2017 Ram 3500 Chassis Cab check engine

Seat Belt Maintenance
Do not bleach, dye or clean the belts with chemical solvents
or abrasive cleaners. This will weaken the fabric. Sun
damage can also weaken the fabric.
If the belts need cleaning, use a mild soap solution or
lukewarm water. Do not remove the belts from the vehicle
to wash them. Dry with a soft cloth.
Replace the belts if they appear frayed or worn or if the
buckles do not work properly.
NOTE:If the belts retract slowly, inspect the upper turning
loop for soiling. If soiling is present, clean with a wet soft
cloth until all residue is removed.
WARNING!
A frayed or torn belt could rip apart in a collision and
leave you with no protection. Inspect the belt system
periodically, checking for cuts, frays, or loose parts.
Damaged parts must be replaced immediately. Do not
disassemble or modify the system. Seat belt assemblies
must be replaced after a collision if they have been
damaged (i.e., bent retractor, torn webbing, etc.).
FUSES
WARNING!
• When replacing a blown fuse, always use an appro-
priate replacement fuse with the same amp rating as
the original fuse. Never replace a fuse with another
fuse of higher amp rating. Never replace a blown
fuse with metal wires or any other material. Failure
to use proper fuses may result in serious personal
injury, fire and/or property damage.
• Before replacing a fuse, make sure that the ignition is
off and that all the other services are switched off
and/or disengaged.
• If the replaced fuse blows again, contact an autho-
rized dealer.
• If a general protection fuse for safety systems (air
bag system, braking system), power unit systems
(engine system, gearbox system) or steering system
blows, contact an authorized dealer.
492 MAINTAINING YOUR VEHICLE

MAINTENANCE SCHEDULE
Your vehicle is equipped with an automatic oil change
indicator system. The oil change indicator system will
remind you that it is time to take your vehicle in for
scheduled maintenance.
Based on engine operation conditions, the oil change
indicator message will illuminate. This means that service
is required for your vehicle. Operating conditions such as
frequent short-trips, trailer tow, extremely hot or cold
ambient temperatures, and E85 fuel usage will influence
when the “Oil Change Required” message is displayed.
Severe Operating Conditions can cause the change oil
message to illuminate as early as 3,500 miles (5,600 km)
since last reset. Have your vehicle serviced as soon as
possible, within the next 500 miles (805 km).
Your authorized dealer will reset the oil change indicator
message after completing the scheduled oil change. If a
scheduled oil change is performed by someone other than
your authorized dealer, the message can be reset by
referring to the steps described under “Instrument Cluster
Display” in “Understanding Your Instrument Panel” for
further information.Gasoline Engines:
Under no circumstances should oil change intervals exceed
8,000 miles (13,000 km), twelve months or 350 hours of
engine run time, whichever comes first. The 350 hours of
engine run or idle time is generally only a concern for fleet
customers.
Severe Duty:
Change Engine Oil at 4,000 miles (6,500 km) if the vehicle
is operated in a dusty and off road environment or is
operated predominately at idle or very low engine RPM’s.
This type of vehicle use is considered Severe Duty.
Once A Month Or Before A Long Trip:
•
Check engine oil level
• Check windshield washer fluid level
• Check the tire inflation pressures and look for unusual
wear or damage
• Check the fluid levels of the coolant reservoir, brake
master cylinder, power steering and automatic transmis-
sion, and fill as needed
• Check function of all interior and exterior lights
512 MAINTENANCE SCHEDULES

Mileage or time passed (which-ever comes first)
20,000
30,000
40,000
50,000
60,000
70,000
80,000
90,000
100,000
110,000
120,000
130,000
140,000
150,000
Or Years: 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Or Kilometers:
32,000
48,000
64,000
80,000
96,000
112,000
128,000
144,000
160,000
176,000
192,000
208,000
224,000
240,000
Additional Inspections
Inspect the CV/Universal joints. XX X XX
Inspect front suspension, tie rod
ends, and replace if necessary. XXX X X X X
Inspect the front and rear axle sur-
faces. If gear oil leakage is sus-
pected, check the fluid level. If us-
ing your vehicle for police, taxi,
fleet, off-road or frequent trailer
towing, change axle fluid. XXX X X X X
Inspect the brake linings, parking
brake function. XXX X X X X
Additional Maintenance
Replace engine air filter. XX X XX
Replace spark plugs. ** X
Flush and replace the engine cool-
ant at 10 years or 150,000 miles
(240,000 km) whichever comes
first. XX
514 MAINTENANCE SCHEDULES

Adding Engine Coolant (Antifreeze).............478
Adding Fuel ............................. .406
Additives, Fuel ........................... .404
Adjust Down .............................113,114
Forward ............................112,113
Rearward ...........................112,113
Up................................113,114
Adjustable Pedals ......................... .140
Air Bag Air Bag Operation .........................58
Air Bag Warning Light .....................55
Enhanced Accident Response ..............64, 448
Event Data Recorder (EDR) .................449
If A Deployment Occurs ....................63
Knee Impact Bolsters .......................59
Maintaining Your Air Bag System ..............65
Side Air Bags ............................59
Transporting Pets .........................91
Air Bag Light ....................... .55, 94, 201
Air Bag Maintenance .........................65
Air Cleaner, Engine (Engine Air Cleaner Filter) ......460
Air Conditioner Maintenance ..................464
Air Conditioning .......................... .280
Air Conditioning Controls ....................280 Air Conditioning Filter
...................295, 465
Air Conditioning, Operating Tips ...............295
Air Conditioning Refrigerant ...............464, 465
Air Conditioning System ...............280, 294, 464
Air Pressure, Tires ......................... .382
Alarm, Panic ...............................24
Alarm (Security Alarm) ....................19, 203
Alarm System (Security Alarm) .................19
Alterations/Modifications, Vehicle ................7
Antifreeze (Engine Coolant) ...................477
Capacities ............................. .507
Disposal .............................. .479
Anti-Lock Brake System (ABS) .................358
Appearance Care .......................... .486
Ashtray ................................ .177
Assist, Hill Start .......................... .360
Auto

Down Power Windows ...................39
Automatic Door Locks ........................32
Automatic Headlights ...................... .128
Automatic High Beams ..................... .130
Automatic Temperature Control (ATC) ...........294
Automatic Transmission ..................... .484
Adding Fluid .......................... .485
Fluid And Filter Changes ...................486
Fluid Level Check .....................484, 485
524 INDEX

Fluid Type......................... .484, 510
Shifting .............................. .331
Special Additives ........................ .484
Axle Fluid ........................ .482, 483, 510
Axle Lubrication ....................... .482, 483
Back-Up Camera .......................... .160
Battery .............................. .204, 463
Charging System Light ....................204
Keyless Key Fob Replacement ................25
Belts, Seat .................................93
Body Builders Guide ..........................6
Body Mechanism Lubrication ..................471
B-Pillar Location .......................... .376
Brake Assist System ........................ .359
Brake Control System, Electronic ................357
Brake Fluid .......................... .481, 510
Brake System ......................... .356, 481
Fluid Check ........................... .481
Master Cylinder ........................ .481
Parking .............................. .355
Warning Light .......................... .202
Brake/Transmission Interlock ..................331
Bulb Replacement ......................... .501Bulbs, Light
........................... .96, 500
Cab Top Clearance Lights .....................505
Camera, Rear ............................ .160
Capacities, Antifreeze (Engine Coolant) ...........507
Capacities, Fluid .......................... .507
Caps, Filler Oil (Engine) ........................... .459
Power Steering ......................... .354
Radiator (Coolant Pressure) .................479
Carbon Monoxide Warning .................93, 405
Cargo Light ............................. .135
Car Washes .............................. .487
Center High Mounted Stop Light ...............504
Center

Seat Storage Compartment ...............183
Certification Label ......................... .407
Chart, Tire Sizing .......................... .372
Check Engine Light (Malfunction Indicator Light). . . .455
Checking Your Vehicle For Safety ................92
Checks, Safety .............................92
Child Restraint .............................67
Child Restraints Booster Seats ............................71
Child Restraints ..........................67
Child Seat Installation ...................81, 82
10
INDEX 525

Ethanol................................. .403
Exhaust Gas Caution .....................93, 405
Exhaust System ........................ .93, 475
Exterior Lighting .......................... .128
Exterior Lights .............................96
Filters Air Cleaner ............................ .460
Air Conditioning .....................295, 465
Engine Fuel ........................... .508
Engine Oil ......................... .459, 508
Engine Oil Disposal ...................... .459
Flashers Turn Signal ...................... .96, 135, 220
Flat Tire Stowage .......................... .440
Flooded Engine Starting ..................... .327
Fluid, Brake ............................. .510
Fluid Capacities ........................... .507
Fluid Leaks ...............................96
Fluid Level Checks Automatic Transmission ....................485
Brake ................................ .481
Power Steering ......................... .354
Fluids, Lubricants And Genuine Parts ............508
Fog Lights ........................... .131, 503Fold Flat Load Floor
....................... .189
Four-Way Hazard Flasher .....................430
Four Wheel Drive ......................... .342
Freeing A Stuck Vehicle ..................... .443
Front Axle (Differential) ..................... .482
Fuel ................................... .402
Adding .............................. .406
Additives ............................. .404
Clean Air ............................. .402
Ethanol .............................. .403
Filler Cap (Gas Cap) ..................... .407
Filter ................................ .508
Gasoline .............................. .402
Light ................................ .214
Materials

Added ........................ .404
Methanol ............................. .403
Octane Rating .......................... .402
Requirements .......................... .402
Tank Capacity .......................... .507
Fuses .................................. .492
Garage Door Opener (HomeLink) ............164, 171
Gas Cap (Fuel Filler Cap) .................407, 455
Gasoline, Clean Air ........................ .402
Gasoline (Fuel) ........................... .402
528 INDEX

Interior..................... .132, 133, 134, 164
Low Fuel ............................. .214
Malfunction Indicator (Check Engine) ..........208
Park ................................. .219
Passing ............................... .136
Seat Belt Reminder ...................... .201
Security Alarm ......................... .203
Service ............................ .500, 501
Tire Pressure Monitoring (TPMS) ..........212, 395
Traction Control ........................ .366
Transfer Case .......................... .345
Turn Signal ....................96, 135, 220, 501
Warning (Instrument Cluster Description) . . . .204, 220
Limited-Slip Differential ..................350, 483
Loading Vehicle ........................... .407
Tires................................. .376
Load Shed Battery Saver Mode ...................... .237
Battery Saver On ........................ .237
Electrical Load Reduction ...................237
Intelligent Battery Sensor ...................237
Locks ....................................31
Automatic Door ..........................32
Child Protection ..........................33 Door
..................................31
Power Door .............................32
Low Tire Pressure System .....................395
Lubrication, Body ......................... .471
Lug Nuts ......................... .431, 437, 439
Maintenance Free Battery .....................463
Maintenance Procedures ..................... .457
Maintenance Schedule ...................... .512
Malfunction Indicator Light (Check Engine) . . . .208, 455
Manual, Service ........................... .522
Manual Transmission Fluid Level Check ....................... .484
Memory Seat ............................. .121
Methanol ............................... .403
Mirr

ors ................................. .101
Electric Powered ........................ .108
Heated ............................... .109
Memory .............................. .121
Outside .............................. .107
Rearview .......................... .101, 106
Trailer Towing ...........................111
Modifications/Alterations, Vehicle ................7
Monitor, Tire Pressure System ..................395
10
INDEX 531
