2017 DODGE JOURNEY TPMS

•After driving the vehicle for up to 20 minutes above
15 mph (24 km/h), the “Tire Pressure Monitoring Tell-
tale Light” will flash on and off for 75 seconds and then
remain on solid. In addition, the instrument cluster will
display a SERVICE TPM SYSTEM message for a mini-
mum of five seconds and then display dashes (- -) in
place of the pressure value.
• For each subsequent ignition switch cycle, a chime will
sound, the “Tire Pressure Monitoring Telltale Light” will
flash on and off for 75 seconds and then remain on solid,
and the instrument cluster will display a SERVICE TPM
SYSTEM message for a minimum of five seconds and
then display dashes (- -) in place of the pressure value.
• Once you repair or replace the original road tire and
reinstall it on the vehicle in place of the compact spare,
the TPMS will update automatically. In addition, the
“Tire Pressure Monitoring Telltale Light” will turn off
and the graphic in the instrument cluster will display a
new pressure value instead of dashes (- -), as long as no
tire pressure is below the low-pressure warning limit in
any of the four active road tires. The vehicle may need to
be driven for up to 20 minutes above 15 mph (24 km/h)
in order for the TPMS to receive this information.TPMS Deactivation — If Equipped
The TPMS can be deactivated if replacing all four wheel
and tire assemblies (road tires) with wheel and tire assem-
blies that do not have TPMS Sensors, such as when
installing Winter wheel and tire assemblies on your ve-
hicle. To deactivate the TPMS, first, replace all four wheel
and tire assemblies (road tires) with tires not equipped
with Tire Pressure Monitoring (TPM) Sensors. Then, drive
the vehicle for 10 minutes above 15 mph (24 km/h). The
TPMS will chime, the “TPM Telltale Light” will flash on
and off for 75 seconds and then remain on and the
instrument cluster will display the “SERVICE TPM SYS-
TEM” message and then display dashes (--) in place of the
pressure values. Beginning with the next ignition switch
cycle, the TPMS will no longer chime or flash the TPM
telltale and display the “SERVICE TPM SYSTEM” message
in the instrument cluster display but dashes (--) will remain
in place of the pressure values.
To reactivate the TPMS, replace all four wheel and tire
assemblies (road tires) with tires equipped with TPM
sensors. Then, drive the vehicle for up to 10 minutes above
15 mph (24 km/h). The TPMS will chime, the “TPM Telltale
Light” will flash on and off for 75 seconds and then turn
off, and the instrument cluster will display the “SERVICE
TPM SYSTEM” message. The instrument cluster will also
5
STARTING AND OPERATING 379

Exterior................................84
Fog .............................. .170, 468
Hazard Warning Flasher ...................404
Headlights ......................... .168, 467
Headlights On Reminder ...................170
Headlights On With Wipers ..............169, 175
Headlight Switch ........................ .168
High Beam ......................... .171, 467
High Beam/Low Beam Select ................171
Illuminated Entry .........................15
Instrument Cluster ...................... .168
Interior ............................... .172
License ............................... .471
Lights On Reminder ..................... .170
Low Fuel ............................. .238
Malfunction Indicator (Check Engine) ..........233
Map Reading .......................... .172
Park ............................. .240, 467
Passing ............................... .172
Reading .............................. .172
Rear Servicing .......................... .469
Rear Tail Lamps ........................ .469
Seat Belt Reminder ...................... .225
Security Alarm ......................... .228
Service ............................ .465, 467Side Marker
........................... .467
Tire Pressure Monitoring (TPMS) ..........235, 374
Traction Control ........................ .351
Turn Signal ................84, 171, 241, 467, 469
Vanity Mirror ............................93
Warning (Instrument Cluster Description) . . . .228, 241
Load Floor, Cargo ......................... .210
Loading Vehicle ....................... .387, 389
Capacities ............................. .389
Tires................................. .358
Load Shed Battery Saver Mode ...................... .248
Battery

Saver On ........................ .248
Electrical Load Reduction ...................248
Intelligent Battery Sensor ...................248
Locks ....................................22
Automatic Door ..........................24
Auto Unlock .............................24
Child Protection ..........................25
Door ..................................22
Power Door .............................23
Low Tire Pressure System .....................374
Lubrication, Body ......................... .441
Luggage Rack (Roof Rack) ....................216
498 INDEX

Aging (Life Of Tires)..................... .370
Air Pressure ........................... .362
Chains ............................... .371
Changing ............................. .407
Compact Spare ......................... .367
General Information ...................362, 366
High Speed ............................ .364
Inflation Pressures ....................... .363
Jacking ............................... .407
Life Of Tires ........................... .370
Load Capacity ...................... .358, 359
Pressure Monitor System (TPMS) .............374
Pressure Warning Light ....................235
Quality Grading ........................ .373
Radial ............................... .364
Replacement ........................... .370
Rotation .............................. .372
Safety ............................ .353, 362
Sizes ................................ .354
Snow Tires ............................ .365
Spare Tire ...................... .366, 368, 407
Spinning .............................. .369
Trailer Towing .......................... .396
Tread Wear Indicators .....................369
Tire Safety Information ...................... .353Tongue Weight/Trailer Weight
.................394
To Open Hood ........................... .166
Towing ................................. .389
Behind A Motorhome ..................... .400
Disabled Vehicle ........................ .423
Guide ................................ .393
Recreational ........................... .400
Weight ............................... .393
Towing Vehicle Behind A Motorhome ............400
T

raction ............................. .337, 338
Traction Control .......................... .348
Trailer Towing ............................ .389
Cooling System Tips ..................... .400
Hitches ............................... .392
Minimum Requirements ....................395
Tips ................................. .399
Trailer And Tongue Weight ..................394
Wiring ............................... .397
Trailer Towing Guide ....................... .393
Trailer Weight ............................ .393
Transaxle Autostick ............................. .336
Transmission Automatic ......................... .329, 451
Filter ................................ .453
504 INDEX
