Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-10287885) -
2017 - crc - 6/16/16
VEHICLE CARE 245
reason for fluid loss. If a leak occurs,
take the vehicle to your dealer and
have it repaired as soon as possible.
The vehicle is not equipped with a
transmission fluid level dipstick.
There is a special procedure for
checking and changing the
transmission fluid. Because this
procedure is difficult, this should be
done at the dealer. Contact your dealer
for additional information.
Change the fluid and filter at the
intervals listed inMaintenance
Schedule 0307, and be sure to use the
fluid listed in Recommended Fluids and
Lubricants 0314.
Engine Air Cleaner/Filter
The engine air cleaner/filter is in the
engine compartment on the driver
side of the vehicle. See Engine
Compartment Overview 0234 for
location.
When to Inspect the Engine Air
Cleaner/Filter
For intervals on changing and
inspecting the engine air cleaner/filter,
see Maintenance Schedule 0307.
How to Inspect the Engine Air
Cleaner/Filter
Do not start the engine or have the
engine running with the engine air
cleaner/filter housing open. Before
removing the engine air cleaner/filter,
make sure that the engine air cleaner/
filter housing and nearby components
are free of dirt and debris. Remove the
engine air cleaner/filter. Lightly tap
and shake the engine air cleaner/filter
(away from the vehicle), to release
loose dust and dirt. Inspect the engine
air cleaner/filter for damage, and
replace if damaged. Do not clean the
engine air cleaner/filter or
components with water or
compressed air. To inspect or replace the air cleaner/
filter:
2.0L L4 Engine (LTG) Shown, 2.5L L4
Engine (LCV), and 3.6L V6 Engine (LGX) Similar
1. Remove the four screws and lift the cover out of the assembly.
2. Inspect or replace the engine air cleaner/filter.
3. Lower the cover and secure with the four screws.

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-10287885) -
2017 - crc - 6/16/16
VEHICLE CARE 251
3. Fill the surge tank top chamberwith the proper DEX-COOL
coolant mixture to the bottom of
the fill neck. The top chamber
needs to be completely full. Fill
the surge tank bottom chamber
through the service port to
approximately half.
4. With the coolant surge tank pressure cap off and the surge
tank service port cap open, start
the engine and let it run until
you can feel the upper radiator
hose getting hot. Watch out for
the engine cooling fan. By this time, the coolant level
inside the coolant surge tank top
chamber may be lower. If the
level is lower, add more of the
proper DEX-COOL coolant
mixture to the surge tank top
chamber until the level reaches
the bottom of the fill neck.
5. Replace the surge tank pressure cap tightly and close the surge
tank service port cap.Caution
If the pressure cap is not tightly
installed, coolant loss and possible
engine damage may occur. Be sure
the cap is properly and tightly
secured.
Check the level in the surge tank top
and bottom chambers when the
cooling system has cooled down.
If the coolant is not at the proper
levels, repeat Steps 1-3 and reinstall
the pressure cap and close the service
port. If the coolant still is not at the
proper levels when the system cools
down again, see your dealer.
Engine Overheating
The vehicle has several indicators to
warn of the engine overheating.
There is an engine coolant
temperature gauge and an engine
coolant temperature warning light on
the instrument cluster. See Engine
Coolant Temperature Gauge 0111 and
Engine Coolant Temperature Warning
Light 0119. The vehicle may also
display a message on the Driver
Information Center (DIC). See Engine
Cooling System Messages 0129.
If the decision is made not to lift the
hood when this warning appears, get
service help right away.
If the decision is made to lift the
hood, make sure the vehicle is parked
on a level surface.
Then check to see if the engine
cooling fan is running. If the engine is
overheating, the fan should be
running. If it is not, do not continue
to run the engine. Have the vehicle
serviced.

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-10287885) -
2017 - crc - 6/16/16
252 VEHICLE CARE
Caution
Running the engine without coolant
may cause damage or a fire. Vehicle
damage would not be covered by
the vehicle warranty.
If Steam Is Coming from the
Engine Compartment
{Warning
Steam from an overheated engine
can burn you badly, even if you just
open the hood. Stay away from the
engine if you see or hear steam
coming from it. Just turn it off and
get everyone away from the vehicle
until it cools down. Wait until there
is no sign of steam or coolant
before you open the hood.
If you keep driving when the engine
is overheated, the liquids in it can
catch fire. You or others could be
badly burned. Stop the engine if it
overheats, and get out of the
vehicle until the engine is cool.
If Steam Is Coming from the
Engine Compartment with No
Overheat Warning
(V-Series Only)
The V-Series hood vent is functional,
and will allow water from rain and car
washes to enter the engine
compartment and contact hot
surfaces. If steam is seen coming from
the hood vent with no accompanying
overheat warning, no action is
required.
If No Steam Is Coming from the
Engine Compartment
If an engine overheat warning is
displayed but no steam can be seen or
heard, the problem may not be too
serious. Sometimes the engine can get
a little too hot when the vehicle:
.Climbs a long hill on a hot day.
. Stops after high-speed driving.
. Idles for long periods in traffic.
If the overheat warning is displayed
with no sign of steam: 1. Turn the air conditioning off. 2. Turn the heater on to the highest
temperature and to the highest
fan speed. Open the windows as
necessary.
3. When it is safe to do so, pull off the road, shift to P (Park) or
N (Neutral) and let the
engine idle.
If the engine coolant temperature
gauge is no longer in the overheated
area or the engine coolant
temperature warning light no longer
displays, the vehicle can be driven.
Continue to drive the vehicle slowly
for about 10 minutes. Keep a safe
distance from the vehicle in front.
If the warning does not come back on,
continue to drive normally and have
the cooling system checked for proper
fill and function.
If the warning continues, pull over,
stop, and park the vehicle right away.
If there is no sign of steam, idle the
engine for three minutes while parked.
If the warning is still displayed, turn
off the engine until it cools down.

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-10287885) -
2017 - crc - 6/16/16
254 VEHICLE CARE
Caution
Continuing to drive with worn-out
brake pads could result in costly
brake repair.
Some driving conditions or climates
can cause a brake squeal when the
brakes are first applied or lightly
applied. This does not mean
something is wrong with the brakes.
If equipped with high performance
brake linings, there could be an
increased build-up of brake dust as
well as minor noises as compared to
standard brake linings.
Properly torqued wheel nuts are
necessary to help prevent brake
pulsation. When tires are rotated,
inspect brake pads for wear and
evenly tighten wheel nuts in the
proper sequence to torque
specifications. See Capacities and
Specifications 0319.
Brake pads should be replaced as
complete sets.
Brake Pedal Travel
See your dealer if the brake pedal does
not return to normal height, or if
there is a rapid increase in pedal
travel. This could be a sign that brake
service may be required.
Replacing Brake System Parts
Always replace brake system parts
with new, approved replacement parts.
If this is not done, the brakes may not
work properly. The braking
performance expected can change in
many other ways if the wrong
replacement brake parts are installed
or parts are improperly installed.
Brake Fluid
The brake master cylinder reservoir is
filled with GM approved DOT 3 brake
fluid as indicated on the reservoir cap.
See Engine Compartment Overview
0 234 for the location of the reservoir.
Checking Brake Fluid
With the vehicle in P (Park) on a level
surface, the brake fluid level should be
between the minimum and maximum
marks on the brake fluid reservoir.
There are only two reasons why the
brake fluid level in the reservoir may
go down:
. Normal brake lining wear. When
new linings are installed, the fluid
level goes back up.
. A fluid leak in the brake hydraulic
system. Have the brake hydraulic
system fixed. With a leak, the
brakes will not work well.
Always clean the brake fluid reservoir
cap and the area around the cap
before removing it.
Do not top off the brake fluid. Adding
fluid does not correct a leak. If fluid is
added when the linings are worn,
there will be too much fluid when

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-10287885) -
2017 - crc - 6/16/16
INDEX 325
IndexA
Accessories and Modifications . . . . . 232
Accessory Power . . . . . . . . . . . . . . . . . . . . 188
Adaptive Cruise Control . . . . . . . . . . . . 207
Adaptive ForwardLighting (AFL) . . . . . . . . . . . . . . . . . . . . . 148
Adaptive Forward Lighting (AFL) Light . . . . . . . . . . . . . . . . . . . . . . . . 121
Add-On Electrical Equipment . . . . . . 230
Adjustments Lumbar, Front Seats . . . . . . . . . . . . . . . . 54
Thigh Support . . . . . . . . . . . . . . . . . . . . . . 55
Air Cleaner/Filter, Engine . . . . . . . . . . 245
Air Conditioning . . . . . . . . . . . . . . .160, 163
Air Filter, Passenger Compartment . . . . . . . . . . . . . . . . . . . . . 169
Air Vents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
Airbag System Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
How Does an Airbag Restrain? . . . . . 72
Passenger Sensing System . . . . . . . . . 73
What Makes an Airbag Inflate? . . . . 71
What Will You See after anAirbag Inflates? . . . . . . . . . . . . . . . . . . . 72
When Should an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Where Are the Airbags? . . . . . . . . . . . . 69 Airbags
Adding Equipment to the
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Passenger Status Indicator . . . . . . . 113
Readiness Light . . . . . . . . . . . . . . . . . . . 113
Servicing Airbag-Equipped Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
System Check . . . . . . . . . . . . . . . . . . . . . . . 67
Alarm Vehicle Security . . . . . . . . . . . . . . . . . . . . . 40
Alert
Lane Change . . . . . . . . . . . . . . . . . . . . . . 222
Side Blind Zone (SBZA) . . . . . . . . . . 222
All-Season Tires . . . . . . . . . . . . . . . . . . . . . 271
Antilock Brake System (ABS) . . . . . . 195 Warning Light . . . . . . . . . . . . . . . . . . . . 117
Appearance Care Exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . 298
Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . 302
Armrest Storage . . . . . . . . . . . . . . . . . . . . . . 97
Assistance Systems for Driving . . . . 218
Assistance Systems for Parking and Backing . . . . . . . . . . . . . . . . . . . . . . . 215
Automatic Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Forward Braking . . . . . . . . . . . . . . . . . . 221
Headlamp System . . . . . . . . . . . . . . . . 147
Transmission . . . . . . . . . . . . . . . . . . . . . . 191

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-10287885) -
2017 - crc - 6/16/16
326 INDEX
Automatic (cont'd)Transmission Fluid . . . . . . . . . . . . . . . 244
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . . . . . 193
Shift Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . 257
B
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255Exterior Lighting Battery
Saver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Jump Starting . . . . . . . . . . . . . . . . . . . . . 292
Power Protection . . . . . . . . . . . . . . . . . . 151
Voltage and Charging Messages . . . . . . . . . . . . . . . . . . . . . . . . 127
Blade Replacement, Wiper . . . . . . . . . 257
Brake System Warning Light . . . . . . . . . . . . 116
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253
Antilock . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254
Parking . . . . . . . . . . . . . . . . . . . . . . . 195, 196
System Messages . . . . . . . . . . . . . . . . . 128
Braking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172 Automatic Forward . . . . . . . . . . . . . . . 221
Break-In, New Vehicle . . . . . . . . . . . . . . 184
Bulb Replacement . . . . . . . . . . . . . . . . . . 261 Back-up Lamps . . . . . . . . . . . . . . . . . . . 259 Bulb Replacement (cont'd)
Halogen Bulbs . . . . . . . . . . . . . . . . . . . . 259
Headlamp Aiming . . . . . . . . . . . . . . . . 258
Headlamps . . . . . . . . . . . . . . . . . . . . . . . . 259
High Intensity Discharge
(HID) Lighting . . . . . . . . . . . . . . . . . . . 259
License Plate Lamps . . . . . . . . . . . . . . 260
Buying New Tires . . . . . . . . . . . . . . . . . . . 280
C
Capacities and Specifications . . . . . . 319
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . . . . . 190
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Winter Driving . . . . . . . . . . . . . . . . . . . . 179
Cargo Tie-Downs . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Caution, Danger, and Warning . . . . . . . . 2
Center Console Storage . . . . . . . . . . . . . . 97
Chains, Tire . . . . . . . . . . . . . . . . . . . . . . . . . 284
Charging Wireless . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Charging System Light . . . . . . . . . . . . . 114
Check Malfunction Indicator EngineLight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Child Restraints Infants and Young Children . . . . . . . . 81 Child Restraints (cont'd)
Lower Anchors and Tethers for
Children . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Older Children . . . . . . . . . . . . . . . . . . . . . . 79
Securing . . . . . . . . . . . . . . . . . . . . . . . . .91, 93
Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Circuit Breakers . . . . . . . . . . . . . . . . . . . . . 261
Cleaning Exterior Care . . . . . . . . . . . . . . . . . . . . . . 298
Interior Care . . . . . . . . . . . . . . . . . . . . . . 302
Climate Control Systems Dual Automatic . . . . . . . . . . . . . . 160, 163
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Cluster, Instrument . . . . . . . . . . . . . . . . . 107
Compartments Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Competitive Driving Mode . . . . . . . . . 201
Composite Materials . . . . . . . . . . . . . . . . 184
Compressor Kit, Tire Sealant . . . . . . . 286
Control Traction and ElectronicStability . . . . . . . . . . . . . . . . . . . . . . . . . . 198
Control of a Vehicle . . . . . . . . . . . . . . . . 171
Convex Mirrors . . . . . . . . . . . . . . . . . . . . . . 42
Coolant
Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248
Engine Temperature Gauge . . . . . . 111

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-10287885) -
2017 - crc - 6/16/16
INDEX 327
Coolant (cont'd)Engine Temperature Warning
Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Cooling . . . . . . . . . . . . . . . . . . . . . . . . .160, 163
Cooling System . . . . . . . . . . . . . . . .246, 248
Engine Messages . . . . . . . . . . . . . . . . . . 129
Courtesy Lamps . . . . . . . . . . . . . . . . . . . . . 150
Cruise Control . . . . . . . . . . . . . . . . . . . . . . . 204 Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Cruise Control, Adaptive . . . . . . . . . . . 207
Cupholders . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
D
Danger, Warning, and Caution . . . . . . . . 2
Data Collection Infotainment System . . . . . . . . . . . . . 324
Data Recorder Performance . . . . . . . . . . . . . . . . . . . . . . . 153
Data Recorders, Event . . . . . . . . . . . . . . 323
Daytime Running Lamps (DRL) . . . 147
Defensive Driving . . . . . . . . . . . . . . . . . . . 171
Delayed Locking . . . . . . . . . . . . . . . . . . . . . 36
Distracted Driving . . . . . . . . . . . . . . . . . . 171
Dome Lamps . . . . . . . . . . . . . . . . . . . . . . . . 150
Door Ajar Messages . . . . . . . . . . . . . . . . . . . . . 129
Delayed Locking . . . . . . . . . . . . . . . . . . . . 36
Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Door (cont'd)
Power Locks . . . . . . . . . . . . . . . . . . . . . . . . . 36
Rear Seat Pass-Through . . . . . . . . . . . . 61
Drive Belt Routing, Engine . . . . . . . . . 322
Driver Assistance Systems . . . . . . . . . 214
Driver Information
Center (DIC) . . . . . . . . . . . . . . . . . . . . . . . 122
Driver Mode Control . . . . . . . . . . . . . . . . 199
Driving Assistance Systems . . . . . . . . . . . . . . . 218
Competitive . . . . . . . . . . . . . . . . . . . . . . . 201
Defensive . . . . . . . . . . . . . . . . . . . . . . . . . . 171
For Better Fuel Economy . . . . . . . . . . . 26
Hill and Mountain Roads . . . . . . . . 178
If the Vehicle is Stuck . . . . . . . . . . . . 180
Loss of Control . . . . . . . . . . . . . . . . . . . . 173
Off-Road Recovery . . . . . . . . . . . . . . . . 173
Track Events and Competitive . . . 174
Vehicle Load Limits . . . . . . . . . . . . . . 181
Wet Roads . . . . . . . . . . . . . . . . . . . . . . . . . 178
Winter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Dual Automatic Climate Control System . . . . . . . . . . . . . . .160, 163
E
Easy Entry Seat . . . . . . . . . . . . . . . . . . . . . . 51
Electrical Equipment, Add-On . . . . . 230 Electrical System
Engine Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
Fuses and Circuit Breakers . . . . . . . 261
Instrument Panel Fuse Block . . . . 265
Overload . . . . . . . . . . . . . . . . . . . . . . . . . . . 261
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Engine Air Cleaner/Filter . . . . . . . . . . . . . . . . . 245
Check and Service EngineSoon Light . . . . . . . . . . . . . . . . . . . . . . . 114
Compartment Overview . . . . . . . . . . 234
Coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248
Coolant Temperature Gauge . . . . . 111
Coolant Temperature Warning Light . . . . . . . . . . . . . . . . . . . 119
Cooling System . . . . . . . . . . . . . . 246, 248
Cooling System Messages . . . . . . . . 129
Drive Belt Routing . . . . . . . . . . . . . . . . 322
Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
Oil Life System . . . . . . . . . . . . . . . . . . . . 243
Oil Messages . . . . . . . . . . . . . . . . . . . . . . 130
Oil Pressure Light . . . . . . . . . . . . . . . . . 120
Overheating . . . . . . . . . . . . . . . . . . . . . . . 251
Power Messages . . . . . . . . . . . . . . . . . . 130
Running While Parked . . . . . . . . . . . 191
Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186

Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-MidEast-10287885) -
2017 - crc - 6/16/16
INDEX 331
OilEngine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 241
Engine Oil Life System . . . . . . . . . . . 243
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Pressure Light . . . . . . . . . . . . . . . . . . . . . 120
Older Children, Restraints . . . . . . . . . . . 79
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Overheating, Engine . . . . . . . . . . . . . . . . 251
P
Park Shifting Into . . . . . . . . . . . . . . . . . . . . . . 188
Shifting Out of . . . . . . . . . . . . . . . . . . . . 189
Parking Brake . . . . . . . . . . . . . . . . . . . . . . . . . 195, 196
Brake and P (Park)Mechanism Check . . . . . . . . . . . . . . . 257
Extended . . . . . . . . . . . . . . . . . . . . . . . . . . 190
Over Things That Burn . . . . . . . . . . . 190
Parking Assist . . . . . . . . . . . . . . . . . . . . . . . 215
Parking Brake
Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Parking or Backing Assistance Systems . . . . . . . . . . . . . . . 215
Passenger Airbag Status
Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Passenger Compartment Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169 Passenger Sensing System . . . . . . . . . . 73
Performance Data
Recorder (PDR) . . . . . . . . . . . . . . . . . . . . 153
Personalization Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Power Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Outlets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Protection, Battery . . . . . . . . . . . . . . . . 151
Retained Accessory (RAP) . . . . . . . . 188
Seat Adjustment . . . . . . . . . . . . . . . . . . . . 52
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Pregnancy, Using Safety Belts . . . . . . 66
Privacy Vehicle Data Recording . . . . . . . . . . 323
R
Reading Lamps . . . . . . . . . . . . . . . . . . . . . 150
Rear AxleLimited-Slip . . . . . . . . . . . . . . . . . . . . . . . 204
Rear Seat Pass-Through Door . . . . . . . 61
Rear Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Rear Vision Camera (RVC) . . . . . . . . . 215
Rearview Mirrors Automatic Dimming . . . . . . . . . . . . . . . . 45
Reclining Seatbacks . . . . . . . . . . . . . . . . . 55
Recommended Fluids and Lubricants . . . . . . . . . . . . . . . . . . . . . . . . . 314 Records
Maintenance . . . . . . . . . . . . . . . . . . . . . . 317
Recreational Vehicle Towing . . . . . . . 296
Remote Keyless Entry (RKE) System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Remote Vehicle Start . . . . . . . . . . . . . . . . 33
Replacement Bulbs . . . . . . . . . . . . . . . . . 261
Replacement Parts Airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Maintenance . . . . . . . . . . . . . . . . . . . . . . 315
Replacing Airbag System . . . . . . . . . . . . 78
Replacing LATCH System Parts
after a Crash . . . . . . . . . . . . . . . . . . . . . . . . 91
Replacing Safety Belt System Parts after a Crash . . . . . . . . . . . . . . . . . 67
Restraints
Where to Put . . . . . . . . . . . . . . . . . . . . . . . . 84
Retained Accessory Power (RAP) . . . . . . . . . . . . . . . . . . . . . . . 188
Reverse Tilt Mirrors . . . . . . . . . . . . . . . . . 44
Ride Control Systems Limited Slip Rear Axle . . . . . . . . . . . 204
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Roads Driving, Wet . . . . . . . . . . . . . . . . . . . . . . . 178
Roof Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Rotation, Tires . . . . . . . . . . . . . . . . . . . . . . 278
