3 –13 Before Driving
Doors and LocksNOTE 
The system can be set to unlock
both doors and the fuel-filler lid by
performing a single operation.
Refer to Personalization Features on
page 9-9 .
Use the following procedure to change
the setting.
1. Switch the ignition off and close
both of the doors and the trunk lid.
2. Open the driver's door.
3. Within 30 seconds of opening the
driver's door, press and hold the
UNLOCK button on the key for 5
seconds or longer (the sound of
the doors locking/unlocking can be
heard).
After this, the system switches the
setting of pressing the driver's
request switch once or twice
to unlock both doors each time
the UNLOCK button is pressed
(the sound of the doors locking/
unlocking can be heard).
4. The setting change is completed by
doing any one of the following: 
Switching the ignition to ACC or
ON. 
Closing the driver's door. 
Opening the trunk lid. 
Not operating the key for 10
seconds. 
Pressing any button except the
UNLOCK button on the key. 
Pressing a request switch. 
Confirm that both doors and the fuel-
filler lid are securely locked. 
Both doors and the fuel-filler lid cannot
be locked when any door is open. 
It may require a few seconds for the
doors to unlock after the request switch
is pressed. 
A beep sound is heard for confirmation
when the doors and the fuel-filler lid
are locked/unlocked using the request
switch. If you prefer, the beep sound can
be turned off.
The volume of the beep sound can also
be changed. Refer to Personalization
Features on page 9-9 .
Use the following procedure to change
the setting.
1. Switch the ignition off and close
both of the doors and the trunk lid.
2. Open the driver's door.
3. Within 30 seconds of opening the
driver's door, press and hold the
LOCK button on the key for 5
seconds or longer.
Both of the doors and the fuel-
filler lid lock and the beep sound
activates at the currently set volume.
The setting changes each time the
LOCK button on the key is pressed
and the beep sound activates at the
set volume. (If the beep sound has
been set to not activate, it will not
activate.)
4. The setting change is completed by
doing any one of the following: 
Switching the ignition to ACC or
ON. 
Closing the driver's door. 
Opening the trunk lid. 
Not operating the key for 10
seconds. 
Pressing any button except the
LOCK button on the key. 
Pressing a request switch.
MX-5_8FR4-EA-16J_Edition1.indb 13 2016/08/11 20:28:30

3 –14 Before Driving
Doors and Locks 
(With theft-deterrent system)
The hazard warning lights flash when
the theft-deterrent system is armed or
turned off.
Refer to Theft-Deterrent System on page
3-49 . 
The setting can be changed so that the
doors and the fuel-filler lid are locked
automatically without pressing the
request switch.
Refer to Personalization Features on
page 9-9 .
(Auto-lock function)
A beep sound is heard when both doors
are closed while the advanced key
is being carried. Both doors and the
fuel-filler lid are locked automatically
after about three seconds when the
advanced key is out of the operational
range. Also, the hazard warning lights
flash once. (Even if the driver is in the
operational range, both doors and the
fuel-filler lid are locked automatically
after about 30 seconds.) If you are out
of the operational range before the
doors and the trunk lid are completely
closed or another key is left in the
vehicle, the auto-lock function will not
work. Always make sure that both doors
and the trunk lid are closed and locked
before leaving the vehicle. The auto-
lock function does not close the power
windows. 
Auto re-lock function
After unlocking with the request
switch, both doors and the fuel-filler
lid will automatically lock if any of the
following operations are not performed
within about 60 seconds. If your
vehicle has a theft-deterrent system,
the hazard warning lights will flash for
confirmation.
The time required for the doors and the
fuel-filler lid to lock automatically can
be changed.
Refer to Personalization Features on
page 9-9 . 
Opening a door or the trunk lid. 
Switching the ignition to any position
other than off.
Locking, Unlocking with
Transmitter Both doors and the fuel-filler lid can be
locked/unlocked by operating the keyless
entry system transmitter, refer to Keyless
Entry System (page 3-3 ).
Locking, Unlocking with Door-
Lock Switch Both doors and the fuel-filler lid lock
automatically when the lock side is
pressed. They unlock when the unlock side
is pressed.
Driver's door
Unlock Lock
MX-5_8FR4-EA-16J_Edition1.indb 14 2016/08/11 20:28:30

3 –15 Before Driving
Doors and LocksFront passenger's door
Unlock Lock
To lock both the doors and the fuel-filler
lid from an open door, press the lock side
of the door lock switch and then close the
door.
NOTE
When locking the doors this way, be
careful not to leave the key inside the
vehicle.
Auto Lock/Unlock Function
WARNING Do not pull the inner handle on a door:
Pulling the inner handle on a
door while the vehicle is moving
is dangerous. Passengers can fall
out of the vehicle if the door opens
accidentally , which could result in
death or serious injury. 
When the vehicle speed exceeds 20
km/h (12 mph), both doors and the fuel-
filler lid lock automatically. 
When the ignition is switched off, both
doors and the fuel-filler lid unlock
automatically.
These functions can also be disabled so
that they do not operate. Auto lock/unlock function setting
change using door-lock switch
The doors and the fuel-filler lid can be
set to lock or unlock automatically by
selecting any one of the functions from the
following table and using the driver's door-
lock switch on the interior door panel.
NOTE 
Function number 3 in the following
table is the factory setting for your
vehicle. 
There are only a total of six auto lock/
unlock settings available for automatic
transmission vehicles, and three for
manual transmission vehicles. Be sure
to press the unlock side of the driver's
door-lock switch the correct number of
times according to the selected function
number. If the switch is mistakenly
pressed seven times on an automatic
transmission vehicle or four times on a
manual transmission, the procedure will
be cancelled. If this occurs, start the
procedure from the beginning. Function
number Function *1
1 The auto door-lock function is
disabled.
2 Both the doors and the fuel-filler lid
lock automatically when the vehicle
speed is about 20 km/h (12 mph) or
more.
3 (Factory
Setting) Both the doors and the fuel-filler lid
lock automatically when the vehicle
speed is about 20 km/h (12 mph) or
more. Both the doors and the fuel-
filler lid unlock when the ignition is
switched from ON to Off.
4 (Automatic transmission vehicles
only)
When the ignition is switched ON and
the selector lever is shifted from park
(P) to any other gear position, both
the doors and the fuel-filler lid lock
automatically.
MX-5_8FR4-EA-16J_Edition1.indb 15 2016/08/11 20:28:30

3 –18 Before Driving
Doors and Locks Operation from outside
To lock the passenger door with the door-
lock knob from the outside, press the
door-lock knob to the lock position and
close the door (holding the door handle in
the open position is not required).
This does not operate the other door locks. Door-lock knob
NOTE
When locking the door this way: 
Be careful not to leave the key inside the
vehicle. 
The driver's door lock knob cannot be
used while the driver's door is open. Trunk Lid WARNING Never allow a person to ride in the
trunk:
Allowing a person to ride in the trunk
is dangerous. The person in the trunk
could be seriously injured or killed
during sudden braking or a collision.
Do not drive with the trunk lid open:
Exhaust gas in the cabin of a vehicle
is dangerous. An open trunk lid in a
moving vehicle will cause exhaust
gas to be drawn into the cabin. This
gas contains CO (carbon monoxide),
which is colorless, odorless, and highly
poisonous, and it can cause loss of
consciousness and death. Moreover, an
open trunk lid could cause occupants
to fall out in an accident.
CAUTION 
Before opening the trunk lid, remove
any snow and ice accumulation on it.
Otherwise, the trunk lid could close
under the weight of the snow and ice
resulting in injury. 
Be careful when opening/closing the
trunk lid during strong winds. If a strong
gust blows against the trunk lid, it could
close suddenly resulting in injury. 
Fully open the trunk lid and make sure
that it stays open. If the trunk lid is only
opened partially, it could slam shut
by vibration or wind gusts resulting in
injury. 
When loading or unloading luggage in
the trunk, turn off the engine. Otherwise,
you could get burned by the heat of the
exhaust gas.
MX-5_8FR4-EA-16J_Edition1.indb 18 2016/08/11 20:28:31

3 –19 Before Driving
Doors and Locks Opening and Closing the Trunk
LidOpening the trunk lid
Using the remote release button
Push the release button.
The remote release button function can
be disabled by locking the doors using
the transmitter, auxiliary key, or a request
switch to prevent an intruder in the vehicle
from opening the trunk.
To enable the remote release button
operation, unlock the doors by using the
transmitter, auxiliary key, or a request
switch, or switch the ignition ON.
NOTE
The remote release button cannot be
disabled by locking the doors using the
door-lock switch/door-lock knob.
Refer to Locking, Unlocking with Door-
Lock Switch on page 3-14 .
Refer to Locking, Unlocking with Door-
Lock Knob on page 3-17 . Using the electric trunk lid opener
(With the advanced keyless function)
A trunk lid can also be opened while the
key is being carried.
Press the electric trunk lid opener and raise
the trunk lid when the latch releases. Electric trunk lid
opener
NOTE 
When opening the trunk lid with the
doors locked, it may require a few
seconds for the trunk lid latch to release
after the electric trunk lid opener is
pressed. 
The trunk lid can be closed when the
doors are locked with the key left in the
vehicle. However, to prevent locking the
key in the vehicle, the trunk lid can be
opened by pressing the electric trunk lid
opener. If the trunk lid cannot be opened
despite doing this procedure, first push
the trunk lid completely closed, then
press the electric trunk lid opener to
fully open the trunk lid. 
If the vehicle battery is dead or there
is a malfunction in the electrical
system and the trunk lid cannot be
unlocked, the trunk lid can be opened by
performing the emergency procedure.
Refer to When Trunk Lid Cannot be
Opened on page 7-52 .
MX-5_8FR4-EA-16J_Edition1.indb 19 2016/08/11 20:28:31

3 –20 Before Driving
Doors and Locks
*Some models.Closing the trunk lid
Use both hands to push the trunk lid down
until the lock snaps shut. Do not slam it.
Pull up on the trunk lid to make sure it is
secure.
Inside Trunk Release
Lever *
Your vehicle is equipped with an inside
trunk release lever that provides a means
of escape for children and adults in the
event they become locked inside the trunk.
No matter how careful adults might be
with keys and locking their cars, parents
should be aware that children may be
tempted to play around vehicles and use
the trunk as a hiding place.
Adults are advised to familiarize
themselves with the operation and location
of the inside trunk release lever so that
all children can be told about it in an
appropriate way, keeping in mind that
most vehicles do not have such levers.
WARNING Close the trunk lid, do not allow children
to play inside the trunk:
Leaving the trunk lid open or leaving
children in the vehicle with the keys is
dangerous. Children could open the
trunk lid and climb inside resulting
in possible injury or death from heat
exposure.
Always keep the car from being a
tempting place to play by latching the
doors and the trunk, and keeping the
keys where children can not play with
them:
Leaving children or animals
unattended in a parked vehicle is
dangerous. Babies left sleeping and
children who lock themselves in cars or
trunks can die very quickly from heat
prostration. Do not leave your children
or pets alone in a car at any time. Do
not leave the car, the trunk unlocked.
MX-5_8FR4-EA-16J_Edition1.indb 20 2016/08/11 20:28:31

3 –47 Before Driving
Security System
Modification and Add-On
Equipment Mazda cannot guarantee the immobilizer
and the theft-deterrent systems' operation
if the system has been modified or if any
add-on equipment has been installed.
CAUTION To avoid damage to the vehicle, do
not modify the system or install any
add-on equipment to the immobilizer
and the theft-deterrent systems or the
vehicle.
Immobilizer System The immobilizer system allows the
engine to start only with a key the system
recognizes.
If someone attempts to start the engine
with an unrecognized key, the engine
will not start, thereby helping to prevent
vehicle theft.
If you have a problem with the
immobilizer system or the key, consult an
Authorized Mazda Dealer.
CAUTION 
Radio equipment like this is governed by
laws in the United States.
Changes or modifications not expressly
approved by the party responsible
for compliance could void the user's
authority to operate the equipment. 
To avoid damage to the key, do not: 
Drop the key. 
Get the key wet. 
Expose the key to any kind of
magnetic field. 
Expose the key to high temperatures
on places such as the dashboard or
hood, under direct sunlight. 
If the engine does not start with the
correct key, and the security indicator
light keeps illuminating or flashing, the
system may have a malfunction. Consult
an Authorized Mazda Dealer.
MX-5_8FR4-EA-16J_Edition1.indb 47 2016/08/11 20:28:37

3 –48 Before Driving
Security System NOTE 
The keys carry a unique electronic code.
For this reason, and to assure your
safety, obtaining a replacement key
requires some waiting time. They are
only available through an Authorized
Mazda Dealer. 
Always keep a spare key in case one
is lost. If a key is lost, consult an
Authorized Mazda Dealer as soon as
possible. 
If you lose a key, an Authorized Mazda
Dealer will reset the electronic codes of
your remaining keys and immobilizer
system. Bring all the remaining keys to
an Authorized Mazda Dealer to reset.
Starting the vehicle with a key that has
not been reset is not possible.
OperationNOTE 
The engine may not start and security
indicator light may illuminate or flash
if the key is placed in an area where it
is difficult for the system to detect the
signal, such as on the dashboard. Move
the key to a location within the signal
range, switch the ignition off, and then
restart the engine. 
Signals from a TV or radio station, or
from a transceiver or mobile telephone
could interfere with your immobilizer
system. If you are using the proper key
and the engine fails to start, check the
security indicator light. Arming
The system is armed when the ignition is
switched from ON to off.
The security indicator light in the
instrument cluster flashes every 2 seconds
until the system is disarmed.
Disarming
The system is disarmed when the
ignition is switched ON with the correct
programmed key. The security indicator
light illuminates for about 3 seconds and
then turns off. If the engine does not start
with the correct key, and the security
indicator light remains illuminated or
flashing, try the following:
Make sure the key is within the
operational range for signal transmission.
Switch the ignition off, and then restart the
engine. If the engine does not start after
3 or more tries, contact an Authorized
Mazda Dealer.
NOTE 
If the security indicator light flashes
continuously while you are driving,
do not shut off the engine. Go to an
Authorized Mazda Dealer and have it
checked. If the engine is shut off while
the indicator light is flashing, you will
not be able to restart it. 
Because the electronic codes are
reset when the immobilizer system
is repaired, the keys are needed.
Make sure to bring all the keys to an
Authorized Mazda Dealer so that they
can be programmed.
MX-5_8FR4-EA-16J_Edition1.indb 48 2016/08/11 20:28:38
