2017 SUBARU BRZ door lock

TABLE OF CONTENTS
1
1Before drivingAdjusting and operating features such as door locks,
mirrors, and steering column.
2When drivingDriving, stopping and safe-driving information.
3Interior fea-
turesAir conditioning and audio systems, as well as other in-
terior features for a comfortable driving experience.
4Maintenance
and careCleaning and protecting your vehicle, performing do-it-
yourself maintenance, and maintenance information.
5When trouble
arisesWhat to do if the vehicle needs to be towed, gets a flat
tire, or is involved in an accident.
6Vehicle
specificationsDetailed vehicle information.
7For ownersReporting safety defects for US owners, and seatbelt
and SRS airbag instructions for Canadian owners
IndexAlphabetical listing of information contained in this
manual.

TABLE OF CONTENTSIndex
2
1-1. Key information
Keys ..................................... 22
1-2. Opening, closing and
locking the doors and
trunk lid
Keyless access with push
button start system ............. 25
Remote keyless entry
system ................................ 38
Doors.................................... 43
Trunk lid ............................... 46
1-3. Adjustable components
(seats, mirrors, steering
wheel)
Front seats ........................... 53
Rear seats ............................ 56
Head restraints ..................... 58
Seatbelts .............................. 60
Steering wheel ..................... 67
Anti-glare inside rear view
mirror .................................. 68
Outside rear view mirrors ..... 69
1-4. Opening and closing
the windows
Power windows .................... 72
1-5. Refueling
Opening the fuel tank cap .... 761-6. Security system
Engine immobilizer
system ................................ 80
Theft prevention labels
(U.S.A.) ............................... 84
Alarm .................................... 85
1-7. Safety information
Correct driving posture ......... 89
SRS airbag
(Supplemental Restraint
System airbag) ................... 91
Front passenger occupant
detection system .............. 129
Child restraint systems ....... 139
Installing child restraints ..... 143
2-1. Driving procedures
Driving the vehicle .............. 154
Push-button ignition
switch ............................... 169
Engine (ignition)
switch ............................... 178
Automatic transmission ...... 181
Manual Transmission ......... 188
Turn signal lever ................. 191
Parking brake ..................... 192
Horn .................................... 193
1Before driving
2When driving

9
B
AA
Anti-glare inside rear view mirror P. 68
Interior light P. 297
Vanity mirrors P. 304
Sun visors P. 303

: If equipped
*1: Refer to the Owner’s Manual supplement for the audio system.
*2: Refer to “Navigation System Owner’s Manual”.
Lock levers P. 44
Outside rear view mirror switch
P. 69
Window lock switch P. 72
Power window switches
P. 72
Power door lock switch P. 44
Microphone P. 295

Before driving1
21
1-1. Key information
Keys ................................... 22
1-2. Opening, closing and
locking the doors and
trunk lid
Keyless access with push
button start system .......... 25
Remote keyless
entry system .................... 38
Doors ................................. 43
Trunk lid ............................. 46
1-3. Adjustable components
(seats, mirrors,
steering wheel)
Front seats ......................... 53
Rear seats.......................... 56
Head restraints................... 58
Seatbelts ............................ 60
Steering wheel ................... 67
Anti-glare inside rear
view mirror ....................... 68
Outside rear view
mirrors.............................. 691-4. Opening and closing
the windows
Power windows .................. 72
1-5. Refueling
Opening the fuel tank
cap ................................... 76
1-6. Security system
Engine immobilizer
system ............................. 80
Theft prevention labels
(U.S.A.) ............................ 84
Alarm.................................. 85
1-7. Safety information
Correct driving posture....... 89
SRS airbag (Supplemental
Restraint System
airbag) .............................. 91
Front passenger occupant
detection system ............ 129
Child restraint systems..... 139
Installing child
restraints ........................ 143

25
1
Before driving
1-2. Opening, closing and locking the doors and trunk lid
Keyless access with push button start system
The following operations can be performed simply by carrying the
access key on your person, for example in your pocket.
(The driver should always carry the access key.)
Unlocks and locks the doors (oP. 2 6 )
Unlocks the trunk lid (
oP. 2 6 )
Starts the engine (
oP. 1 6 9 )
Access key
Access key
Access key

: If equipped

26 1-2. Opening, closing and locking the doors and trunk lid
Unlocking and locking the doors
Grip the driver’s door handle to
unlock the door. Grip the passen-
ger’s door handle to unlock all
the doors.
Make sure to touch the sensor on
the back of the handle.
The doors cannot be unlocked for
3 seconds after the door is
locked.
Touch the lock sensor (the
indentation on the side of the
door handle) to lock the doors.
Check that the door is securely
locked.
Unlocking the trunk lid
Press the button to unlock the
trunk lid.

27 1-2. Opening, closing and locking the doors and trunk lid
1
Before driving
Antenna location and effective range
■Antenna location
Antennas outside the cabin
Antennas inside the cabin
Antenna outside the trunk
Antenna inside the trunk

28 1-2. Opening, closing and locking the doors and trunk lid
■Effective range (areas within which the access key is
detected)
When locking or unlocking
the doors
The system can be operated
when the access key is
within about 1.3 - 2.6 ft. (0.4 -
0.8 m) of either of the outside
door handles. (Only the
doors detecting the key can
be operated.)
When unlocking the trunk
lid
The system can be operated
when the access key is
within about 1.3 - 2.6 ft. (0.4 -
0.8 m) of the trunk lid release
button.
When starting the engine
or changing push-button
ignition switch modes
The system can be operated
when the access key is
inside the vehicle.
