2017.75 VAUXHALL CROSSLAND X traction control

In brief111Power windows .....................37
2 Exterior mirrors .....................34
3 Cruise control .....................146
Speed limiter ....................... 148
4 Turn and lane-change
signals, headlight flash,
low/high beam, high beam
assist ................................... 110
Exit lighting ......................... 113
Parking lights ...................... 111
Buttons for Driver
Information Centre ................92
5 Side air vents ...................... 123
6 Instruments .......................... 82
Driver Information Centre ...... 92
7 Buttons for Driver
Information Centre ................92
8 Windscreen wiper and
washer, rear wiper and
washer ................................. 74
9 Head-up display ....................96
10 Centre air vents .................. 123
11 Hazard warning flashers ....109
12 Info-Display .......................... 9413Centre air vent ......................94
14 Light sensor
15 Central locking system ..........24
16 Glovebox .............................. 63
Fuse box ............................ 192
17 Controls for Info-Display
operation ............................... 94
18 Climate control system ........ 115
19 USB charging port ................ 77
20 Parking assist/Advanced
parking assist .....................150
Lane departure warning .....164
Eco button for stop-start
system ................................. 131
Electronic Stability Control and Traction Control ..........145
21 Power outlet .......................... 77
22 Manual transmission ..........142
Automatic transmission ......139
23 Manual parking brake .........144
24 Power button ....................... 128
25 Ignition switch .....................127
26 Steering wheel adjustment ..7327 Horn ..................................... 74
28 Bonnet release lever ..........176
29 Storage ................................. 63
30 Head-up display ....................96
31 Light switch ........................ 106
Headlight range
adjustment ......................... 108
Front/rear fog lights ............110
Instrument illumination .......111

72Instruments and controlsInstruments and
controlsControls ....................................... 73
Steering wheel adjustment ........73
Steering wheel controls .............73
Heated steering wheel ...............73
Horn ........................................... 74
Windscreen wiper/washer .........74
Rear window wiper/washer .......76
Outside temperature ..................76
Clock ......................................... 77
Power outlets ............................. 77
Inductive charging .....................78
Ashtrays .................................... 78
Warning lights, gauges and indi‐ cators ........................................... 79
Instrument cluster ......................79
Speedometer ............................. 82
Odometer .................................. 83
Trip odometer ............................ 83
Tachometer ............................... 83
Fuel gauge ................................ 84
Engine coolant temperature gauge ....................................... 84
Service display .......................... 84
Control indicators ......................85Turn signal................................. 85
Seat belt reminder .....................86
Airbag and belt tensioners .........86
Airbag deactivation ....................87
Charging system .......................87
Malfunction indicator light ..........87
Service vehicle soon .................87
Stop engine ............................... 87
System check ............................ 88
Brake and clutch system ...........88
Antilock brake system (ABS) .....88
Gear shifting .............................. 88
Lane departure warning ............88
Electronic Stability Control and Traction Control system ...........89
Electronic Stability Control and Traction Control system off ......89
Engine coolant temperature ......89
Preheating ................................. 89
Diesel particle filter ....................89
AdBlue ....................................... 89
Deflation detection system ........90
Engine oil pressure ....................90
Low fuel ..................................... 90
Autostop .................................... 90
Exterior light .............................. 90
High beam ................................. 91
High beam assist .......................91
Low beam .................................. 91
Fog light ..................................... 91Rear fog light............................. 91
Rain sensor ............................... 91
Cruise control ............................ 91
Speed limiter ............................. 91
Traffic sign assistant ..................91
Door open .................................. 91
Information displays .....................92
Driver Information Centre ..........92
Info display ................................ 94
Head-up display ........................96
Vehicle messages ........................97
Warning chimes .........................98
Battery voltage .......................... 98
Vehicle personalisation ................99
Telematics service .....................102
OnStar ..................................... 102

82Instruments and controlsOverviewOTurn signal 3 85XSeat belt reminder 3 86vAirbag and belt tensioners
3 86VAirbag deactivation 3 87pCharging system 3 87ZMalfunction indicator light
3 87HService vehicle soon 3 87STOPStop engine 3 87JSystem check 3 88RBrake and clutch system
3 88uAntilock brake system (ABS)
3 88RGear shifting 3 88)Lane departure warning
3 88bElectronic Stability Control
and Traction Control system
3 89aElectronic Stability Control
and Traction Control system
off 3 89!Preheating 3 89%Diesel particle filter 3 89YAdBlue 3 89wDeflation detection system
3 90IEngine oil pressure 3 90Y oLow fuel 3 90W oEngine coolant temperature
high 3 89DAutostop 3 908Exterior light 3 909Low beam 3 91CHigh beam 3 91fHigh beam assist 3 91>Fog light 3 91øRear fog light 3 91 Speedometer
Indicates vehicle speed.

Instruments and controls89Electronic Stability Controland Traction Control system
b illuminates or flashes yellow.
Illuminates
A fault in the system is present.
Continued driving is possible. Driving
stability, however, may deteriorate
depending on road surface
conditions.
Have the cause of the fault remedied
by a workshop.
Flashes
The system is actively engaged.
Engine output may be reduced and the vehicle may be braked
automatically to a small degree.
Electronic Stability Control and
Traction Control system 3 145.
Electronic Stability Control and Traction Control system
off
n illuminates yellow.
The systems are deactivated.Engine coolant temperature
o illuminates red.
Illuminates when the engine is
running
Stop, switch off engine.Caution
Coolant temperature too high.
Check coolant level immediately
3 178.
If there is sufficient coolant, consult a workshop.
Preheating
! illuminates yellow.
Preheating of Diesel engine is
activated. Only activates when
outside temperature is low. Start the
engine when control indicator
extinguishes.
Diesel particle filter % or H illuminates yellow.
The diesel particle filter requires
cleaning.
Continue driving until the control
indicator extinguishes.
Illuminates temporarily Start of saturation of the particle filter.
Start cleaning process as soon as possible by driving at a vehicle speed
of at least 40 mph.
Illuminates constantlyIndication of a low additive level. Seek
the assistance of a workshop.
Diesel particle filter 3 135.
AdBlue Y flashes or illuminates yellow.
Illuminates yellow
The remaining driving range is
between 600 km and 2400 km.
Have the AdBlue® topped-up as soon as possible by a qualified workshop.
You can add up to 10 litres of
AdBlue® to its tank.

126Driving and operatingDriving and
operatingDriving hints ............................... 127
Control of the vehicle ...............127
Steering ................................... 127
Starting and operating ...............127
New vehicle running-in ............127
Ignition switch positions ...........127
Power button ........................... 128
Power saving mode .................129
Starting the engine ..................130
Overrun cut-off ........................ 131
Stop-start system ....................131
Parking .................................... 134
Engine exhaust .......................... 135
Diesel particle filter ..................135
Catalytic converter ...................136
AdBlue ..................................... 136
Automatic transmission ..............139
Transmission display ...............139
Selector lever .......................... 139
Manual mode ........................... 140
Electronic driving programmes 141
Fault ........................................ 141
Interruption of power supply ....141Manual transmission ..................142
Brakes ........................................ 143
Antilock brake system .............143
Parking brake .......................... 144
Brake assist ............................. 144
Hill start assist ......................... 144
Ride control systems .................145
Electronic Stability Control and Traction Control system .........145
Driver assistance systems .........146
Cruise control .......................... 146
Speed limiter ........................... 148
Parking assist .......................... 150
Advanced parking assist .........153
Side blind spot alert .................158
Panoramic view system ...........160
Rear view camera ...................162
Lane departure warning ..........164
Driver alert ............................... 165
Fuel ............................................ 166
Fuel for petrol engines .............166
Fuel for diesel engines ............167
Refuelling ................................ 167
Fuel consumption - CO 2-
Emissions .............................. 168
Trailer hitch ................................ 169
General information .................169Driving characteristics and
towing tips .............................. 169
Trailer towing ........................... 170
Towing equipment ...................170

Driving and operating145Ride control systems
Electronic Stability Control and Traction Control system
Electronic Stability Control improves
driving stability when necessary, regardless of the type of road surface
or tyre grip.
As soon as the vehicle starts to
swerve (understeer/oversteer),
engine output is reduced and the wheels are braked individually.
Electronic Stability Control operates
in combination with the Traction
Control system. It prevents the driven wheels from spinning.
The Traction Control system is a
component of the Electronic Stability
Control.
Traction Control improves driving
stability when necessary, regardless
of the type of road surface or tyre grip,
by preventing the driven wheels from
spinning.
As soon as the driven wheels starts to spin, engine output is reduced and
the wheel spinning the most is brakedindividually. This considerably
improves the driving stability of the
vehicle on slippery road surfaces.
Electronic Stability Control and
Traction Control are operational after
each engine start as soon as the
control indicator b extinguishes.
When Electronic Stability Control and Traction Control operate, b flashes.
9 Warning
Do not let this special safety
feature tempt you into taking risks
when driving.
Adapt speed to the road
conditions.
Control indicator b 3 89.
Deactivation
Electronic Stability Control and
Traction Control can be deactivated,
everytime it is required: press a.
Control indicator a illuminates.
Control indicator a 3 89.
A status message appears in the
Driver Information Centre when
Electronic Stability Control Traction
Control are deactivated.
Electronic Stability Control and
Traction Control are reactivated by
pressing the a button again, by

146Driving and operatingapplying the brake or in the case that
the vehicle is driven faster than 30
mph.
a extinguishes when Electronic
Stability Control and Traction Control
are reactivated.
Electronic Stability Control and
Traction Control are also reactivated
the next time the ignition is switched
on.
Fault
If there is a fault in the system, the
control indicator b illuminates
continuously and a message appears in the Driver Information Centre. The
system is not operational.
Have the cause of the fault remedied by a workshop.Driver assistance
systems9 Warning
Driver assistance systems are
developed to support the driver
and not to replace the driver's
attention.
The driver stays in full control of
the vehicle and accepts full
responsibility when driving the
vehicle.
When using driver assistance
systems, always take care
regarding the current traffic
situation and follow applicable
traffic rules.
Cruise control
The cruise control can store and
maintain speeds above 25 mph.
Additionally at least the third gear
must be engaged on manual
transmission, on automatic
transmission position D or the second
or a higher gear in position M must be
selected.
Deviations from the stored speeds
may occur when driving uphill or
downhill.
The system maintains the vehicle
speed at the preset speed by the
driver, without any action on the
accelerator pedal.
The preset speed can be exceeded
temporarily by pressing the
accelerator pedal.
The status and preset speed is
displayed in the Driver Information Centre.
Do not use the cruise control if it is not advisable to maintain a constant
speed.

148Driving and operating
Press MEM on the steering wheel to
request saving of the suggested
speed.
Press MEM on the steering wheel
once more to confirm and save the
new speed setting.
This speed is the new value for the
cruise control.
This function can be deactivated or activated in the personalisation
menu, 3 99.
Exceeding the set speed
Vehicle speed can be increased bydepressing the accelerator pedal.
When the accelerator pedal is
released, the previously stored speed
is resumed.
Deactivation
Press Ñ: cruise control is in pause
mode, Pause is indicated. The
vehicle is driven without cruise
control.
Cruise control is deactivated, but not
switched off. Last stored speed
remains in memory for later speed
resume.
Cruise control is deactivated
automatically:
● The brake pedal is depressed.
● The clutch pedal is depressed.
● Vehicle speed is below 25 mph.
● The Traction Control system or Electronic Stability Control is
operating.
● The selector lever is in N.Resume stored speed
Press toggle switch to RES/+ or Ñ at
a speed above 25 mph. The stored
speed will be obtained.
Switching off
Press m: the cruise control mode is
deselected and the cruise control
indication extinguishes in the Driver
Information Centre.
Pressing ß to activate the speed
limiter deactivates cruise control.
Switching off the ignition cancels any
programmed speed value.
Fault
In the event of a cruise control fault,
the speed is cleared resulting in
flashing of the dashes.
Speed limiter
The speed limiter prevents the vehicle exceeding a preset maximum
speed.
The maximum speed can be set at
speeds above 18 mph.
