2017.5 VAUXHALL INSIGNIA lock

6In briefIn briefInitial drive informationVehicle unlocking
Press c
to unlock the doors and load
compartment. Open the doors by
pulling the handles. To open the
tailgate, push the brand emblem and
open the tailgate.
Electronic key system 3 20, Central
locking system 3 22, Load
compartment 3 27.
Seat adjustment
Longitudinal adjustment
Pull handle, slide seat, release
handle. Try to move the seat back and forth to ensure that the seat is locked
in place.
Seat position 3 41, Manual seat
adjustment 3 42, Power seat
adjustment 3 44.

In brief9Exterior mirrors
Select the relevant exterior mirror by
pushing left or right mirror button.
LED in button indicates the selection.
Then swivel the control to adjust the
mirror.
Convex exterior mirrors 3 32,
Electric adjustment 3 32, Folding
exterior mirrors 3 32, Heated
exterior mirrors 3 33.
Steering wheel adjustment
Unlock lever, adjust steering wheel,
then engage lever and ensure it is fully locked. Do not adjust steering
wheel unless vehicle is stationary and steering wheel lock has been
released.
Airbag system 3 52.

In brief111Power windows .....................34
2 Exterior mirrors .....................32
3 Central locking system ..........22
4 Side air vents ...................... 148
5 Cruise control .....................177
Speed limiter ....................... 179
Adaptive cruise control .......180
Forward collision alert .........188
6 Turn and lane-change
signals, headlight flash,
low/high beam, high beam
assist ................................... 132
Exit lighting ......................... 136
Parking lights ...................... 133
Buttons for Driver
Information Centre ..............103
7 Instruments .......................... 92
Driver Information Centre .... 103
8 Buttons for Driver
Information Centre ..............103
9 Head-up display ..................11210Windscreen wiper and
washer, headlight washer,
rear wiper and washer .........79
11 Centre air vents .................. 148
12 Hazard warning flashers ....132
13 Info-Display ........................ 110
14 Anti-theft alarm system
status LED ........................... 29
15 Electronic Stability Control . 173
Traction Control system .....172
16 Glovebox .............................. 67
17 Controls for Info-Display
operation ............................. 110
18 Climate control system ........ 139
19 Storage ................................. 67
20 Sport/Tour mode ................174
Parking assist/Advanced
parking assist .....................197
Lane keep assist ................218
Eco button for stop-start
system ................................. 156
21 Manual transmission ..........168
Automatic transmission ......16422Electric parking brake .........170
23 Power switch ....................... 153
25 Steering wheel adjustment ..78
26 Horn ..................................... 79
27 Bonnet release lever ..........230
28 Fuse box ............................ 247
29 Light switch ........................ 125
Headlight range
adjustment ......................... 128
Front/rear fog lights ............133
Instrument illumination .......134
30 Head-up display ..................112

In brief17Starting offCheck before starting off ● Tyre pressure and condition 3 250, 3 285.
● Engine oil level and fluid levels 3 231.
● All windows, mirrors, exterior lighting and number plates are
free from dirt, snow and ice and
are operational.
● Proper position of mirrors, seats, and seat belts 3 32, 3 41,
3 51.
● Brake function at low speed, particularly if the brakes are wet.Starting the engine
● Ignition switch: turn key toposition 2.
Power button: press
Engine Start/Stop for a few
seconds until green LED
illuminates.
● Move the steering wheel slightly to release the steering wheel
lock.
● Operate clutch and brake.
● Automatic transmission: operate brake pedal and move selector
lever to P or N.
● Do not operate accelerator pedal.
● Diesel engines: wait until control
indicator ! for preheating
extinguishes.
● Ignition switch: turn key to position 3 and release.
Power button: press
Engine Start/Stop and release.
● The engine starts after a short delay.
Starting the engine 3 154.

18In briefStop-start system
If the vehicle is at a low speed or at astandstill and certain conditions are
fulfilled, an Autostop is activated.
An Autostop is indicated by the
needle at the AUTOSTOP position in
the tachometer.
A restart is indicated by the needle at
the idle speed position in the
tachometer.
Stop-start system 3 156.
Parking9 Warning
● Do not park the vehicle on an
easily ignitable surface. The
high temperature of the
exhaust system could ignite the
surface.
● Always apply the parking brake. Pull switch m for
approx. one second and check
if the control indicator m
illuminates.
The electric parking brake is applied when control indicator
m illuminates 3 98.
● Switch off the engine. ● If the vehicle is on a level surface or uphill slope, engage
first gear or set the selector
lever to position P before
removing the ignition key or
switching off ignition on
vehicles with power button. On
an uphill slope, turn the front
wheels away from the kerb.
If the vehicle is on a downhill
slope, engage reverse gear or
set the selector lever to position P before removing the ignition
key or switching off ignition on
vehicles with power button.
Turn the front wheels towards
the kerb.
● Close the windows and the sunroof.
● Remove the ignition key from the ignition switch or switch off
ignition on vehicles with power
button. Turn the steering wheel
until the steering wheel lock is
felt to engage.
For vehicles with automatic
transmission, the key can only
be removed when the selector
lever is in position P.
●
Lock the vehicle with button e on
the radio remote control.
Activate the anti-theft alarm
system 3 29.
● The engine cooling fans may run
after the engine has been
switched off 3 230.

20Keys, doors and windowsKeys, doors and
windowsKeys, locks ................................... 20
Electronic key system ................20
Memorised settings ...................22
Central locking system ..............22
Automatic locking ......................26
Child locks ................................. 27
Doors ........................................... 27
Load compartment ....................27
Vehicle security ............................ 28
Anti-theft locking system ...........28
Anti-theft alarm system ..............29
Immobiliser ................................ 31
Exterior mirrors ............................ 32
Convex shape ........................... 32
Electric adjustment ....................32
Folding mirrors .......................... 32
Heated mirrors ........................... 33
Automatic dimming ....................33
Interior mirrors ............................. 33
Manual anti-dazzle ....................33
Automatic anti-dazzle ................34
Windows ...................................... 34
Windscreen ............................... 34Power windows......................... 34
Heated rear window ..................36
Heated windscreen ....................37
Sun visors .................................. 37
Roof ............................................. 37
Sunroof ...................................... 37Keys, locks
Electronic key system
Enables a keyless operation of the
following functions:
● central locking system 3 22
● switching on ignition and starting the engine 3 154

22Keys, doors and windows2. Insert the key blade again forapprox. 6 mm and turn the key to
open the housing. Further
insertion of the key blade can
damage the housing.
3. Remove and replace battery. Use
CR 2032 or equivalent battery.
Pay attention to the installation
position.
4. Close the housing and insert key blade.
Batteries do not belong in household
waste. They must be disposed of at
an appropriate recycling collection
point.
Fault
If the central locking cannot be
operated or the engine cannot be
started, the cause may be one of the
following:
● Fault in electronic key.
● Electronic key is out of reception range.
● The battery voltage is too low.● Overload of the central locking system by operating at frequent
intervals, the power supply is
interrupted for a short time.
● Interference from higher-power radio waves from other sources.
To rectify the cause of the fault,
change the position of the electronic
key.
Manual unlocking 3 22.
Memorised settings
Whenever the ignition is switched off, the following settings are
automatically memorised by the
electronic key:
● automatic climate control
● lighting
● Infotainment system
● central locking system
● Sport mode settings
● comfort settings
The saved settings are automatically
used the next time the ignition is
switched on with the memorised
electronic key 3 20.A precondition is that Personalisation
by Driver is activated in the personal
settings of the Info-Display. This must
be set for each electronic key which is used. The status change is available
only after locking and unlocking the
vehicle.
The assigned memory position of the
power seat is automatically recalled
when switching on ignition and Auto
Memory Recall is activated in the
Info-Display for the memorised electronic key.
Power seat 3 44.
Vehicle personalisation 3 116.
Central locking system
Unlocks and locks doors, load
compartment and fuel filler flap.
A pull on an interior door handle
unlocks the respective door. Pulling
the handle once more opens the door.
Notice
In the event of an accident in which
airbags or belt pretensioners are
deployed, the vehicle is
automatically unlocked.

Keys, doors and windows23Notice
A short time after unlocking with the
remote control the doors are locked
automatically if no door has been
opened. A precondition is that the
setting is activated in the vehicle
personalisation 3 116.
Electronic key system operation
The electronic key must be outside
the vehicle, within a range of approx. one metre of the relevant door side.
Unlocking
Press the button on the respective
exterior door handle and pull the
handle.
Unlocking mode can be set in the
vehicle personalisation menu in the
Info-Display. Two settings are
selectable:
● All doors, load compartment and fuel filler flap will be unlocked by
pressing the button on any
exterior handle once.
● Only the driver's door, load compartment and fuel filler flap
will be unlocked by pressing the
button on the driver's door
exterior handle once. To unlock
all doors, press button twice.
The setting can be changed in the
menu Settings in the Info-Display.
Vehicle personalisation 3 116.
Locking
Press the button on any exterior door
handle.
All doors, load compartment and fuel
filler flap will be locked.
