2017.5 VAUXHALL MOVANO_B climate control

Introduction.................................... 2
In brief ............................................ 6
Keys, doors and windows ............19
Seats, restraints ........................... 41
Storage ........................................ 70
Instruments and controls .............81
Lighting ...................................... 106
Climate control ........................... 114
Driving and operating .................130
Vehicle care ............................... 172
Service and maintenance ..........218
Technical data ........................... 221
Customer information ................245
Index .......................................... 250Contents

In brief111Fixed air vents .................... 128
2 Headlight range
adjustment ......................... 108
Ultrasonic parking assist .....161
Traction control system ......154
Electronic Stability
Program ............................. 155
3 Side air vents .....................127
4 Light switch ........................ 106
Turn and lane-change
signals ................................ 109
High beam and low beam,
headlight flash ....................107
Sidelights ............................ 106
Automatic light control .......106
Exit lighting ......................... 113
Front fog lights ...................110
Rear fog light ...................... 110
High beam assist ................107
5 Instruments .......................... 87
Transmission display ............91Driver Information Centre .... 100
Trip computer ...................... 102
6 Horn ..................................... 82
Driver airbag ........................ 58
7 Remote control on
steering wheel .......................82
Cruise control .....................157
8 Windscreen wiper,
windscreen washer system ..83
Trip computer ...................... 102
9 Coin tray ............................... 70
10 Power outlet, USB slot ..........85
11 Centre air vents .................. 127
12 Storage compartment ...........70
13 Info-display .......................... 100
14 Front passenger airbag .........58
15 Storage compartment ..........70
16 Glovebox .............................. 71
17 Seat belt reminder ................. 94
Front passenger airbag
deactivation ........................... 59
18 Cupholders ........................... 7119Climate control system ....... 114
Electronic climate control
system ................................. 116
20 Cigarette lighter .................... 87
Power outlet ......................... 85
21 Gear lever, Manual
transmission ........................ 148
Manual transmission
automated ........................... 148
22 Cruise control and speed
limiter ................................. 157
Manual transmission
automated,
Winter and Laden modes ....150
Idle speed control ...............134
Stop-start system ................134
ECO mode .......................... 131
23 Ignition switch with
steering wheel lock ............132
24 Steering column controls .....82
25 Steering wheel adjustment ..82
26 Bonnet release lever ..........174
27 Auxiliary heater ...................121

In brief15Climate control
Heated rear window
Heating is operated by pressing Ü.
Heated rear window 3 39.
Heated exterior mirrors
Pressing Ü also activates the heated
exterior mirrors.
Heated exterior mirrors 3 35.
Demisting and defrosting the
windows
Climate control system
● Set temperature control to warmest level.
● Set fan speed to highest level.
● Set air distribution control to V.
● Switch on heated rear window Ü.
● Switch cooling A/C on.
● Open side air vents as required and direct them towards door
windows.
Climate control system 3 114.
Electronic climate control system
Press V.
Temperature and air distribution are
set automatically and the fan runs at
a high speed.
Electronic climate control system 3 116.

36Keys, doors and windowsHeating works with the engine
running and is switched off
automatically after a short time.
Climate control system 3 114.
Electronic climate control system 3 116.Interior mirrors
Manual anti-dazzle
To reduce dazzle, adjust the lever on the underside of the mirror housing.
Wide view mirror
Depending on vehicle, a large convex
mirror is located in the front
passenger sun visor which helps to
increase visibility and reduce blind
spots.

Keys, doors and windows39Rear reversing lens
A rear reversing lens may be fitted to
the rear window.
The rear reversing lens assists the
driver when reversing by reducing
blind spots.
Heated rear window
Operated by pressing Ü on either
system. LED illuminates in button
during operation.
Heating works with the engine
running and is switched off
automatically after a short time.
Climate control system 3 114.
Electronic climate control system 3 116.
Sun visors
The sun visors can be folded down or swivelled to the side to prevent
dazzling.
If the sun visors have integral mirrors, the mirror covers should be closed
when driving.
Sun visors may also feature a holder for parking tickets etc.
Wide view mirror 3 36.

114Climate controlClimate controlClimate control systems.............114
Heating and ventilation system 114
Air conditioning system ...........115
Electronic climate control system .................................... 116
Rear heating system ...............118
Rear air conditioning system ...120
Auxiliary heater ........................121
Air vents ..................................... 127
Adjustable air vents .................127
Fixed air vents ......................... 128
Glovebox cooler ......................128
Maintenance .............................. 128
Air intake ................................. 128
Pollen filter ............................... 128
Air conditioning regular operation ................................ 128
Service .................................... 128Climate control systems
Heating and ventilation system
Controls for: ● temperature
● fan speed
● air distribution
● demisting and defrosting
Heated rear window Ü 3 39, Heated
seats ß 3 48.
Temperaturered:warmblue:cold
Heating will not be fully effective until
the engine has reached normal
operating temperature.
Fan speed
Adjust the air flow by switching the fan
to the desired speed.
Air distribution
M:to head areaL:to head area and foot wellK:to foot wellJ:to windscreen, front door
windows and foot wellV:to windscreen and front door
windows
Intermediate settings are possible.
Demisting and defrosting the
windows
● Set temperature control to warmest level.
● Set fan speed to highest level.

Climate control115●Set air distribution control to V.
● Switch on heated rear window Ü.
● Open side air vents as required and direct them towards door
windows.
● For simultaneous warming of the
foot well, set air distribution
control to J.
Air conditioning system
Additional to the heating and
ventilation system, the air
conditioning system has controls for:
A/C:coolingu:air recirculationHeated rear window Ü 3 39, Heated
seats ß 3 48.
Cooling (A/C)
Press A/C to switch on cooling. The
LED in the button illuminates to
indicate activation. Cooling is only
functional when the engine is running
and climate control fan is switched on.
Press A/C again to switch off cooling.
The air conditioning system cools and
dehumidifies (dries) the air when
outside temperature is a little above
the freezing point. Therefore
condensation may form and drip from under the vehicle.
If no cooling or drying is required,
switch the cooling system off to save
fuel.
Notice
If the climate control is set to
maximum cooling while the ambient temperature is high, an Autostop
may be inhibited until the required
temperature in the passenger
compartment has been reached.If the climate control is set to
maximum cooling while the engine is
in an Autostop, the engine may
restart automatically.
Stop-start system 3 134.
Air recirculation system Press u to activate air recirculation
mode. The LED in the button
illuminates to indicate activation.
Press u again to deactivate air
recirculation mode.9 Warning
The exchange of fresh air is
reduced in air recirculation mode.
In operation without cooling the air humidity increases, so the
windows may mist up. The quality
of the passenger compartment air
deteriorates, which may cause the vehicle occupants to feel drowsy.
Maximum cooling
Briefly open the windows so that hotair can disperse quickly.

116Climate control● Cooling A/C on.
● Air recirculation system u on.
● Set air distribution control to M.
● Set temperature control to coldest level.
● Set fan speed to highest level.
● Open all air vents.
Demisting and defrosting the
windows
● Switch cooling A/C on.
● Set temperature control to warmest level.
● Set fan speed to highest level.
● Set air distribution control to V.
● Switch on heated rear window Ü.
● Open side air vents as required and direct them towards door
windows.
● For simultaneous warming of the
foot well, set air distribution
control to J.Notice
If V is pressed while the engine is
running, an Autostop will be inhibited
until V is pressed again.
If V is pressed while the engine is
in an Autostop, the engine will restart automatically.
Stop-start system 3 134.
Electronic climate control systemControls for: ● temperature
● air distribution ( ï or î) and
menu selection
● fan speed xAUTO:automatic modeu:air recirculationV:demisting and defrostingÜ:heated rear window,
heated exterior mirrorsA/C OFF:switch off air conditioning
Heated rear window, heated exterior
mirrors Ü 3 39, 3 35.
Heated seats ß 3 48.
The preselected temperature is
automatically regulated. In automatic
mode, the fan speed and air
distribution automatically regulate the
air flow.
The system can be manually adapted by use of air distribution and air flowcontrols.
The electronic climate control system
is only fully operational when the
engine is running.
For correct operation, do not cover
the sensor on the instrument panel.
