2017 MAZDA MX5 MIATA check engine

4 –28 When Driving
Instrument Cluster and Display
*Some models.Signal Warning Lights Page
Seat Belt Warning Light 7-41*
Door-Ajar Warning Light 7-41*
Door-Ajar Warning Indication 7-41*
Trunk lid-Ajar Warning Indication 7-41*
Low Fuel Warning Indication/Warning Light 7-41
Check Fuel Cap Warning Light *1
7-41*
Low Washer Fluid Level Warning Indication/Warning Light 7-41
*1 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or
when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is applied.
Indication/Indicator Lights
These lights turn on or flash to notify the user of the system o peration status or a system
malfunction. Signal Indicator Lights Page*
Passenger Air Bag Deactivation Indicator Light *1
2-37
(White/Green) *
KEY Indicator/Indicator Light 3-8
MX-5_8FR4-EA-16J_Edition1.indb 28 2016/08/11 20:28:48

4 –30 When Driving
Instrument Cluster and Display
*Some models.Signal Indicator Lights Page
(Green) *
High Beam Control System (HBC) Indicator Light 4-78*
Blind Spot Monitoring (BSM) OFF Indicator Light *1
4-90*
Lane Departure Warning System (LDWS) OFF Indicator
Light *1
4-82
(White/Amber) Cruise Main Indication/Indicator Light 4-101
(Green) Cruise Set Indication/Indicator Light 4-101
*1 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or
when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an
Authorized Mazda Dealer.
Wrench Indication/Indicator
Light *
Type A instrument cluster
Perform maintenance in accordance with
the message.
Type B instrument cluster
When the ignition is switched ON, the
wrench indicator light is illuminated and
then turns off after a few seconds.
The wrench indicator light is illuminated
when the preset maintenance period
arrives. Verify the content and perform
maintenance.
Refer to Maintenance Monitor on page
6-20 . Low Engine Coolant Temperature
Indicator Light (Blue)
The light illuminates continuously when
the engine coolant temperature is low and
turns off after the engine is warm.
If the low engine coolant temperature
indicator light remains illuminated after
the engine has been sufficiently warmed
up, the temperature sensor could have
a malfunction. Consult an Authorized
Mazda Dealer.
MX-5_8FR4-EA-16J_Edition1.indb 30 2016/08/11 20:28:49

4 –37 When Driving
TransmissionTake the vehicle to an Authorized Mazda
Dealer to have the system checked.
Manual Shift ModeThe manual shift mode gives you the feel
of driving a manual transmission vehicle
by allowing you to operate the selector
lever manually. This allows you to control
engine rpm and torque to the drive wheels
much like a manual transmission when
more control is desired.
To change to manual shift mode, shift the
lever from D to M.
NOTE
Changing to manual shift mode while
driving will not damage the transmission.
To return to automatic shift mode, shift the
lever from M to D.
NOTE 
If you change to manual shift mode
when the vehicle is stopped, the gear
will shift to M1. 
If you change to manual shift mode
without depressing the accelerator
pedal when driving in D range, 5th
gear/6th gear, the gear will shift to M4/
M5. Indicators
Manual shift mode indication
In manual shift mode, the “M” of the shift
position indication in the instrument panel
illuminates.
Gear position indication
The numeral for the selected gear
illuminates. Manual shift mode indication
Gear position indication
NOTE
If the gears cannot be shifted down when
driving at higher speeds, the gear position
indication will flash twice to signal that
the gears cannot be shifted down (to
protect the transmission).
MX-5_8FR4-EA-16J_Edition1.indb 37 2016/08/11 20:28:51

5 –2 Interior Features
Climate Control System
Operating Tips 
Operate the climate control system with
the engine running. 
To prevent the battery from being
discharged, do not leave the fan control
dial on for a long period of time with the
ignition switched ON when the engine is
not running. 
Clear all obstructions such as leaves,
snow and ice from the hood and the air
inlet in the cowl grille to improve the
system efficiency. 
Use the climate control system to defog
the windows and dehumidify the air. 
The recirculate mode should be used
when driving through tunnels or while in
a traffic jam, or when you would like to
shut off outside air for quick cooling of
the interior. 
Use the outside air position for
ventilation or windshield defrosting. 
If the vehicle has been parked in direct
sunlight during hot weather, open the
windows to let warm air escape, then
run the climate control system. 
Run the air conditioner about 10 minutes
at least once a month to keep internal
parts lubricated. 
Have the air conditioner checked before
the weather gets hot. Lack of refrigerant
may make the air conditioner less
efficient.
The refrigerant specifications are
indicated on a label attached to the
inside of the engine compartment. Check
the label before refilling the refrigerant.
If the wrong type of refrigerant is used,
it could result in a serious malfunction
of the air conditioner.
For details, consult an Authorized
Mazda Dealer. Label
MX-5_8FR4-EA-16J_Edition1.indb 2 2016/08/11 20:29:06

5 –129 Interior Features
Bluetooth ®
TroubleshootingMazda Bluetooth ®
Hands-Free Customer Service
If you have any problems with Bluetooth ®
, contact our toll-free customer service center.
U.S.A.
Phone: 800-430-0153 (Toll-free)
Web: www.mazdausa.com/mazdaconnect 
Canada
Phone: 800-430-0153 (Toll-free)
Web: www.mazdahandsfree.ca 
Mexico
Center of Attention to Client (CAC)
Phone: 01-800-01-MAZDA (Toll-free)
Web: www.mazdamexico.com.mx
Bluetooth ®
Device pairing, connection problems Symptom Cause Solution method
Unable to perform pairing — First make sure the device is
compatible with the Bluetooth ®

unit, and then check whether the
Bluetooth ®
function and the Find
Mode/Visible setting *1
on the device
are turned on. If pairing is still
not possible after this, contact an
Authorized Mazda Dealer or Mazda
Bluetooth ®
Hands-Free Customer
Service.
Pairing cannot be performed again The pairing information paired to
the Bluetooth ®
unit or device is not
recognized correctly. Perform pairing using the following
procedure. 
Clear “Mazda” stored in the device. 
Perform pairing again.
Unable to perform pairing
The Bluetooth ®
function and the
Find Mode/Visible setting *1
on the
device may turn off automatically
after a period of time has elapsed
depending on the device. Check whether the Bluetooth ®

function and the Find Mode/Visible
setting *1
on the device are turned on
and pairing or reconnect.Does not connect automatically
when starting the engine
Automatically connects, but then
disconnects suddenly
Disconnects intermittently The device is in a location in which
radio wave interference can occur
easily, such as in a bag or in a rear
pocket of a pair of pants. Move the device to a location in
which radio wave interference is less
likely to occur.
Does not connect automatically
when starting the engine The pairing information is updated
when the device OS is updated. Perform pairing again.
*1 Setting which detects the existence of a device external to the Bluetooth ®
unit
MX-5_8FR4-EA-16J_Edition1.indb 129 2016/08/11 20:29:34

6 –6 Maintenance and Care
Scheduled Maintenance Chart symbols:
I: Inspect: Inspect and clean, repair, adjust, fill up, or replace if necessary.
T: Tighten
Remarks:
*1 The engine oil and filter must be changed at least once a year o r within 16,000 km (10,000 miles) since last
engine oil and filter change. The system must be reset whenever replacing the engine oil regardless of the
message/wrench indicator light display.
*2 Use of FL-22 is recommended when replacing engine coolant. Usin g engine coolant other than FL-22 may
cause serious damage to the engine and cooling system.
*3 According to state/provincial and federal regulations, failure to perform maintenance on these items will not
void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the
recommended time or mileage/kilometer period to ensure long-term reliability.
*4 The Tire Pressure Monitoring System (TPMS) initialization must be performed so that the system operates
normally (if equipped).
*5 If this component has been submerged in water, the oil should be replaced.
*6 Check the tire repair fluid expiration date every year when perf orming the periodic maintenance. Replace the
tire repair fluid bottle with new one before the expiration date .
MX-5_8FR4-EA-16J_Edition1.indb 6 2016/08/11 20:29:37

6 –8 Maintenance and Care
Scheduled Maintenance Remarks:
*1 Use of FL-22 is recommended when replacing engine coolant. Usin g engine coolant other than FL-22 may
cause serious damage to the engine and cooling system.
*2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not
void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the
recommended time or mileage/kilometer period to ensure long-term reliability.
*3 To equalize tread wear for maintaining good performance in handling and braking, rotate the tires every 12,000
km (7,500 miles). However Mazda recommends to rotate every 8,000 km (5,000 miles) to help increase tire life
and distribute wear more evenly.
*4 The Tire Pressure Monitoring System (TPMS) initialization must be performed so that the system operates
normally (if equipped).
*5 If this component has been submerged in water, the oil should be replaced.
*6 Check the tire repair fluid expiration date every year when perf orming the periodic maintenance. Replace the
tire repair fluid bottle with new one before the expiration date .
MX-5_8FR4-EA-16J_Edition1.indb 8 2016/08/11 20:29:38

6 –10 Maintenance and Care
Scheduled Maintenance Maintenance Interval Number of months or kilometers (miles), whichever comes first.
Months 6 12 18 24 30 36 42 48 54 60 66 72
×1000 km 8 16 24 32 40 48 56 64 72 80 88 96
×1000 miles 5 10 15 20 25 30 35 40 45 50 55 60
All locks and hinges L L L L L L L L L L L L
Washer fluid level I I I I I I I I I I I I
Emergency flat tire repair kit (if installed) *7
Inspect annually.
Chart symbols:
I: Inspect: Inspect and clean, repair, adjust, fill up, or replace if necessary.
R: Replace
L: Lubricate
T: Tighten
Remarks:
*1 Engine oil flexible maintenance is available for U.S.A. and Puer to Rico residents whose vehicle is operated
mainly where none of the following conditions apply. 
Extended periods of idling or low-speed operation such as polic e car, taxi or driving school car
Driving in dusty conditions
If any do apply, follow fixed maintenance.
The engine oil and filter must be changed at least once a year o r within 16,000 km (10,000 miles) since last
engine oil and filter change. Reset the engine oil data whenever replacing the engine oil regardless of the
message/wrench indicator light display.
*2 Use of FL-22 is recommended when replacing engine coolant. Usin g engine coolant other than FL-22 may
cause serious damage to the engine and cooling system.
*3 If the vehicle is operated in very dusty or sandy areas, clean and if necessary, replace the air filter more often
than the recommended intervals.
*4 According to state/provincial and federal regulations, failure to perform maintenance on these items will not
void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the
recommended time or mileage/kilometer period to ensure long-term reliability.
*5 The Tire Pressure Monitoring System (TPMS) initialization must be performed so that the system operates
normally (if equipped).
*6 If this component has been submerged in water, the oil should be replaced.
*7 Check the tire repair fluid expiration date every year when perf orming the periodic maintenance. Replace the
tire repair fluid bottle with new one before the expiration date .
MX-5_8FR4-EA-16J_Edition1.indb 10 2016/08/11 20:29:38
