2017.5 VAUXHALL CORSA F dimensions

Technical data239Technical dataVehicle identification..................239
Vehicle Identification Number ..239
Identification plate ...................240
Engine identification ................240
Vehicle data ............................... 241
Recommended fluids and lubricants ................................ 241
Engine data ............................. 244
Performance ............................ 246
Vehicle weight ......................... 248
Vehicle dimensions .................250
Capacities ................................ 251
Tyre pressures ........................ 252Vehicle identification
Vehicle IdentificationNumber
The Vehicle Identification Number is
stamped on the identification plate
and on the floor pan, under the floor
covering, visible under a cover.
The Vehicle Identification Number
may be embossed on the instrument
panel, visible through the windscreen,
or in the engine compartment on the
right body panel.

250Technical dataVehicle dimensions5-door vehicle3-door vehicleVXRLength [mm]402140364036Width without exterior mirrors [mm]174617361736Width with two exterior mirrors [mm]194419441944Height (without antenna) [mm]4)1466 - 15161466 - 15011466 - 1501Length of load compartment floor [mm]705705705Length of load compartment with folded rear seats [mm]137213721372Load compartment width [mm]944944944Load compartment height with cover [mm]542542542Load compartment height without cover [mm]876843843Wheelbase [mm]251025102510Turning circle diameter [m]5)11.0 - 11.911.0 - 11.911.0 - 11.94)
Depending on options.
5) Depending on body- and equipment variants.

264Upholstery.................................. 235
Using this manual ..........................3
V Vehicle battery ........................... 195
Vehicle checks............................ 191 Vehicle data ................................ 241
Vehicle data recording and privacy ..................................... 258
Vehicle detected ahead ................95
Vehicle dimensions .................... 250
Vehicle Identification Number ....239
Vehicle jack ................................ 211
Vehicle messages .....................102
Vehicle personalisation .............105
Vehicle security ............................ 26
Vehicle specific data ......................3
Vehicle storage ........................... 190
Vehicle tools ............................... 211
Vehicle unlocking ........................... 6
Vehicle weight ........................... 248
Ventilation ................................... 122
W
Warning chimes .........................104
Warning lights ............................... 82
Warning triangle .......................... 71
Washer and wiper systems .........14
Washer fluid ............................... 195
Wheel changing .........................225
Wheel covers ............................. 219Wheels and tyres .......................212
Windows ....................................... 30
Windscreen................................... 30 Windscreen wiper/washer ...........76
Winter tyres ............................... 212
Wiper blade replacement ..........197
X Xenon headlights .......................201
Xenon lighting system ................115
