Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-10287885) -
2017 - crc - 6/16/16
SERVICE AND MAINTENANCE 307
checks and services. The Additional
Required Services - Normal are for
vehicles that:
.Carry passengers and cargo within
recommended limits on the Tire
and Loading Information label. See
Vehicle Load Limits 0181.
. Are driven on reasonable road
surfaces within legal driving limits.
. Use the recommended fuel. See
Fuel 0226.
Refer to the information in the
Maintenance Schedule Additional
Required Services - Normal chart.
The Additional Required Services -
Severe are for vehicles that are:
. Mainly driven in heavy city traffic
in hot weather.
. Mainly driven in hilly or
mountainous terrain.
. Frequently towing a trailer.
. Used for high speed or competitive
driving.
. Used for taxi, police, or delivery
service. Refer to the information in the
Maintenance Schedule Additional
Required Services - Severe chart.
{Warning
Performing maintenance work can
be dangerous and can cause serious
injury. Perform maintenance work
only if the required information,
proper tools, and equipment are
available. If they are not, see your
dealer to have a trained technician
do the work. See
Doing Your Own
Service Work 0233.
Maintenance Schedule
Owner Checks and Services
At Each Fuel Stop
.
Check the engine oil level. See
Engine Oil 0241.
Once a Month
. Check the tire inflation pressures.
See Tire Pressure 0273.
. Inspect the tires for wear. See Tire
Inspection 0278.
. Check the windshield washer fluid
level. See Washer Fluid 0253.
Engine Oil Change
Change the engine oil and filter when
the CHANGE ENGINE OIL SOON
message displays, 12 000 km/7,500 mi,
or at one year, whichever comes first.
If driven under the best conditions,
the engine oil life system may not
indicate the need for vehicle service
for up to a year. The engine oil and
filter must be changed at least once a
year and the oil life system must be
reset. Your trained dealer technician
can perform this work. If the engine

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-10287885) -
2017 - crc - 6/16/16
308 SERVICE AND MAINTENANCE
oil life system is reset accidentally,
service the vehicle within 5 000 km/
3,000 mi since the last service. Reset
the oil life system when the oil is
changed. SeeEngine Oil Life
System 0243.
Tire Rotation and Required
Services Every 12 000 km/
7,500 mi
Rotate the tires, if recommended for
the vehicle, and perform the following
services. See Tire Rotation0278.
. Check engine oil level and oil
life percentage. If needed, change
engine oil and filter, and reset oil
life system. See Engine Oil0241
and Engine Oil Life System 0243.
. Check engine coolant level. See
Engine Coolant 0248.
. Check windshield washer fluid
level. See Washer Fluid 0253.
. Visually inspect windshield wiper
blades for wear, cracking,
or contamination. See Exterior
Care 0298. Replace worn or
damaged wiper blades. See Wiper
Blade Replacement 0257. .
Check tire inflation pressures. See
Tire Pressure 0273.
. Inspect tire wear. See Tire
Inspection 0278.
. Visually check for fluid leaks.
. Inspect engine air cleaner filter.
See Engine Air Cleaner/Filter 0245.
. Inspect brake system. See Exterior
Care 0298.
. Visually inspect steering,
suspension, and chassis
components for damaged, loose,
or missing parts or signs of wear.
See Exterior Care 0298.
. Check restraint system
components. See Safety System
Check 066.
. Visually inspect fuel system for
damage or leaks.
. Visually inspect exhaust system
and nearby heat shields for loose
or damaged parts.
. Lubricate body components. See
Exterior Care 0298.
. Check starter switch. See Starter
Switch Check 0256. .
Check automatic transmission
shift lock control function. See
Automatic Transmission Shift Lock
Control Function Check 0257.
. Check parking brake and
automatic transmission park
mechanism. See Park Brake and
P (Park) Mechanism Check 0257.
. Check accelerator pedal for
damage, high effort, or binding.
Replace if needed.
. Visually inspect gas strut for signs
of wear, cracks, or other damage.
Check the hold open ability of the
strut. See your dealer if service is
required.
. Check tire sealant expiration date,
if equipped. See Tire Sealant and
Compressor Kit 0286.
. Inspect sunroof track and seal,
if equipped. See Sunroof048.

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-10287885) -
2017 - crc - 6/16/16
SERVICE AND MAINTENANCE 309
Maintenance Schedule
Additional Required Services -
Normal12 000 km/7,500 mi
24 000 km/15,000 mi
36 000 km/22,500 mi
48 000 km/30,000 mi
60 000 km/37,500 mi
72 000 km/45,000 mi
84 000 km/52,500 mi
96 000 km/60,000 mi
108 000 km/67,500 mi
120 000 km/75,000 mi
132 000 km/82,500 mi
144 000 km/90,000 mi
156 000 km/97,500 mi
168 000 km/105,000 mi
180 000 km/112,500 mi
192 000 km/120,000 mi
204 000 km/127,500 mi
216 000 km/135,000 mi
228 000 km/142,500 mi
240 000 km/150,000 mi
Rotate tires and perform Required Services. Check
engine oil level and oil life percentage. Change
engine oil and filter, if needed.@ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @
Replace passenger compartment air filter. (1)@ @@@@@
Inspect evaporative control system. (2)@ @@
Replace engine air cleaner filter. (3)@ @ @ @ @ @ @ @ @ @
Change rear axle fluid, if equipped with limited slip
differential.@@@
2.0L or 3.6L Twin Turbo Engine Only: Replace spark
plugs. Inspect spark plug wires.@ @
Except 2.0L or 3.6L Twin Turbo Engine: Replace
spark plugs. Inspect spark plug wires.@
Drain and fill engine cooling system. (4)@
Visually inspect accessory drive belts. (5)@
Replace brake fluid. (6)
Footnotes—Maintenance Schedule
Additional Required Services -
Normal
(1) Or every two years, whichever
comes first. More frequent passenger
compartment air filter replacement
may be needed if driving in areas with heavy traffic, poor air quality, high
dust levels, or environmental
allergens. Passenger compartment air
filter replacement may also be needed
if there is reduced airf low, window
fogging, or odors. Your GM dealer can
help determine when to replace the
filter.
(2)
Visually check all fuel and vapor
lines and hoses for proper attachment,
connection, routing, and condition.

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-10287885) -
2017 - crc - 6/16/16
SERVICE AND MAINTENANCE 311
Maintenance Schedule
Additional Required Services -
Severe12 000 km/7,500 mi
24 000 km/15,000 mi
36 000 km/22,500 mi
48 000 km/30,000 mi
60 000 km/37,500 mi
72 000 km/45,000 mi
84 000 km/52,500 mi
96 000 km/60,000 mi
108 000 km/67,500 mi
120 000 km/75,000 mi
132 000 km/82,500 mi
144 000 km/90,000 mi
156 000 km/97,500 mi
168 000 km/105,000 mi
180 000 km/112,500 mi
192 000 km/120,000 mi
204 000 km/127,500 mi
216 000 km/135,000 mi
228 000 km/142,500 mi
240 000 km/150,000 mi
Rotate tires and perform Required Services. Check
engine oil level and oil life percentage. Change
engine oil and filter, if needed.@ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @
Replace passenger compartment air filter. (1)@ @@@@@
Inspect evaporative control system. (2)@ @@
Replace engine air cleaner filter. (3)@ @ @ @ @ @ @ @ @ @
Change automatic transmission fluid and filter.@@@
Change rear axle fluid.@@@
2.0L or 3.6L Twin Turbo Engine Only: Replace spark
plugs. Inspect spark plug wires.@ @
Except 2.0L or 3.6L Twin Turbo Engine: Replace
spark plugs. Inspect spark plug wires.@
Drain and fill engine cooling system. (4)@
Visually inspect accessory drive belts. (5)@
Replace brake fluid. (6)
Footnotes—Maintenance Schedule
Additional Required Services -
Severe
(1) Or every two years, whichever
comes first. More frequent passenger
compartment air filter replacement may be needed if driving in areas with
heavy traffic, poor air quality, high
dust levels, or environmental
allergens. Passenger compartment air
filter replacement may also be needed
if there is reduced airf low, window
fogging, or odors. Your GM dealer can
help determine when to replace the
filter.
(2)
Visually check all fuel and vapor
lines and hoses for proper attachment,
connection, routing, and condition.

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-10287885) -
2017 - crc - 6/16/16
320 TECHNICAL DATA
ApplicationCapacities
Metric English
Wheel Nut Torque –ATS-V 190 Y140 lb ft
All capacities are approximate. When adding, be sure to fill to the approximate level, as recommended in this manual.
Recheck fluid level after filling.
Engine Specifications
Engine VIN Code Horsepower TorqueSpark Plug Gap
2.0L L4 Engine X203 kW@ 5600 rpm
(272 hp@ 5600 rpm) 400
Y@ 3800 rpm
(295 lb ft @ 3800 rpm) 0.75–0.90 mm (0.030–
0.035 in)
2.5L L4 Engine A151 kW@ 6300 rpm
(202 hp@ 6300 rpm) 258
Y@ 4400 rpm
(190 lb ft @ 3800 rpm) 0.95–1.10 mm (0.037–
0.043 in)
3.6L V6 Engine S239 kW@ 6800 rpm
(321 hp@ 6800 rpm) 372
Y@ 4800 rpm
(274 lb ft @ 4800 rpm) 0.80–0.90 mm (0.031–
0.035 in)
3.6L V6 Twin Turbo
Engine Y
339 kW@ 5750 rpm
(455 hp@ 5750 rpm) 603
Y@ 3500 rpm
(445 lb ft @ 3500 rpm) 0.75–0.90 mm (0.030–
0.035 in)
Vehicle Top Speed
Engine MetricEnglish
2.0L L4 Engine 240 km/h149 mph

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-10287885) -
2017 - crc - 6/16/16
INDEX 325
IndexA
Accessories and Modifications . . . . . 232
Accessory Power . . . . . . . . . . . . . . . . . . . . 188
Adaptive Cruise Control . . . . . . . . . . . . 207
Adaptive ForwardLighting (AFL) . . . . . . . . . . . . . . . . . . . . . 148
Adaptive Forward Lighting (AFL) Light . . . . . . . . . . . . . . . . . . . . . . . . 121
Add-On Electrical Equipment . . . . . . 230
Adjustments Lumbar, Front Seats . . . . . . . . . . . . . . . . 54
Thigh Support . . . . . . . . . . . . . . . . . . . . . . 55
Air Cleaner/Filter, Engine . . . . . . . . . . 245
Air Conditioning . . . . . . . . . . . . . . .160, 163
Air Filter, Passenger Compartment . . . . . . . . . . . . . . . . . . . . . 169
Air Vents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
Airbag System Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
How Does an Airbag Restrain? . . . . . 72
Passenger Sensing System . . . . . . . . . 73
What Makes an Airbag Inflate? . . . . 71
What Will You See after anAirbag Inflates? . . . . . . . . . . . . . . . . . . . 72
When Should an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Where Are the Airbags? . . . . . . . . . . . . 69 Airbags
Adding Equipment to the
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Passenger Status Indicator . . . . . . . 113
Readiness Light . . . . . . . . . . . . . . . . . . . 113
Servicing Airbag-Equipped Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
System Check . . . . . . . . . . . . . . . . . . . . . . . 67
Alarm Vehicle Security . . . . . . . . . . . . . . . . . . . . . 40
Alert
Lane Change . . . . . . . . . . . . . . . . . . . . . . 222
Side Blind Zone (SBZA) . . . . . . . . . . 222
All-Season Tires . . . . . . . . . . . . . . . . . . . . . 271
Antilock Brake System (ABS) . . . . . . 195 Warning Light . . . . . . . . . . . . . . . . . . . . 117
Appearance Care Exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . 298
Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . 302
Armrest Storage . . . . . . . . . . . . . . . . . . . . . . 97
Assistance Systems for Driving . . . . 218
Assistance Systems for Parking and Backing . . . . . . . . . . . . . . . . . . . . . . . 215
Automatic Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Forward Braking . . . . . . . . . . . . . . . . . . 221
Headlamp System . . . . . . . . . . . . . . . . 147
Transmission . . . . . . . . . . . . . . . . . . . . . . 191

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-10287885) -
2017 - crc - 6/16/16
326 INDEX
Automatic (cont'd)Transmission Fluid . . . . . . . . . . . . . . . 244
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . . . . . 193
Shift Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . 257
B
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255Exterior Lighting Battery
Saver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Jump Starting . . . . . . . . . . . . . . . . . . . . . 292
Power Protection . . . . . . . . . . . . . . . . . . 151
Voltage and Charging Messages . . . . . . . . . . . . . . . . . . . . . . . . 127
Blade Replacement, Wiper . . . . . . . . . 257
Brake System Warning Light . . . . . . . . . . . . 116
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253
Antilock . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254
Parking . . . . . . . . . . . . . . . . . . . . . . . 195, 196
System Messages . . . . . . . . . . . . . . . . . 128
Braking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172 Automatic Forward . . . . . . . . . . . . . . . 221
Break-In, New Vehicle . . . . . . . . . . . . . . 184
Bulb Replacement . . . . . . . . . . . . . . . . . . 261 Back-up Lamps . . . . . . . . . . . . . . . . . . . 259 Bulb Replacement (cont'd)
Halogen Bulbs . . . . . . . . . . . . . . . . . . . . 259
Headlamp Aiming . . . . . . . . . . . . . . . . 258
Headlamps . . . . . . . . . . . . . . . . . . . . . . . . 259
High Intensity Discharge
(HID) Lighting . . . . . . . . . . . . . . . . . . . 259
License Plate Lamps . . . . . . . . . . . . . . 260
Buying New Tires . . . . . . . . . . . . . . . . . . . 280
C
Capacities and Specifications . . . . . . 319
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . . . . . 190
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Winter Driving . . . . . . . . . . . . . . . . . . . . 179
Cargo Tie-Downs . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Caution, Danger, and Warning . . . . . . . . 2
Center Console Storage . . . . . . . . . . . . . . 97
Chains, Tire . . . . . . . . . . . . . . . . . . . . . . . . . 284
Charging Wireless . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Charging System Light . . . . . . . . . . . . . 114
Check Malfunction Indicator EngineLight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Child Restraints Infants and Young Children . . . . . . . . 81 Child Restraints (cont'd)
Lower Anchors and Tethers for
Children . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Older Children . . . . . . . . . . . . . . . . . . . . . . 79
Securing . . . . . . . . . . . . . . . . . . . . . . . . .91, 93
Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Circuit Breakers . . . . . . . . . . . . . . . . . . . . . 261
Cleaning Exterior Care . . . . . . . . . . . . . . . . . . . . . . 298
Interior Care . . . . . . . . . . . . . . . . . . . . . . 302
Climate Control Systems Dual Automatic . . . . . . . . . . . . . . 160, 163
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Cluster, Instrument . . . . . . . . . . . . . . . . . 107
Compartments Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Competitive Driving Mode . . . . . . . . . 201
Composite Materials . . . . . . . . . . . . . . . . 184
Compressor Kit, Tire Sealant . . . . . . . 286
Control Traction and ElectronicStability . . . . . . . . . . . . . . . . . . . . . . . . . . 198
Control of a Vehicle . . . . . . . . . . . . . . . . 171
Convex Mirrors . . . . . . . . . . . . . . . . . . . . . . 42
Coolant
Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248
Engine Temperature Gauge . . . . . . 111

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-10287885) -
2017 - crc - 6/16/16
INDEX 327
Coolant (cont'd)Engine Temperature Warning
Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Cooling . . . . . . . . . . . . . . . . . . . . . . . . .160, 163
Cooling System . . . . . . . . . . . . . . . .246, 248
Engine Messages . . . . . . . . . . . . . . . . . . 129
Courtesy Lamps . . . . . . . . . . . . . . . . . . . . . 150
Cruise Control . . . . . . . . . . . . . . . . . . . . . . . 204 Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Cruise Control, Adaptive . . . . . . . . . . . 207
Cupholders . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
D
Danger, Warning, and Caution . . . . . . . . 2
Data Collection Infotainment System . . . . . . . . . . . . . 324
Data Recorder Performance . . . . . . . . . . . . . . . . . . . . . . . 153
Data Recorders, Event . . . . . . . . . . . . . . 323
Daytime Running Lamps (DRL) . . . 147
Defensive Driving . . . . . . . . . . . . . . . . . . . 171
Delayed Locking . . . . . . . . . . . . . . . . . . . . . 36
Distracted Driving . . . . . . . . . . . . . . . . . . 171
Dome Lamps . . . . . . . . . . . . . . . . . . . . . . . . 150
Door Ajar Messages . . . . . . . . . . . . . . . . . . . . . 129
Delayed Locking . . . . . . . . . . . . . . . . . . . . 36
Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Door (cont'd)
Power Locks . . . . . . . . . . . . . . . . . . . . . . . . . 36
Rear Seat Pass-Through . . . . . . . . . . . . 61
Drive Belt Routing, Engine . . . . . . . . . 322
Driver Assistance Systems . . . . . . . . . 214
Driver Information
Center (DIC) . . . . . . . . . . . . . . . . . . . . . . . 122
Driver Mode Control . . . . . . . . . . . . . . . . 199
Driving Assistance Systems . . . . . . . . . . . . . . . 218
Competitive . . . . . . . . . . . . . . . . . . . . . . . 201
Defensive . . . . . . . . . . . . . . . . . . . . . . . . . . 171
For Better Fuel Economy . . . . . . . . . . . 26
Hill and Mountain Roads . . . . . . . . 178
If the Vehicle is Stuck . . . . . . . . . . . . 180
Loss of Control . . . . . . . . . . . . . . . . . . . . 173
Off-Road Recovery . . . . . . . . . . . . . . . . 173
Track Events and Competitive . . . 174
Vehicle Load Limits . . . . . . . . . . . . . . 181
Wet Roads . . . . . . . . . . . . . . . . . . . . . . . . . 178
Winter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Dual Automatic Climate Control System . . . . . . . . . . . . . . .160, 163
E
Easy Entry Seat . . . . . . . . . . . . . . . . . . . . . . 51
Electrical Equipment, Add-On . . . . . 230 Electrical System
Engine Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
Fuses and Circuit Breakers . . . . . . . 261
Instrument Panel Fuse Block . . . . 265
Overload . . . . . . . . . . . . . . . . . . . . . . . . . . . 261
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Engine Air Cleaner/Filter . . . . . . . . . . . . . . . . . 245
Check and Service EngineSoon Light . . . . . . . . . . . . . . . . . . . . . . . 114
Compartment Overview . . . . . . . . . . 234
Coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248
Coolant Temperature Gauge . . . . . 111
Coolant Temperature Warning Light . . . . . . . . . . . . . . . . . . . 119
Cooling System . . . . . . . . . . . . . . 246, 248
Cooling System Messages . . . . . . . . 129
Drive Belt Routing . . . . . . . . . . . . . . . . 322
Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
Oil Life System . . . . . . . . . . . . . . . . . . . . 243
Oil Messages . . . . . . . . . . . . . . . . . . . . . . 130
Oil Pressure Light . . . . . . . . . . . . . . . . . 120
Overheating . . . . . . . . . . . . . . . . . . . . . . . 251
Power Messages . . . . . . . . . . . . . . . . . . 130
Running While Parked . . . . . . . . . . . 191
Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186
