CAUTION!
Racing the engine or spinning the wheels may lead to
transmission overheating and failure. Allow the en-
gine to idle with the transmission in NEUTRAL for at
least one minute after every five rocking-motion
cycles. This will minimize overheating and reduce the
risk of clutch or transmission failure during prolonged
efforts to free a stuck vehicle.
NOTE: Push the ESC Off switch, to place the Electronic
Stability Control (ESC) system in Partial Offmode, before
rocking the vehicle. Refer to “Electronic Brake Control” in
“Starting And Operating” for further information. Once
the vehicle has been freed, push the ESC Offswitch again
to restore ESC Onmode.
WARNING!
Fast spinning tires can be dangerous. Forces generated
by excessive wheel speeds may cause damage, or even
failure, of the axle and tires. A tire could explode and
injure someone. Do not spin your vehicle’s wheels
faster than 30 mph (48 km/h) or for longer than 30
seconds continuously without stopping when you are
stuck and do not let anyone near a spinning wheel, no
matter what the speed.
CAUTION!
•When “rocking” a stuck vehicle by shifting between
DRIVE/2nd gear and REVERSE, do not spin the
wheels faster than 15 mph (24 km/h), or drivetrain
damage may result.
• Revving the engine or spinning the wheels too fast
may lead to transmission overheating and failure. It
can also damage the tires. Do not spin the wheels
above 30 mph (48 km/h) while in gear (no transmis-
sion shifting occurring).
622 WHAT TO DO IN EMERGENCIES

EMERGENCY TOW HOOKS — IF EQUIPPED
Your vehicle may be equipped with emergency tow hooks.
NOTE:For off-road recovery, it is recommended to use
both of the front tow hooks to minimize the risk of damage
to the vehicle.
WARNING!
• Do not use a chain for freeing a stuck vehicle. Chains
may break, causing serious injury or death.
• Stand clear of vehicles when pulling with tow hooks.
Tow straps may become disengaged, causing serious
injury.
CAUTION!
Tow hooks are for emergency use only to rescue a
vehicle stranded off-road. Do not use tow hooks for
tow truck hookup or highway towing. You could
damage your vehicle.
GEAR SELECTOR OVERRIDE — 6-SPEED
TRANSMISSION
If a malfunction occurs and the gear selector cannot be
moved out of the PARK position, you can use one of the
following procedures to temporarily move the gear selec-
tor:
Column Shifter — If Equipped
1. Turn the engine off.
2. Firmly apply the parking brake.
3. Tilt the steering wheel to the full up position.
4. Press and maintain firm pressure on the brake pedal.
5. Insert a screwdriver or similar tool into the access port (ringed circle) on the bottom of the steering column, and
push and hold the override release lever up.6
WHAT TO DO IN EMERGENCIES 623

6. Move the gear selector to the NEUTRAL position.
7. The vehicle may then be started in NEUTRAL.
Center Console Shifter — If Equipped
1. Turn the engine off.
2. Firmly apply the parking brake.
3. Using a small screwdriver or similar tool, remove thegear selector override access cover (located to the right
of the gear selector). 4. Press and maintain firm pressure on the brake pedal.
5. Insert the screwdriver or similar tool into the access
hole, and push and hold the override release lever
down.
6. Move the gear selector to the NEUTRAL position.
7. The vehicle may then be started in NEUTRAL.
8. Reinstall the gear selector override access cover.
Gear Selector Override Access Port
Gear Selector Override Access Cover
624 WHAT TO DO IN EMERGENCIES

4. While holding the locking tab in the disengaged posi-tion, pull the tether strap to rotate the lever rearward,
until it locks in place pointing towards the driver’s seat.
Release the locking tab and verify that the Manual Park
Release lever is locked in the released position.
5. The vehicle is now out of PARK and can be towed. Release the parking brake only when the vehicle is
securely connected to a tow vehicle.
To Reset The Manual Park Release:
1. Push the locking tab to the right, to unlock the lever.
2. Rotate the Manual Park Release lever forward to its original position, until the locking tab snaps into place
to secure the lever.
3. Pull gently on the tether strap to confirm that the lever is locked in its stowed position.
4. Re-install the access cover.TOWING A DISABLED VEHICLE
This section describes procedures for towing a disabled
vehicle using a commercial towing service. If the transmis-
sion and drivetrain are operable, disabled vehicles may
also be towed as described under “Recreational Towing” in
the “Starting And Operating” section.
NOTE: Vehicles equipped with air suspension must be
placed in Transport mode, before tying them down (from
the body) on a trailer or flatbed truck. Refer to Air
Suspension inStarting And Operating for more informa-
tion. If the vehicle cannot be placed in Transport mode (for
example, engine will not run), tie-downs must be fastened
to the axles (not to the body). Failure to follow these
instructions may cause fault codes to be set and/or cause
loss of proper tie-down tension.
626 WHAT TO DO IN EMERGENCIES

CAUTION!
Towing this vehicle in violation of the above require-
ments can cause severe engine and/or transmission
damage. Damage from improper towing is not covered
under the New Vehicle Limited Warranty.
Four-Wheel Drive Models
The manufacturer recommends towing with all wheels
OFFthe ground. Acceptable methods are to tow the vehicle
on a flatbed or with one end of vehicle raised and the
opposite end on a towing dolly.
If flatbed equipment is not available, and the transfer case
is operable, the vehicle may be towed (in the forward
direction, with ALLwheels on the ground), IFthe transfer
case is in NEUTRAL (N) and the transmission is in PARK
(for automatic transmissions) or in gear (NOT in NEU-
TRAL, for manual transmissions). Refer to “Recreational
Towing” in “Starting And Operating” for further informa-
tion and detailed instructions.
CAUTION!
• Front or rear wheel lifts must not be used. Internal
damage to the transmission or transfer case will
occur if a front or rear wheel lift is used when
towing.
• Towing this vehicle in violation of the above require-
ments can cause severe transmission and/or transfer
case damage. Damage from improper towing is not
covered under the New Vehicle Limited Warranty.
6
WHAT TO DO IN EMERGENCIES 629

MAINTAINING YOUR VEHICLE
CONTENTS
ENGINE COMPARTMENT — 3.6L ...........633
 ENGINE COMPARTMENT — 5.7L ...........634
 ENGINE COMPARTMENT — 6.4L ...........635
 ONBOARD DIAGNOSTIC SYSTEM (OBD II) . . . .636
▫ Onboard Diagnostic System (OBD II)
Cybersecurity ........................ .636
▫ Loose Fuel Filler Cap Message .............637
 EMISSIONS INSPECTION AND
MAINTENANCE PROGRAMS ..............637
 REPLACEMENT PARTS ...................639
 DEALER SERVICE ...................... .639
 MAINTENANCE PROCEDURES .............639
▫ Engine Oil .......................... .640
▫ Engine Oil Filter ...................... .642
▫ Engine Air Cleaner Filter .................643 ▫
Accessory Drive Belt Inspection ............646
▫ Maintenance-Free Battery .................648
▫ Air Conditioner Maintenance ..............649
▫ Front Driveshaft Lubrication — 2500/3500
(Four-Wheel Drive Models Only) ............655
▫ Body Lubrication ..................... .656
▫ Windshield Wiper Blades .................656
▫ Adding Washer Fluid ...................659
▫ Exhaust System ....................... .660
▫ Cooling System ....................... .662
▫ Brake System ........................ .667
▫ Rear Axle And 4x4 Front Driving
Axle Fluid Level ...................... .668
▫ Transfer Case ........................ .669
▫ Automatic

Transmission ..................669
7

▫Appearance Care And Protection
From Corrosion ....................... .672
 FUSES ............................... .679
▫ Power Distribution Center ................680
 VEHICLE STORAGE .....................688
 REPLACEMENT BULBS ...................688
 BULB REPLACEMENT ....................690
▫ Base Quad / Premium Bi-Halogen: Low Beam
Headlamp, High Beam Headlamp, Front Park
And Turn — If Equipped .................690
▫ Fog Lamps — If Equipped ................691
▫ Rear Tail/Stop, Turn Signal
And Backup Lamps .....................692 ▫
Center High-Mounted Stoplamp (CHMSL)
With Cargo Lamp ..................... .693
▫ Cab Top Clearance Lamps — If Equipped .....694
▫ Rear Lamp Bar ID Marker
(Dual Rear Wheels) — If Equipped ..........696
▫ Side Marker Lamps (Dual Rear Wheels) —
If Equipped ......................... .696
 FLUID CAPACITIES ..................... .697
 FLUIDS, LUBRICANTS, AND
GENUINE PARTS ...................... .698
▫ Engine ............................. .698
▫ Chassis ............................ .701
632 MAINTAINING YOUR VEHICLE

ENGINE COMPARTMENT — 3.6L
1 — Air Cleaner Filter
2 — Engine Oil Dipstick
3 — Engine Oil Fill
4 — Brake Fluid Reservoir
5 — Battery6 — Washer Fluid Reservoir
7 — Power Distribution Center (Fuses)
8 — Coolant Pressure Cap
9 — Engine Coolant Reservoir
7
