254Vehicle careWheels and tyres
Tyre condition, wheel condition Drive over edges slowly and at right
angles if possible. Driving over sharp
edges can cause tyre and wheel
damage. Do not trap tyres on the kerb when parking.
Regularly check the wheels for
damage. Seek the assistance of a
workshop in the event of damage or
unusual wear.
Winter tyres
Winter tyres improve driving safety at temperatures below 7 °C and shouldtherefore be fitted on all wheels.
In accordance with country-specific
regulations, affix the speed sticker in
the driver's field of view.
All tyre sizes are permitted as winter
tyres 3 295.Tyre designations
E.g. 215/60 R 16 95 H215:tyre width, mm60:cross-section ratio (tyre height
to tyre width), %R:belt type: RadialRF:type: RunFlat16:wheel diameter, inches95:load index e.g. 95 is equivalent
to 690 kgH:speed code letter
Speed code letter:
Q:up to 160 km/hS:up to 180 km/hT:up to 190 km/hH:up to 210 km/hV:up to 240 km/hW:up to 270 km/h
Choose a tyre appropriate for the
maximum speed of your vehicle.
The maximum speed is achievable at kerb weight with driver (75 kg) plus
125 kg payload. Optional equipment
could reduce the maximum speed of
the vehicle.
Performance 3 286.
Directional tyres
Directional tyres should be mounted
so that they rotate in the correct
direction. The proper rotation
direction is indicated by a symbol
(e.g. an arrow) on the sidewall.
Tyre pressure
Check the pressure of cold tyres at
least every 14 days and before any
long journey. Do not forget the spare
wheel. This also applies to vehicles
with tyre pressure monitoring system.
Unscrew the valve cap.
Tyre pressure 3 295.

292Technical dataKerb weight, basic model without any optional equipmentCountry TourerEngineManual transmissionAutomatic transmission[kg]B16SHL - Front-wheel-drive17011701B20NHT - All-wheel drive18431843[kg]B20DTH - Front-wheel-drive17331733B20DTH - All-wheel drive18651929
Optional equipment and accessories increase the kerb weight.
Loading information 3 83.
Vehicle dimensions4-door Saloon5-door HatchbackSports TourerCountry TourerLength [mm]4842484249204920Width without exterior mirrors [mm]1856185618561856Width with two exterior mirrors [mm]2084208420842084Height (without antenna) [mm]1498149815201530Vehicle height - Rear compartment open [mm]1830217521842195Length of load compartment floor [mm]1003100310861086Length of load compartment with folded rear seats
[mm]1895189519081908

Technical data2934-door Saloon5-door HatchbackSports TourerCountry TourerLoad compartment width [mm]1027102710301030Load compartment height [mm]356436677677Wheelbase [mm]2737273727372737Turning circle diameter [m]11.3 - 12.0511.3 - 12.0511.3 - 12.0511.3 - 12.05
