CAUTION!
Be sure to mount the spare tire with the valve stem
facing outward. The vehicle could be damaged if the
spare tire is mounted incorrectly.
NOTE: Do not install the wheel cover on the spare tire.
7. Lower the vehicle by turning the jack screw to the left.
8. Refer to “Torque Specifications” in this section for proper wheel lug bolt torque.
9. Lower the jack to its fully-closed position.
10. Stow the damaged wheel/spare tire with the cable and wheel spacer before driving the vehicle.
11. Install the winch extension and rotate the wrench
handle clockwise until the winch mechanism indica-
tion window turns yellow and the operator hears “3
clicks” from the device to show the wheel is properly
stowed under the vehicle.
Winch Mechanism Properly Engaged (Yellow DOT Will
Appear In The Winch Indication Window)
6
WHAT TO DO IN EMERGENCIES 263
transmission fluid at the correct level using the recom-
mended fluid. No chemical flushes should be used in any
transmission; only the approved lubricant should be used.
CAUTION!
Using a transmission fluid other than the manufactur-
er’s recommended fluid may cause deterioration in
transmission shift quality and/or torque converter
shudder, and will require more frequent fluid and
filter changes. Refer to “Fluids, Lubricants, And Genu-
ine Parts” in this section for fluid specifications.
Special Additives
The manufacturer strongly recommends against using any
special additives in the transmission.
Automatic Transmission Fluid (ATF) is an engineered
product and its performance may be impaired by supple-
mental additives. Therefore, do not add any fluid additives
to the transmission. The only exception to this policy is the
use of special dyes for diagnosing fluid leaks. Avoid using
transmission sealers as they may adversely affect seals.
CAUTION!
Do not use chemical flushes in your transmission as
the chemicals can damage your transmission compo-
nents. Such damage is not covered by the New Vehicle
Limited Warranty.
Fluid Level Check
The fluid level is preset at the factory and does not require
adjustment under normal operating conditions. Routine
fluid level checks are not required, therefore the transmis-
sion filler tube is capped and no dipstick is provided. Your
authorized dealer can check your transmission fluid level
using a special service dipstick. If you notice fluid leakage
or transmission malfunction, visit your authorized dealer
immediately to have the transmission fluid level checked.
Operating the vehicle with an improper fluid level can
cause severe transmission damage.
CAUTION!
If a transmission fluid leak occurs, visit your autho-
rized dealer immediately. Severe transmission damage
may occur. Your authorized dealer has the proper tools
to adjust the fluid level accurately.
296 MAINTAINING YOUR VEHICLE
Telescoping Steering Column...................81
Tire And Loading Information Placard ........204, 205
Tire Markings ............................ .198
Tires.......................... .53, 207, 212, 331
Aging (Life Of Tires) ..................... .216
Air Pressure ........................... .207
Chains ............................... .217
Compact Spare ......................... .212
General Information ...................207, 212
High Speed ............................ .209
Inflation Pressures ....................... .209
Life Of Tires ........................... .216
Load Capacity ...................... .204, 205
Pressure Monitor System (TPMS) .............219
Pressure Warning Light ....................112
Quality Grading ........................ .331
Radial ............................... .210
Replacement ........................... .216
Rotation .............................. .218
Safety ............................ .198, 207
Sizes ................................ .200
Snow Tires .............................211
Spare Tire ......................... .212, 214
Spinning .............................. .214
Trailer Towing .......................... .235Tread Wear Indicators
.....................215
Tire Safety Information ...................... .198
Tire Service Kit ............244, 245, 247, 248, 250, 251
Tongue Weight/Trailer Weight .................233
Torque Converter Clutch .....................185
Towing ............................. .230, 272
Disabled Vehicle ........................ .272
Guide ................................ .233
Recreational ........................... .239
Weight ............................... .233
Towing Vehicle Behind A Motorhome ............239
T
raction ................................ .186
Traction Control .......................... .192
Traction Control Switch ..................... .192
Trailer Sway Control (TSC) ....................196
Trailer Towing ............................ .230
Cooling System Tips ..................... .239
Hitches ............................... .232
Minimum Requirements ....................234
Tips ................................. .238
Trailer And Tongue Weight ..................233
Wiring ............................... .236
Trailer Towing Guide ....................... .233
Trailer Weight ............................ .233
10
INDEX 343
