3. MEDIA OPERATION
GX460_Navi_OM60N98U_(U)16.05.30 14:27
7. VTR
■CONTROL SCREEN
OVERVIEW
The VTR operation screen can be reached by the following methods:
X Connecting a device to the AUX port ( →P.163)
Press the “A U D I O ” button to display the audio control screen.
Select “Source” and select “A / V ”.
GX_Navi_OM60N98U_(U).book Page 224 Monday, May 30, 2016 2:28 PM

225
3. MEDIA OPERATION
GX460_Navi_OM60N98U_(U)16.05.30 14:27
4
AUDIO/VISUAL SYSTEM
■CONTROL PANEL
No.Function
Select to display the audio source selection screen.
Select to display the sound setting screen.
Select to display the audio setting screen.
Select to display the option screen. ( →P.226)
Select to display full screen video.
•Turn to adjust volume.
• Press to turn the audio system on/off.
• Press and hold to restart the audio system.
GX_Navi_OM60N98U_(U).book Page 225 Monday, May 30, 2016 2:28 PM

227
GX460_Navi_OM60N98U_(U)16.05.30 14:27
4
AUDIO/VISUAL SYSTEM
4. REAR SEAT ENTERTAINMENT SYSTEM OPERATION
1. REAR SEAT ENTERTAINMENT SYSTEM FEATURES*
The rear seat entertainment system is designed for the rear passengers to enjoy audio
and DVD video separately from the front audio/visual system. The rear seat entertain-
ment system can be used when the engine switch is in ACCESSORY or IGNITION
ON mode.
No.Name
Front audio/visual system
Displays
Rear seat entertainment system controller
Headphone volume control dials and headphone jacks
HDMI port
A/V input port
*: If equipped
GX_Navi_OM60N98U_(U).book Page 227 Monday, May 30, 2016 2:28 PM

228
4. REAR SEAT ENTERTAINMENT SYSTEM OPERATION
GX460_Navi_OM60N98U_(U)16.05.30 14:27
1Remove the insulating sheet before us-
ing the remote controller.
1Remove the cover.
2Remove the depleted batteries and in-
stall the new ones.
DISPLAY
A display is installed in the back of each
front seat. When audio-video equip-
ment is connected to the A/V input port
or HDMI port, rear passengers can en-
joy different audio sources on each dis-
play. (→P.250)
REAR SEAT ENTERTAINMENT
SYSTEM CONTROLLER
BEFORE USING THE
CONTROLLER (FOR NEW
VEHICLE OWNERS)
INFORMATION
●
An insulating sheet is set to prevent the
batteries from being discharged.
REPLACING THE
CONTROLLER BATTERIES
GX_Navi_OM60N98U_(U).book Page 228 Monday, May 30, 2016 2:28 PM

229
4. REAR SEAT ENTERTAINMENT SYSTEM OPERATION
GX460_Navi_OM60N98U_(U)16.05.30 14:27
4
AUDIO/VISUAL SYSTEM
1Press and release the lid.
2Turn the knob clockwise to increase the
volume. Turn the knob counterclock-
wise to decrease the volume.INFORMATION
●
If the batteries are discharged, the
following symptoms may occur:
• The rear seat entertainment system controller will not function properly.
• The operational range is reduced.
●When using AA batteries
• Batteries can be purchased at your Lexus dealer, electric appliance shop,
or camera stores.
• Replace only with the same or equiva- lent type recommended by your Lexus
dealer.
• Dispose of used batteries according to the local laws.
HEADPHONE JACKS
Adjust the volume when you connect
the headphones to the jack. Loud
sounds may have a significant impact on
the human body.
No.Function
To use the headphones, connect
them to the jack.
To adjust the volume.
GX_Navi_OM60N98U_(U).book Page 229 Monday, May 30, 2016 2:28 PM

230
4. REAR SEAT ENTERTAINMENT SYSTEM OPERATION
GX460_Navi_OM60N98U_(U)16.05.30 14:27
zWith some headphones generally avail-
able in the market, it may be difficult to
catch signals properly. Lexus recommends
the use of Lexus genuine wireless head-
phones.
z Contact your Lexus dealer for further
details.
■ COMMUNICATION SYSTEM
Infrared rays
■CHANNEL (FREQUENCY) SPECI-
FICATION
To listen to the audio of the right side
display
R channel: 3.8 MHz
L channel: 3.2 MHz
To listen to the audio of the left side dis-
play
R channel: 2.8 MHz
L channel: 2.3 MHz
HEADPHONES
To listen to the rear audio, use head-
phones.
USING WIRELESS
HEADPHONES
The rear audio channels (frequencies)
that are output from the left and right
rear seat displays are different.
When using wireless headphones, use
headphones that comply with the follow-
ing conditions.
GX_Navi_OM60N98U_(U).book Page 230 Monday, May 30, 2016 2:28 PM

231
4. REAR SEAT ENTERTAINMENT SYSTEM OPERATION
GX460_Navi_OM60N98U_(U)16.05.30 14:27
4
AUDIO/VISUAL SYSTEM
zThis screen appears for a few seconds
when the engine switch is in ACCESSORY
or IGNITION ON mode.
1Press the button. When the switch is moved to “R”, opera-
tions can be performed on the right screen.
When switch is moved to “L”, operations
can be performed on the left screen.
1Press the button.
z
While the display is off, some remote con-
trol buttons can be operated.
CAUTION SCREEN
TURNING THE REAR DISPLAY
ON/OFF
CHANGING THE DISPLAY TO
BE OPERATED
TURNING THE REAR DISPLAY
OFF USING THE REMOTE
CONTROLLER
GX_Navi_OM60N98U_(U).book Page 231 Monday, May 30, 2016 2:28 PM

232
4. REAR SEAT ENTERTAINMENT SYSTEM OPERATION
GX460_Navi_OM60N98U_(U)16.05.30 14:27
1Press the “SOURCE” button to display
the audio source selection screen.
2Select the desired source.
z To switch the screen page, move the cursor
point to the left or right side edge of the
icons list. Then press the
“” or “ ” but-
ton on the controller.
CHANGING THE SOURCE
No.Function
Press to display the audio source se-
lection screen.
Press to select an icon.
Press to input the selected icon.
