2017 Lexus IS350 towing

3
1
9 8
7 5 4
3
2
10
IS350/300/200t_U (OM53D76U)
6
4-1. Before driving Driving the vehicle ..................... 158
Cargo and luggage ....................166
Vehicle load limits .......................169
Trailer towing ................................170
Dinghy towing ................................ 171
4-2. Driving procedures Engine (ign ition) switch ............. 172
Automatic transmission ............ 177
Turn signal lever .......................... 184
Parking brake ............................... 186
ASC (Active Sound Control) .........187
4-3. Operating the lights and wipers
Headlight switch ......................... 188
Automatic High Beam...............192
Windshield wipers and washer ...........................................196
4-4. Refueling Opening the fuel tank cap ..... 203 4-5. Using the driving support
systems
Lexus Safety System+ .............. 207
PCS (Pre-Collision System) ........... 214
LDA (Lane Departure Alert with steering co ntrol) .............227
Dynamic radar cruise control ......................................... 236
Intuitive parking assist.............. 248
Lexus parking assist monitor........................................ 257
BSM (Blind Spot Monitor) ............. 273
• BSM function.......................... 277
• RCTA function......................280
Driving mode select switch ... 285
Driving assist systems .............. 289
4-6. Driving tips Winter driving tips..................... 294
4Driving

16Pictorial index
IS350/300/200t_U (OM53D76U)
■Instrument panel
Engine switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P . 172
Starting the engine/changing the modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 172
Emergency stop of the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 507
When the engine will not start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 557
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 54 1
Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 177
Changing the shift position. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 177
Precautions against towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 508
When the shift lever does not move . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 182
Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 79
Reading the meters/adjusting the instrument panel light . . . . . . . . . . . . . . . . . P. 79
Warning lights/indicator lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 74
When the warning lights come on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 516
1
2
3

157
Driving4
IS350/300/200t_U (OM53D76U)
4-1. Before drivingDriving the vehicle ......................158
Cargo and luggage .................... 166
Vehicle load limits ....................... 169
Trailer towing ................................ 170
Dinghy towing ................................ 171
4-2. Driving procedures Engine (ignition) switch ............ 172
Automatic transmission.............177
Turn signal lever........................... 184
Parking brake ............................... 186
ASC (Active Sound Control)......... 187
4-3. Operating the lights and wipers
Headlight switch ..........................188
Automatic High Beam .............. 192
Windshield wipers and washer........................................... 196
4-4. Refueling Opening the fuel tank cap..... 203 4-5. Using the driving
support systems
Lexus Safety System+ .............. 207
PCS (Pre-Collision System) ...........214
LDA (Lane Departure Alert with steering
control)........................................ 227
Dynamic radar cruise control ......................................... 236
Intuitive parking assist .............. 248
Lexus parking assist monitor ........................................ 257
BSM (Blind Spot Monitor) ..... 273 • BSM function ..........................277
• RCTA function......................280
Driving mode select switch ...........................................285
Driving assist systems ..............289
4-6. Driving tips Winter driving tips ..................... 294

1604-1. Before driving
IS350/300/200t_U (OM53D76U)
■Drum-in-disc type parking brake system
Your vehicle has a drum-in-disc type parking brake system. This type of brake system
needs bedding-down of the brake shoes peri odically or whenever the parking brake
shoes and/or drum are replaced. Have your Lexus dealer perform the bedding down
operation.
■Operating your vehicle in a foreign country
Comply with the relevant vehicle registration laws and confirm the availability of the cor-
rect fuel. ( →P. 587)
■Idling time before engine stop (IS200t)
To prevent damage to the turbocharger, allow the engine to idle immediately after high-
load driving.
Driving conditionIdling time
Normal city driving or high-spe ed driving (at the highway speed
limit or recommended speed)
Not necessary
Steep hill driving, continuous driv ing (race track driving etc.), or
towing a trailer or another vehicle (vehicles with towing pack-
age)
Approximately 1 minute

1664-1. Before driving
IS350/300/200t_U (OM53D76U)
Cargo capacity depends on the total weight of the occupants.
(Cargo capacity) = (Total load capac ity) — (Total weight of occupants)
Steps for Determining Correct Load Limit —
(1) Locate the statement “The combined weight of occupants and cargo should
never exceed XXX kg or XXX lbs. ” on your vehicle’s placard.
(2) Determine the combined weight of th e driver and passengers that will be rid-
ing in your vehicle.
(3) Subtract the combined weight of th e driver and passengers from XXX kg or
XXX lbs.
(4) The resulting figure equals the ava ilable amount of cargo and luggage load
capacity.
For example, if the “XXX” amount equals 1400 lbs. and there will be five 150
lb passengers in your vehicle, the amou nt of available cargo and luggage load
capacity is 650 lbs. (1400 − 750 (5 × 150) = 650 lbs.)
(5) Determine the combined weight of luggage and cargo being loaded on the
vehicle. That weight may not safely exceed the available cargo and luggage
load capacity calculated in Step 4.
(6) If your vehicle will be towing a trailer, load from your trailer will be transferred
to your vehicle. Consult this manual to determine how this reduces the avail-
able cargo and luggage load capacity of your vehicle.
(→ P. 169)
Lexus does not recommend towing a trailer with your vehicle. Your vehicle is not
designed for trailer towing.
Cargo and luggage
Take notice of the following informat ion about storage precautions, cargo
capacity and load:
Capacity and distribution

1694-1. Before driving
4
Driving
IS350/300/200t_U (OM53D76U)
◆Total load capacity (vehicle capacity weight): (→P. 574)
Total load capacity means the combined weight of occupants, cargo and lug-
gage.
◆Seating capacity: 5 occupants (Front 2, Rear 3)
Seating capacity means the maximum number of occupants whose estimated
average weight is 150 lb. (68 kg) per person.
◆Towing capacity
Lexus does not recommend towing a trailer with your vehicle.
◆Cargo capacity
Cargo capacity may increase or decrease depending on the weight and the
number of occupants.
■Total load capacity and seating capacity
These details are also described on the tire and loading information label. (→P. 486)
Vehicle load limits
Vehicle load limits include total load capacity, seating capacity, towing capac-
ity and cargo capacity.
WARNING
■Overloading the vehicle
Do not overload the vehicle.
It may not only cause damage to the tires, but also degrade steering and braking ability,
resulting in an accident.

1704-1. Before driving
IS350/300/200t_U (OM53D76U)
Trailer towing
Lexus does not recommend towing a trailer with your vehicle. Lexus also does
not recommend the installation of a tow hitch or the use of a tow hitch carrier
for a wheelchair, scooter, bicycle, etc. Your vehicle is not designed for trailer
towing or for the use of tow hitch mounted carriers.

1714-1. Before driving
4
Driving
IS350/300/200t_U (OM53D76U)
Dinghy towing
Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground)
behind a motor home.
NOTICE
■To avoid serious damage to your vehicle
Do not tow your vehicle with the four wheels on the ground.
