2017 DODGE CHALLENGER hood release

WARNING!
•Do not start or run an engine in a closed garage or
confined area. Exhaust gas contains Carbon Monox-
ide (CO) which is odorless and colorless. Carbon
Monoxide is poisonous and can cause serious injury
or death when inhaled.
• Keep key fobs away from children. Operation of the
Remote Start System, windows, door locks or other
controls could cause serious injury or death.
Remote Start Abort Message
The following messages will display in the instrument
cluster if the vehicle fails to remote start or exits remote
start prematurely:
• Remote Start Aborted — Door Open
• Remote Start Aborted — Hood Open
• Remote Start Aborted — Trunk Open
• Remote Start Aborted — Fuel Low
• Remote Start Disabled — Start Vehicle To Reset
The instrument cluster message stays active until the
ignition is placed in the ON/RUN position.
To Enter Remote Start Mode
Push and release the Remote Start button on the key fob
twice within five seconds. The vehicle doors will lock, the
parking lights will flash, and horn will chirp twice (if
programmed). Then, the engine will start and the vehicle
will remain in the Remote Start mode for a 15-minute cycle.
NOTE:
• If an engine fault is present, the vehicle will start and
then shut down 10 seconds later.
• The park lamps will turn on and remain on during
Remote Start mode.
• For security, power window and power sunroof opera-
tion (if equipped) are disabled when the vehicle is in the
Remote Start mode.
• The engine can be started two consecutive times with
the key fob. However, the ignition must be activated by
pushing the keyless ignition button twice (or the ignition
must be placed in the ON/RUN position) before you can
repeat the start sequence for a third cycle.
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21

To Exit Remote Start Mode Without Driving The
Vehicle
Push and release the Remote Start button one time or allow
the engine to run for the entire 15-minute cycle.
NOTE:To avoid unintentional shut downs, the system will
disable the one time push of the Remote Start button for
two seconds after receiving a valid Remote Start request.
To Exit Remote Start Mode And Drive The Vehicle
Before the end of 15-minute cycle, push and release the
unlock button on the key fob to unlock the doors, or unlock
the vehicle using Passive Entry via the door handles, and
disarm the vehicle security alarm (if equipped). Then, prior
to the end of the 15-minute cycle, push and release the
keyless ignition button.
NOTE: In vehicles equipped with the Keyless Enter-N-Go
— Ignition feature, the message “Remote Start Active -
Push Start Button” will display. This message will clear
once the START button is pushed.
Cancel Remote Start
Remote Starting will also cancel if any of the following
occur:
• The engine stalls or engine speed exceeds 2500 rpm. •
Any engine warning lights come on.
• Low Fuel Light turns on.
• The hood is opened.
• The hazard switch is pushed.
• The gear selector is moved out of PARK.
• The brake pedal is pushed.
General Information
The following regulatory statement applies to all Radio
Frequency (RF) devices equipped in this vehicle:
This device complies with Part 15 of the FCC Rules and
with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, in-
cluding interference that may cause undesired opera-
tion.
NOTE: Changes or modifications not expressly approved
by the party responsible for compliance could void the
user ’s authority to operate the equipment.
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

When the seatback is folded to the upright position, make
sure it is latched by strongly pulling on the top of the
seatback above the seat strap.
WARNING!
•Be certain that the seatback is securely locked into
position. If the seatback is not securely locked into
position, the seat will not provide the proper stabil-
ity for child seats and/or passengers. An improperly
latched seat could cause serious injury.
(Continued)
WARNING! (Continued)
•The cargo area in the rear of the vehicle (with the rear
seatbacks in the locked-up or folded down position)
should not be used as a play area by children when
the vehicle is in motion. They could be seriously
injured in a collision. Children should be seated and
using the proper restraint system.
TO OPEN AND CLOSE THE HOOD
Two latches must be released to open the hood.
1. Pull the hood release lever located under the left side of the instrument panel.
Folded Rear Seat
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

2. Move to the outside of the vehicle, the safety catch islocated under the center front edge of the hood. 3. Push the safety catch to the left.
Hood Release LeverHood Safety Catch Location
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103

5. Close the filter access cover.
Refer to the “Maintenance Schedule” for the proper main-
tenance intervals.
Body Lubrication
Locks and all body pivot points, including such items as
seat tracks, door hinge pivot points and rollers, liftgate,
tailgate, decklid, sliding doors and hood hinges, should be
lubricated periodically with a lithium based grease, such as
Mopar Spray White Lube to assure quiet, easy operation
and to protect against rust and wear. Prior to the applica-
tion of any lubricant, the parts concerned should be wipedclean to remove dust and grit; after lubricating excess oil
and grease should be removed. Particular attention should
also be given to hood latching components to ensure
proper function. When performing other underhood ser-
vices, the hood latch, release mechanism and safety catch
should be cleaned and lubricated.
The external lock cylinders should be lubricated twice a
year, preferably in the Fall and Spring. Apply a small
amount of a high quality lubricant, such as Mopar Lock
Cylinder Lubricant directly into the lock cylinder.
Windshield Wiper Blades
Clean the rubber edges of the wiper blades and the
windshield periodically with a sponge or soft cloth and a
mild nonabrasive cleaner. This will remove accumulations
of salt or road film.
Operation of the wipers on dry glass for long periods may
cause deterioration of the wiper blades. Always use washer
fluid when using the wipers to remove salt or dirt from a
dry windshield.
Avoid using the wiper blades to remove frost or ice from
the windshield. Keep the blade rubber out of contact with
petroleum products such as engine oil, gasoline, etc.A/C Air Filter
7
MAINTAINING YOUR VEHICLE 427

Washers.............................. .428
Headlight Washers ......................... .428
Head Restraints ............................99
Head Rests ................................99
Heated Mirrors .............................86
Heater ................................. .269
Heater, Engine Block ....................... .303
High Beam/Low Beam Select (Dimmer) Switch .....109
Hill Start Assist ........................... .327
Hitches Trailer Towing .......................... .374
HomeLink (Garage Door Opener) ...............150
Hood Release ............................ .102
Ignition Key....................................9
Illuminated Entry ...........................16
Immobilizer (Sentry Key) ......................12
Information Center, Vehicle ...................199
Inside Rearview Mirror .......................79
Instrument Cluster ............171, 178, 180, 191, 194
Instrument Cluster Display Instrument Cluster Display ..................202
Instrument Panel And Controls .................170
Instrument Panel Lens Cleaning ................443Interior Appearance Care
.....................442
Interior Lights .............................110
Intermittent Wipers (Delay Wipers) ..............112
Introduction ................................4
iPod Control ............................. .265
iPod/USB/MP3 Control ..................... .265
Bluetooth Streaming Audio .................265
Jacking Instructions ........................ .395
Jack Location ............................ .393
Jack Operation ........................ .392, 395
Jump Starting ..................... .399, 400, 401
KeyFob...................................9 Arm The Alarm ..........................14
Lock The Doors ..........................17
Panic Alarm .............................18
Programming Additional Key Fobs ..........13, 18
Remote Keyless Entry ......................16
Unlatch The Trunk ........................17
Unlock

The Doors .........................16
Key Fob Battery Service (Remote Keyless Entry) .....18
Key Fob Programming (Remote Keyless Entry) ......18
Key Fob, Remote Keyless Entry .................16
Key-In Reminder ............................10
492 INDEX

Deck Lid Release.........................30
Distribution Center (Fuses) ..................449
Door Locks ..............................24
Mirrors ................................85
Outlet (Auxiliary Electrical Outlet) ............159
Seats ..................................94
Steering .............................. .321
Sunroof .............................. .157
Tilt/Telescoping Steering Column .............115
Windows ...............................29
Power Seats Down .................................95
Forward ................................94
Power Lumbar ...........................95
Rearward ...............................94
Tilt ...................................95
Up....................................95
Power Steering Fluid ...........462, 463, 464, 465, 466
Pregnant Women And Seat Belts .................40
Preparation For Jacking ..................... .394
Pretensioners Seat Belts ...............................40
Programmable Electronic Features ...............213
Programmable Features ...................212, 213 Radial Ply Tires
........................... .347
Radiator Cap (Coolant Pressure Cap) .............432
Radio Frequency General Information .............11,13,20,22,29
Radio Operation .......................... .267
Radio Remote Controls ..................... .266
Radio (Sound Systems) .......................211
Rain Sensitive Wiper System ...................113
Rear Camera ............................. .147
Rear Cupholder ........................... .164
Rear ParkSense System ..................... .140
Rear Seat, Folding ......................... .101
Rear Window Defroster ..................... .166
Rear Window Features ...................... .166
Recreational Towing ........................ .380
Reformulated Gasoline ...................... .365
Refrigerant .............................. .425
Release, Hood ............................ .102
Reminder, Lights On ....................... .107
Reminder

, Seat Belt ..........................34
Remote Control Starting System ...........................20
Remote Keyless Entry Arm The Alarm ..........................14
Lock The Doors ..........................17
496 INDEX

Replacement........................ .353, 398
Rotation .............................. .355
Safety ............................ .335, 345
Sizes ................................ .336
Snow Tires ............................ .348
Spare Tire ...................... .349, 351, 393
Spinning .............................. .352
Trailer Towing .......................... .376
Tread Wear Indicators .....................352
Wheel Mounting ........................ .398
Tire Safety Information ...................... .335
Tire Service Kit ............383, 384, 385, 387, 389, 390
Tongue Weight/Trailer Weight .................375
To Open Hood ........................... .102
Towing ................................. .371
Disabled Vehicle ........................ .406
Guide ................................ .374
Recreational ........................... .380
Weight ............................... .374
Towing Vehicle Behind A Motorhome ............380
Traction ................................ .318
Traction Control .......................... .329
Trailer Towing ............................ .371
Cooling System Tips ..................... .380
Hitches ............................... .374Minimum Requirements
....................375
Tips ................................. .379
Trailer And Tongue Weight ..................375
Wiring ............................... .378
Trailer Towing Guide ....................... .374
Trailer Weight ............................ .374
Transfer Case ............................ .438
Fluid ............................. .438, 463
Maintenance ........................... .438
Transmission ............................. .437
Automatic ...................... .308,

309, 437
Fluid .................437, 462, 463, 464, 465, 466
Manual ............................... .304
Shifting .............................. .308
Transporting Pets ...........................68
Tread Wear Indicators ...................... .352
Trunk Lid (Deck Lid) ..................... .30, 31
Trunk Release, Emergency .....................31
Trunk Release Remote Control ..................30
Turn Signals .......................... .108, 194
Uconnect Customer Programmable Features .........223, 241
Operation ..............................211
Uconnect Settings ..................17, 223, 241
500 INDEX
