2017 JEEP WRANGLER display

•MENU Button
Push and release the MENUbutton to advance the display
to each of the instrument cluster display Main Menu
features or to return to the Main Menu from a submenu.
Upon reaching the last item in the Main Menu the instru-
ment cluster display will advance to the first item in the
Main Menu with the next MENUbutton push and release.
• Compass Button
Push and release the compassbutton to return to the
Compass/Outside Temperature/Audio Information/ECO
screen whenever the current display is not the Compass/
Outside Temperature/Audio Information/ECO screen.
• Right Arrow Button
Push and release the rightarrow button when prompted
by the instrument cluster display to Reset Main Menu
features with a reset capability or to change Personal
Settings.
• Down Arrow Button
Push and release the downarrow button when prompted
by the instrument cluster display to step through Vehicle
Info submenu, stored system warning messages, or Per-
sonal Settings features.Instrument Cluster Display Menu Items
NOTE: The instrument cluster display menu items display
in the center of the instrument cluster. Menu items may
vary depending on your vehicle features.
Average Fuel Economy
Shows the average fuel economy since the last reset.
Average fuel economy can be reset by pushing and holding
the right arrow button (as prompted in the instrument
cluster display). Upon reset, the history information will be
erased, and the averaging will continue from the last fuel
average reading before the reset.
Compass, Outside Temperature Display / ECO (Fuel
Saver Mode) — If Equipped
The compass readings indicate the direction the vehicle is
facing. Push and release the compassbutton to display one
of eight compass headings, the outside temperature/ECO
if the instrument cluster display is not already displaying
this screen.
4
GETTING TO KNOW YOUR INSTRUMENT PANEL 187

NOTE:The system will display the last known outside
temperature when starting the vehicle and may need to be
driven several minutes before the updated temperature is
displayed. Engine temperature can also affect the dis-
played temperature; therefore, temperature readings are
not updated when the vehicle is not moving.
ECO (Fuel Saver Mode) — If Equipped
The ECO message will display below the outside tempera-
ture in the instrument cluster display (if the audio system
is on the ECO indicator will override the audio information
display line if the Display Fuel Saver personal setting is
ON — see Personal Settings section). This message will
appear whenever you are driving in a fuel efficient manner.
This feature allows you to monitor when you are driving in
a fuel efficient manner, and it can be used to modify
driving habits in order to increase fuel economy.
Automatic Compass Calibration
This compass is self-calibrating, which eliminates the need
to set the compass manually. When the vehicle is new, the
compass may appear erratic, and the instrument cluster
display will display “CAL” until the compass is calibrated.
You may also calibrate the compass by completing one or
more 360–degree turns (in an area free from large metal or metallic objects) until the “CAL” message displayed in the
instrument cluster display turns off. The compass will now
function normally.
NOTE:
A good calibration requires a level surface and an
environment free from large metallic objects such as build-
ings, bridges, underground cables, railroad tracks, etc.
Manual Compass Calibration
If the compass appears erratic and the “CAL” indicator
does not appear in the instrument cluster display, you must
put the compass into the Calibration Mode manually as
follows:
1. Start the engine. Leave the gear selector in PARK in order to enter the instrument cluster display Program-
ming Menus.
2. Push the MENUbutton until Personal Settings
(Customer-Programmable Features) displays in the in-
strument cluster display.
3. Push the downarrow button until “Calibrate Compass”
displays in the instrument cluster display.
4. Push and release the rightarrow button to start the
calibration. The “CAL” indicator will display in the
instrument cluster display.
188 GETTING TO KNOW YOUR INSTRUMENT PANEL

5. Complete one or more 360–degree turns (in an area freefrom large metal or metallic objects) until the “CAL”
indicator turns off. The compass will now function
normally.
Compass Variance
Compass Variance is the difference between Magnetic
North and Geographic North. To compensate for the
differences, the variance should be set for the zone where
the vehicle is driven, per the zone map. Once properly set,
the compass will automatically compensate for the differ-
ences and provide the most accurate compass heading.
NOTE: Magnetic materials should be kept away from the
top of the instrument panel; this is where the compass
sensor is located.
To Change The Compass Variance:
1. Turn the ignition switch RUN (it is not necessary to start the engine).
2.
Push the MENUbutton until Personal Settings (Customer-
Programmable Features) displays in the instrument cluster
display.
3. Push the downarrow button until “Compass Variance”
message and the last variance zone number displays in
the instrument cluster display.
Compass Variance Map
4
GETTING TO KNOW YOUR INSTRUMENT PANEL 189

4. Push and release therightarrow button until the proper
variance zone is selected according to the map.
5. Push and release the COMPASSbutton to exit.
Distance To Empty (DTE)
Shows the estimated distance that can be traveled with the
fuel remaining in the tank. This estimated distance is
determined by a weighted average of the instantaneous
and average fuel economy, according to the current fuel
tank level. DTE cannot be reset.
NOTE:Significant changes in driving style or vehicle
loading will greatly affect the actual drivable distance of
the vehicle, regardless of the DTE display value.
When the DTE value is less than 30 miles (48 km) estimated
driving distance, the DTE display will change to a text
display of LOW FUEL.” This display will continue until
the vehicle runs out of fuel. Adding a significant amount of
fuel to the vehicle will turn off the LOW FUEL text, and a
new DTE value will display.
Elapsed Time
Shows the total elapsed time of travel since the last reset.
Elapsed time will increment when the ignition switch is in
the RUN or START position.
Elapsed time displays Minutes: Seconds.
After 59 minutes: 59 seconds have elapsed, Hours will be
displayed before Minutes.
Elapsed time can be reset by pushing and holding the right
arrow button (as prompted in the instrument cluster dis-
play). Upon reset, all digits will change to zeros and time
will start again if the ignition switch is in RUN or START.
Units Selection (UNITS IN Display)
Displays the units used for the Outside Temperature,
Average Fuel Economy and Distance to Empty features.
Push and release the downarrow button to toggle units
between U.S.andMETRIC.
190 GETTING TO KNOW YOUR INSTRUMENT PANEL

Personal Settings (Customer-Programmable Features)
Personal Settings allows the driver to set and recall features
when the vehicle speed is at 0 mph (0 km/h) (manual
transmission) or when the gear selector is in PARK (auto
transmission).
Push and release theMENUbutton until Personal Settings
displays in the instrument cluster display.
Use the downarrow button to display one of the following
choices:
Language
When in this display you may select one of five languages
for all display nomenclature, including the trip functions
and the navigation system (if equipped). Push the right
arrow button while in this display to select English,
Espanol or Francais. Then, as you continue, the informa-
tion will display in the selected language.
Auto Lock Doors — If Equipped
When this feature is selected, all doors will lock automati-
cally when the vehicle reaches a speed of 15 mph
(24 km/h). The auto door lock feature can be enabled or
disabled, to make your selection, push and release the right
arrow button until “On” or “Off” appears. Auto Unlock On Exit
When ON is selected, all doors will unlock when the
vehicle is stopped and the transmission is in the PARK or
NEUTRAL position, and the driver’s door is opened. To
make your selection, push and release the
rightarrow
button until “On” or “Off” appears.
Key Fob Unlock — If Equipped
When “Driver Door 1st Press” is selected, only the driver’s
door will unlock on the first push of the key fob unlock
button. When “Driver Door 1st Press” is selected, you must
push the key fob unlock button twice to unlock the
passenger’s doors. When “All Doors 1st Press” is selected,
all of the doors will unlock on the first push of the key fob
unlock button. To make your selection, push and release
the right arrow button until “Driver Door 1st Press” or “All
Doors 1st Press” appears.
Sound Horn With Lock
When on is selected, a short horn sound will occur when
the key fob lock button is pushed. This feature may be
selected with or without the Flash Lamp with Lock feature.
To make your selection, push and release the rightarrow
button until “On” or “Off” appears.
4
GETTING TO KNOW YOUR INSTRUMENT PANEL 191

Hill Start Assist (HSA) — If Equipped
When “On” is selected, the HSA system is active. Refer to
“Electronic Brake Control System” in “Starting And Oper-
ating” for system function and operating information. To
make your selection, push and release therightarrow
button until “On” or “Off” appears.
Display Units In
The instrument cluster display can be changed between
English and Metric units of measure. The units apply to the
Outside Temperature, Average Fuel Economy, and Dis-
tance to Empty. To make your selection, push and release
the right arrow button until “U.S.” or METRICappears.
Nav–Turn By Turn — If Equipped
When on enables display of Navigation System street
name, turn direction, and distance to turn information in
the instrument cluster display. To make your selection,
push and release the rightarrow button until “On” or
“Off” appears. Display Fuel Saver — If Equipped
The “ECO” message is located in the compass/outside
temperature/audio information/ECO display. If Display
Fuel Saver is selected as ON, only the ECO message will
display in the audio information/ECO line of the display. If
Display Fuel Saver is selected as OFF, only the audio
information will display in the audio information/ECO
line of the display when the audio system is on. To make
your selection, push and release the
rightarrow button
until “ON” or “OFF” appears.
Compass Variance
Refer to “Instrument Cluster Display” in “Getting To Know
Your Instrument Panel” for further information.
Calibrate Compass
Push the rightarrow button to calibrate the compass.
Digital Speedometer
Shows the actual vehicle speed in mph or km/h.
4
GETTING TO KNOW YOUR INSTRUMENT PANEL 193

System Warnings
Displays “SYSTEM OK” if there are no active Warning
Messages stored. Pushing and releasing thedownarrow
button when “SYSTEM OK” is displayed will do nothing.
Displays “SYSTEM WARNINGS PRESENT” if there are
active Warning Messages stored. Pushing and releasing the
down arrow button when “SYSTEM WARNINGS PRES-
ENT” is displayed will display each stored warning for
each button push. Push and release the MENUbutton to
return to the Main Menu.
Tire Pressure — If Equipped
Push and release the MENUbutton until “Tire PSI/kpa:”
displays in the instrument cluster display. It shows a
graphic of the vehicle with a tire pressure value at each
corner of the graphic.
Vehicle Information
Push and release the MENUbutton until “Vehicle Infor-
mation” displays in the instrument cluster display. Then,
push the downarrow button to display any one of the
following choices:
• Coolant Temperature
Shows the actual coolant temperature.
• Oil Pressure
Shows the actual oil pressure.
• Transmission Temperature — Automatic Transmission
Only
Shows the actual transmission fluid temperature.
• Oil Life Remaining (Automatic Oil Change Indicator)
— If Equipped
Shows the oil life measured in percentage.
194 GETTING TO KNOW YOUR INSTRUMENT PANEL

Oil Change Required
Your vehicle is equipped with an engine oil change indi-
cator system. The “Oil Change Required” message will
display in the instrument cluster display for approximately
10 seconds after a single chime has sounded to indicate the
next scheduled oil change interval. The engine oil change
indicator system is duty cycle based, which means the
engine oil change interval may fluctuate dependent upon
your personal driving style.
Unless reset, this message will continue to display each
time you turn the ignition switch to the ON position. To
turn off the message temporarily, push and release the
MENUbutton. To reset the oil change indicator system
(after performing the scheduled maintenance), perform the
following procedure:
1. Turn the ignition switch to the ON position. Do not start
the engine.
2. Fully push the accelerator pedal slowly three times within 10 seconds.
3. Turn the ignition switch to the LOCK position.
NOTE: If the indicator message illuminates when you
start the vehicle, the oil change indicator system did not
reset. If necessary, repeat this procedure.
WARNING/INDICATOR LIGHTS AND MESSAGES
The warning/indicator light switches on in the instrument
panel together with a dedicated message and/or acoustic
signal when applicable. These indications are indicative
and precautionary and as such must not be considered as
exhaustive and/or alternative to the information contained
in the Owner Manual, which you are advised to read
carefully in all cases. Always refer to the information in this
chapter in the event of a failure indication.
All active telltales will display first, if applicable. The
system check menu may appear different based upon
equipment options and current vehicle status. Some tell-
tales are optional and may not appear.
4
GETTING TO KNOW YOUR INSTRUMENT PANEL 195
