Changing foglamp bulbs
(on models with halogen
headlamps)
F Introduce a flat screwdriver in the hole in the finisher.
F

P
ull and lever to unclip the front bumper
finisher.
F

U
sing a Torx screwdriver, remove the two
module fixing screws.
F

R
emove the module from its housing. F

D
isconnect the bulb holder connector.
F
T
urn the bulb holder a quarter of a turn and
pull it out.
F C hange the assembly.
To refit, carry out these operations in reverse
o r d e r.
To replace this type of bulb, you can
also contact a PEUGEOT dealer or a
qualified workshop.
In the event of a breakdown

328
3008-2_en_Chap08_en cas-de-panne_ed01-2016
Direction indicators
(on the wings)
F Open the tailgate then unclip the access cover on the side in question.
F

S
lacken the lamp fixing nut using a 10 mm
box spanner or socket.
F

T
o avoid losing the nut if it drops into the
wing trim, first place a cloth below it.
F

M
anually unscrew and remove the lamp
fixing nut.
F

D
isengage the retaining clip, while pushing
the lamp out slightly.
Rear lamps
1. Brake lamps (LEDs).
2. Si delamps / daytime running lamps
(LEDs).
3.
D

irection indicators (WY16W amber).
4.
R

eversing lamps (W16W).
5.
F

oglamp (P21W).
LEDs: light-emitting diodes. F

F
rom the outside, carefully remove the
lamp by pulling it to the rear, then up.
F
D
isconnect the lamp connector.
F
T
urn the bulb holder a quarter turn and pull
it out using a standard pair of pliers.
F
P
ull the bulb out and replace it.
For reassembly, carry out these operations in
reverse order.
In the event of a breakdown

329
3008-2_en_Chap08_en cas-de-panne_ed01-2016
Reversing lamp
(tailgate)
F Open the tailgate, then introduce a flat screwdriver into the cut-out to unclip the
access cover on the side in question.
F

S
lacken the lamp fixing nut using a 10 mm
box spanner or socket.
F

M
anually unscrew and remove the lamp
fixing nut.
F

D
isengage the retaining clip, while pushing
the lamp out slightly. F
F rom the outside, carefully remove the
lamp by pulling it to the rear.
F

D
isconnect the lamp connector by pressing
on each side.
F

T
urn the bulb holder a quarter turn and pull
it out.
F

P
ull the bulb out and replace it.
For reassembly, carry out these operations in
reverse order.
Changing foglamp bulbs
These bulbs are replaced from outside the rear
bumper:
F
p
ass your hand under the bumper,
F

t
urn the bulb holder a quarter turn and
remove it,
F

t
urn the bulb a quarter turn, pull it out and
fit a new bulb.
For reassembly, carry out these operations in
reverse order.
Take care not to touch the silencer;
there is a risk of burns if changing a
bulb within a few minutes of switching
off the ignition.
8
In the event of a breakdown

330
3008-2_en_Chap08_en cas-de-panne_ed01-2016
Third brake lamp (light emitting
diodes - LEDs)
Contact a PEUGEOT dealer or qualified
workshop.
Number plate lamps
F Insert a thin screwdriver into the slot in the lens.
F

P
ush it outwards to unclip it.
F

R
emove the lens.
F

P
ull the bulb out and change it.
In the event of a breakdown
