2017 SUBARU BRZ inflation pressure

TABLE OF CONTENTSIndex
4
4-1. Maintenance and care
Cleaning and protecting
the vehicle exterior ........... 314
Cleaning and protecting
the vehicle interior ............ 318
Cleaning and protecting
the Alcantara
® area.......... 322
4-2. Maintenance
Maintenance
requirements .................... 324
General maintenance ......... 327
Emission inspection and
maintenance (I/M)
programs .......................... 330
4-3. Do-it-yourself
maintenance
Do-it-yourself service
precautions ...................... 331
Engine hood ....................... 334
Engine compartment .......... 336
Tires ................................... 350
Tire inflation pressure......... 357
Wheels ............................... 361
Air conditioning filter ........... 364
Transmitter/access key
battery .............................. 367
Checking and replacing
fuses ................................ 372
Light bulbs .......................... 3805-1. Essential information
Hazard warning flashers ..... 392
If your vehicle needs to
be towed ........................... 393
If you think something is
wrong ................................ 400
Fuel pump shut off
system .............................. 401
5-2. Steps to take in an
emergency
If a warning light turns
on or a warning buzzer
sounds... .......................... 402
If a warning message is
displayed .......................... 414
If you have a flat tire ........... 431
If the engine will not start .... 444
If the select lever cannot
be shifted from P .............. 447
If you lose your keys ........... 448
If the access key does
not operate properly ......... 449
If the battery is
discharged ........................ 453
If your vehicle
overheats .......................... 458
If the vehicle becomes
stuck ................................. 461
4Maintenance and care5When trouble arises

7
Tires
●Rotation
●Replacement
●Inflation pressure
●Information
P. 350
P. 431
P. 357
P. 480
Rear window defogger P. 292
Trunk lid P. 46
Doors P. 43
Fuel filler lid P. 76
Turn signal lights
P. 191
Rear side marker lights P. 228

: If equipped
License plate lights P. 228
Tail lights/stop lights P. 228
Towing eyelet
P. 393
Towing eyelet
P. 393
Rear view camera P. 242
Stop lights

257 2-4. Using other driving systems
2
When driving
WARNING
■TRAC may not operate effectively when
Directional control and power may not be achievable while driving on slip-
pery road surfaces, even if the TRAC system is operating.
Do not drive the vehicle in conditions where stability and power may be lost.
■When the Vehicle stability control (VSC) and/or brake LSD function is
activated
The slip indicator light flashes. Always drive carefully. Reckless driving may
cause an accident. Exercise particular care when the indicator light flashes.
■When the TRAC/Vehicle stability control (VSC) systems are turned off
Be especially careful and drive at a speed appropriate to the road condi-
tions. As these are the systems to help ensure vehicle stability and driving
force, do not turn the TRAC/Vehicle stability control (VSC) systems off
unless necessary.
■Replacing tires
Make sure that all tires are of the specified size, brand, tread pattern and
total load capacity. In addition, make sure that the tires are inflated to the
recommended tire inflation pressure level.
The ABS, TRAC and Vehicle stability control (VSC) systems will not function
correctly if different tires are installed on the vehicle.
Contact your SUBARU dealer for further information when replacing tires or
wheels.
■Handling of tires and suspension
Using tires with any kind of problem or modifying the suspension will affect
the driving assist systems, and may cause a system to malfunction.

Maintenance and care4
313
4-1. Maintenance and care
Cleaning and protecting
the vehicle exterior......... 314
Cleaning and protecting
the vehicle interior.......... 318
Cleaning and protecting
the Alcantara
® area ....... 3224-2. Maintenance
Maintenance
requirements .................. 324
General maintenance....... 327
Emission inspection and
maintenance (I/M)
programs ........................ 330
4-3. Do-it-yourself maintenance
Do-it-yourself service
precautions .................... 331
Engine hood ..................... 334
Engine compartment ........ 336
Tires ................................. 350
Tire inflation pressure ...... 357
Wheels ............................. 361
Air conditioning filter......... 364
Transmitter/access key
battery ............................ 367
Checking and replacing
fuses .............................. 372
Light bulbs........................ 380

329 4-2. Maintenance
4
Maintenance and care
Vehicle exterior
ItemsCheck points
Door/trunk lid • Operate smoothly?
Engine hood • The lock system works properly?
Fluid leaks• Is there any leakage after park-
ing?
Ti re• Inflation pressure is correct?
• Tire surfaces not worn or dam-
aged?
• Tires rotated according to the
maintenance schedule?
• Wheel nuts are not loose?
Windshield wipers
•The wiper blades should not show
any signs of cracking, splitting,
wear, contamination or deforma-
tion.
•The wiper blades should clear the
windshield without streaking or
skipping.
WARNING
■If the engine is running
Turn the engine off and ensure that there is adequate ventilation before per-
forming maintenance checks.

332 4-3. Do-it-yourself maintenance
ItemsParts and tools
Light bulbs (oP. 380)• Bulb with same number and watt-
age rating as original
• Phillips-head screwdriver
• Flathead screwdriver
Radiator and condenser
(oP. 342)

Tire inflation pressure (oP. 357)• Tire pressure gauge
• Compressed air source
Washer fluid (oP. 348)• Water washer fluid containing anti-
freeze (for winter use)
• Funnel

351 4-3. Do-it-yourself maintenance
4
Maintenance and care
Installing tire pressure warning valves and transmitters (vehicles
with a tire pressure monitoring system)
When replacing tires or wheels, tire pressure warning valves and
transmitters must also be installed.
When new tire pressure warning valves and transmitters are
installed, new tire pressure warning valve and transmitter ID codes
must be registered in the tire pressure warning computer and tire
pressure monitoring system must be initialized. Have tire pressure
warning valve and transmitter ID codes registered by your SUBARU
dealer. (oP. 352)
Vehicles with a spare tire of the same wheel type as the
installed tires
Rotate the tires in the order
shown.
To equalize tire wear and
extend tire life, SUBARU rec-
ommends that tire rotation is
carried out at the same inter-
val as tire inspection.
■The tire pressure monitoring system (if equipped)
Your SUBARU is equipped with a tire pressure monitoring sys-
tem that uses tire pressure warning valves and transmitters to
detect low tire inflation pressure before serious problems arise.
(oP. 406)
Front

353 4-3. Do-it-yourself maintenance
4
Maintenance and care
■Maximum load of tire
Check that the maximum load of the replacement tire is greater than 1/2
of the Gross Axle Weight Ratings (GAWR) of either the front axle or the
rear axle, whichever is greater.
■Tire types
1Summer tires
Summer tires are high-speed performance tires best suited to highway
driving under dry conditions. Since summer tires do not have the same
traction performance as snow tires, summer tires are inadequate for
driving on snow-covered or icy roads. For driving on snow-covered
roads or icy roads, the use of snow tires is recommended. When
installing snow tires, be sure to replace all four tires.
2 All season tires
All season tires are designed to provide better traction in snow and to
be adequate for driving in most winter conditions, as well as for use
year round. All season tires, however, do not have adequate traction
performance compared with snow tires in heavy or loose snow. Also,
all season tires fall short in acceleration and handling performance
compared with summer tires in highway driving.
3 Snow tires
For driving on snow-covered roads or icy roads, we recommend using
snow tires. If you need snow tires, select tires of the same size, con-
struction and load capacity as the originally installed tires. Since your
vehicle has radial tires as original equipment, make sure your snow
tires also have radial construction. Do not install studded tires without
first checking local regulations for possible restriction. Snow tires
should be installed on all wheels. (oP. 2 6 8 ) For the GAWR, see the Certification
Label. For the maximum load of the
tire, see the load limit at maximum cold
tire inflation pressure mentioned on the
sidewall of the tire. (oP. 4 8 0 )
