WIPER AND WASHER SWITCH
Move the lever to one of the following positions to operate the front
windshield wipers:
1 Mist ( MIST) – One sweep operation of the
front wipers.
2 Intermittent (INT) – To operate intermittently, push the lever down. The
intermittent speed can be adjusted by
twisting the time control ring
3 to
increase or decrease wiper speed.
4 Low ( LO) – Front wipers operate at a
continuous low-speed.
5 High ( HI) – Front wipers operate at a
continuous high-speed.
6 Front washer – Pull the lever toward
you to activate the front washer. The
front wipers will operate several times.
REAR WIPER AND WASHER
7 Intermittent (INT) – Rear wiper operates intermittently.
8 Low ( ON) – Rear wiper operates at a
continuous low-speed.
9 Rear washer – Push the lever forward to activate the rear washer. The
rear wiper will operate several times.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
1
2
4
5
MIST
OFFINT
LO
HI
69
3
INT
ON7
8
