Range indicators
Rules on the display of alertsFor more information on the
displays and warning lamps, refer
to chapter 3, "Instruments and
controls"
  section. Range greater than 1 500 miles
(2 400 km)
No
  information   displayed.
Once   the   1   500   miles   (2   400   km)
threshold is reached, the UREA


warning lamp comes on temporarily
and the remaining range message is
displayed.
The alert is repeated every 200 miles
(300
  km)   until   the   next   threshold   is
reached.
Every time the ignition is switched
on, the alert is given, together with an
audible

  signal.
Remaining range less than
1
500 miles (2 400 km) and greater
than 350 miles (600 km)
Driving range
With
  the   touch   screen   tablet:
If the range is greater than 3 100 miles
(5
  000   km),   a   range   value   is   not   given.
Press this button to display
the
  information.
-

select the "Driving
assistance" menu,
-


select "Diagnostic",
-


select
  CHECK.
Different levels of alert are triggered
according to the remaining driving
range threshold
You will be informed as each mileage
threshold is reached and the alerts will
change
  from   temporary   to   permanent.
-

The 1st is triggered at a remaining
driving range of 1 500 miles
(2

400
  km).
-

The 2nd is triggered at a remaining
driving range of 350 miles
(600

km).
-

Up to 0 miles, at which point it will
be impossible to restart the engine
after


a

stop.
AdBlue®

 167
Berlingo2VP_en_Chap07_Verification_ed02-2016Berlingo2VP_en_Chap07_Verification_ed02-2016
Once the 350 miles (600 km) threshold is reached, the UREA warning lamp
flashes
  and   the   Service   warning   lamp
comes on, accompanied by a message
on

  the   remaining   driving   range.
The alert is repeated every 30 seconds
with an update of the remaining driving
range
  in   steps   of   30   miles   (50   km)
travelled.
Every time the ignition is switched
on, the alert is given together with an
audible

  signal.
At 0 miles the system installed in
the vehicle to meet the emissions
standard will prevent engine
starting. Your vehicle's exhaust emissions no
longer meet the "Euro 6" standard and
the
  engine   will   not   start.
To be able to restart the vehicle, you
must add at least 4 litres of AdBlue
®.
-

Pour


the

additive

into

the

tank

(by
the


filler

with

the

blue

cap).
-

Switch on the ignition without
starting.
-


W

ait 10 seconds before starting the
engine.
Remaining range less than 350 miles
(600 km) and more than 0 miles
Starting prevented, breakdown related
to a lack of AdBlue
®
in the special tank
The

0

fluid

level

has   been   reached.
Avoid waiting until the
remaining range is 0 miles!
The alert is repeated when driving until
the AdBlue
® tank has been topped-up with

sufficient   additive.
Unless the additive in the special
additive

tank   is   topped-up,   you   risk
immobilisation

  of   the   vehicle. Following
  this,   make   a   further   fill  to
  the   special   additive   tank,   the
capacity of which is

17 litres.
Fault with the SCR system
The UREA, Service and diagnostic
warning  lamps   comes   on.
Every time the ignition is switched on,
the
  emissions   fault   is   confirmed   by   an
audible

  signal   and   a   message.
If it is a temporary fault, the alert
disappears as soon as the exhaust
emissions return to the levels required
by
  the   standard.
Detection
On the other hand, if the warning
lamps are still on after 30 miles
(50   km)   of   driving,   the   fault   is
confirmed.
An engine start prevention system
will be activated automatically after
650 miles

  (1   100   km)   travelled
following

  this   confirmation.
Go
  to   a   CITROËN   dealer   or   a   qualified
workshop.
Or go to a CITROËN dealer or a
qualified


workshop.
CHECKS
7
AdBlue®

168
Berlingo2VP_en_Chap07_Verification_ed02-2016Berlingo2VP_en_Chap07_Verification_ed02-2016
Fault confirmed
In addition to the previous signals,
the  UREA

warning   lamp   flashes   and
the remaining range allowed will be
displayed

  in   miles   (kilometres).
The alert will be repeated every
30
seconds with an update of the
driving range in steps of 30 miles
(50 km).
Go
  to   a   CITROËN   dealer   or   a   qualified
workshop

  as   soon   as   possible.
You
  risk   not   being   able   to   start   the
engine.
Starting prevented, having
covered the 650 miles (1 100 km)
At each attempt at starting, the alert is
activated and the message "Emissions
fault:

  Starting   prevented"   is   displayed.Refilling / Topping-up the
AdBlue®
Precautions to take
Use only AdBlue ® that meets the
ISO

22241

standard.
The AdBlue
® fluid is an urea-based solution.
This

fluid

is

non-flammable,   colourless
and


odourless.
To

be

kept

in
  a   cool   area.
Containers (5 or 10 litres) and
bottles (1.89 litres) of AdBlue
®
Please check the use-by date.
Read   the   instructions   on   the   label.
Ensure that you have a suitable
filler
  pipe,   which   may   or   may   not   be
supplied

  with   the   container. In
  the   event   of   an   overflow,   wipe
around

  the   filler   mouth   using   a
damp

  cloth.
If any AdBlue
® fluid is split or splashed on to you, wash immediately with cold
water or wipe yourself with a clean
damp

cloth.
If

the

fluid

has
  crystallised,   clean   it   off
using


a

sponge   and   hot   water.
To

facilitate   filling,   an   adaptor   is
available


from   CITROËN   dealers.
AdBlue®

169
Berlingo2VP_en_Chap07_Verification_ed02-2016Berlingo2VP_en_Chap07_Verification_ed02-2016
Filling
Ensure that the vehicle is parked on a flat  and   level   surface.
Pour
  the   contents   of   the   container   /
bottle

  into   the   dedicated   tank.
After
  filling   the
AdBlue® tank, observe the

following

procedure:
-

Switch on the ignition without
starting.
-


W

ait 10 seconds before starting the
engine.
Never dispose of empty AdBlue
®
containers and bottles in the
household

waste.
Place them in a special container
provided

this

purpose

or

take

them

to
your


dealer. Keep AdBlue
® out of the
reach of children, in its original
container.
Never transfer AdBlue
® to another
container:

it

would

loose   its   purity.
Never

dilute

the

fluid

with   water.
Never

pour

the

fluid

into   the   Diesel   fuel
tank.
Recommendations on storage
Never store containers or bottles of
AdBlue® in your vehicle.
Freezing of the AdBlue
®
AdBlue® freezes at about -11°C (12.2° F) and

deteriorates   above   25°C   (77°F).
It is recommended that containers and
bottles be stored in a cool area and
protected
  from   direct   sunlight.
Under

these   conditions,   the   fluid   can
be


kept
  for   at   least   a   year.
Additive that has been frozen can
be used once it has thawed out in
ambient air. The SCR system includes an
AdBlue
® tank heater that ensures operation of the vehicle in normal
conditions.
In exceptional situations, such as when
the

vehicle

is   kept   at   temperatures
below -15°C (5°F) for a long period,
there may be an emission fault alert
related to freezing of the

AdBlue
®
additive.
Park

the

vehicle

in

an

area

at

a

more
moderate temperature for a few hours
until

the AdBlue
® becomes a fluid again.
The emissions warning lamp does not
go of
f immediately, but does so after a
few

miles

of

driving.
CHECKS
7
AdBlue®

170
Berlingo2VP_en_Chap08_Aide-rapide_ed02-2016
BATTERY
Before disconnecting the battery, you
must wait for 2 minutes after switching
off  the   ignition.
Never disconnect a terminal when the
engine
  is   running.
Never
  charge   a   battery   without   first
disconnecting

  the   terminals.
After every reconnection of the battery,
switch on the ignition and wait 1 minute
before starting to allow the electronic
systems
  to   be   initialised.   If   problems
remain after doing this, please contact
a

  CITROËN   dealer   or   a   qualified
workshop.
After changing bulbs, wait
approximately 3 minutes before
reconnecting

  the   battery.
It is advisable to disconnect the
battery if the vehicle is not to be
used for a period of more than
one month.
To charge the battery using a
battery charger
- Disconnect  the   battery.
-
Follow the instructions for use
given by the battery charger
manufacturer

.
-

Reconnect starting with the
negative

  (-)   terminal.
-

Check
  that   the   terminals   and
connectors

  are   clean.   If   they   are
covered with sulphate (white or
greenish deposit), disconnect them
and

  clean   them.
To start the vehicle from
another battery
- Connect the red cable to the
positive (+) terminals of the
two batteries.
-

Connect one end of the green
or

  black   cable   to   the   negative   (-)
terminal

  of   the   slave   battery.
-

Connect the other end of the green
or

  black   cable   to   an   earth   point   on
the

  broken   down   vehicle   as   far   as
possible

  from   the   battery.
-
 Operate

  the   starter,   let   the   engine   run.
-

W
ait for the engine to return to idle,
then
  disconnect   the   cables.
The presence of this label
indicates the use of a 12 V
lead-acid battery with special
technology

and

specification,

for

which

the involvement of a CITROËN dealer
or


qualified

workshop

is

required

when

replacing


or

disconnecting

the

battery.
Failure to observe this recommendation
may cause premature wear of the
battery.
After

refitting

the

battery,

the

Stop &

Start system will only be active after
several hours depending on the
climatic conditions and the state of
charge of the battery (up to about
8 hours).
The Stop & Start battery does not have
to


be

disconnected

for

charging.
Battery

261
Berlingo2VP_en_Chap10a_SMEGplus_ed02-2016
QUESTIONANSWER SOLUTION
There is a difference in
sound quality between the
different
  audio   sources. For
  optimum   sound   quality,   the   audio   settings   for   Volume:,   Bass:,
T

reble:,   Ambience   and   Loudness   can   be   adapted   to   the   different
s

ound sources, which may result in audible differences when
changing
 s

ource. Check
  that   the   audio   settings   for   (Volume:,   Bass:,
T

reble:,   Ambience,   Loudness)   are   adapted   to   the
s

ources   listened   to.   It   is   advisable   to   set   the   audio
f

unctions   (Bass:,   Treble:,   Balance)   to   the   middle
p

osition, select the "None" musical ambience
and set the loudness correction to the "Inactive"
position
  in   radio   mode.
With the engine off, the
system switches off after a
few

minutes   of   use. When the engine is switched off, the system's operating time
depends
  on   the   state   of   charge   of   the   battery.
The
  switch-off   is   normal:   the   system   switches   to   economy   mode   and
s

witches   off   to   prevent   discharging   of   the   vehicle's   battery.Start the vehicle's engine to increase the battery
charge.
Audio and Telematics
TECHNOLOGY on BOARD
10

280
Berlingo2VP_en_Chap10b_RD45_ed02-2016
The table below gives answers to the most frequently asked questions on your audio system.
Q UESTION ANSWER SOLUTION
With the engine off, the
audio system switches off
after
  a   few   minutes   of   use.When the engine is switched off, the audio system operating time
depends
  on   the   state   of   charge   of   the   battery.
The
  switch-off   is   normal:   the   audio   equipment   switches   to   economy
m

ode and switches off to prevent discharging of the vehicle's
battery. Start the vehicle's engine to increase the battery
charge.
The message "the audio
system is overheated"
appears
  on   the   display.In order to protect the installation if the surrounding temperature
is too high, the audio system switches to an automatic thermal
protection mode leading to a reduction in volume or CD play
stopping. Switch the audio system off for a few minutes to
allow
  the   system   to   cool.
Frequently asked questions
QUESTIONANSWER SOLUTION
There is a difference in
sound quality between the
different audio sources
(radio,
 C

D...). For optimum sound quality, the audio settings (Volume, Bass,
Treble, Ambience, Loudness) can be adapted to the different sound
sources, which may result in audible differences when changing
source
  (radio,   CD...). Check
  that   the   audio   settings   (Volume,   Bass,
T

reble, Ambience, Loudness) are adapted to
the
  sources   listened   to.   It   is   advisable   to   set
t

he audio functions (Bass, Treble, Front-Rear
Balance, Left-Right Balance) to the middle
position, select the musical ambience "None"
and set the loudness correction to the "Active"
position in CD mode or to the "Inactive" position
in
  radio   mode.
Radio
Audio and Telematics
