Page 323 of 516
4. Install the new headlamp bulb making sure it is prop-erly locked.
5. Install the headlamp bulb and socket; turn it clockwise making sure it is properly locked.
WARNING!
Carry out the operation of replacing lamps only with
the engine off. Also make sure that the engine is cold,
to avoid the danger of burns.
Headlamp Bulb ConnectorHeadlamp Bulb
7
IN CASE OF EMERGENCY 321
Page 324 of 516
Position Lights/Daytime Running Lights/Fog Lights
To replace the bulbs proceed as follows:
1. Turn the front wheels completely.
2. Use a suitable tool to remove the access door.
3. Remove the electrical connectors.4. Rotate in a counterclockwise direction (on the left-hand
socket) or in a clockwise direction (on the right-hand
socket) and remove the bulb and bulb socket.
Position Light/Daytime Running Light/Fog Light Access
1 — Screws
2 — Access Door
Electrical Connectors
322 IN CASE OF EMERGENCY
Page 325 of 516
5. To replace the bulb gently push bulb and rotate coun-terclockwise. 6. Insert the new bulb by pushing on it and turning it
clockwise. Make sure the bulb is correctly locked in
place.
7. Install the bulb and sockets and rotate them clockwise (right side) and clockwise (left side), making sure that it
is properly locked.
8. Reconnect the electrical connectors.
Position Light/Daytime Running Light Assembly
1 — DRL Bulb Socket
2 — Turn Signal Bulb Socket
Bulb and Socket Assembly
1 — Bulb
2 — Rotate Bulb
7
IN CASE OF EMERGENCY 323
Page 326 of 516
9. Reinstall the access door.
Front Fog Lights
To replace the bulbs proceed as follows:
1. Turn the front wheels completely.
2. Use a suitable tool to remove the access door.
3. By pushing the electrical connector tab remove theelectrical connector. 4. Rotate the bulb counterclockwise, and then replace the
bulb.
5. Insert the new bulb in the socket, making sure the bulb is locked into place.
6. Reconnect the electrical connector.
7. Reinstall the access door.
Position Light/Daytime Running Light/Fog Light Access
1 — Screws
2 — Access Door
Fog Light Assembly
1 — Bulb Socket
2 — Electrical Connector
3 — Bulb
324 IN CASE OF EMERGENCY
Page 328 of 516
3. Remove the electrical connector by pushing the tab thendisconnect the electrical connector. 4. Rotate counterclockwise to release the bulb socket from
the lamp assembly, and remove it.
Electrical ConnectorBulb Socket
326 IN CASE OF EMERGENCY
Page 329 of 516
5. Remove the bulb from the socket.
6. Insert the new bulb in the socket.
7. Reinstall the bulb and socket into the lamp assembly byturning it clockwise, making sure it is locked into place.
8. Reconnect the electrical connector.
9. Reinstall the lamp assembly on the car, making sure it is locked into place. Side Indicators on External Rear View Mirrors – (If
Equipped)
CAUTION!
The procedure is described as a guideline. For the
replacement of the lamp it is recommended that you
contact your authorized dealer.
To replace the bulb proceed as follows:
1. Remove the mirror cap on the outside rear view mirror.
Bulb
Mirror Cap
7
IN CASE OF EMERGENCY 327
Page 330 of 516
2. Remove the transparent lens assembly as shown. 3. Remove the bulb socket and bulb from the transparentlens assembly by rotating the socket counterclockwise.
Removing the mirror capTransparent Lens
328 IN CASE OF EMERGENCY
Page 342 of 516
Access To The Fuses
The fuses are grouped into four controllers located in the
engine compartment, under the instrument panel and on
the inside of the left side cargo trim panel.
Engine Compartment Fuses/Distribution Unit
The engine compartment fuse panel is located on the left
side of the engine compartment.Removing Fuse Cover and Locking Screw
Proceed as follows:
•Slowly turn the screw counterclockwise.
• Slowly release the screw.
• Remove the fuse cover by sliding it upward.
Engine Compartment Fuse Cavities
Fuse Panel & Cover Location
1 — Mounting Screw
2 — Fuse Cover
340 IN CASE OF EMERGENCY
