2017 INFINITI QX60 odometer

INFINITI CARES...
Both INFINITI and your INFINITI retailer are dedi-
cated to serving all your automotive needs. Your
satisfaction with your vehicle and your INFINITI
retailer are our primary concerns. Your INFINITI
retailer is always available to assist you with all
your automobile sales and service needs.
However, if there is something that your INFINITI
retailer cannot assist you with or you would like to
provide INFINITI directly with comments or ques-
tions, please contact our (INFINITI’s) Consumer
Affairs Department using our toll-free number:
For U.S. customers1-800-662-6200
For Canadian customers 1-800-361-4792 The Consumer Affairs Department will ask for the
following information:
– Your name, address, and telephone number
– Vehicle identification number (on dash panel)
– Date of purchase
– Current odometer reading
– Your INFINITI retailer’s name
– Your comments or questions
OR
You can write to INFINITI with the information on
the left at:
For U.S. customers
INFINITI Division
Nissan North America, Inc. Consumer Affairs Department
P.O. Box 685003
Franklin, TN 37068-5003
or via e-mail at:
[email protected]
For Canadian customers INFINITI Division
Nissan Canada Inc.
5290 Orbitor Drive
Mississauga, Ontario L4W 4Z5
or via e-mail at:
information.centre@nissancanada. com
If you prefer, visit us at:
www.infinitiUSA.com (for U.S. customers)
or
www.infiniti.ca (for Canadian customers)
We appreciate your interest in INFINITI and thank you for buying a quality INFINITI vehicle.
INFINITI CUSTOMER CARE PROGRAM

2 Instruments and controls
Instrument panel...................................2-2
Meters and gauges ................................2-4
Speedometer and odometer .....................2-4
Tachometer ....................................2-6
Engine coolant temperature gauge ...............2-6
Fuel gauge ....................................2-7
Warning lights, indicator lights and audible
reminders .........................................2-8
Checking lights ................................2-8
Warning lights .................................2-9
Indicator lights ................................ 2-13
Audible reminders ............................. 2-15
Vehicle information display ......................... 2-16
How to use the vehicle information display .......2-17
Startup display ................................ 2-17
Resetting the trip computer .....................2-17
Settings ...................................... 2-17
Vehicle information display warnings and
indicators ..................................... 2-25
Security systems ................................. 2-30
Vehicle security system ......................... 2-30
INFINITI vehicle immobilizer system ..............2-31
Wiper and washer switch ......................... 2-33Switch operation
.............................. 2-33
Rain-sensing auto wiper system
(if so equipped) ............................... 2-34
Rear switch operation .......................... 2-35
Rear window and outside mirror defroster switch .....2-36
Headlight and turn signal switch ....................2-37
Xenon headlights .............................. 2-37
Headlight control switch ........................ 2-37
Daytime running light system ....................2-41
Instrument brightness control ...................2-42
Turn signal switch ............................. 2-42
Fog light switch ............................... 2-43
Horn ............................................ 2-43
Climate controlled seat switches (if so equipped) ....2-44
Heated seat switches (if so equipped) ..............2-45
Heated 2nd row seat switches (if so equipped) ......2-46
Heated steering

wheel switch (if so equipped) .......2-47
Warning systems switch (if so equipped) ............2-47
Vehicle Dynamic Control (VDC) off switch ...........2-48
E-call (SOS) switch (if so equipped) ................2-49
Power inverter switch (if so equipped) ..............2-49
Power outlets .................................... 2-50
12v outlets ................................... 2-50

1. Tachometer
2. Warning and indicator lights
3. Vehicle information display
4. Speedometer
5. Fuel gauge6. Odometer
Twin trip odometer
7. Engine coolant temperature gauge
SPEEDOMETER AND ODOMETER
This vehicle is equipped with a speedometer and
odometer. The speedometer is located on the
right side of the meter cluster. The odometer is
located below the vehicle information display.
LIC2254
METERS AND GAUGES
2-4Instruments and controls

Speedometer
The speedometer indicates vehicle speed.
Odometer/Twin trip odometer
The odometer1and the twin trip odometer2
are displayed below the vehicle information dis-
play when the ignition switch is placed in the ON
position.
The odometer records the total distance the ve-
hicle has been driven.
The twin trip odometer records the distance of
individual trips.Changing the display
Push the TRIP RESET
3switch on the right of
the combination meter to change the display as
follows:
Trip
→ Trip→Trip
Resetting the trip odometer
Pushing the TRIP RESET switch
3for more
than 1 second resets the currently displayed trip
odometer to zero.
Average fuel economy and distance to empty
information is also available. For additional infor-
mation, refer to “Vehicle information display” in
this section.
LIC2218LIC2234
Instruments and controls2-5

To help ensure smooth, safe and economical
driving, INFINITI provides two maintenance
schedules that may be used, depending upon the
conditions in which you usually drive. These
schedules contain both distance and time inter-
vals, up to 120,000 miles
(192,000 km)/144 months. For most people, the
odometer reading will indicate when service is
needed. However, if you drive very little, your
vehicle should be serviced at the regular time
intervals shown in the schedule.
After 120,000 miles
(192,000 km)/144 months, continue main-
tenance at the same mileage/time inter-
vals.
ADDITIONAL MAINTENANCE ITEMS
FOR SEVERE OPERATING
CONDITIONS
Additional maintenance items for severe
operating conditionsshould be performed on
vehicles that are driven under especially de-
manding conditions. Additional maintenance
items should be performed if you primarily oper-
ate your vehicle under the following conditions:
● Repeated short trips of less than 5 miles
(8 km) . ●
Repeated short trips of less than 10 miles
(16 km) with outside temperatures remain-
ing below freezing.
● Operating in hot weather in stop-an-go
“rush hour” traffic.
● Extensive idling and/or low speed driving for
long distances, such as police, taxi or door-
to-door delivery use.
● Driving in dusty conditions.
● Driving on rough, muddy or salt spread
roads.
● Towing a trailer, using a camper or a car-top
carrier.
NOTE:
For vehicles operated in Canada, both
standard and severe maintenance items
should be performed at every interval. The following tables show the standard mainte-
nance schedule. Depending upon weather and
atmospheric conditions, varying road surfaces,
individual driving habits and vehicle usage, addi-
tional or more frequent maintenance may be re-
quired.
After 120,000 miles
(192,000 km)/144 months, continue main-
tenance at the same mileage/time interval.
MAINTENANCE SCHEDULES STANDARD MAINTENANCE
Maintenance and schedules9-7

Extendedstorageswitch ............2-52F
Flashers (See hazard warning flasher switch) . .6-2
Flat tire .......................6-3
Floor mat positioning aid .............7-5
Fluid Brake fluid ..................8-10
Capacities and recommended
fuel/lubricants ................10-2
Continuously Variable Transmission (CVT)
fluid.......................8-9
Engine coolant .................8-4
Engine oil ...................8-6
Power steering fluid ..............8-9
Windshield-washerfluid...........8-10
F.M.V.S.S. certification label ..........10-11
Foglightswitch .................2-43
Forward Emergency Braking (FEB) .......2-10
Front air bag system (See supplemental
restraint system) .................1-58
Front and rear sonar system ..........5-138
Front power seat adjustment ...........1-3
Frontseats.....................1-2
Fuel Capacities and recommended
fuel/lubricants ................10-2
Fuel economy ................5-128
Fuel-filler door and cap ...........3-29
Fuel gauge ...................2-7
Fuel octane rating ..............10-5
Fuel recommendation ............10-4
Loose fuel cap warning ...........2-27
Fuel efficient driving tips ............5-126 Fuel-filler door
..................3-29
Fuelgauge.....................2-7
Fuses.......................8-18
Fusiblelinks ...................8-18
G
Garage door opener, HomeLink® Universal
Transceiver .............2-69,2-71,2-72
Gascap .....................3-29
Gauge Engine coolant temperature gauge .....2-6
Fuel gauge ...................2-7
Odometer ...................2-5
Speedometer .................2-5
Tachometer ..................2-6
Trip odometer .................2-5
General maintenance ...............9-2
Glovebox.....................2-54
Gloveboxlock..................2-54
H
Hazard warning flasher switch ..........6-2
Headlight and turn signal switch ........2-37
Headlight control switch ............2-37
Headlights ....................8-22
Headphones (See INFINITI mobile
entertainment system) .............4-107
Head restraints ..................1-12
Heated rear seats ................2-46
Heated seats ...................2-45
Heated steering wheel .............2-47 Heater
Heater and air conditioner (automatic)
(if so equipped) ...............4-48
Heater and air conditioner controls .....4-49
Heater operation ...............4-50
Heater and air conditioner (automatic) .....4-48
Hill start assist system .............5-137
HomeLink® Universal
Transceiver.............2-69,2-71,2-72
H o

od.......................3-21
Hook Luggage hook ................2-58
Horn .......................2-43
I
Ignition Switch Push-Button Ignition Switch ........5-13
Immobilizer system ................5-16
Important vehicle information label ......10-11
In-cabin microfilter ................8-15
Increasing fuel economy ............5-128
Indicator lights and audible reminders
(See warning/indicator lights and audible
reminders)...............2-8,2-9,2-13
INFINITI Drive mode selector ..........5-23
INFINITI Intelligent Key System .......3-2,3-7
INFINITI vehicle immobilizer
system ................2-31,3-4,5-16
Information display ................2-17
Inside automatic anti-glare mirror ........3-33
Instrument brightness control ..........2-42
Instrumentpanel...............0-6,2-2
Instrument panel dimmer switch ........2-42
11-3

Map pocket....................2-53
Memory Seat ...............3-36,3-38
Meters and gauges ................2-4
Instrument brightness control ........2-42
Mirror Automatic anti-glare inside mirror ......3-33
Outside mirrors ...............3-34
Vanity mirror .................3-33
Mirrors ......................3-33
Mobile Entertainment System (MES) ......4-95
Moonroof ......................7-4
Moving Object Detection (MOD) ........4-43
O
Octanerating(Seefueloctanerating).....10-5
Odometer .....................2-5
Oil Capacities and recommended
fuel/lubricants ................10-2
Changing engine oil ..............8-7
Changing engine oil filter ...........8-8
Checking engine oil level ...........8-6
Engine oil ...................8-6
Engine oil and oil filter recommendation . .10-6
Engine oil viscosity ..............10-7
Outside mirrors .................3-34
Overheat Ifyourvehicleoverheats...........6-12
Owner’s manual order form ..........10-33
Owner’s manual/service manual order
information ...................10-33 P
Parking Parking brake operation ...........5-22
Parking/parking on hills ..........5-132
Parking brake ...................5-22
Personallights..................2-68
Power Power door locks ............3-5,3-6
Power outlet ..............2-50,2-51
Power rear windows .............2-61
Power steering fluid ..............8-9
Power steering system ...........5-132
Power windows ...............2-60
Rear power windows ............2-61
Power inverter switch ..............2-49
Power outlet ................2-50,2-51
Power steering .................5-132
Power steering fluid ................8-9
Precautions Maintenance precautions ...........8-2
On-pavement and off-road driving
precautions ..................5-8
Precautions on booster
seats...........1-29,1-36,1-42,1-47
Precautions on child
restraints .........1-29,1-36,1-42,1-47
Precautions on seat belt usage .......1-17
Precautions on supplemental restraint
system ....................1-50
Precautions when starting and driving ....5-4
Predictive Forward Collision Warning
(PFCW) .....................5-115
Push starting ...................6-12 R
Radio CarphoneorCBradio...........4-115
FM/AM radio with compact disc (CD)
player .....................4-70
Steering wheel audio control switch .4-7, 4-71
Rainsensor....................2-34
Readiness for

inspection maintenance (I/M)
test .......................10-31
Rear Cross Traffic Alert (RCTA) ........5-66
Rear power windows ..............2-61
RearView Monitor ................4-20
Rear window and outside mirror defroster
switch.......................2-36
Rear window wiper and washer switches . . .2-35
Recommended Fluids ..............10-2
Recorders EventData .................10-32
Refrigerant recommendation ..........10-7
Registering a vehicle in another country . . .10-10
Remote controller (See INFINITI mobile
entertainment system) .............4-105
Remote Start ...............3-19,5-17
Reporting safety defects (US only) ......10-30
Roadside assistance program ..........6-2
Roof rack .....................2-59
S
Safety Child safety rear door lock ..........3-6
Child seat belts .....1-29,1-36,1-42,1-47
Reporting safety defects (US only) ....10-30
11-5

Tirepressure .............8-24,8-24
Tire rotation..................8-32
Types of tires.................8-30
Uniform tire quality grading ........10-29
Wheels and tires ...............8-24
Wheel/tire size ................10-9
Tire pressure Low tire pressure warning light .......2-10
Tire Pressure Monitoring System (TPMS) ....5-5
Top tether strap child restraint .........1-33
Towing Flattowing.................10-28
Towing load/specification .........10-21
Towtrucktowing...............6-13
Trailer towing ................10-17
Towing a trailer .................10-17
Transceiver HomeLink® Universal
Transceiver...........2-69,2-71,2-72
Transmission Continuously Variable Transmission (CVT)
fluid.......................8-9
Driving with Continuously Variable
Transmission (CVT) .............5-17
Travel (See registering a vehicle in another
country) .....................10-10
Trip odometer ...................2-5
Turn signal switch ................2-42
U
Uniform tire quality grading ..........10-29
USB interface ...............4-62,4-79
USB/iPod®ChargingPorts ..........4-85 V
Vanity mirror ...................3-33
Vehicle dimensions and weights ........10-9
Vehicle dynamic control (VDC) off switch . . .2-48
Vehicle dynamic control (VDC) system ....5-134
Vehicle Dynamic Control (VDC) system . . .5-134
Vehicle identification ..............10-10
Vehicle identification number (VIN) ......10-10
Vehicle identification number (VIN)
(Chassis number) ...............10-10
Vehicle identification number (VIN) plate . . .10-10
Vehicle immobilizer system ...........5-16
Vehicle Information Display ...........2-17
Vehicle loading information ..........10-13
Vehicle recovery ..............6-15,6-16
Vehicle security system .............2-30
(INFINITI vehicle immobilizer system) ,
engine start ...........2-31,3-4,5-16
Vents.......................4-47
Visors.......................3-32
Voice Recognition System ...........4-140
W
Warning Airbagwarninglight.........1-69,2-12
Anti-lock brake warning light .........2-9
Battery charge warning light ........2-10
Blind Spot Intervention (BSI) warning
light......................5-46
Blind Spot Warning (BSW) warning
light......................5-37
Brake warning light ..............2-9 Distance Control Assist (DCA)
.......5-96
Hazard warning flasher switch ........6-2
Lane Departure Prevention . .5-26, 5-31, 5-34
Lane Departure Warning
light...............5-26,5-31,5-34
Loose fuel cap warning ...........2-27
Low fuel warning light ........2-12,2-27
Low tire pressure warning light .......2-10
Low windshield-washer fluid warning
light......................2-27
Passenger air bag and status light .....1-60
Seat belt warning light ........1-20,2-12
Supplemental air bag warning
light ..................1-69,2-12
Vehicle security system ...........2-30
Warning/indicator lights and audible
reminders .............2-8,2-9,2-13
Warning labels (for SRS) ..........1-68
Warning/indicator lights and audible
reminders...............2-8, 2-9, 2-13 Audiblereminders.........2-8,2-9,2-13
Indicatorlights...........2-8,2-9,2-13
Warning lights ...........2-8,2-9,2-13
Warning lights .............
2
-8,2-9,2-13
Warning lights, indicator lights and audible
reminders .....................2-8
Warning systems switch ............2-47
Washer switch Rear window wiper and washer
switches...................2-35
Weights (See dimensions and weights) ....10-9
Wheels and tires .................8-24
Wheel/tire size ..................10-9
When traveling or registering in another
country .....................10-10
Windows .....................2-60
11-7
