2017 SUBARU BRZ keyless entry

377 4-3. Do-it-yourself maintenance
4
Maintenance and care
Note
One of each of the following spare fuses are provided: 7.5 A, 10 A, 15
A, 20 A, 25 A, 30 A.
37HORN NO. 2 7.5 A Horn
38HORN NO. 1 7.5 A Horn
39H-LP LH LO 15 A Left-hand headlight (low beam)
40H-LP RH LO 15 A Right-hand headlight (low beam)
41H-LP LH HI 10 A Left-hand headlight (high beam)
42H-LP RH HI 10 A Right-hand headlight (high beam)
43INJ 30 AMultiport fuel injection system/
sequential multiport fuel injection
system
44H-LP WASHER 30 A
45AM2 NO. 1 40 A Starting system, engine control unit
46EPS 80 A Electric power steering
47A/B MAIN 15 A SRS airbag system
48ECU-B 7.5 ARemote keyless entry system,
main body ECU
49DOME 20 A Interior light
50IG2 7.5 A Engine control unit
FuseAmpereCircuit

5
When trouble arises
449
5-2. Steps to take in an emergency
If the access key does not operate properly (vehicles with a keyless access with push button star t system)
Unlocking and locking the doors, unlocking the trunk lid
Use the mechanical key built in to the access keys to operate the
doors and trunk lid. (oP. 2 3 )
The mechanical key is directional. If the key cannot be inserted,
change the direction that the grooved side is facing and insert it
again.
Vehicles with an alarm: An alarm will sound if the alarm is set when the
trunk lid or doors are unlocked. (oP. 85)
Doors
Locks driver’s door
Unlocks driver’s door
If communication between the access key and vehicle is interrupted
(oP. 31) or the access key cannot be used because the battery is
depleted, the keyless access with push button start system and
remote keyless entry system cannot be used. In such cases, the
doors and trunk lid can be opened or the engine can be started by
following the procedure below.

452 5-2. Steps to take in an emergency
■Stopping the engine
Vehicles with an automatic transmission: Shift the select lever to P and press
the push-button ignition switch as you normally do when stopping the
engine.
Vehicles with a manual transmission: Shift the shift lever to neutral and press
the push-button ignition switch as you normally do when stopping the
engine.
■Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the
access key battery be replaced immediately when the battery depletes.
(oP. 367)
■Alarm (if equipped)
Using the mechanical key to lock the doors will not set the alarm system.
If a door is unlocked using the mechanical key when the alarm system is set,
the alarm may be triggered. (oP. 85)
■If the doors cannot be locked or unlocked by the keyless access with
push button start system
Lock and unlock the doors by the mechanical key or remote keyless entry
system.

5
When trouble arises
455 5-2. Steps to take in an emergency
■Starting the engine when the battery is discharged
The engine cannot be started by push-starting.
■Avoiding a discharged battery
●Turn off the headlights and the air conditioning system while the engine is
off.
●Turn off any unnecessary electrical components when the vehicle is run-
ning at a low speed for an extended period, such as in heavy traffic, etc.
■Charging the battery
The electricity stored in the battery will discharge gradually even when the
vehicle is not in use, due to natural discharge and the draining effects of cer-
tain electrical appliances. If the vehicle is left for a long time, the battery may
discharge, and the engine may be unable to start. (The battery recharges
automatically during driving.)
■Precautions when the battery is discharged (vehicles with a keyless
access with push button start system)
●In some cases, it may not be possible to unlock the doors using the key-
less access with push button start system when the battery is dis-
charged. Use the remote keyless entry system or the mechanical key to
lock or unlock the doors.
●The engine may not start on the first attempt after the battery has
recharged but will start normally after the second attempt. This is not a
malfunction.
●The push-button ignition switch mode is memorized by the vehicle. When
the battery is reconnected, the system will return to the mode it was in
before the battery was discharged. Before disconnecting the battery, turn
the push-button ignition switch off.
If you are unsure what mode the push-button ignition switch was in
before the battery discharged, be especially careful when reconnecting
the battery.

493
6
Vehicle specifications
6-2. Customization
Customizable features
ItemFunctionDefault settingCustomized
setting
Keyless
access with
push button
start system
(
oP. 25)Keyless access with
push button start sys-
temOn Off
Operation signal
(Hazard warning flash-
ers) On Off
Operation signal
(Buzzer)On Off
Operation buzzer
volumeLevel 5 Level 0 to 7
Number of permissible
times of continuous
smart lockTwice Unlimited
Remote key-
less entry
system
(
oP. 38)Unlocking operationDriver's door
unlocked in
one step, both
side doors
unlocked in
two stepsBoth side
doors
unlocked in
one step
Automatic door lock
function to be activated
if door is not opened
after being unlockedOn Off
Your vehicle includes a variety of electronic features that can be per-
sonalized to your preferences. Programming these preferences
requires specialized equipment and may be performed by your
SUBARU dealer.
Some function settings are changed simultaneously with other functions
being customized. Contact your SUBARU dealer.

528 Alphabetical index
Front passenger's seatbelt
reminder light......................... 406
Front seats
Adjustment ..............................53
Front side marker light
Replacing light bulbs ............. 380
Wattage.................................475
Front turn signal lights
Switch.................................... 191
Fuel
Capacity ................................ 467
Fuel gauge ............................ 194
Fuel pump shut off system .... 401
Gas station information ......... 536
Information ............................ 476
Refueling .................................76
Fuel door.....................................76
Fuel filler lid ................................76
Fuel pump shut off system ..... 401
Fuses......................................... 372
Gauges ...................................... 194
Glove box.................................. 299
Hazard lights
Switch.................................... 392
Hazard warning flashers
Switch.................................... 392
Head restraints
Adjusting ................................58
Headlights
Automatic headlight
leveling................................ 231
Switch.................................... 228
Heaters
Seat heaters.......................... 308
Side mirror............................. 292
Hill start assist ......................... 258
Horn...........................................193I/M test ...................................... 330
Identification
Engine................................... 465
Vehicle .................................. 465
Ignition switch.................. 169, 178
Ignition switch light
Ignition switch light ................ 296
Illuminated entry system......... 296
Immobilizer system ................... 80
Indicator lights ......................... 198
Inside rear view mirror .............. 68
Interior light
Interior light ........................... 297
Switch ................................... 297
Wattage................................. 475
Jack
Vehicle-equipped
jack ..................................... 431
Jack handle .............................. 431
Jam protection function
Power windows ....................... 73
Keyless access with
push button start system
Antenna location ..................... 27
“Keyless access” entry
function ................................. 25
Starting the engine................ 169
Keyless entry ............................. 38
Keys
Access key.............................. 22
Engine switch................ 169, 178
If you lose your keys ............. 448
If your access key
battery is discharged .......... 449
Key number............................. 22
Keyless entry .......................... 38
Keys ........................................ 22
Mechanical key ....................... 23
Transmitter.............................. 38
