2017 CITROEN DS3 CABRIO technical data

Technical data22
DS3-Cabrio_en_Chap10_caracteristiques_ed02-2015
Diesel engineBlueHDi 100 S&SBlueHDi 120 S&SBlueHDi 115 S&S **
Gearbox Manual (5-speed) Manual (6-speed)
Model code: SB... BHY6/S BHZM/S BHXM/S **
Cubic capacity (cc) 1 560 1 560
Bore x stroke (mm) 75 x 88.3 75 x 88.3
Max power: EU standard (kW) * 73 88 85 **
Max power engine speed (rpm) 3 750 3 500
Max torque: EU standard (Nm) 254 300
Max torque engine speed (rpm) 1 750 1 750
Fuel Diesel Diesel
Catalytic converter Ye s Ye s
Particle filter (FAP) Ye s Ye s
Engine oil capacity (in litres) (with filter replacement) 3.75 3.75
.../S: model fitted with Stop & Start
Diesel engines
* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC). ** For Belgium.

23Technical data
DS3-Cabrio_en_Chap10_caracteristiques_ed02-2015
Diesel engineBlueHDi 100 S&SBlueHDi 120 S&SBlueHDi 115 S&S **
Gearbox Manual (5-speed) Manual (6-speed)
Model code: SB... BHY6/S BHZM/S BHXM/S **
- Unladen weight 1 148 1 200
- Kerb weight 1 223 1 275
- Gross vehicle weight (GV W) 1 652 1 665
- Gross train weight (GTW) on a 12 % gradient 2 552 2 565
- Braked trailer (within GTW limit) on a 12 % gradient 900 900
- Braked trailer * (with load transfer with the GTW limit) 1 150 1 150
- Unbraked trailer 570 570
- Recommended nose weight 46 46
* The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount. Warning: towing using a lightly loaded towing vehicle may have an adverse effect on its road holding. ** For Belgium.
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude. The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country). High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C, limit the towed load.
Diesel weights and towed loads (in kg)

Technical data24
DS3-Cabrio_en_Chap10_caracteristiques_ed02-2015

Dimensions (in mm)

25Technical data
DS3-Cabrio_en_Chap10_caracteristiques_ed02-2015
Dimensions (in mm) - GT RACING
Bumpers and lower body
Your vehicle has reduced ground clearance. Take care when traversing kerbs, speed humps, access ramps, fords, unmade roads…
