2017 JEEP RENEGADE door lock

To Unlock/Enter The Liftgate
The liftgate Passive Entry unlock feature is built into the
electronic liftgate release. With a valid Passive Entry key
fob within 5 ft (1.5 m) of the liftgate, push the Electronic
Liftgate release to open with one fluid motion.
To Lock The Liftgate
With a valid Passive Entry key fob within 5ft (1.5 m) of the
liftgate, push the Passive Entry lock button located to the
right of electronic liftgate release.
NOTE:
•The liftgate Passive Entry lock button will lock the
liftgate and the doors. The liftgate unlock feature is built
into the Electronic Liftgate release.
• If “Unlock All Doors 1st Press” is programmed in the
instrument cluster display, if equipped, only the liftgate
will unlock when you push the Electronic Release. If
Unlock Driver Door 1st Press is programmed in
Uconnect, the liftgate will unlock when you push the
electronic unlock/lock button on the liftgate. For further
information, refer to “Uconnect Touch Settings” in
“Multimedia.” Emergency Unlocking Driver Door
If the key fob battery is low or dead, the emergency key can
be used to unlock the driver side door lock cylinder.
To release the emergency key, proceed as follows:
1. Slide the emergency key release button to the side.
Liftgate Release/Passive Entry
1 — Electronic Liftgate Release
2 — Liftgate Passive Lock Location
3
GETTING TO KNOW YOUR VEHICLE 35

2. Remove the emergency key from the key fob withRemote Control housing.
NOTE: The Emergency Key can be inserted into the door
lock cylinder from either direction.WARNING!
• Never leave children alone in a vehicle, or with
access to an unlocked vehicle. Allowing children to
be in a vehicle unattended is dangerous for a number
of reasons. A child or others could be severely
injured or killed. Children should be warned not to
touch the parking brake, brake pedal, or the gear
selector. Do not leave the key fob in or near the
vehicle, or in a location accessible to children, and do
not leave the ignition in the ON or RUN mode. A
child could start the vehicle, operate power win-
dows, other controls, or move the vehicle.
• Do not leave children or animals inside parked
vehicles in hot weather. Interior heat buildup may
cause them to be severely injured or killed
Dead Lock Device — If Equipped
The Dead Lock Device is a safety device that prevents the
use of the internal door handles of the vehicle and the
power door lock switch.
This device prevents the doors from opening within the
passenger compartment.
Emergency Key Release
1 — Emergency Key Release Button
2 — Emergency Key 36 GETTING TO KNOW YOUR VEHICLE

Arming The Dead Lock Device
•The device works on all doors and requires two presses
of the lock button on the key fob.
• The arming of the device is indicated by three flashes of
the direction indicators.
• The device does not operate if one or more doors are not
properly closed.
Disarming The Device
• The device will automatically disarm by pushing the
unlock button on the key fob.
• Placing the ignition in the ON or RUN position.
Child Locks
To provide a safer environment for small children riding in
the rear seats, the rear doors are equipped with a Child-
Protection Door Lock system.
To use the system, open each rear door, use a flat blade
screwdriver (or ignition key) and rotate the dial to the lock
or unlock position. When the system on a door is engaged,
that door can only be opened by using the outside door
handle even if the inside door lock is in the unlocked
position. NOTE:
•
When the child lock system is engaged, the door can
only be opened by using the outside door handle even
though the inside door lock is in the unlocked position.
• After disengaging the Child-Protection Door Lock sys-
tem, always test the door from the inside to make certain
it is in the desired position.
• After engaging the Child-Protection Door Lock system,
always test the door from the inside to make certain it is
in the desired position.
Child-Protection Door Lock Location
3
GETTING TO KNOW YOUR VEHICLE 37

•For emergency exit with the system engaged, rotate the
lock/unlock dial to the unlocked position, roll down the
window, and open the door with the outside door
handle.
WARNING!
Avoid trapping anyone in a vehicle in a collision.
Remember that the rear doors can only be opened from
the outside when the Child-Protection locks are en-
gaged (locked).
SEATS
Seats are a part of the Occupant Restraint System of the
vehicle.
WARNING!
• It is dangerous to ride in a cargo area, inside or
outside of a vehicle. In a collision, people riding in
these areas are more likely to be seriously injured or
killed.
• Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat belts.
(Continued)
WARNING! (Continued)
In a collision, people riding in these areas are more
likely to be seriously injured or killed.
• Be sure everyone in your vehicle is in a seat and
using a seat belt properly.
Manual Front Seats
Manual Seat Adjustment Levers
1 — Forward/Rearward Adjustment Bar
2 — Seat Height Adjustment Lever
3 — Recline Lever
38 GETTING TO KNOW YOUR VEHICLE

WARNING!(Continued)
•Seats should be adjusted before fastening the seat
belts and while the vehicle is parked. Serious injury
or death could result from a poorly adjusted seat belt.
• Do not ride with the seatback reclined so that the
shoulder belt is no longer resting against your chest.
In a collision you could slide under the seat belt,
which could result in serious injury or death.
CAUTION!
Do not place any article under a power seat or impede
its ability to move as it may cause damage to the seat
controls. Seat travel may become limited if movement
is stopped by an obstruction in the seat’s path.
Power Lumbar Adjustment— If Equipped
Push the switch forward or rearward to increase or de-
crease the lumbar support. Push the switch upward or
downward to raise or lower the lumbar support. NOTE:
Power seat adjustments are only allowed when the
ignition device is turned to ON, and for about 30 minutes
after it is turned to OFF. The seats can also be moved after
opening/closing the doors for about 30 minutes, locking or
unlocking the doors, or switching on of the front courtesy
lights.
Heated Seats — If Equipped
The heated seat switches are located on the instrument
panel.
You can choose between two heating levels:
• Push the heated seat button
once to turn the HI
setting on.
• Push the heated seat buttona second time to turn
the LO setting on.
• Push the heated seat buttona third time to turn the
heating elements off.
If the HI-level setting is selected, the system will automati-
cally switch to LO-level after approximately 145 minutes of
continuous operation. At that time, the display will change
from HI to LO, indicating the change. The LO-level setting
will turn off automatically after approximately 60 minutes.
3
GETTING TO KNOW YOUR VEHICLE 41

Vehicles With Retractable Roof
For vehicles equipped with a retractable roof, there are two
interior lights located above the grab handles of the rear
doors.The lights come on by opening any of the doors.
Dome Light Timing
The Dome Light will automatically illuminate when the
doors are unlocked, the doors are opened or after the doors
are closed.
Rear Interior Light
Interior Light Locations
3
GETTING TO KNOW YOUR VEHICLE 59

Timing Entering The Vehicle
The dome lights illuminate in the following ways:
•When the doors are unlocked, the dome light will
illuminate for approximately 27 seconds.
• When one of the doors is opened, the dome light will
illuminate for approximately three minutes.
• When the doors are closed, the dome light will automati-
cally shut off after approximately 27 seconds.
The timing stops once the ignition is placed in the RUN or
ON position.
The dome light will turn off under any of the following
conditions:
• The dome light is disabled when the ignition is placed in
the RUN or ON position.
• The dome lights will turn off automatically when the
doors are locked.
• The dome lights will automatically turn off after ap-
proximately fifteen minutes of inactivity to preserve the
battery. Timing Exiting The Vehicle
The dome light will illuminate under the following condi-
tions when the ignition is placed to the OFF position and
the key is removed:
•
The dome light will illuminate for 27 seconds after the
ignition is placed in the OFF position.
• The opening of one of the doors (approximately three
minutes).
• After closing a door (approximately 27 seconds).
The dome light timing is disabled when the doors are
locked.
Internal Compartment Lights
Illuminated Vanity Mirrors — If Equipped
An illuminated vanity mirror is located on each sun visor.
To use the mirror, rotate the sun visor down and swing the
mirror cover upward. The lights will turn on automatically.
Closing the mirror cover will turn the light off.
60 GETTING TO KNOW YOUR VEHICLE

WINDOWS
Power Window Controls
The power window switch is located on the driver ’s door
panel. The driver ’s power window switch controls the
operation of all the windows.There are single window controls on each passenger door
trim panel, which operate the passenger door windows.
The window controls will operate only when the ignition is
in the ON or RUN position.
NOTE:
For vehicles equipped with Uconnect, the power
window switches will remain active for up to three min-
utes after the ignition is cycled to the OFF position.
Opening either front door will cancel this feature. Refer to
“Uconnect Settings” in “Multimedia” for further informa-
tion.
WARNING!
Never leave children unattended in a vehicle, and do
not let children play with power windows. Do not
leave the key fob in or near the vehicle, or in a location
accessible to children, and do not leave the ignition of
a vehicle equipped with Keyless Enter-N-Go in the
ACC or ON/RUN mode. Occupants, particularly unat-
tended children, can become entrapped by the win-
dows while operating the power window switches.
Such entrapment may result in serious injury or death.
Power Window Switches
1 — Opening/Closing Left/Right Front Window
2 — Opening/Closing Left/Right Rear Window (If Equipped)
3 — Window Lockout Switch (Rear Doors)
3
GETTING TO KNOW YOUR VEHICLE 83
