551-1. For safe use
1
For safety and security
IS350/300/200t_U (OM53D76U)
WARNING
■Child restraint precautions
●For effective protection in automobile accidents and sudden stops, a child must be
properly restrained, using a seat belt or child restraint system depending on the age
and size of the child. Holding a child in your arms is not a su bstitute for a child restraint
system. In an accident, the child can be crushed against the windshield, or between
you and the vehicle’s interior. This may cause death or serious injury to the child in the
event of a sudden stop, sudden swerve or an accident.
●Lexus strongly urges the use of a proper ch ild restraint system that conforms to the
size of the child, installed on the rear seat. According to accident statistics, the child is
safer when properly restrained in th e rear seat than in the front seat.
●Never install a rear-facing child restraint sy stem on the front passenger seat even if
the “AIR BAG OFF” indicator light is illuminated.
In the event of an accident, the force of the rapid inflation of the front passenger air-
bag can cause death or serious injury to the child if the rear-facing child restraint sys-
tem is installed on th e front passenger seat.
●A forward-facing child restraint system ma y be installed on the front passenger seat
only when it is unavoidable. A child restraint system that requires a top tether strap
should not be used in the front passenger seat since there is no top tether strap
anchor for the front passenger seat. Adjust the seatback as upright as possible and
always move the seat as far back as possible even if the “AIR BAG OFF” indicator
light is illuminated, because the front passenger airbag co uld inflate with considerable
speed and force. Otherwise, the chil d may be killed or seriously injured.
●Do not use the seat belt extender when inst alling a child restraint system on the front
or rear passenger seat. If in stalling a child restraint system with the seat belt extender
connected to the seat belt, th e seat belt will not securely hold the child restraint sys-
tem, which could cause death or serious injury to the child or other passengers in the
event of a sudden stop, sudden swerve or accident.
●Do not allow the child to lean his/her head or any part of his/her body against the
door or the area of the seat, front, center an d rear pillars or roof side rails from which
the SRS side airbags or SRS cu rtain shield airbags deploy even if the child is seated in
the child restraint system. It is dangerous if the SRS side airbags and curtain shield air-
bags inflate, and the impact could caus e death or serious injury to the child.
●Make sure you have complied with all insta llation instructions provided by the child
restraint manufacturer and that the system is properly secured. If it is not secured
properly, it may cause death or serious inju ry to the child in the event of a sudden
stop, sudden swerve or an accident.

651-1. For safe use
1
For safety and security
IS350/300/200t_U (OM53D76U)
WARNING
■When installing a booster seat
To prevent the belt from going into ALR lock mode, do not fully extend the shoulder
belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort to
the child. (→P. 32)
■When installing a child restraint system
Follow the directions given in the child rest raint system installation manual and fix the
child restraint system securely in place.
If the child restraint system is not correctly fixed in place, the child or other passengers
may be seriously injured or ev en killed in the event of a sudden braking or an accident.
●If the driver’s seat interferes with the child
restraint system and prevents it from being
attached correctly, attach the child restraint
system to the right-hand rear seat.
●Adjust the front passenger seat so that it does
not interfere with the child restraint system.
●Only put a forward-faci ng child restraint sys-
tem on the front seat when unavoidable.
When installing a forward-facing child
restraint system on the front passenger seat,
move the seat as far back as possible even if
the “AIR BAG OFF” indicator light is illumi-
nated. Failure to do so may result in death or
serious injury if the airbags deploy (inflate).

671-1. For safe use
1
For safety and security
IS350/300/200t_U (OM53D76U)
Exhaust gas precautions
Harmful substance to the human body is included in exhaust gases if inhaled.
WARNING
Exhaust gases include harmful carbon monoxide (CO), which is colorless and odorless.
Observe the following precautions.
Failure to do so may cause exhaust gases enter the vehicle and may lead to an accident
caused by light-headedness, or may lead to death or a serious health hazard.
■Important points while driving
●Keep the trunk lid closed.
●If you smell exhaust gases in the vehicle even when the trunk lid is closed, open the
windows and have the vehicle inspected at your Lexus dealer as soon as possible.
■When parking
●If the vehicle is in a poorly ventilated area or a closed area, such as a garage, stop the
engine.
●Do not leave the vehicle with the engine on for a long time.
If such a situation cannot be avoided, park the vehicle in an open space and ensure
that exhaust fumes do not enter the vehicle interior.
●Do not leave the engine running in an area with snow build-up, or where it is snowing.
If snowbanks build up around the vehicle while the engine is running, exhaust gases
may collect and enter the vehicle.
■Exhaust pipe
The exhaust system needs to be checked periodically. If there is a hole or crack caused
by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle
inspected and repaired by your Lexus dealer.

73
Instrument cluster2
IS350/300/200t_U (OM53D76U)
2. Instrument clusterWarning lights and indicators ....................................... 74
Gauges and meters ..................... 79
Multi-information display .......... 84
Fuel consumption information ................................... 99

74
IS350/300/200t_U (OM53D76U)2. Instrument cluster
Except F SPORT models
F SPORT models
The units used on the meters and some indi
cators may differ depending on the target
region.
Warning lights and indicators
The warning lights and indicators on th e instrument cluster and center panel
inform the driver of the status of the vehicle’s various systems.
For the purpose of explanation, the following illustrations display all warning
lights and indicators illuminated.

752. Instrument cluster
2
Instrument cluster
IS350/300/200t_U (OM53D76U)
Warning lights inform the driver of malfunctions in the indicated vehicle systems.
Warning lights
*1
(U.S.A.)
Brake system warning light
(→ P. 516)*1Electric power steering sys-
tem warning light
(→ P. 517)
*1
(Canada)
Brake system warning light
(→ P. 516) LDA (Lane Departure
Alert) indicator (
→P. 517)
*1
(if equipped)
Charging system warning
light ( →P. 516)*1, 2PCS warning light
(→ P. 517)
*1
(U.S.A.)
Malfunction indicator lamp
(→ P. 516)*1
Slip indicator ( →P. 518)
*1
(Canada)
Malfunction indicator lamp
(→ P. 516)*1, 2
(if equipped)
“AFS OFF” indicator
(→ P. 518)
*1SRS warning light
(→ P. 516)Open door warning light
(→ P. 518)
*1
(U.S.A.)
ABS warning light
(→ P. 516)Low fuel level warning light
(→ P. 518)
*1
(Canada)
ABS warning light
(→ P. 516)Driver’s and front passen-
ger’s seat belt reminder light
(→ P. 518)
(U.S.A.)
Parking brake warning light
(→ P. 517)*3Rear passengers’ seat
belt reminder lights
(→ P. 518)
(Canada)
Parking brake warning light
(→ P. 517)*1Master warning light
(→ P. 518)

762. Instrument cluster
IS350/300/200t_U (OM53D76U)
*1: These lights turn on when the engine switch is turned to IGNITION ON mode to indicate that a system check is being performed. They will turn off after the engine is
started, or after a few seconds. There may be a malfunction in a system if a light does
not come on, or turn off. Have the ve hicle inspected by your Lexus dealer.
*2: The light flashes to indicate a malfunction.
*3: This light illuminates on the center panel.
The indicators inform the driver of the op erating state of the vehicle’s various sys-
tems.
*1Tire pressure warning light
( → P. 518)
Indicators
Turn signal indicator
(→ P. 184) LDA (Lane Departure
Alert) indicator (
→P. 227)
(U.S.A.)
Headlight indicator
(→ P. 188) LDA (Lane Departure
Alert) indicator (
→P. 227)
(Canada)
Tail light indicator
(→ P. 188) *2LDA (Lane Departure
Alert) indicator ( →P. 227)
Headlight high beam indi-
cator (→ P. 189)
(if equipped)
Intuitive parkin g assist indi-
cator ( →P. 248)
*1Automatic High Beam indi-
cator (→ P. 192)*1, 2
Slip indicator ( →P. 290)
Cruise control indicator
( → P. 236)
*1VSC OFF indicator
(→ P. 291)
Dynamic radar cruise con-
trol indicator ( →P. 236)
*1, 3PCS warning light
(→ P. 218)
Cruise control “SET” indica-
tor (→ P. 236)
*1
(if equipped)
“AFS OFF” indicator
(→ P. 189)

782. Instrument cluster
IS350/300/200t_U (OM53D76U)
*4: In order to confirm operation, the BSM ou tside rear view mirror indicators illuminate
in the following situations:
• When the engine switch is turned to IGNITION ON mode while the BSM main switch is set to ON.
• When the BSM main switch is set to ON while the engine switch is in IGNITION
ON mode.
If the system is functioning correctly, the BSM outside rear view mirror indicators will
turn off after a few seconds.
If the BSM outside rear view mirror indicators do not illuminate or do not turn off,
there may be a malfunction in the system.
If this occurs, have the vehicle inspected by your Lexus dealer.
*5: This light illuminates on the outside rear view mirrors.
*6: This light illuminates on the center panel.
*7: When the outside temperature is approximately 37 °F (3 °C) or lower, the indicator
will flash for approximately 10 seconds, then stay on.
*8:Except F SPORT models
*9:F SPORT models
WARNING
■If a safety system warnin g light does not come on
Should a safety system light such as the ABS and SRS warning light not come on when
you start the engine, this could mean that these systems are not available to help pro-
tect you in an accident, which could result in death or serious injury. Have the vehicle
inspected by your Lexus dealer immediately if this occurs.
