Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9804281) - 2017 - crc - 4/25/16
144 Instruments and Controls
Window Messages
OPEN, THEN CLOSE DRIVER/
PASSENGER WINDOW
This message is displayed when the
window needs to be reprogrammed.
If the vehicle's battery has been
recharged or disconnected, you will
need to program each front window
for the express-up feature to work.
SeePower Windows 047.
Vehicle
Personalization
Use the audio system controls to
access the personalization menus
for customizing vehicle features.
The following are all possible
personalization features. Depending
on the vehicle, some may not be
available.
Base Radio Audio System
Controls
{:Press to access the Home
Page Menu.
QorR: Touch to scroll through the
menus or setup items.
0: Touch to exit or return to the
previous screen or menu.
Uplevel Radio Audio System
Controls
1. Touch the desired feature to display a list of available
options.
2. Select the desired feature setting. 3. Press
SBACK on the
faceplate or touch
0to return
to the previous menu or exit.
Turn the vehicle to ON/RUN to
access the Settings menu, then
select SETTINGS from the Home
page on the infotainment system
display.
Personalization Menus
The following list of menu items may
be available:
. Time and Date
. Driving Mode
. Language (Language)
. Valet Mode
. Teen Driver
. Radio
. Vehicle
. Bluetooth
. Apple CarPlay
. Android Auto
. USB Auto Launch
. Voice

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9804281) - 2017 - crc - 4/25/16
150 Instruments and Controls
Voice Mail Numbers
This feature displays the voice mail
number for all connected phones.
To change the voice mail number,
select EDIT or press the EDIT
button. Type a new number, then
select SAVE or press the SAVE
button.
Text Message Alerts
This allows the feature to be turned
on or off.
Select Off or On.
Apple CarPlay™
Select and the following may
display:
.Apple CarPlay
. Manage Apple CarPlay Devices
Apple CarPlay
This feature allows Apple devices to
be connected to the infotainment
system through a USB port.
Select Off or On. Manage Apple CarPlay Devices
Select to manage Apple devices.
Apple CarPlay must be on for this
feature to be accessed.
Android Auto
Select and the following may
display:
.
Android Auto
. Manage Android Auto Devices
Android Auto
This feature allows Android devices
to be connected to the infotainment
system through a USB port.
Select Off or On.
Manage Android Auto Devices
Select to manage Android devices.
Android Auto must be on for this
feature to be accessed.
USB Auto Launch
This allows Android and Apple
CarPlay devices to automatically
connect when plugged into the
USB port.
Select Off or On.
Voice
Select and the following may
display:
. Confidence Threshold
. Prompt Length
. Audio Feedback Speed
. Display “What Can I Say?” Tips
Confidence Threshold
This feature allows the adjustment
of the sensitivity of the speech
recognition system.
Select Confirm More or
Confirm Less.
Prompt Length
This feature adjusts the voice
prompt length.
Select Short or Long.
Audio Feedback Speed
This feature adjusts the audio
feedback speed.
Select Slow, Medium, or Fast.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9804281) - 2017 - crc - 4/25/16
162 Infotainment System
Infotainment
System
Introduction
Infotainment . . . . . . . . . . . . . . . . . . 162
Theft-Deterrent Feature . . . . . . 163
Overview . . . . . . . . . . . . . . . . . . . . . 164
Home Page . . . . . . . . . . . . . . . . . . 165
Operation . . . . . . . . . . . . . . . . . . . . . 165
Radio
AM-FM Radio . . . . . . . . . . . . . . . . 166
Satellite Radio . . . . . . . . . . . . . . . . 167
Radio Reception . . . . . . . . . . . . . . 169
Antenna (Convertible Only) . . . 169
Backglass Antenna(Coupe Only) . . . . . . . . . . . . . . . 169
Multi-Band Antenna . . . . . . . . . . 170
Audio Players
Avoiding Untrusted Media Devices . . . . . . . . . . . . . . . . . . . . . 170
USB Port . . . . . . . . . . . . . . . . . . . . . 170
Auxiliary Devices . . . . . . . . . . . . . 176
Performance Data
Recorder (PDR)
Performance Data Recorder (PDR) . . . . . . . . . . . . . 177
Phone
Bluetooth (Overview) . . . . . . . . . 182
Bluetooth (InfotainmentControls) . . . . . . . . . . . . . . . . . . . . 184
Apple CarPlay and Android Auto . . . . . . . . . . . . . . . . 188
Hands-Free Phone . . . . . . . . . . . 188
Trademarks and License
Agreements
Trademarks and License Agreements . . . . . . . . . . . . . . . . . 191
Introduction
Infotainment
Base radio information is included in
this manual. See the infotainment
manual for information on other
available infotainment systems.
Read the following pages to
become familiar with these features.
{Warning
Taking your eyes off the road for
too long or too often while using
any infotainment feature can
cause a crash. You or others
could be injured or killed. Do not
give extended attention to
infotainment tasks while driving.
Limit your glances at the vehicle
displays and focus your attention
on driving. Use voice commands
whenever possible.
The infotainment system has built-in
features intended to help avoid
distraction by disabling some
functions when driving. These

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9804281) - 2017 - crc - 4/25/16
188 Infotainment System
.The infotainment system outputs
the audio from the cell phone or
Bluetooth device as it is
transmitted.
Apple CarPlay and
Android Auto
If equipped, Android Auto™ and/or
Apple CarPlay™ capability may be
available through a compatible
smartphone. If available, a
PROJECTION icon will appear as
Android Auto or Car Play on the
Home Page of the infotainment
display.
To use Android Auto and/or Apple
CarPlay:
1. Download the Android Auto app to your phone from the
Google™ Play store. There is
no app required for Apple
CarPlay. Use the latest
available operation system.
2. Connect your Android phone or Apple iPhone by using the
compatible phone USB cable
and plugging into a USB data
port. For best performance, use the device’
s factory-provided
USB cable. Aftermarket or
third-party cables may
not work.
The PROJECTION icon on the
Home Page will change to Android
Auto or Apple CarPlay depending
on the phone. Android Auto and/or
Apple CarPlay may automatically
launch upon USB connection. If not,
press the ANDROID AUTO and/or
APPLE CARPLAY icon on the
Home Page to launch.
For further information on how to set
up Android Auto and Apple CarPlay
in the vehicle, see
www.my.chevrolet.com for U.S. and
Canada only or Customer
Assistance Offices 0356.
Android Auto is provided by Google
and is subject to Google’s terms
and privacy policy. CarPlay is
provided by Apple and is subject to
Apple’ s terms and privacy policy.
For Android Auto support see
https://support.google.com/
androidauto or Apple CarPlay
support at https://www.apple.com/
ios/carplay/. Apple or Google may change or suspend availability at
any time. Android Auto is a
trademark of Google Inc.; Apple
CarPlay is a trademark of Apple Inc.
Hands-Free Phone
General Information
Vehicles with a Hands-Free Phone
system can use a Bluetooth-capable
cell phone with a hands-free profile
to make and receive phone calls.
The infotainment system and voice
control are used to operate the
system. Not all phones support all
functions and not all phones work
with the Hands-Free Phone system.
Hands-Free Phone Controls
Use the buttons on the infotainment
system and the steering wheel to
operate the Hands-Free Phone
system.
Steering Wheel Controls
Steering wheel controls can be
used to:
.
Answer incoming calls.
. Confirm system information.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9804281) - 2017 - crc - 4/25/16
372 OnStar
2. The Wi-Fi settings will displaythe Wi-Fi hotspot name (SSID),
password, and on some
vehicles, the connection type
(no Internet connection, 3G,
4G, 4G LTE), and signal quality
(poor, good, excellent).
3. To change the SSID or password, press
|or call
1-888-4ONSTAR to connect
with an Advisor.
After initial set-up, your vehicles’ s
Wi-Fi hotspot will connect
automatically to your mobile
devices. Manage data usage by
turning Wi-Fi on or off on your
mobile device, using the
RemoteLink mobil app, or by
contacting an OnStar Advisor.
OnStar RemoteLink
®Mobile App
(If Equipped)
Download the OnStar RemoteLink
mobile app to select Apple
®iOS,
Android™, BlackBerry®,
or Windows®mobile devices.
OnStar Subscribers can access the
following services from a mobile
device: .
Remotely start/stop the vehicle,
if factory-equipped.
. Lock/unlock doors, if equipped
with automatic locks.
. Activate the horn and lamps
. Check the vehicles’s fuel level,
oil life, or tire pressure,
if factory-equipped with the Tire
Pressure Monitor System.
. Send directions to the vehicle.
. Locate the vehicle on a map
(U.S. market only).
. Turn the vehicle’ s Wi-Fi hotspot
on/off, manage settings, and
monitor data consumption,
if equipped.
For OnStar RemoteLink information
and compatibility, see
www.onstar.com (U.S.) or
www.onstar.ca (Canada).
Remote Services
Contact an OnStar Advisor to
unlock the doors or sound the horn
and flash the lamps.
OnStar AtYourService
OnStar Advisors can provide offers
from restaurants and retailers on
your route, help locate hotels,
or book a room. These services
vary by market.
OnStar Hands-Free Calling
Make and receive calls with the
built-in wireless calling service
which requires available minutes.
To Make a Call
1. Press
Q. System responds:
“OnStar ready.”
2. Say “Call.”System responds:
“Call. Please say the name or
number to call.”
3. Say the entire number without pausing, including a “1”and the
area code. System responds:
“OK, calling.”
Calling 911 Emergency
1. PressQ. System responds:
“OnStar ready.”

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9804281) - 2017 - crc - 4/25/16
380 Index
Apple CarPlay andAndroid Auto . . . . . . . . . . . . . . . . . . 188
Assistance Program, Roadside . . . . . . . . . . . . . . . . . . . . . . 358
Assistance Systems for Parking and Backing . . . . . . . . . . 246
Audio
Theft-Deterrent Feature . . . . . . . 163
Automatic Climate Control System . . . . . . . 193
Dimming Mirrors . . . . . . . . . . . . . . . . 45
Door Locks . . . . . . . . . . . . . . . . . . . . . 39
Headlamp System . . . . . . . . . . . . 156
Transmission . . . . . . . . . . . . . . . . . 225
Transmission Fluid . . . . . . . . . . . 267
Automatic Transmission
Manual Mode . . . . . . . . . . . . . . . . . 227
Shift Lock Control FunctionCheck . . . . . . . . . . . . . . . . . . . . . . . 280
Auxiliary Devices . . . . . . . . . . . . . . . . . . . . . . . 176
Avoiding Untrusted Media Devices . . . . . . . . . . . . . . . . . . . . . . . 170
Axle, Rear . . . . . . . . . . . . . . . . . . . . . . 280B
Backglass Antenna . . . . . . . . . . . . . 169
Battery Exterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . 160
Load Management . . . . . . . . . . . . 160
Power Protection . . . . . . . . . . . . . 160
Voltage and Charging Messages . . . . . . . . . . . . . . . . . . . 135
Battery - North America . . . . 279, 320
Blade Replacement, Wiper . . . . . 281
Bluetooth
Overview . . . . . . . . . . . . . . . . 182, 184
Boost Gauge . . . . . . . . . . . . . . . . . . . 115
Brake
Parking, Electric . . . . . . . . . . . . . . 232
System Warning Light . . . . . . . . 123
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 277 Antilock . . . . . . . . . . . . . . . . . . . . . . . 232
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 234
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 278
System Messages . . . . . . . . . . . . 135
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 202
Break-In, New Vehicle . . . . . . . . . . 215
Bulb Replacement . . . . . . . . . . . . . . 285 Front Turn Signal Lamps . . . . . 283
Halogen Bulbs . . . . . . . . . . . . . . . . 282
Headlamp Aiming . . . . . . . . . . . . . 282 Bulb Replacement (cont'd)
Headlamps . . . . . . . . . . . . . . . . . . . 282
High Intensity Discharge
(HID) Lighting . . . . . . . . . . . . . . . 283
License Plate Lamps . . . . . . . . . 284
Taillamps, Turn Signal, Sidemarker, Stoplamps,
and Backup Lamps . . . . . . . . . . 283
Buying New Tires . . . . . . . . . . . . . . . 308
C
Calibration . . . . . . . . . . . . . . . . . . . . . . 105
California Fuel Requirements . . . . . . . . . . . 251
Perchlorate Materials
Requirements . . . . . . . . . . . . . . . 256
California Proposition
65 Warning . . . . . . . . . .256, 279, 320
Canadian Vehicle Owners . . . . . . . . 2
Capacities and Specifications . . . . . . . . . . . . . . . . . 351
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . 224
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Winter Driving . . . . . . . . . . . . . . . . 210
Caution, Danger, and Warning . . . . 2
Center Console Storage . . . . . . . . 100
Chains, Tire . . . . . . . . . . . . . . . . . . . . 312

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9804281) - 2017 - crc - 4/25/16
386 Index
OnStar®Additional
Information . . . . . . . . . . . . . . . . . . . . 373
OnStar
®Connections . . . . . . . . . . . 371
OnStar®Diagnostics . . . . . . . . . . . . 373
OnStar®Emergency . . . . . . . . . . . . 370
OnStar®Navigation . . . . . . . . . . . . . 370
OnStar®Overview . . . . . . . . . . . . . . 368
OnStar®Security . . . . . . . . . . . . . . . 370
Operation Infotainment System . . . . . . . . . . 165
Ordering
Service Publications . . . . . . . . . . 363
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . 107
Overheating, Engine . . . . . . . . . . . . 274
Overview . . . . . . . . . . . . . . . . . . . . . . . 164
P
Park Shifting Into . . . . . . . . . . . . . . . . . . . 221
Shifting Out of . . . . . . . . . . . . . . . . 222
Parking . . . . . . . . . . . . . . . . . . . . . . . . . 223 Brake and P (Park)Mechanism Check . . . . . . . . . . 281
Over Things That Burn . . . . . . . 223
Parking Assist . . . . . . . . . . . . . . . . . . 246
Parking or Backing
Assistance Systems . . . . . . . . . . 246 Passenger Airbag Status
Indicator . . . . . . . . . . . . . . . . . . . . . . 120
Passenger Compartment Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . 199
Passenger Sensing System . . . . . 75
Perchlorate Materials Requirements, California . . . . . . 256
Performance Data Recorder (PDR) . . . . . . . . . . . . . . . 177
Personalization Vehicle . . . . . . . . . . . . . . . . . . . . . . . 144
Phone Apple CarPlay andAndroid Auto . . . . . . . . . . . . . . . . 188
Bluetooth . . . . . . . . . . . . . . . . 182, 184
Hands-Free . . . . . . . . . . . . . . . . . . . 188
Port USB . . . . . . . . . . . . . . . . . . . . . . . . . . 170
Power Door Locks . . . . . . . . . . . . . . . . . . . . . 38
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Outlets . . . . . . . . . . . . . . . . . . . . . . . 107
Protection, Battery . . . . . . . . . . . . 160
Retained Accessory (RAP) . . . 221
Seat Adjustment . . . . . . . . . . . . . . . . 57
Windows . . . . . . . . . . . . . . . . . . . . . . . 47
Pregnancy, Using Safety Belts . . . 66 Privacy
Vehicle Data Recording . . . . . . . 366
Program Courtesy Transportation . . . . . . 360
Proposition 65 Warning,
California . . . . . . . . . . . .256, 279, 320
R
Radio Frequency Statement . . . . 364
Radio Reception . . . . . . . . . . . . . . . . 169
RadiosAM-FM Radio . . . . . . . . . . . . . . . . . 166
Satellite . . . . . . . . . . . . . . . . . . . . . . . 167
Reading Lamps . . . . . . . . . . . . . . . . . 159
Rear Axle . . . . . . . . . . . . . . . . . . . . . . . 280 Limited-Slip . . . . . . . . . . . . . . . . . . . 242
Rear Seats . . . . . . . . . . . . . . . . . . . . . . 62
Rear Storage . . . . . . . . . . . . . . . . . . . . 99
Rear Vision Camera (RVC) . . . . . 246
Rearview Mirrors . . . . . . . . . . . . . . . . 46 Automatic Dimming . . . . . . . . . . . . . 46
Reclining Seatbacks . . . . . . . . . . . . . 58
Recommended Fluids and Lubricants . . . . . . . . . . . . . . . . . . . . . 346
Records
Maintenance . . . . . . . . . . . . . . . . . . 349
Recreational Vehicle Towing . . . . 325
