Usage .......................................... 10General information
The Infotainment system provides
you with state-of-the-art in-car
infotainment.
The radio can easily be used by
registering a large number of FM, AM
and DAB (Digital Audio Broadcasting)
radio stations with the 1...6 preset
buttons.
You can connect external data
storage devices to the Infotainment
system as further audio sources;
either via cable or via Bluetooth ®
.
The navigation system reliably guides
you to your destination and, if desired, automatically avoids traffic jams or
other traffic problems.
In addition, the Infotainment system is
equipped with a phone application
that allows for comfortable and safe
use of your mobile phone in the
vehicle.
The Infotainment system can be
operated using the instrument panel
controls, the touch screen, the
controls on the steering wheel or the
speech recognition function.The well-thought-out design of the
control elements and the clear
displays enable you to control the
system easily and intuitively.
Information on operation details and
news on software updates can be
obtained on our website.
Notice
This manual describes all options
and features available for the
various Infotainment systems.
Certain descriptions, including those for display and menu functions, may
not apply to your vehicle due to
model variant, country
specifications, special equipment or
accessories.
Important information on
operation and traffic safety9 Warning
The Infotainment system must be
used so that the vehicle can be
driven safely at all times. If in
doubt, stop the vehicle and
operate the Infotainment system
while the vehicle is stationary.
Page 9 of 111
Introduction91m VOL
Press: switch on/off
Infotainment system ..............10
Turn: adjust volume ..............10
2 MENU SELECT
Turn: mark menu options
or set alphanumeric values ..12
Press: select/activate the
marked option; confirm set
value; switch function on/
off; open audio or
navigation menu ...................12
3 BACK
Menu: one level back ............12
Input: delete last character
or entire entry ........................ 12
4 HOME
Access Home Page ..............12
5 H
Radio: search forwards .........19
External devices: skip
track forwards ....................... 256I
Radio: search backwards .....19
External devices: skip
track backwards ....................25
7 SRC (Source)
Press to toggle through the
different audio sources
USB ....................................... 24
Bluetooth ............................... 24
AM ......................................... 19
FM ......................................... 19
DAB ....................................... 19
8 q
Take phone call or
activate/deactivate mute .......57
9 DEST
Open navigation
destination menu ..................34
10 NAV
Display map ......................... 30Steering wheel audio controls
1qw
Short press: take phone call . 57
or dial number in call list .......57
or activate speech
recognition ............................ 45
Long press: show call list ......57
or activate voice pass-thru
(if supported by phone) .........45
2 SRC (Source)
Press: select audio source ....19
Page 11 of 111
Introduction11Automatic switch-off
If the Infotainment system is switched
on by pressing X VOL while the
ignition is switched off, it switches off
again automatically after 10 minutes.
Setting the volume
Turn X VOL . The current setting is
shown in a pop-up at the bottom of the screen.
When the Infotainment system is
switched on, the last selected volume is set, provided that the volume is
lower than the maximum start-up
volume.
The following volume settings can be
set separately:
● The maximum start-up volume 3 16
● The volume of the traffic announcements 3 16
● The volume of the navigation messages 3 30Auto volume
When auto volume is activated
3 16, the volume is adapted
automatically to compensate for the
road and wind noise as you drive.
Mute
Press q to mute the audio sources.
To cancel mute again: turn X VOL or
press q again.
Modes of operation Audio players
Repeatedly press SRC to toggle
between the AM, FM, USB,
Bluetooth or DAB main menus.
For detailed descriptions of: ● USB port 3 24
● Bluetooth audio 3 24
● AM radio 3 19
● FM radio 3 19
● DAB radio 3 23
Navigation
Press NAV to display the map of the
navigation application.Press MENU SELECT to open a
submenu with options for the input of
destinations and the structuring of a
route.
For a detailed description of the
navigation functions 3 28.
Phone
Press q to display the phone main
menu with options for the input or selection of numbers.
For a detailed description of the
mobile phone functions 3 54.
Page 12 of 111
12Basic operationBasic operationBasic operation............................ 12
Tone settings ............................... 15
Volume settings ........................... 16
System settings ........................... 17Basic operation
MENU SELECT knob Turn the MENU SELECT knob:
● To mark a menu option.
● To set an alphanumeric value.
Press the MENU SELECT knob:
● To select or activate the marked option.
● To confirm a set value.
● To open an application or submenu.
Touch screen Touch a screen button: ● To activate the respective option or function.
● To open an application or submenu.
Touch the screen and move your
finger:
● To scroll a list.
● To scroll the map.HOME button
Press HOME to access the Home
Page .
To display the next home page, select
More at the bottom of the screen.
Page 13 of 111
Basic operation13
You may then access the different
applications.
BACK button or Back screen
button
Press BACK or touch Back on the
screen:
● To exit a menu or screen.
● To return from a submenu to the next higher menu level.
● To delete the last character in a character sequence.
Press and hold BACK or touch and
hold Back for a few seconds to delete
the entire entry.
Examples of menu operation
Selecting a screen element
To select a screen button or menu
item, you may optionally:
● Touch the respective screen button or menu item.
● Turn MENU SELECT to move the
cursor to the desired option and then press MENU SELECT to
select the marked item.
The corresponding system function is
activated, a message is shown, or a
submenu with further options is
displayed.
Notice
In subsequent chapters, the
operating steps for selecting and
activating a screen button or menu
item will be described as "...select
Page 15 of 111
Basic operation15
Notice
In subsequent chapters, the
operating steps for entering
characters will be described as
"...enter the desired characters...".
Tone settings Press HOME and then select More at
the bottom of the screen. On the second Home Page , select Tone. The
tone settings menu is displayed.Bass
Use this setting to enhance or
attenuate the deep frequencies of the audio sources.
Adjust the setting as desired.
Mid
Use this setting to enhance or
attenuate the midrange frequencies
of the audio source.
Adjust the setting as desired.
Treble
Use this setting to enhance or
attenuate the high frequencies of the
audio sources.
Adjust the setting as desired.
EQ mode (EQ: Equaliser)
Use this setting to optimise the tone
for a specific style of music, e.g.
Rock or Classical .
Select EQ. A submenu with
predefined sound styles is displayed.
Select the desired sound style.
If one of the predefined sound styles
is selected, Bass, Mid and Treble are
preadjusted by the system.
If you manually adjust one of the
settings described above, EQ is set to
Manual .
Fade and Balance
When Fade or Balance are selected,
an illustration is displayed on the right side of the screen.
Page 16 of 111
16Basic operation
To adjust the volume distribution
between the front and rear speakers
in the vehicle, select Fade. Adjust the
setting as desired.
To adjust the volume distribution
between the left and right speakers in the vehicle, select Balance. Adjust
the setting as desired.
Volume settings
Adjusting the Auto Volume
Press HOME and then select Config
to display the settings menu.
Select Radio Settings and then Auto
Volume .
To adjust the degree of volume
adaptation, set Auto Volume to Off,
Low , Medium or High .
Off : no enhancement of volume with
increasing vehicle speed.
High : maximum enhancement of
volume with increasing vehicle
speed.
Adjusting the Startup Volume
Press HOME and then select Config
to display the settings menu.
Select Radio Settings and then
Startup Volume .
Adjust the setting as desired.
Adjusting the volume of traffic
announcements
The volume of traffic announcements
can be preset to a level independent
of the "normal" volume level.
Press HOME and then select Config
to display the settings menu.
Select Radio Settings , RDS Options
and then Traffic Volume .
Adjust the setting as desired.Notice
While an announcement is being
broadcasted, the volume can be adjusted by turning m VOL .
Adjusting the Chime Volume
When operating the controls in the
vehicle, beeping sounds confirm your
actions. The volume of the beeping
sounds may be adjusted.
Press HOME and then select Config
to display the settings menu.
Select Vehicle Settings , Comfort and
Convenience and then Chime
Volume .
Select Low or High .
Adjusting the Navigation Volume
Press HOME and then select Config
to display the settings menu.
Select Navigation Settings , Voice
Prompt and then Navigation Volume .
To adjust the volume of the
announcements, select
Announcement and then adjust the
setting as desired.
Page 17 of 111
Basic operation17To adjust the volume of the audio
source possibly playing in the
background, select Background and
then adjust the setting as desired.
Select Volume Test to get an audio
example of the settings.
Notice
While an announcement is being broadcasted, the volume can beadjusted by turning m VOL .
System settings
Various Infotainment system settings
may be adjusted via the Config
application.Language settings
Press HOME , select Config and then
Languages .
A list of all languages available is
displayed.
Select the desired language.
Time and date settings
Press HOME , select Config and then
Time and Date .
Automatic time adjustment
The system constantly receives
information on the current time and
date.
If you wish the time and date settings to be updated automatically, activate
RDS Auto Time Adjust .
If you wish to set time and date
manually, deactivate RDS Auto Time
Adjust .
Set time
To adjust the time settings, select Set
Time .
Adjust the settings as desired.
Set date
To adjust the date settings, select Set
Date . Adjust the settings as desired.
Time format
To choose the desired time format,
select 12 hr / 24 hr Format . A
submenu is displayed. Activate 12
Hour or 24 Hour .
Software information
Press HOME , select Config and then
Radio Settings .
