2017 Citroen BERLINGO dashboard

130
Berlingo2VP_en_Chap05_Securite_ed02-2016
130
Berlingo2VP_en_Chap05_Securite_ed02-2016
Advice
Sit  in   a   normal   upright   position.
Wear
  a   correctly   adjusted   seat   belt.
Do not allow anything to come between
the occupants and the airbags
(a
  child,   pet,   object...),   do   not   attach   or
fix

  anything   near   to   the   airbags   or   their
trajectories

  when   inflating   as   this   could
cause

  injuries   when   the   airbags   are
deployed.
Never

  modify   the   original   definition   of
your vehicle, particularly in the area
directly

  around   the   airbags.
After an accident or if the vehicle has
been
  stolen   or   broken   into,   have   the
airbag

  systems   checked.
All
  work   on   the   airbag   system   must   be
carried out by a CITROËN dealer or a
qualified

  workshop.
Even if all of the precautions
mentioned
  are   observed,   a   risk   of
injury

  or   of   minor   burns   to   the   head,
chest or arms when an airbag is
deployed

  cannot   be   ruled   out.
The

bag inflates

  almost   instantly   (within   a
few

  milliseconds)   then   deflates   within
the same time discharging the hot gas
via

  openings   provided   for   this   purpose.Front airbags
Do not drive holding the steering wheel
by
  its   spokes   or   resting   your   hands   on
the

  centre   part   of   the   wheel.
Passengers must not place their feet
on
  the   dashboard.
Do
  not   smoke   as   deployment   of   the
airbags

  can   cause   burns   or   the   risk   of
injury

  from   a   cigarette   or   pipe.
Never remove or pierce the steering
wheel
  or   hit   it   violently.
Do
  not   fit   or   attach   anything   to   the
steering wheel or dashboard, this could
cause

  injuries   with   deployment   of   the
airbags.
Lateral airbags
Use only approved covers on the
seats, compatible with the deployment
the

  lateral   airbags.   For   information
on the range of seat covers suitable
for your vehicle, you can contact a
CITROËN dealer

.
For more information on accessories,
refer to "Other accessories" in
section 6.
Do
  not   fix   or   attach   anything   to   the   seat
backs

  (clothing...).
This
  could   cause
injury

  to   the   chest   or   arms   if   the   lateral
airbag

  is   deployed.
Do not sit with the upper part of the
body any nearer to the door than
necessary.
Airbags only operate when the
ignition is switched on.
This

equipment

only

operates

once.

If a second impact occurs (during the
same or a subsequent accident), the
airbag


will

not

operate.
The deployment of an airbag or airbags
is accompanied by a slight discharge
of

smoke

and

a

noise,

due

to

the

activation of the pyrotechnic cartridge
incorporated


in

the

system.
This

smoke

is

not

harmful,

but

sensitive individuals may experience
some


irritation.
The noise of the detonation may result
in a slight loss of hearing for a short
time.
The passenger's front airbag must
be deactivated if a child seat is
installed

rearward

facing.
Chapter

5,

"Child

safety"

section.
Airbags

132
Berlingo2VP_en_Chap05_Securite_ed02-2016
132
Berlingo2VP_en_Chap05_Securite_ed02-2016
Front airbags
Deployment
They are deployed, except the
passenger's front airbag if it has been
deactivated, in the event of a serious
front impact applied to all or part of the
front impact zone A in the longitudinal
centreline of the vehicle on a horizontal
plane directed from the front towards
the  rear   of   the   vehicle.
The
  front   airbag   inflates   between   the
front occupant of the vehicle and the
dashboard to cushion their forward
movement. Deactivating the passengers front
airbag
Only the passenger's front airbag can
be

  deactivated.
-
W
ith the ignition switched off,
insert   the   key   into   the   passenger's  front
  airbag   deactivation   switch.
- T urn it to the "OFF"   position.
-

Remove
  the   key   keeping   the   switch
in

  the   new   position.
The passenger's front airbag
warning lamp in the instrument
panel remains on while the
airbag
  is   deactivated.If the two airbag warning lamps
are on continuously, do not install
a rearward facing child seat and
contact a CITROËN dealer or a
qualified
  workshop.
Front airbag fault
To ensure the safety of your child,
it is essential to deactivate the
passenger's front airbag when you
install a rearward facing child seat on
the
  front   passenger   seat.   Otherwise,
the

  child   would   risk   being   killed   or
seriously

  injured   if   the   airbag   were
deployed.Reactivation
In the

"OFF" position, the passenger's
front airbag will not be deployed in the
event   of   an   impact.
As soon as the child seat is removed,
turn the passenger's front airbag switch
to the "ON" position to reactivate the
airbag and thus ensure the safety
of your passenger in the event of an
impact.
If this warning lamp comes
on, accompanied by an
audible signal and a message
in the screen, consult a
CITROËN dealer or a
qualified   workshop   to   have  the
  system   checked.
The
  front   airbags   are   fitted   in   the
centre of the steering wheel for the
driver and in the dashboard for the
front

  passenger.
Airbags

 147
Berlingo2VP_en_Chap05_Securite_ed02-2016
 147
Berlingo2VP_en_Chap05_Securite_ed02-2016
CHILD LOCK
This prevents opening of the siding
side  doors   from   the   inside.
Manual Electric
With the ignition on, press
this button in the middle of
the
  dashboard.
Indicator lamp on = child
lock on.
Please

note:   this   system   is
independent

  of   the   central   locking
control.Always

  remove   the   ignition   key
when leaving the vehicle, even for
a


short   time.
It

is

advisable   to   check   the   state   of
the


child

lock   each   time   the   ignition   is
switched

  on.
In the event of a serious impact the
electric

child   lock   is   deactivated
automatically

.
A label indicates the position of the
lever

and

the

state

of

the

child

lock.
-

Open fully past the point of
resistance.
-


T

ilt the lever, located on the rear
section

of

the

door.
SAFETY
5
Child safety

154
Berlingo2VP_en_Chap07_Verification_ed02-2016
OPENING THE BONNET
Bonnet stay
Secure the stay in its location,
identified  by   a   sticker   on   the   right-hand
side of the vehicle, to hold the bonnet
open.
Before closing the bonnet, put the stay
back

  in   its   clip   without   using   excessive
force.
On the outside
Raise the bonnet slightly by reaching
in  a   flat   hand,   palm   down,   to   make
access

  to   the   lever   easier.
With this hand, push the safety catch
to
  the   left.   Raise   the   bonnet.
On the inside
Pull the lever below the dashboard
towards  you.  The   bonnet   is   released.
To close
Lower the bonnet and release it at the
end  of   its   travel.   Check   that   the   bonnet
is

  secure.
Avoid opening the bonnet in strong
winds.
Opening the bonnet

158
Berlingo2VP_en_Chap07_Verification_ed02-2016Berlingo2VP_en_Chap07_Verification_ed02-2016
Cooling system
Only use the fluid recommended by the manufacturer.
Otherwise,
  you   risk   seriously   damaging
your

  engine.
When the engine is warm, the
temperature of the coolant is controlled
by
  the   engine   fan.
As
  this   fan   can
operate

  with   the   ignition   key   removed
and because the cooling system is
pressurised, wait for at least one hour
after the engine has stopped before
carrying

  out   any   work.
Slacken
  the   cap   by   1/4   of   a   turn   to
release the pressure to prevent any
risk

  of   scalding.   When   the   pressure
has dropped, remove the cap and top
up

  the   level   with   coolant.
If
  fluid   has   to   be   added   frequently,
this indicates a fault which must be
checked

  by   a   CITROËN   dealer   as
soon

  as   possible.
Power steering fluid level
The vehicle must be parked on level ground  with   the   engine   cold.   Unscrew
the cap integrated with the gauge and
check

  the   level   which   must   be   between
the

  MIN   and   MAX   marks. In
  order   to   regenerate   the   filter,   you  are advised to drive at a speed higher
than
  40   mph   (60   km/h)   for   at   least   five  minutes as soon as possible, when
traffic
  conditions   permit   (until   the
message disappears and the service
warning

  lamp   goes   off).
During regeneration of the particle
emission
  filter,   the   noise   of   a   relay
operating may be heard under the
dashboard.
If the message is still displayed and
if the service warning lamp remains
on, contact a CITROËN dealer or a
qualified

  workshop.
Topping up
The level must be between the MIN
and

MAX

marks

on

the

expansion

bottle.


If

more

than

1

litre

of

fluid

is

required to top up the level, have the
system


checked

by

a

CITROËN

dealer

or


a

qualified

workshop.
Screenwash level
For best quality cleaning and for your
safety, we would advise that you use
products   of   the   CITROËN   range.
For optimum cleaning and to avoid
freezing,
  this   fluid   must   not   be   topped
up

  or   replaced   with   plain   water.
Capacity
  of   the   screenwash   reservoir:
approximately

  3   litres.
Diesel additive level
(Diesel with particle
filter)
Topping up
This additive must be topped up by
a  CITROËN   dealer   or   a   qualified
workshop

  without   delay.
Waste products
Avoid prolonged contact of used oil
with  the   skin.
Brake
  fluid   is   harmful   to   health   and
very

  corrosive.
Do
  not   dispose   of   used   oil,   brake   fluid
or coolant into drains or into the ground
but into the containers dedicated to this
use at a CITROËN dealer (France) or
an

  authorised   waste   disposal   site.
The minimum level of this additive
is indicated by lighting of the service
warning lamp, accompanied by an
audible signal and a message in the
screen.
When this occurs with the engine
running it is due to the start of
saturation

of

the

particle

filter

(exceptionally prolonged urban type
driving


conditions:

low

speed,

long

traffic


jams,

...).
Levels

187
Berlingo2VP_en_Chap08_Aide-rapide_ed02-2016Berlingo2VP_en_Chap08_Aide-rapide_ed02-2016
CHANGING A FUSE
The fuseboxes are located:
-
in the lower dashboard on the left-
hand side (behind the cover),
-


under
  the   bonnet   (near   the   battery).
The information given concerns only
those fuses which can be changed by
the user using the tweezer, located
behind the dashboard storage
compartment
  on   the   right-hand   side.
For

  any   other   work,   visit   a   CITROËN
dealer

  or   a   qualified   workshop.
Removing and fitting a fuse
Always replace a failed fuse with a
fuse of the same rating.
Motor

trade

technicians:

for

complete information on the fuses
and relays, refer to the "Repair
Manual" diagrams via the dealer
network.
CITROËN will not accept responsibility
for the cost incurred in repairing
your vehicle or for rectifying the
malfunctions resulting from the
installation of accessories not
supplied and not recommended by the
CITROËN


network

and

not

installed

in accordance with its instructions,
in particular when the combined
consumption of all of the additional
equipment connected exceeds
10 millia

mperes. Before replacing a fuse, the cause of
the
  incident   must   be   identified   and
rectified.
●


Use
  the   tweezer.
QUICK HELP
8
Changing a fuse

188
Berlingo2VP_en_Chap08_Aide-rapide_ed02-2016Berlingo2VP_en_Chap08_Aide-rapide_ed02-2016
Dashboard fuses
Tilt the cover to gain access to the
fuses.Fuses
F Amperes
A Allocation
1 15 Rear wiper
2 - Not used
3 5 Airbag
4 10 Air
  conditioning,   diagnostic   socket,   mirror   control,
headlamp beam
5 30 Electric windows
6 30 Locks
7 5Rear courtesy lamp, front map reading lamp, roof
console
8 20 Audio

  equipment,   screen,   tyre   under-inflation
detection, alarm and siren
9 30 Front

  and   rear   12V   socket
10 15 Central column 11 15 Low current ignition switch
12 15 Rain and sunshine sensor, airbag
13 5 Instrument panel
14 15 Parking
  sensors,   digital   air   conditioning   controls,
hands-free

  phone   kit
15 30 Locks
16 - Not used
17 40Rear
  screen/mirrors   demist/defrost
Changing a fuse
