F Pull the strap B and guide the seat to the r e a r.
The backrest reclines and the seat base pivots
s li g ht l y.
"Comfort" position
Returning the seat to the initial
position
F Pull the strap B and guide the seat for ward.
Super vise any movements of seats
when made by children. To remove it:
- m
ove the head restraint to the high position,
-

p
ress lug A pulling the head restraint
upwards at the same time.
The rear head restraints can be removed and
have two positions:
-

h
igh, position for use,
-
l
ow, stowed position.
To raise a head restraint, pull it upwards.
To lower it, press lug A then the head restraint.
Rear head restraints
Never drive with the head restraints
removed; they must be in place and
correctly adjusted.
To refit it:
-

e

ngage the head restraint rods in the
apertures, keeping them in line with the
seat backrest. Depending on version, the sides can be folded
to obtain a more comfortable position.
Relax head restraints
3
Ease of use and comfort

88
C4-Picasso-II_en_Chap03_ergonomie-confort_ed02-2016
Access to the third-row
seats
Access to the third-row seats is via the outer
second-row seats.
F
P
ull the lever E . The seat is released and
the seat cushion comes up against the
backrest.
F

H
old the lever E in the raised position,
pushing for wards. The whole seat slides
towards the front seat.
Space becomes free behind the seat, the
third-row passengers can get to their seats.
Leaving the vehicle from
the third-row seats Repositioning a seat, from
the outside, with the door
open
In the event of a failure of this system
(lever E
), the passengers in the third
row can also leave the vehicle after first
folding the backrests of the second-row
seats using the strap D .
Do not allow children to operate the
seats without supervision.
F

L

ift the lever E
. The seat is released and
the seat cushion comes up against the
backrest.
F

P

ush the seat backrest, still holding the
lever E in the raised position. If there are passengers seated in the third row:
F

m

anually return the assembly as far
as possible rear wards; the seat does
not return to the fully back position, so
as to retain legroom for the third-row
passengers,
F

f

old the seat cushion until it locks.
Ensure that there is no object on or under the
seat that you want to move.
Before operating the seats, ensure that
the tables on the backs of the first-row
seats are folded away.
Ease of use and comfort

94
C4-Picasso-II_en_Chap03_ergonomie-confort_ed02-2016
Ventilation
Air intake
The air circulating in the passenger
compartment is filtered and originates either
from the outside via the grille located at the
base of the windscreen or from the inside in air
recirculation mode.
Air treatment
The incoming air follows various routes
depending on the controls selected by the
driver:
-
d
irect arrival in the passenger
compartment (air intake),
-

p
assage through a heating circuit (heating),
-

p
assage through a cooling circuit (air
conditioning).
Control panel
The controls of this system are accessible
in the Air conditioning menu of the touch
screen


A.
The demisting/defrosting controls for the
windscreen and rear screen are located on the
left of the touch screen. 1. W
indscreen demisting-defrosting vents.
2. F ront quarter light demisting-defrosting
vents.
3.
F

ront side window demisting-defrosting
vents.
A

djustable side air vents.4. C
entral adjustable air vents.
5. A ir outlets for the front footwells.
6.
S

ide vents for the 2
nd row.
7. A
ir outlets for 2nd row footwells.
8. S
unshine sensor.
Air distribution
Ease of use and comfort

95
C4-Picasso-II_en_Chap03_ergonomie-confort_ed02-2016
In order for these systems to be fully effective, follow the operation and maintenance
guidelines below:
F
T
o obtain an even air distribution, take care not to obstruct the exterior air intake grilles
located at the base of the windscreen, the nozzles, the vents and the air outlets, as well
as the air extractor located in the boot.
F

D
o not cover the sunshine sensor, located on the dashboard; this is used for regulation
of the air conditioning system.
F

O
perate the air conditioning system for at least 5 to 10 minutes, once or twice a month
to keep it in per fect working order.
F

E
nsure that the passenger compartment filter is in good condition and have the filter
elements replaced regularly.
W

e recommend the use of a combined passenger compartment filter. Thanks to its
special active additive, it contributes to the purification of the air breathed by the
occupants and the cleanliness of the passenger compartment (reduction of allergic
symptoms, bad odours and greasy deposits).
F

T
o ensure correct operation of the air conditioning system, you are also advised to have
it checked regularly as recommended in the maintenance and warranty guide.
F

I
f the system does not produce cold air, switch it off and contact a CITROËN dealer or a
qualified workshop.
Recommendations for ventilation and air conditioning
If after an extended stop in sunshine,
the interior temperature is very high, first
ventilate the passenger compartment for
a few moments.
Put the air flow control at a setting high
enough to quickly change the air in the
passenger compartment.
The condensation created by the air
conditioning results in a discharge
of water under the vehicle which is
per fectly normal.
When towing the maximum load on a steep gradient in high temperatures, switching off the
air conditioning increases the available engine power and so improves the towing ability.
Stop & Start
The heating and air conditioning
systems only work when the engine is
running.
To maintain a comfortable temperature
in the passenger compartment, you can
temporarily deactivate the Stop & Start
system.
For more information on Stop & Star t ,
refer to the corresponding section.
3
Ease of use and comfort

101
C4-Picasso-II_en_Chap03_ergonomie-confort_ed02-2016
In cold weather with the engine cold,
the air flow is increased gradually until
the system has warmed up, in order
to limit the delivery of cold air into the
passenger compartment.
On entering the vehicle, if the interior
temperature is much colder or warmer
than the comfort value setting, there
is no need to alter the value displayed
in order to reach more quickly the
required level of comfort. The system
compensates automatically and
corrects the temperature difference.
This setting is associated with AUTO mode
only. However, on deactivation of AUTO mode,
the last setting remains on.
Changing the setting does not reactivate AUTO
mode if deactivated.
When the indicator lamp in the button is on, the
air conditioning system operates automatically:
the system manages the temperature, air
flow and air distribution in the passenger
compartment in an optimum way according to
the comfort level selected.
You can always choose to modify a setting
manually. In this case the indicator lamp in the
button is off.
F

P

ress this button again to activate the
automatic comfort programme again. F

P

ress this button to activate or
deactivate the automatic mode of
the air conditioning system.
Automatic comfort
programme
To change the current setting, press the button
to display the different modes in turn:
"SOFT": provides soft and quiet operation by
limiting air flow.
"NORMAL": offers the best compromise
between a comfortable temperature and quiet
operation (default setting).
"FAST": provides strong and effective air flow.
It is possible to modulate the intensity of the
automatic comfort programme by choosing one
of the mode settings offered in the secondary
page of the Air conditioning
menu.
F

P

ress this button to go to the
secondary page.
3
Ease of use and comfort

109
C4-Picasso-II_en_Chap03_ergonomie-confort_ed02-2016
Removable console
The removable console is a portable storage space secured to the lower centre console.
It has a sliding lid, an open storage space and two cup holders.
F
R
aise the locking control located at the
front of the console.
F

W
ith one hand, lift the front part of the
console.
F

W
ith the other hand, grasp the rear part to
release the removable console. F

C
arry out these operations in reverse
order. Ensure that the console has locked
into place.
When not fixed to its carrier, the
removable console should be stowed
in the boot. It could become a projectile
in the event of a sudden stop or violent
impact.
Releasing the removable
console Refitting the removable
console
3
Ease of use and comfort

111
C4-Picasso-II_en_Chap03_ergonomie-confort_ed02-2016
When the USB port is used, the
portable device charges automatically.
A message is displayed if the power
consumption of the portable device
exceeds the current supplied by the
vehicle.
12 V socket
The auxiliary socket is located in the central
storage box.
It permits the connection of a portable device,
such as a digital audio player of the iPod
® type,
to listen to your music files using the vehicle's
speakers.
The management of the files is done using your
portable device. The USB port is located in the central storage
compartment.
It allows the connection of a portable device or
a USB memory stick.
It plays the audio files transmitted to your audio
system and heard via the vehicle's speakers.
You can manage these files using the steering
mounted or touch screen controls.
Auxiliary socket
USB port
For more information on the use of this
equipment, refer to the "Audio and telematics"
supplement.
F

T

o connect a 12 V accessory (maximum
power: 120 Watts), lift the cover and
connect a suitable adaptor.
Do not exceed the maximum power
rating of the socket (other wise there is a
risk of damaging your portable device).
The connection of an electrical device
not approved by CITROËN, such as a
USB charger, may adversely affect the
operation of vehicle electrical systems,
causing faults such as poor telephone
reception or inter ference with displays
in the screens.
3
Ease of use and comfort

113
C4-Picasso-II_en_Chap03_ergonomie-confort_ed02-2016
Storage below
the steering wheel
This storage compartment below the steering
wheel is intended for stowing your vehicle's
handbook pack.
Rear fittings
Aircraft-style rear tables
These tables, fitted to the backs of the front
seats, incorporate a cup-holder recess A and a
retaining strap B .
F

P
ull the table downwards to open.
F

T
o stow the table, raise it until the latch
locks.
For safety reasons, these tables collapse
downwards if excessive pressure is exerted on
them. Reading lamps C may be fitted in the front seat
backrests, behind the tables. They illuminate
the sur face of the tables without disturbing the
other passengers.
They can be used only while the table is down.
F

P
ress the "
On/Of
f " button to turn the lamp
on or off.
Individual reading lamps
Rear table stowed
Rear table opened
3
