C4-Picasso-II_en_Chap00a_sommaire_ed02-2016
General safety recommendations 229
Hazard warning lamps
2
30
Horn

2
30
Emergency or assistance

2
31
Electronic stability control (ESC)

2
33
Seat belts
23

6
Airbags
2

41
Child seats

2
45
Deactivating the passenger's front airbag

2
47
ISOFIX mountings

2
54
Child lock

2
61
Safety
Fuel 26 2
Misfuel prevention (Diesel)
2
63
Snow chains

2
65
Very cold climate screen(s)

2
66
Towbar with quickly detachable towball

2
67
Towing a trailer

2
69
Energy economy mode

2
70
Changing a wiper blade

2
71
Roof bars

2
72
B o n n e t
2

74
Petrol engines

2
75
Diesel engines

2
76
Checking levels

2
77
Checks

2
80
AdBlue
® additive and SCR system
(BlueHDi Diesel) 2 82
Practical information
Warning triangle 2 86
Temporary puncture repair kit
2
87
Spare wheel

2
94
Changing a bulb

3
04
Changing a fuse

3
13
12 V battery

3
18
To w i n g
3

2 2
Running out of fuel (Diesel)

3
24
In the event of a breakdown
Petrol engines 325
Petrol weights
3
27
Diesel engines

3
29
Diesel weights

3
31
Dimensions
3

33
Identification markings
3

34
Technical data
Mirrors 2 08
Lighting control stalk
2
11
Automatic illumination of headlamps

2
16
Automatic headlamp dipping

2
17
Daytime running lamps

2
19
Direction indicators

2
20
Adjusting the headlamp beam height

2
20
Directional lighting
2

22
Wiper control stalk

2
23
Screenwash

2
25
Automatic rain sensitive wipers

2
26
Panoramic sunroof

2
28
Lighting and visibility Alphabetical index
For the audio and telematic systems,
refer to the supplement to the handbook
or go to the following internet address:
http://service.citroen.com/ddb/
Contents

18
C4-Picasso-II_en_Chap01_instruments-bord_ed02-2016
Monochrome digital instrument panel
1. Rev counter (x 1 000 rpm or tr/min), graduation depending on engine (petrol or
Diesel).
2.
G

ear efficiency indicator, selector position
and gear for an automatic gearbox.
3.
D

igital speedometer (mph or km/h).
4.
C

ruise control or speed limiter settings.
Dials and screens
5. Fuel gauge.
6. Service indicator, then total mileage
recorder (miles or km).
T

hese functions are displayed in turn when
the ignition is switched on.
7.
T

rip recorder (miles or km).
8.
R

ecall of heating and air conditioning
settings. A. M
ain lighting dimmer buttons.
B. R ecall of servicing information.
R

esetting of the function selected to zero
(service indicator or trip recorder).
R

ecall of the remaining driving range with
the SCR system and the AdBlue
®. W
arning log (current warnings).
Control buttons
Instruments

19
C4-Picasso-II_en_Chap01_instruments-bord_ed02-2016
This instrument panel can be personalised. Depending on the display mode selected, some information can be hidden.
12-inch HD colour instrument panel
1. Rev counter (x 1000 tr/min or rpm) ("Dials" m ode).
2.
G

ear efficiency indicator, selector position
and gear for an automatic gearbox.
3.
D

igital speedometer (mph or km/h).
4.
C

ruise control or speed limiter setting. A. R
ecall of servicing information. R
ecall of the remaining driving range with
the SCR system and the AdBlue
®. R
esetting of the function selected to zero
(service indicator or trip recorder).
Control button
Dials and screens
5. Fuel gauge.
6. T
otal distance recorder (miles or km).
7.
T

rip recorder (miles or km).
8.
R

epeat of the current media or telephone
information.
9.
R

epeat of the trip computer information.
10.
E

xterior temperature (a blue warning lamp
comes on if there is a risk of ice).
1
Instruments

29
C4-Picasso-II_en_Chap01_instruments-bord_ed02-2016
Warning / indicator lampStateCause Action / Observations
or Service
temporarily,
accompanied by the
display of a message. One or more minor faults for which
there is no specific warning lamp
have been detected. Identify the cause of the fault using the message
displayed in the instrument panel.
You can deal with some problems yourself, such as a
door open or the start of saturation of the particle filter
(as soon as the traffic conditions allow, regenerate
the filter by driving at a speed of at least 40 mph
(60
km/h), until the warning lamp goes off).
For any other problems, such as a fault with the tyre
under inflation detection system, contact a CITROËN
dealer or a qualified workshop.
fixed, accompanied
by the display of a
message. One or more major faults for which
there is no specific warning lamp
have been detected. Identify the cause of the fault using the message
displayed in the instrument panel; you must then
contact a CITROËN dealer or a qualified workshop.
fixed, associated with the
flashing and then fixed
display of the service
indicator spanner.The servicing interval has been
exceeded.
Only on BlueHDi Diesel versions.
Your vehicle must be serviced as soon as possible.
1
Instruments

30
C4-Picasso-II_en_Chap01_instruments-bord_ed02-2016
Assisted Lane
Departure
Warning Systemfixed.
The system is not availableThe system has been deactivated or is on automatic
st a n dby.
For more information on the Assisted Lane Departure
Warning System, refer to the corresponding section.
flashing. You are about to cross a solid lane
marking without operating the
direction indicators. The system is activated, then corrects the trajectory
on the side of the lane marking detected.
+ fixed, accompanied
by the display of a
message, an audible
signal and the Service
warning lamp.The system has a fault.
Be vigilant and drive carefully.
Have the system checked by a CITROËN dealer or a
qualified workshop.
For more information on the Assisted Lane
Departure Warning System, refer to the
corresponding section.
Warning / indicator lamp
StateCause Action / Observations
Braking fixed. The brake fluid level has dropped
significantly. You must stop as soon as it is safe to do so.
Top-up with brake fluid listed by CITROËN.
If the problem persists, have the system checked by
a CITROËN dealer or a qualified workshop.
+ fixed, associated
with the ABS warning
lamp.The electronic brake force distribution
(EBFD) system has a fault.
You must stop as soon as it is safe to do so.
Have it checked by a CITROËN dealer or a qualified
workshop.
Anti-lock
Braking System
(ABS) fixed.
The anti-lock braking system has a
fault. The vehicle retains conventional braking.
Drive carefully at reduced speed and contact a
CITROËN dealer or a qualified workshop without
d e l ay.
Instruments

35
C4-Picasso-II_en_Chap01_instruments-bord_ed02-2016
Under-inflationfixed, accompanied by
an audible signal and
a message. The pressure in one or more tyres is
too low.
Check the tyre pressures as soon as possible.
This check should preferably be carried out when the
tyres are cold.
You must reinitialise the system after the adjustment
of one or more tyre pressures and after changing one
or more wheels.
For more information on Under-inflation detection
,
refer to the corresponding section.
+ flashing then fixed,
accompanied by the
Service warning lamp.The system has a fault: the tyre
pressures are no longer monitored.
Check the tyre pressures as soon as possible.
Have the system checked by a CITROËN dealer or a
qualified workshop.
Warning / indicator lamp
StateCause Action / Observations
Foot on the
brake pedal *fixed.
The brake pedal is not pressed. With an automatic gearbox, press the brake pedal to
move the gear selector out of position P.
Foot on the
clutch* fixed.
In the STOP mode of Stop & Start,
changing to START mode is denied
because the clutch pedal is not fully
down. You must declutch fully to allow the change to engine
START mode.
* Only with the monochrome digital instrument panel.
1
Instruments

36
C4-Picasso-II_en_Chap01_instruments-bord_ed02-2016
Warning / indicator lampStateCause Action / Observations
AdBlue
®
(BlueHDi Diesel) fixed, on switching
on the ignition,
accompanied by an
audible signal and a
message indicating the
remaining driving range. The remaining driving range is
between 350 miles (600 km) and
1500 miles (2400 km).
Top-up the AdBlue® as soon as possible or go to a
CITROËN dealer or a qualified workshop.
+ flashing, associated
with the SERVICE
warning lamp,
accompanied by an
audible signal and a
message indicating the
remaining driving range.The remaining driving range is
between 0 and 350 miles (600 km).
You must top-up the AdBlue
® to avoid a breakdown

or go to a CITROËN dealer or a qualified workshop.
flashing, associated
with the SERVICE
warning lamp,
accompanied by an
audible signal and a
message indicating that
starting is prevented. The AdBlue
® tank is empty: the
starting inhibition system required
by legislation prevents starting of the
engine. To be able to start the engine, you must top-up
the
AdBlue® or call on a CITROËN dealer or a qualified
workshop.
It is essential to add at least 3.8 litres of AdBlue
® to
the fluid tank
For topping-up or for more information on AdBlue
® and the SCR system , refer to the corresponding section.
Instruments

37
C4-Picasso-II_en_Chap01_instruments-bord_ed02-2016
Warning / indicator lampState CauseAction / Observations
+
+ SCR emissions
control system

(BlueHDi Diesel) fixed, on switching on the ignition,
associated with the SERVICE and
engine diagnostic warning lamps,
accompanied by an audible signal and
a message. A fault with the SCR emissions control
system has been detected.
This alert disappears once the
exhaust emissions return to normal
levels.
flashing, on switching on the ignition,
associated with the SERVICE and
engine diagnostic warning lamps,
accompanied by an audible signal and
a message indicating the remaining
driving range. After confirmation of the fault with the
emissions control system, you can
drive for up to 650 miles (1 100 km)
before the engine starting inhibition
system is triggered.
Contact a CITROËN dealer or a
qualified workshop
without delay,
to avoid a breakdown .
flashing, on switching on the ignition,
associated with the SERVICE and
engine diagnostic warning lamps,
accompanied by an audible signal and
a message. You have exceeded the authorised
driving limit following confirmation
of a fault with the emissions control
system: the engine starting inhibition
system prevents starting of the
engine.To be able to start the engine, you
must
call on a CITROËN dealer or a
qualified workshop.
1
Instruments
