CAUTION!
It is necessary to follow these steps to be certain that
the transfer case is fully in NEUTRAL (N) before
recreational towing to prevent damage to internal
parts.
1. Bring the vehicle to a complete stop, with the engine running. Firmly apply the parking brake.
2. Shift the transmission to NEUTRAL.
NOTE: If vehicle is equipped with air suspension, ensure
the vehicle is set to Normal Ride Height.
3. Press and hold the brake pedal.
4. Depress the clutch pedal on a manual transmission.
5. With manual shift transfer case, shift the transfer case lever into NEUTRAL (N).
• With electronic shift transfer case, push and hold the
transfer case NEUTRAL (N) button. Some models
have a small, recessed “N” button (at the center of the
transfer case switches) that must be pushed using a
ballpoint pen or similar object. Other models have a
rectangular NEUTRAL switch, below the rotary trans-
fer case control knob. The NEUTRAL (N) indicator light will blink while the shift is in progress. The light
will stop blinking (stay on solid) when the shift to
NEUTRAL (N) is complete. After the shift is completed
and the NEUTRAL (N) light stays on, release the
NEUTRAL (N) button.
6. Release the parking brake.
7. Shift the transmission into REVERSE.
8. Release the brake pedal (and clutch pedal on manual transmissions) for five seconds and ensure that there is
no vehicle movement.
9. Repeat steps 7 and 8 with automatic transmission in DRIVE or manual transmission in first gear.
10. Shift the transmission to NEUTRAL. Firmly apply the parking brake. Turn OFF the engine. For vehicles with
Keyless Enter-N-Go, push and hold the ENGINE
START/STOP button until the engine shuts off.
11. Shift the transmission into PARK or place manual transmission in gear (NOT in Neutral). On 8-speed
transmissions the shifter will automatically select
PARK when the engine is turned off.
5
STARTING AND OPERATING 575

12. Turn the ignition to the OFF mode, then cycle theignition to the RUN mode and back to the OFF mode.
Remove the key fob from the ignition.
13. Attach the vehicle to the tow vehicle using a suitable tow bar.
14. Release the parking brake.
NOTE: With electronic shift transfer case:
• Steps 2 through 4 are requirements that must be met
before pushing the NEUTRAL (N) button, and must
continue to be met until the shift has been completed. If
any of these requirements are not met before pushing
the NEUTRAL (N) button or are no longer met during
the shift, the NEUTRAL (N) indicator light will flash
continuously until all requirements are met or until the
NEUTRAL (N) button is released.
• The ignition must be in the ON/RUN mode for a shift to
take place and for the position indicator lights to be
operable. If the ignition is not in the ON/RUN mode, the
shift will not take place and no position indicator lights
will be on or flashing.
• A flashing NEUTRAL (N) position indicator light indi-
cates that shift requirements have not been met. •
If the vehicle is equipped with air suspension, the engine
should be started and left running for a minimum of 60
seconds (with all the doors closed) at least once every 24
hours. This process allows the air suspension to adjust
the vehicle’s ride height to compensate for temperature
effects.
Shifting Out Of NEUTRAL (N)
Use the following procedure to prepare your vehicle for
normal usage:
1. Bring the vehicle to a complete stop, leaving it con- nected to the tow vehicle.
2. Firmly apply the parking brake.
3. Press and hold the brake pedal.
4. Start the engine. Shift the transmission into NEUTRAL. Depress the clutch pedal on a manual transmission.
• With manual shift transfer case, shift the transfer case
lever to the desired position.
• With electronic shift transfer case with rotary selector
switch, push and hold the transfer case NEUTRAL (N)
button until the NEUTRAL (N) indicator light turns
off. After the NEUTRAL (N) indicator light turns off,
release the NEUTRAL (N) button. After the NEUTRAL
576 STARTING AND OPERATING

Proper towing or lifting equipment is required to prevent
damage to your vehicle. Use only tow bars and other
equipment designed for this purpose, following equipment
manufacturer ’s instructions. Use of safety chains is man-
datory. Attach a tow bar or other towing device to main
structural members of the vehicle, not to bumpers or
associated brackets. State and local laws regarding vehicles
under tow must be observed.
If you must use the accessories (wipers, defrosters, etc.)
while being towed, the ignition must be in the ON/RUN
mode, not the ACC mode.
If the key fob is unavailable or the vehicle’s battery is
discharged, refer to ”Manual Park Release” or “Gear Selector
Override” in this section for instructions on shifting the
automatic transmission out of PARK for towing.
CAUTION!
•Do not use sling type equipment when towing.
Vehicle damage may occur.
• When securing the vehicle to a flat bed truck, do not
attach to front or rear suspension components. Dam-
age to your vehicle may result from improper towing.
Two-Wheel Drive Models
The manufacturer recommends towing your vehicle with
all four wheels OFFthe ground using a flatbed.
If flatbed equipment is not available, and the transmission
is operable, this vehicle may be towed (with rear wheels on
the ground) under the following conditions:
• The transmission must be in NEUTRAL.
• The towing speed must not exceed 30 mph (48 km/h).
• The towing distance must not exceed 15 miles (24 km)
for 6-speed transmission, or 30 miles (48 km) for 8-speed
transmission.
If the transmission is not operable, or the vehicle must be
towed faster than 30 mph (48 km/h) or farther than 15
miles (24 km) for 6-speed transmission, or 30 miles (48 km)
for 8-speed transmission, tow with the rear wheels OFFthe
ground. Acceptable methods are to tow the vehicle on a
flatbed, or with the front wheels raised and the rear wheels
on a towing dolly, or (when using a suitable steering wheel
stabilizer to hold the front wheels in the straight position)
with the rear wheels raised and the front wheels on the
ground.
628 WHAT TO DO IN EMERGENCIES

CavityCartridge Fuse Micro Fuse Description
F46 –10 Amp Red Upfitter – If Equipped
F49 –10 Amp Red Instrument Panel Cluster
(Except Fleet Vehicles)
F50 –20 Amp Yellow Air Suspension Control Module –
If Equipped
F51 –10 Amp Red Ignition Node Module / Keyless Ignition
(Instrument Panel Cluster –Fleet Vehicles Only)
F52 –5 Amp Tan Battery Sensor
F53 –20 Amp Yellow Trailer Tow – Left Turn/Stop Lights
F54 –20 Amp Yellow Adjustable Pedals
F56 –15 Amp Blue Additional Diesel Content – If Equipped
F57 –20 Amp Yellow Transmission
F58 –20 Amp Yellow Spare Fuse
F59 –10 Amp Red SCR Relay – If Equipped
F60 –15 Amp Blue Underhood Lamp
F61 –10 Amp Red (1500
LD Diesel &
Cummins Diesel) PM Sensor – If Equipped
684 MAINTAINING YOUR VEHICLE

Shifting........................... .395, 405
Special Additives ........................ .670
Axle Fluid ........................... .668, 701
Axle Lubrication .......................... .668
Back-Up Camera .......................... .171
Bar, Stabilizer/Sway System ...................455
Battery .............................. .245, 648
Charging System Light ....................245
Keyless Key Fob Replacement ................25
Belts, Seat .................................95
Body Builders Guide ..........................6
Body Mechanism Lubrication ..................656
B-Pillar Location .......................... .513
Brake Assist System ........................ .497
Brake Control System, Electronic ................495
Brake Fluid .......................... .667, 701
Brake System ......................... .494, 667
Fluid Check ........................... .667
Master Cylinder ........................ .667
Parking .............................. .492
Warning Light .......................... .242
Brake/Transmission Interlock ..................387
Bulb Replacement ...................... .688, 690Bulbs, Light
........................... .98, 688
Cab Top Clearance Lights .....................694
Camera, Rear ............................ .171
Camper ................................ .220
Capacities, Fluid .......................... .697
Caps, Filler Oil (Engine) ........................... .642
Power Steering ......................... .492
Radiator (Coolant Pressure) .................664
Carbon Monoxide Warning .................95, 545
Cargo Light ............................. .146
Car Washes .............................. .673
Center High Mounted Stop Light ...............693
Center

Seat Storage Compartment ...............195
Certification Label ......................... .549
Chart, Tire Sizing .......................... .509
Check Engine Light (Malfunction Indicator Light). . . .637
Checking Your Vehicle For Safety ................94
Checks, Safety .............................94
Child Restraint .............................69
Child Restraints Booster Seats ............................73
Child Restraints ..........................69
Child Seat Installation ...................82, 85
10
INDEX 717

KeyFob................................32
Remote................................32
Remote Keyless Entry ......................32
Door Locks, Automatic .......................34
Door Opener, Garage ....................... .175
Driving Off-Pavement .......................... .457
Off-Road ............................. .457
Through Flowing, Rising, Or Shallow Standing
Water ................................ .472
Dual Rear Wheels ...................... .532, 581
E-85 Fuel ............................... .545
Electrical Power Outlets ..................... .184
Electric Rear Window Defrost ..................200
Electronically Shifted Transfer Case . . . .417, 422, 427, 432
Electronic Brake Control System ................495
Anti-Lock Brake System ....................495
Electronic Roll Mitigation ...................504
Traction Control System ....................500
Electronic Range Select (ERS) ............393, 401, 410
Electronic Speed Control (Cruise Control) .........154
Electronic Stability Control (ESC) ...............500
Electronic Throttle Control Warning Light .........246
Emergency Brake .......................... .492Emergency, In Case Of
Freeing Vehicle When Stuck .................621
Hazard Warning Flasher ...................580
Jump Starting .......................... .618
Tow Hooks ............................ .623
Emission Control System Maintenance ............637
Engine .............................. .634, 635
Air Cleaner ............................ .643
Block Heater ........................... .385
Break-In Recommendations ..................94
Compartment .......................... .633
Compartment Identification ...........633, 634, 635
Coolant (Antifreeze) ..................... .698
Exhaust Gas Caution ...................95, 545
Flooded, Starting ........................ .384
Fuel

Requirements ....................541, 697
Jump Starting .......................... .618
Oil ........................... .640, 697, 698
Oil Filler Cap .......................... .642
Oil Filter .............................. .642
Oil Selection ........................ .641, 697
Oil Synthetic ........................... .642
Overheating ........................... .580
Engine Oil Viscosity .....................641, 642
Engine Oil Viscosity Chart ....................641
10
INDEX 719

Fuel, Flexible............................. .545
Fuses .................................. .679
Garage Door Opener (HomeLink) ............175, 180
Gas Cap (Fuel Filler Cap) .................549, 637
Gasoline, Clean Air ........................ .542
Gasoline (Fuel) ........................... .541
Gasoline, Reformulated ..................... .542
Gear Ranges .......................... .396, 405
Gear Select Lever Override ....................623
General Information ........................ .540
Glass Cleaning ........................... .677
Grocery Bag Retainer ....................... .200
Gross Axle Weight Rating .....................552
Gross Vehicle Weight Rating ...................551
Guide, Body Builders .........................6
GVWR ................................. .550
Hazard Driving Through Flowing, Rising, Or
Shallow Standing Water ....................472
Hazard Warning Flasher ..................... .580
Headlights .............................. .690
Automatic ............................ .139
Cleaning .............................. .677High Beam
............................ .147
High Beam/Low Beam Select Switch ...........147
Passing ............................... .147
Switch ............................... .139
Head Restraints ........................... .129
Heated Mirrors .........................115,200
Heater ................................. .330
Heater, Engine Block ....................... .385
High Beam/Low Beam Select (Dimmer) Switch .....147
Hill Descent Control ....................... .505
Hill Descent Control Indicator .................505
Hill Start Assist ........................... .498
Hitches Trailer Towing .......................... .558
Hoisting ................................ .618
HomeLink

(Garage Door Opener) ...............175
Hood Release ............................ .136
Hub Caps ............................... .617
Ignition ..................................15
Key.................................11,15
Ignition Key Removal ........................15
Illuminated Entry ...........................21
Immobilizer (Sentry Key) ......................17
Inside Rearview Mirror ...................104, 110
10
INDEX 721

Instrument Cluster..................... .244, 263
Instrument Cluster Display Instrument Cluster Display ..................267
Instrument Panel And Controls .................235
Instrument Panel Lens Cleaning ................677
Integrated Trailer Brake Controls ................562
Interior Appearance Care .....................676
Interior Lights ............................ .143
Intermittent Wipers (Delay Wipers) ..............148
Introduction ................................4
Inverter Outlet (115V) ...................... .189
Jack Location ......................... .583, 600
Jump Starting ............................ .618
Key Fob Programming Additional Key Fobs .............18
Key Fob Battery Service (Remote Keyless Entry) .....25
Key Fob Programming (Remote Keyless Entry) ......21
Key Fob, Remote Keyless Entry .................21
Key-In Reminder ............................17
Keyless Enter-N-Go ..................... .36, 382
Lock The Vehicle’s Doors ................295, 315
Passive Entry ............................36
Passive Entry Programming ...........36, 295, 315 Keyless Entry System
........................21
Key, Replacement ...........................18
Keys ....................................11
Key, Sentry (Immobilizer) ......................17
Lane Change And Turn Signals .................146
Lane Change Assist ........................ .147
Latches ..................................98
Lead Free Gasoline ........................ .541
Leaks, Fluid ...............................98
Life Of Tires ............................. .526
Light Bulbs ........................... .98, 688
Lights ............................... .98, 138
AirBag ............................ .96, 241
Automatic Headlights .....................139
Brake Assist Warning ..................... .503
Brake Warning ......................... .242
Bulb Replacement ....................... .690
Cap

Top Clearance ...................... .694
Cargo................................ .146
Center Mounted Stop ..................... .693
Courtesy/Reading .................144, 145, 174
Cruise ......................... .263, 264, 265
Daytime Running ....................... .140
Engine Temperature Warning ................244
722 INDEX
