steep descent thatengine braking aloneinFour-Wheel
Drive (4WD) modecannot control thespeed.
When driving forward onthe descent, thespeed can
be adjusted bythe brake oraccelerator operation.The
system maintains thespeed forreverse drivingonthe
descent.
HILL DESCENT CONTROL SWITCH
T32A130827- A22A42E7-41B 2-4114-88DB-9E1B7 BDE94E3
JVS0402X
When additional brakingisrequired onsteep downhill
roads, activate thehilldescent controlsystem by
pushing thehilldescent controlswitchon.
When thehilldescent controlsystem isactivated, the
hill descent controlsystem onindicator light
will
illuminate. (SeeªHilldescent controlsystem on
indicator lightº(P.2-18) .)Also, thestop/tail lights
illuminate whilethehilldescent controlsystem is
applying thebrakes tocontrol thevehicle speed.
T o activate thehilldescent controlsystem, satisfyallof
the following conditions:
. Shift thetransmission tothe forward orreverse
gear.
. Turn the4WD mode switch tothe LOCK mode
and drive thevehicle ataspeed under25km/h
(15 MPH) . .
Push thehilldescent controlswitchtothe ªONº
position.
If the accelerator orbrake pedal isdepressed whilethe
hill descent controlsystem ison, the system willstop
operating temporarily .As soon asthe accelerator or
brake pedal isreleased, thehilldescent controlsystem
begins tofunction againifthe hilldescent control
operating conditions arefulfilled.
The hilldescent controlsystem onindicator lightblinks
if the hilldescent controlswitchison and allconditions
for system activation arenot met, orifthe system
becomes disengaged forany reason.
When thevehicle speedexceeds 40km/h (25MPH) ,
the 4WD mode indicator lightchanges fromLOCK to
AUT O.Once thespeed decreases to25 km/h (15
MPH) ,turn the4WD mode switch toLOCK again to
turn onthe hilldescent controlsystem.
T o turn offthe hilldescent controlsystem, pushthehill
descent controlswitchtothe OFF position.
GUID-89 EA2F2C-B11 E-4266-AE54-208D2C5 5EC10
The Blind SpotWarning (BSW) systemhelpsalertthe
driver ofother vehicles inadjacent laneswhen
changing lanes.
The Lane Departure Warning (LDW) system helps
alert thedriver whenthevehicle istraveling closeto
either theleftorthe right ofatraveling
lane.
JVS0390X
The BSW/LDW systemsusetherearview cameraunit
*
1
with automatic washerandblower.
WARNING:
. The BSW system isnot areplacement for
proper driving procedure andisnot de-
signed toprevent contactwithvehicles or
objects. Whenchanging lanes,always use
the side andrear mirrors andturn andlook
in the direction youwillmove toensure itis
safe tochange lanes.Neverrelysolely on
the BSW system.
. The LDW system isonly awarning deviceto
help inform thedriver ofapotential unin-
tended lanedeparture. Itwill notsteer the
vehicle orprevent lossofcontrol. Itis the
driver's responsibility tostay alert, drive
safely, keepthevehicle inthe traveling lane,
Starting anddriving
5-31
BLIND
SPOTWARNING (BSW)/
LANE DEPARTURE WARNING (LDW)
S Y STEMS (ifequipped)
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
S Y STEM ON:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
The LDW indicator (white)inthe vehicle information
display willappear.
S Y STEM OFF:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
The LDW indicator (white)inthe vehicle information
display willoff.
Perform thefollowing stepstoenable ordisable the
LDW system.
1. Use the
button untilªSettingsº displaysinthe
vehicle information display.Use the
to select
ªDriver Assistanceº .Then press theENTER
button.
2. Select ªDriving Aidsº,and press theENTER
button.
3. To set the LDW system toon oroff, use the
buttons tonavigate inthe menu andusethe
ENTER buttontoselect ªLaneº andpress the
ENTER button.
WARNING:
. The camera unitmay notbeable todetect
properly underthefollowing conditions:
Ð On roads where therearemultiple
parallel lanemarkers; lanemarkers that
are faded ornot painted clearly;yellow
painted lanemarkers; nonstandard lane
markers; orlane markers coveredwith
water, dirt,snow, etc.
Ð On roads where thediscontinued lane
markers arestill detectable.
Ð On roads where therearesharp curves.
Ð On roads where therearesharply con-
trasting objects, suchasshadows,
snow, water, wheelruts,seams orlines remaining
afterroadrepairs. (TheLDW
system coulddetect theseitemsaslane
markers.)
Ð On roads where thetraveling lane
merges orseparates.
Ð When thevehicle's traveling direction
does notalign withthelane marker.
Ð When theroad surface isvery dark due
to weak ambient lightorimpaired tail
lamp.
. When driving onacurved road,warning will
be late onthe outside ofthe curve.
BSW/LDW TEMPORAR YDISABLED STA-
TUS
GUID-1B DDF44E-AF F2-4E00-9455-635AEAA 0FD68
Under thefollowing condition, theBSW and/or LDW
system isturned offtemporarily ,the BSW indicator
(white) and/orLDWindicator (white)willblink, andthe
following message willappear inthe vehicle informa-
tion display:
. ªBack DoorOpenº
When theabove condition iscorrected, theBSW and/
or LDW system willresume automatically .
BSW/LDW AUTOMA TICDEACTIV ATION
GUID-2F69D EE5-07A4-4D46-9DF 1-D415DC6 DE324
When dirt,rainorsnow accumulates onthe camera,
the BSW and/or LDWsystem willbeturned off
automatically andcannot beremoved bythe automatic
washer andblower. TheBSW indicator (white)and/or
LDW indicator (white)willblink, andtheªNot available
Clean RearCameraº message willappear inthe
vehicle information display.
Action totake:
If the message appears,parkthevehicle inasafe
place, cleanthecamera unitwith asoft cloth. Thenturn off
and restart theengine.
BSW/LDW MALFUNCTION
GUID-BE7 2994E-574 0-4BDE-86C 1-2EB349CD BE95
When theBSW and/or LDWsystem malfunctions,
they willbeturned offautomatically ,the BSW indicator
(orange) and/orLDWindicator (orange)willilluminate
and theªSystem faultºmessage willappear inthe
vehicle information display.
Action totake:
Stop thevehicle inasafe location, turnoffand restart
the engine. Ifthe BSW indicator (orange)and/orLDW
indicator (orange)continues toilluminate, havethe
BSW and/or LDWsystem checked byaNISSAN
dealer.
CAMERA UNITMAINTENANCE
GUID-0ED FD818-00A 6-4767-884 7-3673FFD 43878
JVS0393X
The rearview cameraunit
*
1
for the LDW/BSW
systems islocated abovetherear licence plate.To
maintain theproper operation ofthe LDW/BSW
systems andhelp keep thesystem functioning, be
sure toobserve thefollowing:
. Always keepthecamera unitclean. Becareful not
to damage thenozzle ofautomatic washerand
blower.
Starting anddriving
5-35
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
SSD1034
If the driver activates theturn signal whileanother
vehicle isin the detection zone,thentheBlind Spot
Indicator lightflashes andachime willsound twice.
BSW TEMPORAR YDISABLED STATUS
GUID-0F E9D3F1-03F 8-43CE-BFD8-03D453 EFDB97
Under thefollowing condition, theBSW system is
turned offtemporarily ,the BSW indicator willblink, and
the following message willappear inthe vehicle
information display:
. ªBack DoorOpenº
When theabove condition iscorrected, theBSW
system willresume automatically .
BSW AUTOMA TICDEACTIV ATION
GUID-260373 8E-FAAD-45D6 -AA7E-7BC6 5AFF2F97
When dirt,rainorsnow accumulates onthe camera,
the BSW system willbeturned offautomatically and
cannot beremoved bythe automatic washerand
blower. TheBSW indicator willblink andtheªNot
available CleanRearCameraº message willappear in
the vehicle information display.
Action totake:
If the message appears,parkthevehicle inasafe
place, cleanthecamera unitwith asoft cloth. Thenturn
off and restart theengine.
BSW MALFUNCTION
GUID-DC9E 6DEC-176C-4 D78-A22D-716327A49A9 2
When theBSW system malfunctions, theywillbe
turned offautomatically ,the BSW indicator will
illuminate andtheªSystem faultºmessage willappear
in the vehicle information display.
Action totake:
Stop thevehicle inasafe location, turnoffand restart
the engine. Ifthe BSW indicator continues to
illuminate, havetheBSW system checked bya
NISSAN dealer.
CAMERA UNITMAINTENANCE
GUID-DB 9BD0F8-43C8-4F10 -BC52-E7E5A6 42BDCB
JVS0393X
The rearview cameraunit
*
1
for the BSW system is
located abovetherear licence plate.To maintain the
proper operation ofthe BSW system andhelp keep
the system functioning, besure toobserve the
following:
. Always keepthecamera unitclean. Becareful not
to damage thenozzle ofautomatic washerand
blower.
. Donot attach ªlicence plateaccessoriesº that
reflect light.
. Donot strike ordamage theareas around the
camera unit.
GUID-360 9F050-5091- 4101-96DB-2D 85C79F4D76
The Lane Departure Warning (LDW) system helps
alert thedriver whenthevehicle istraveling closeto
either theleftorthe right ofatraveling lane.
JVI0975X
The LDW system usesthemulti-sensing frontcamera
unit situated onthe windshield infront ofthe inside
rearview mirror
*
1
.
WARNING:
. This system isonly awarning deviceto
inform thedriver ofapotential unintended
lane departure. Itwill notsteer thevehicle or
prevent lossofcontrol. Itis the driver's
responsibility tostay alert, drivesafely, keep
the vehicle inthe traveling lane,andbein
control ofthe vehicle atall times.
. The system willnotoperate atspeeds below
approximately 60km/h (37MPH) orifit
cannot detectlanemarkers.
. Ifthe LDW system malfunctions, itwill
cancel automatically, andtheLDW ªSystem
faultº message willappear inthe vehicle
information display.
. Ifthe LDW ªSystem faultºmessage appears,
pull offthe road toasafe location andstop
Starting anddriving
5-39
LANE
DEPARTURE WARNING (LDW)
S Y STEM (ifequipped forEurope)
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
5-40
Starting anddriving
the vehicle. Turn theengine offand restart
the engine. Ifthe LDW ªSystem faultº
message continues toappear, havethe
system checked byaNISSAN dealer.
. Excessive noisewillinterfere withthewarn-
ing chime sound, andthechime maynotbe
heard.
The system maynotfunction properly underthe
following conditions:
. Onroads where therearemultiple parallellane
markers; lanemarkers thatarefaded ornot
painted clearly;yellowpainted lanemarkers;
non-standard lanemarkers; orlane markers
covered withwater, dirt,snow ,etc.
. Onroads where thediscontinued lanemarkers are
still detectable.
. Onroads where therearesharp curves.
. On roads where therearesharply contrasting
objects, suchasshadows, snow,water, wheel
ruts, seams orlines remaining afterroad repairs.
(The Lane Departure Warning (LDW) system
could detect theseitemsaslane markers.)
. On roads where thetraveling lanemerges or
separates.
. When thevehicle's travelingdirection doesnot
align withthelane marker.
. When traveling closetothe vehicle infront ofyou,
which obstructs thelane camera unitdetection
range.
. When rain,snow ordirt adheres tothe windshield
in front ofthe lane camera unit.
. When theheadlights arenot bright duetodirt on
the lens orifthe aiming isnot adjusted properly.
. When strong lightenters thelane camera unit.
(For example, thelight directly shinesonthe front of
the vehicle atsunrise orsunset.)
. When asudden changeinbrightness occurs.(For
example, whenthevehicle entersorexits atunnel
or under abridge.)
LDW SYSTEM OPERA TION
GUID-5D2 78735-FB2A-4 876-B549-D059C0E4D 50E
JVS0439X
SSD0672
LDW indicator (inthe Vehicle information display)
The LDW system provides alane departure warning
function whenthevehicle isdriven atspeeds
approximately 60km/h (37MPH) andabove.
When thevehicle approaches eithertheleftorthe right
side ofthe traveling lane,awarning chimewillsound
and theLDW indicator inthe vehicle information
display willblink toalert thedriver. The
warning function willstop when thevehicle returns
inside ofthe lane markers.
The LDW system isnot designed towarn under the
following conditions.
. When youoperate thelane change signaland
change traveling lanesinthe direction ofthe
signal. (TheLDW system willbecome operable
again approximately 2seconds afterthelane
change signalisturned off.)
. When thevehicle speedlowers toless than
approximately 60km/h (37MPH) .
After theabove conditions havefinished andthe
necessary operatingconditions aresatisfied, theLDW
functions willresume.
T urning onoroff the LDW system
GUID-32550F 0C-0E6C-49C3-92BB -00578BDFA0E5
The LDW system isturned onoroff using thesettings
menu inthe vehicle information display.
S Y STEM ON:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
The LDW indicator inthe vehicle information display
will appear.
S Y STEM OFF:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
The LDW indicator inthe vehicle information display
will off.
Perform thefollowing stepstoenable ordisable the
LDW system.
1. Use the
button untilªSettingsº displaysinthe
vehicle information display.Use the
to select
ªDriver Assistanceº .Then press theENTER
button.
2. Select ªDriving Aidsº,and press theENTER
button.
3. To set the LDW system toon oroff, use the
buttons tonavigate inthe menu andusethe
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
set speed isexceeded anddriver intervention isnot
detected.
T urning thespeed limiteroff
GUID-604082 45-BB35-4F90-884A-8 3477F15BB08
The speed limitersystem willbeturned offwhen oneof
the following operations isperformed:
. Push thespeed limiterMAINswitch. Thespeed
limiter indicator andthesetspeed indicator onthe
vehicle information displaywillbeturned off.
. Push thecruise control MAINswitch. Thespeed
limiter information onthe vehicle information will
be replaced withthecruise control information.
For details seeªCruise controlº (P.5-43) .
. When thevehicle isstopped andtheignition is
placed tothe offposition.
T urning offthe speed limiterwillerase thesetspeed
limit memory .
Speed limitermalfunction
GUID-56D 8A157-AB4B- 4429-9C83-5333E82C8D98
If the speed limitermalfunctions, thespeed limiteron
the vehicle information displaywillflash.
T urn thespeed limiterMAINswitch offand have the
system checked byaNISSAN dealer.
T32A130 827-FF5B4 88B-DD40- 465E-8AD4-B D88C01B8 0E9
JVS0180X
Models without speedlimiter
JVS0427X
Models withspeed limiter
1. CANCEL switch
2. ACCELERA TE/RESUME switch
3. COAST/SET switch
4. Cruise control MAINswitch
5. Speed limiterMAINswitch
WARNING:
. Always observe theposted speedlimitsand
do not setthe speed overthem.
. Donot use thecruise control whendriving
under thefollowing conditions. Doingso
could cause aloss ofvehicle control and result
inan accident.
Ð When itis not possible tokeep the
vehicle ataconstant speed
Ð When driving inheavy traffic
Ð When driving intraffic thatvaries speed
Ð When driving inwindy areas
Ð When driving onwinding orhilly roads
Ð When driving onslippery (rain,snow, ice,
etc .)roads
CAUTION:
On manual Transmission (MT)model, donot
shift tothe ªNº (Neutral) positionwithout
depressing theclutch pedalwhenthecruise
control isoperated. Shouldthisoccur, depress
the clutch pedalandturn thecruise control MAIN
switch offimmediately. Failuretodo somay
cause engine damage.
PRECAUTIONS ONCRUISE CONTROL
T32A1308 27-DF670F 83-9B80-4A99-B18B-0 4CB9B1ECB D9
. Ifthe cruise control system malfunctions, itwill
cancel automatically .The CRUISE indicator inthe
vehicle information displaywillthen blink towarn
the driver.
. Ifthe CRUISE indicator blinks,turnthecruise
control MAINswitch offand have thesystem
checked byaNISSAN dealer.
. The CRUISE indicator mayblink when thecruise
control MAINswitch isturned ONwhile pushing
the ACCELERA TE/RESUME, COAST/SETor
CANCEL switch.To properly setthe cruise control
system, perform thefollowing procedures.
Starting anddriving
5-43
CRUISE
CONTROL (ifequippe d)
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
GUID-50A61 EEE-50E1-49 FC-B406-D1735C8B3E99
The forward emergency brakingsystemcanassist the
driver whenthereisarisk ofaforward collision withthe
vehicle aheadinthe travelling
lane.
JVS0435X
The forward emergency brakingsystemusesaradar
sensor
*
1
located atthe front ofthe vehicle to
measure thedistance tothe vehicle aheadinthe
travelling lane.
The forward emergency brakingsystemoperates at
speeds aboveapproximately 5km/h (3MPH) .
WARNING:
. The forward emergency brakingsystemisa
supplemental aidtothe driver. Itis not a
replacement forthe driver's attention to
traffic conditions orresponsibility todrive
safely. Itcannot prevent accidents dueto
carelessness ordangerous drivingtech-
niques.
. The forward emergency brakingsystem
does notfunction inall driving, traffic,
weather androad conditions.
S YSTEM OPERA TION
GUID-282 EFFD6-A2A3 -44A1-9162-36F52A814 BFD
The forward emergency brakingsystemwillfunction
when yourvehicle isdriven atspeeds aboveapproxi-
mately 5km/h (3MPH) .
If arisk ofaforward collision isdetected, theforward
emergency brakingsystemwillprovide thefirst
warning tothe driver byflashing theforward emer-
gency braking systemwarning lightandproviding an
audible warning.
If the driver applies thebrakes quickly andforcefully
after thewarning, andtheforward emergency braking
system detects thatthere isstill thepossibility ofa
forward collision, thesystem willautomatically increase
the braking force.
If the driver doesnottake action, theforward
emergency brakingsystemissuesthesecond visual
warning (red)andaudible warning. Ifthe driver
releases theaccelerator pedal,thenthesystem applies
partial braking.
If the risk ofacollision becomes imminent, theforward
emergency brakingsystemapplies harderbraking
automatically .
NO TE:
The vehicle's brakelightscomeonwhen braking
is performed bythe forward emergency braking
system.
Depending onvehicle speedanddistance tothe
vehicle ahead,aswell asdriving androadway
conditions, thesystem mayhelp thedriver avoida
forward collision ormay help mitigate theconse-
quences ifa collision shouldonebeunavoidable.
If the driver ishandling thesteering wheel,accelerating
or braking, theforward emergency brakingsystemwill
function laterorwill not function.
The automatic brakingwillcease underthefollowing conditions:
. When thesteering wheelisturned asfar as
necessary toavoid acollision.
. When theaccelerator pedalisdepressed.
. When thereisno longer avehicle detected ahead.
If the forward emergency brakingsystemhasstopped
the vehicle, thevehicle willremain atastandstill for
approximately 2seconds beforethebrakes are
released.
WARNING:
. The radar sensor doesnotdetect the
following objects:
Ð Pedestrians, animalsorobstacles inthe
roadway
Ð Oncoming vehicles
Ð Crossing vehicles
. The radar sensor hassome performance
limitations. Ifastationary vehicleisin the
vehicle's path,theforward emergency brak-
ing system willnotfunction whenthevehicle
is driven atspeeds overapproximately 80
km/h (50MPH) .
. The radar sensor maynotdetect avehicle
ahead inthe following conditions:
Ð Dirt, ice,snow orother material covering
the radar sensor.
Ð Interference byother radarsources.
Ð Snow orroad spray fromtravelling
vehicles.
Ð If the vehicle aheadisnarrow (e.g.
motorcycle) .
Starting anddriving
5-45
FORWARD
EMERGENCY BRAKIN G
S Y STEM (ifequipped)
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
5-48
Starting anddriving
ECO DRIVE REPORT
GUID-50E2 3061-A0D4-48FA-B1AB-3D 81CC65E BC0
JVI0929X
When theignition switchisin the OFF position, ECO
management displayappears.
*
1
ECO evaluation
*
2
Previous 5times (History)
*
3
Current fueleconomy
*
4
Best fueleconomy
The result ofECO evaluation isdisplayed whenthe
vehicle isdriven forabout 10minutes ormore.
*
1
: The more economically youdrive, the more
appear.
*
2
: The average fueleconomy forthe previous 5
times willbedisplayed.
*
3
: The average fueleconomy sincethelast reset will
be displayed.
*
4
: The best fueleconomy ofthe past history willbe
displayed.
GUID-4EA3AC 09-F236-4911-80A7-FA5BD8B3C 037
WARNING:
. Do not stop orpark thevehicle over
flammable materialssuchasdry grass,
waste paperorrags. Theymayignite and
cause afire.
. Safe parking procedures requirethatboth
the parking brakebeapplied andtheshift
lever placed inthe ªPº(Park) position
(Continuously Variable Transmission model)
or the shift lever placed inan appropriate
gear (Manual Transmission model).Failure
to do socould cause thevehicle tomove
unexpectedly orroll away andresult inan
accident.
. When parking thevehicle, makesurethe
shift lever ismoved tothe ªPº(Park)
position. Theshift lever cannot bemoved
out ofthe ªPº(Park) position without
depressing thefoot brake pedal(Continu-
ously Variable Transmission model).
. Never leavetheengine running whilethe
vehicle isunattended.
. When parking foranextended periodoftime
with Stop/Start SystemorIdling StopSys-
tem (ifequipped) activated,theengine will
restart automatically. Neverleavethevehi-
cle with theignition switchinthe ªONº
position.
. Never leavechildren oradults whowould
normally requirethesupport ofothers alone
in the vehicle. Petsshould notbeleft alone
either. Theycould unknowingly activate
switches orcontrols andinadvertently be-
come involved inaserious accident and
injure themselves. Onhot, sunny days, temperatures
inaclosed vehicle could
quickly become highenough tocause se-
vere orpossibly fatalillness topeople and
animals.
P ARKING
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
SSD0488
Left-Hand Drive(LHD) model
SSD0489
Right-Hand Drive(RHD) model
1. Firmly applytheparking brake.
2. Continuously Variable Transmission (CVT)model:
Move theshift lever tothe ªPº (Park) position.
Manual Transmission (MT)model: Movetheshift
lever tothe ªRº (Reverse) position.Whenparking
on anuphill grade, movetheshift lever tothe ª1º
(1st) position.
3. To help prevent thevehicle frommoving intotraffic
when parked onanincline, itis agood practice to
turn thewheels asillustrated.
HEADED DOWNHILL WITHCURB
*
1
T urn thewheels towards thecurb andmove the vehicle
forward untilthecurb sidewheel gently
touches thecurb. Thenapply theparking brake.
HEADED UPHILLWITHCURB
*
2
T urn thewheels awayfromthecurb andallow the
vehicle tomove backuntilthecurb sidewheel
gently touches thecurb. Thenapply theparking
brake.
HEADED UPHILLORDOWNHILL, WITHOUT
CURB
*
3
T urn thewheels towardtheside ofthe road sothe
vehicle willmove awayfromthecenter ofthe road
if the vehicle moves. Thenapply theparking brake. 4.
Model withIntelligent Key:
Place theignition switchinthe ªOFFº position.
Model without Intelligent Key:
Place theignition switchinthe ªLOCKº position
and remove thekey.
NO TE:
For Model withStop/Start SystemorIdling Stop
System:
Use thissystem whenthevehicle isstopped for
a period oftime, forexample waitingatstop-
lights.
Stop theengine withtheignition switchwhen
parking, etc.for anextended periodoftime.
Starting anddriving
5-49
&RQGLWLRQ
([FHSWIRU&KLQD
