3 –23 Before Driving
Fuel and Emission Emission Control SystemThis vehicle is equipped with an emission control system (the c atalytic converter is
part of this system) that enables the vehicle to comply with existing exhaust emissions
requirements.
WARNING Never park over or near anything flammable:
Parking over or near anything flammable, such as dry grass, is dangerous. Even with the
engine turned off, the exhaust system remains very hot after normal use and could ignite
anything flammable. A resulting fire could cause serious injury or death.
CAUTION Ignoring the following precautions could cause lead to accumulate on the catalyst inside
the converter or cause the converter to get very hot. Either condition will damage the
converter and cause poor performance. 
USE ONLY UNLEADED FUEL. 
Do not drive your Mazda with any sign of engine malfunction. 
Do not coast with the ignition switched off. 
Do not descend steep grades in gear with the ignition switched off. 
Do not operate the engine at high idle for more than 2 minutes. 
Do not tamper with the emission control system. All inspections and adjustments
must be made by a qualified technician. 
Do not push-start or pull-start your vehicle.
NOTE 
Under U.S. federal law, any modification to the original-equipment emission control
system before the first sale and registration of a vehicle is subject to penalties. In some
states, such modification made on a used vehicle is also subject to penalties.
While the engine is off, the sound of a valve opening and closing can be heard at the rear
of the vehicle, however this does not indicate an abnormality. The vehicle has a self-
checking device and it operates while the engine is off.
MX-5_8FR4-EA-16J_Edition1.indb 23 2016/08/11 20:28:32

3 –24 Before Driving
Fuel and Emission Engine Exhaust (Carbon monoxide)
WARNINGDo not drive your vehicle if you smell exhaust gas inside the vehicle:
Engine exhaust gas is dangerous. This gas contains carbon monoxide (CO), which is
colorless, odorless, and poisonous. When inhaled, it can cause loss of consciousness and
death. If you smell exhaust gas inside the vehicle, keep all windows fully open and contact
an Authorized Mazda Dealer immediately.
Do not run the engine when inside an enclosed area:
Running the engine inside an enclosed area, such as a garage, is dangerous. Exhaust
gas, which contains poisonous carbon monoxide, could easily enter the cabin. Loss of
consciousness or even death could occur.
Open the windows or adjust the heating or cooling system to draw fresh air when
idling the engine:
Exhaust gas is dangerous. When the vehicle is stopped with the windows closed and
the engine running for a long time even in an open area, exhaust gas, which contains
poisonous carbon monoxide, could enter the cabin. Loss of consciousness or even death
could occur.
Clear snow from underneath and around your vehicle, particularly the tail pipe, before
starting the engine:
Running the engine when a vehicle is stopped in deep snow is dangerous. The exhaust
pipe could be blocked by the snow, allowing exhaust gas to enter the cabin. Because
exhaust gas contains poisonous carbon monoxide, it could cause loss of consciousness or
even death to occupants in the cabin.
MX-5_8FR4-EA-16J_Edition1.indb 24 2016/08/11 20:28:32

3 –25 Before Driving
Fuel and Emission
Fuel-Filler Lid and Cap WARNING When removing the fuel-filler cap,
loosen the cap slightly and wait for any
hissing to stop, then remove it:
Fuel spray is dangerous. Fuel can
burn skin and eyes and cause illness
if ingested. Fuel spray is released
when there is pressure in the fuel tank
and the fuel-filler cap is removed too
quickly.
Before refueling, stop the engine, and
always keep sparks and flames away
from the filler neck:
Fuel vapor is dangerous. It could be
ignited by sparks or flames causing
serious burns and injuries.
Additionally, use of the incorrect fuel-
filler cap or not using a fuel-filler cap
may result in a fuel leak, which could
result in serious burns or death in an
accident.
Do not continue refueling after the fuel
pump nozzle shuts off automatically:
Continuing to add fuel after the
fuel pump nozzle has shut off
automatically is dangerous because
overfilling the fuel tank may cause
fuel overflow or leakage. Fuel overflow
and leakage could damage the vehicle
and if the fuel ignites it could cause a
fire and explosion resulting in serious
injury or death. CAUTION Always use only a genuine Mazda fuel-
filler cap or an approved equivalent,
available at an Authorized Mazda
Dealer. The wrong cap can result in
a serious malfunction of the fuel and
emission control systems. It may also
cause the check engine light in the
instrument cluster to illuminate.
Fuel-Filler Lid When the fuel-filler lid end is pressed with
the doors unlocked, the fuel-filler lid rises.
The fuel-filler lid operates in conjunction
with the door locking/unlocking
mechanism.
Make sure to lock both the doors when
leaving the vehicle.
Refer to Door Locks on page 3-10 .
To close, press the fuel-filler lid until a
click sound is heard.
NOTE
Lock the doors after closing the fuel lid.
If the fuel lid is closed after locking the
doors, the fuel lid cannot be locked.
MX-5_8FR4-EA-16J_Edition1.indb 25 2016/08/11 20:28:33

3 –26 Before Driving
Fuel and Emission Fuel-Filler CapTo remove the fuel-filler cap, turn it
counterclockwise.
Attach the removed cap to the inner side
of the fuel lid.
To close the fuel-filler cap, turn it
clockwise until a click is heard. Open
Close
CAUTION If the check fuel cap warning light
illuminates, the fuel-filler cap may not
be properly installed. If the warning
light illuminates, park your vehicle
safely off the right-of-way, remove the
fuel-filler cap and reinstall it correctly.
After the cap has been correctly
installed, the fuel cap warning light
may continue to illuminate until a
number of driving cycles have been
completed. A drive cycle consists of
starting the engine (after four or more
hours with the engine off ) and driving
the vehicle on city and highway roads.
Continuing to drive with the check
fuel cap warning light illuminated
could cause the check engine light to
illuminate as well.
MX-5_8FR4-EA-16J_Edition1.indb 26 2016/08/11 20:28:33

3 –33 Before Driving
WindowsEngine-off power window operation
The power window can be operated for
about 40 seconds after the ignition is
switched from ON to off with both doors
closed. If any door is opened, the power
window will stop operating.
NOTE
For engine-off operation of the power
window, the switch must be held up firmly
throughout window closure because the
auto-closing function will be inoperable.
Power Window Lock SwitchThis feature prevents the passenger's
power window from operating. Keep
this switch in the locked position while
children are in the vehicle.
Locked position (button depressed):
Only the driver's power window can be
operated.
Unlocked position (button not
depressed):
Both power windows on each door can be
operated. Lock position
Unlock position
NOTE
When the power window lock switch is
in the locked position, the light on the
passenger power window switch turns off.
The light may be difficult to see depending
on the surrounding brightness.
MX-5_8FR4-EA-16J_Edition1.indb 33 2016/08/11 20:28:35

3 –36 Before Driving
Convertible Top (Soft Top) Lowering the Convertible Top
CAUTION Do not sit on the folded convertible
top. Otherwise, the convertible top
could be damaged or you may fall off
and be injured.
1. Make sure the parking brake is applied.
2. If the engine is running, turn it off.
3. Make sure there are no objects which
have been placed in the area where the
convertible top is to be retracted.
4. With the lock release button depressed
forward, pull back the top latch lever to
unlock it.

Top latchLock release button
5. Remove the striker from the anchor.

Anchor
Striker NOTE
If the power windows do not go down
automatically, fully open the windows or
open the doors.
6. Standing outside of the vehicle, hold
the convertible top along the front edge
and pull it toward the vehicle rear.
Front edge
NOTE
To lower the convertible top from inside
the vehicle, use the convertible top's
handles.
Convertible top's handles
MX-5_8FR4-EA-16J_Edition1.indb 36 2016/08/11 20:28:35

3 –37 Before Driving
Convertible Top (Soft Top)7. Move the convertible top rearward and
fold it while pressing the rear glass
lightly with your hand.

8. With the back end of the convertible
top pressed, press the front end until a
latch sound is heard.
Lightly rock the retracted convertible
top to make sure it is securely locked.

Raising the Convertible Top
1. Make sure the parking brake is applied.
2. If the engine is running, turn it off. 3. Pull up the unlock lever to disengage
the lock.
Unlock Le ve r
4. Standing outside of the vehicle, hold
the convertible top along the front edge
and pull it towards the vehicle front.
Front edge
MX-5_8FR4-EA-16J_Edition1.indb 37 2016/08/11 20:28:35

3 –45 Before Driving
Convertible Top (Retractable Fastback) Opening the Roof1. Park on a hard, level surface off the
right-of-way and firmly set the parking
brake.
2. Put a vehicle with an automatic
transmission in Park (P), a manual
transmission in Neutral.
3. Apply the parking brake with the brake
pedal depressed.
4. Start the Engine.
NOTE
Do not open/close the roof with the engine
stopped. Otherwise the vehicle's battery
power could be depleted.
5. Continue pressing the retractable
fastback switch in the open direction
until the roof is completely open. NOTE 
If the retractable fastback switch is
pressed in the open direction, a warning
beep sounds. 
If the windows are closed, the windows
automatically open partially when the
rear roof opens.
After the rear roof is opened and
the retractable fastback switch is
continuously pressed in the open
direction, the power windows close
completely.
Once you remove your hand from the
switch, the power windows do not
close even if it is operated again. If this
happens, completely close the power
windows using the power window
switch. 
The roof keeps opening and the
operation indicator light flashes while
the retractable fastback switch is
pressed in the open direction. 
If the switch is released while the roof is
opening, the roof stops opening. If the
switch is pressed in the open direction
again, the roof resumes opening. 
When the operation is finished, a beep
sound is heard and the operation
indicator light turns off. 
When the roof is half-open, the front
roof resumes opening after the rear roof
is completely open.
Closing the Roof
1. Park on a hard, level surface off the
right-of-way and firmly set the parking
brake.
2. Put a vehicle with an automatic
transmission in Park (P), a manual
transmission in Neutral.
3. Apply the parking brake with the brake
pedal depressed.
4. Start the Engine.
MX-5_8FR4-EA-16J_Edition1.indb 45 2016/08/11 20:28:37
