Also, it is strongly recom-
mended that any forward facing child seat or booster seat be installed in
the rear seat, and that even children who have outgrown a child restraint
system be also seated in the rear seat. This is because children sitting in
the front passenger’s seat may be killed or severely injured should the
front passenger’s SRS frontal airbag deploy. SUBARU believes that the
rear seats are the safest place for children
●If luggage or electronic devices are placed on the front passenger seat,
the OFF indicator may turn off and the ON indicator may illuminate. If this
occurs, the front passenger’s airbag may deploy during a collision. If this is
not desirable, remove the luggage or electronic devices from the front pas-
senger seat.
●Modifications for persons with disabilities that may affect the front passen-
ger occupant detection system. (U.S. only) Removing, replacing or modify-
ing any parts of the front seats, seatbelts, front bumper, front side frame,
instrument panel, combination meter, steering wheel, steering column,
tires, suspension or floor panel can affect the operation of the SUBARU
front passenger occupant detection system.

526 Alphabetical index
Brightness control
Instrument panel light
control .................................196
Care
Alcantara
®............................. 322
Aluminum wheels .................. 315
Exterior.................................. 314
Interior ................................... 318
Seatbelts ............................... 319
Cargo capacity ......................... 263
Chains ....................................... 270
Child restraint system
Booster seats,
definition ............................. 139
Booster seats,
installation ........................... 143
Convertible seats,
definition ............................. 139
Convertible seats,
installation ........................... 143
Front passenger occupant
detection system .................129
Infant seats,
definition ............................. 139
Infant seats,
installation ........................... 143
Installing CRS with
LATCH anchors .................. 144
Installing CRS with
seatbelts ............................. 146
Installing CRS with
top tether straps .................. 149Child safety
Airbag precautions ................ 123
Battery precautions ....... 347, 456
Child restraint system ........... 139
How your child should
wear the seatbelt .................. 62
Installing child restraints........ 143
Power window lock switch ...... 72
Power window
precautions ........................... 75
Removed key battery
precautions ......................... 370
Seat heater precautions ........ 309
Seatbelt guide ......................... 61
Seatbelt precautions ............... 64
Trunk precautions ................... 49
Cleaning
Alcantara
®............................. 322
Aluminum wheels.................. 315
Exterior.................................. 314
Interior ................................... 318
Seatbelts ............................... 319
Clock ......................................... 305
Condenser ................................ 342
Console tray ............................. 301
Coolant
Capacity ................................ 470
Checking ............................... 340
Cooling system
Engine overheating ............... 458
Cruise control .......................... 237
Cup holders .............................. 301
Curtain airbags .......................... 91
Customizable features ............ 493
Daytime running light
system .................................... 230
Defogger
Rear window ......................... 292
Side mirror ............................ 292
Dimensions .............................. 464
Dinghy towing .......................... 274
C
D
