2017 Lexus IS350 reset

5
OverviewInstrument Panel
Windshield wiper and washer switch P.20
Multi-information display P.12
Turn signal lever
Headlight switch P.11
P.17
Inside lock buttons*
Driving position memory
switches
∗*
See P.8
See P.7
Window lock switch
*
Outside rear view
mirror switches
*
Power window switches*
Door lock switches*
Tire pressure warn ing reset switch P.31

7
OverviewInstrument Panel
BSM (Blind Spot Monitor) main switch∗ P.30
Odometer/trip meter and trip
meter reset button
P.15
Instrument panel light control
switches
*
Windshield wiper
de-icer switch
∗*
Rear sunshade
switch
∗*
Intuitive parking assist
switch
∗ P.29
Automatic high beam
switch
P.18
ASC (Active Sound Control) switch∗*

12
Multi-information Display
■Except F SPORT modelsMenu icon display area ( →P. 16)
Displays the following items.
When a menu icon is not selected, the outside temperature and clock are displayed.
•Menu icons
• Outside temperature
•Clock
Content display area
A variety of information can be displayed by selecting a menu icon. Additionally, warn-
ing or advice pop-up displays will be displayed in some situations.
• Menu icon content
• Warning message
Indicator/shift position display area
Displays the following items:
•Indicators
• Shift position display
Odometer/trip meter display area
Displays the following items:
• Odometer/trip meter
• Distance until next engine oil change (if equipped)
Meter control switches ( →P. 15)
Odometer/trip meter and tr ip meter reset button (→P. 15)
The multi-information display presents the driv er with a variety of driving-related data,
such as the current outside temperature. Th e multi-information display can also be used
to change the display settings and other settings.
1
2
3
4
5
6

14
Clock
Outside temperature
Indicator/shift position display area
Displays the following items:
•Indicators
• Shift position display
Content display area
Main meter in center position:
Displays various drive information on the main meter. Additionally, warning or advice
pop-up displays will be disp layed in some situations.
• Drive information
• Warning message
Main meter moved to the right:
A variety of information can be displayed by selecting a menu icon. Additionally, warn-
ing or advice pop-up displays will be displayed in some situations.
• Menu icon content
• Warning message
Odometer/trip meter display area
Displays the following items:
• Odometer/trip meter
• Distance until next engine oil change (if equipped)
Menu icons ( →P. 16)
Meter control switches ( →P. 15)
Odometer/trip meter and tr ip meter reset button (→P. 15)1
2
3
4
5
6
7
8

15
■Using the multi-information display
■Using the content display area
The content display area is operated using the meter control switches.
:Select menu icons
:Change displayed content,
scroll up/down the screen
and move the cursor
Press: Enter/Set
Press and hold: Reset
Return to the previous screen
Pressing and holding the switch will
display the first screen of the selected
menu icon.
Except F SPORT models Press: Display the top screen
Press and hold: Register current
screen as the top screen
F SPORT models Move the main meter
When the main meter moves to the
right, the menu icons will be displayed
on the left side.
■Using the odometer/trip meter display area
Items in this area are operated using the odometer/trip meter and trip meter reset button.
Press: Change displayed itemEach time the button is pressed, the dis-
played item will be changed.
Press and hold: Reset Display the desired trip meter and press
and hold the button to reset the trip
meter.
1
2
3
4
4
■ Move the main meter (F SPORT models)
Moves between center and right-side positions.

26
■Adjusting the set speed
Increases the speed
Decreases the speed
Fine adjustment: Momentarily move the
lever in the desired direction.
Large adjustment: Hold the lever up or
down to change the speed, and release
when the desired speed is reached.
■ Changing the vehicle-to-vehicle distan ce (vehicle-to-vehicle distance con-
trol mode)
Pressing the button changes the vehicle-to-
vehicle distance as follows:
Long
Medium
Short
The vehicle-to-vehicle distance is set
automatically to long mode when the
engine switch is turned to IGNITION
ON mode.
If a vehicle is running ahead of you, the
preceding vehicle mark will also be dis-
played.
1
2
Preceding vehicle mark
1
2
3
The vehicle-to-vehicle distance control mode maintains the preset cruising speed as long
as no vehicle is detected ahead.

31
Tire Pressure Warning System
■The tire inflation pressure display function
The tire pressure detected by the tire pres-
sure warning system can be displayed on
the multi-information display.
■ Initializing the tire pressure warning system
Press and hold the ti re pressure warning
reset switch until the tire pressure warning
light blinks slowly 3 times.
Your vehicle is equipped with a tire pressure warning system that uses tire pressure warn-
ing valves and transmitters to detect low ti re inflation pressure before serious problems
arise.

41
■Basic operation
Display the audio source selection
screen
Display the sound setting screen
Adjust volume
Turn the audio system on/off
Select a radio/media mode
Play/Pause
Turn mute on/off
■ Radio
Display the cache radio operation but-
tons
Display the radio preset buttons
Scan for receivable stations/channels
Select to store artist and song title
information
Display a list of receivable stations
Select a preset station/channel
Seek for a station/channel
Step up/down frequencies/channels
Move up/down the list
■Entering station/channel presets
Select the desired stat ion/channel by using the tune, th e seek or the scan function.
Select “Presets”.
Select one of the sc reen buttons and hold it until a beep is heard, indicating that the sta-
tion/channel has been set.
1
2
3
4
5
1
2
3
4
5
6
7
1
2
3
