2017.5 VAUXHALL COMBO D winter tyres

Vehicle care139Vehicle careGeneral Information...................139
Accessories and vehicle modifications .......................... 139
Vehicle storage ........................140
End-of-life vehicle recovery .....140
Vehicle checks ........................... 141
Performing work ......................141
Bonnet ..................................... 141
Engine oil ................................. 142
Engine coolant ......................... 143
Power steering fluid .................144
Washer fluid ............................ 144
Brakes ..................................... 144
Brake fluid ............................... 145
Vehicle battery ......................... 145
Wiper blade replacement ........147
Bulb replacement .......................148
Halogen headlights ..................148
Fog lights ................................. 150
Tail lights ................................. 150
Side turn signal lights ..............151
Centre high-mounted brake light ......................................... 151
Number plate light ...................151Interior lights ............................ 152
Instrument panel illumination ...153
Electrical system ........................154
Fuses ....................................... 154
Engine compartment fuse box . 155
Instrument panel fuse box .......156
Vehicle tools .............................. 158
Tools ........................................ 158
Wheels and tyres .......................158
Winter tyres ............................. 158
Tyre designations ....................159
Tyre pressure .......................... 159
Tyre pressure monitoring
system .................................... 160
Tread depth ............................. 161
Changing tyre and wheel size . 162 Wheel covers ........................... 162
Tyre chains .............................. 162
Tyre repair kit .......................... 163
Wheel changing .......................165
Spare wheel ............................ 167
Jump starting ............................. 169
Towing ....................................... 171
Towing the vehicle ...................171
Towing another vehicle ...........171
Appearance care .......................172
Exterior care ............................ 172
Interior care ............................. 174General Information
Accessories and vehiclemodifications
We recommend the use of genuine
parts and accessories and factory
approved parts specific for your
vehicle type. We cannot assess or guarantee reliability of other products
- even if they have a regulatory or
otherwise granted approval.
Any modification, conversion or other
changes made to standard vehicle
specifications (including, without
limitation, software modifications,
modifications of the electronic control units) may invalidate the warrantyoffered by Vauxhall. Furthermore,
such changes may impact fuel
consumption, CO 2 emissions and
other emissions of the vehicle and
cause the vehicle to no longer
conform to the type approval,
impacting the validity of your vehicle
registration.

158Vehicle careVehicle tools
Tools
Van
The tools and the vehicle jacking
equipment are in the storage area behind the front seat. Pull front handle
and slide seat forwards to access
3 36.
Combi, Combo Tour
The tools and the vehicle jacking
equipment are stored in the load
compartment behind a panel on the
right-hand side.
Wheel changing 3 165.
Spare wheel 3 167.
Wheels and tyres
Tyre condition, wheel condition
Drive over edges slowly and at right
angles if possible. Driving over sharp
edges can cause tyre and wheel
damage. Do not trap tyres on the kerb when parking.
Regularly check the wheels for
damage. Seek the assistance of a
workshop in the event of damage or
unusual wear.
Winter tyres Winter tyres improve driving safety at
temperatures below 7 °C and should
therefore be fitted on all wheels.
Tyres of size 185/65 R15,
195/65 R15 and 195/60 R16 C are
permitted as winter tyres.
In accordance with country-specific
regulations, affix the speed sticker in
the driver's field of view.

Vehicle care159Tyre designations
E.g. 215/60 R 16 95 H215:tyre width, mm60:cross-section ratio (tyre height
to tyre width), %R:belt type: RadialRF:type: RunFlatC:cargo or commercial use16:wheel diameter, inches95:load index e.g. 95 is equivalent to 690 kgH:speed code letter
Speed code letter:
Q:up to 100 mphS:up to 112 mphT:up to 118 mphH:up to 130 mphV:up to 150 mphW:up to 168 mph
Choose a tyre appropriate for the
maximum speed of your vehicle.
The maximum speed is achievable at
kerb weight with driver (75 kg) plus
125 kg payload. Optional equipment
could reduce the maximum speed of
the vehicle.
Performance 3 185.
Directional tyres
Directional tyres must be mounted so
that they rotate in the correct
direction. The proper rotation
direction is indicated by a symbol
(e.g. an arrow) on the sidewall.
Tyre pressure
Check the pressure of cold tyres at least every 14 days and before any
long journey. Do not forget the spare
wheel. This also applies to vehicles
with tyre pressure monitoring system.
Unscrew the valve cap.
Tyre pressure 3 190.
The tyre pressure information label
on the door frame (if fitted) indicates the original equipment tyres and the
correspondent tyre pressures.
Always inflate tyres to the pressures
shown on the label.
The tyre pressure data refers to cold
tyres. It applies to summer and winter
tyres.Incorrect tyre pressures will impair
safety, vehicle handling, comfort and
fuel economy and will increase tyre
wear.
Tyre pressures differ depending on
various options. For the correct tyre
pressure value, follow the procedure
below:
1. Identify the engine identifier code.
Engine data 3 182.
2. Identify the respective tyre.
The tyre pressure tables show all
possible tyre combinations 3 190.
For the tyres approved for your
vehicle, refer to the EEC Certificate of Conformity provided with your vehicle
or other national registration
documents.
The driver is responsible for correct
adjustment of tyre pressures.9 Warning
If the pressure is too low, this can
result in considerable tyre warm-
up and internal damage, leading to tread separation and even to tyre
blow-out at high speeds.

Vehicle care161If w illuminates, stop as soon as
possible and inflate the tyres as
recommended 3 190.
After inflating, driving may be
required to update the tyre pressure
values in the system. During this time
w may illuminate.
If w illuminates at lower temperatures
and extinguishes after some driving,
this could be an indicator for
approaching a low tyre pressure
condition. Check tyre pressure of all
four tyres.
If the tyre pressure must be reduced
or increased, switch off ignition.
Only mount wheels with pressure
sensors, otherwise the tyre pressure
value cannot be recognised by the
system and w flashes for several
seconds then illuminates
continuously. In vehicles with
Multifunction version of the Driver
Information Centre, a corresponding message is also displayed.
A spare wheel or temporary spare
wheel is not equipped with pressure
sensors. The tyre pressure
monitoring system is not operationalfor these wheels. For the further three
wheels, tyre pressure monitoring
system remains operational.
Spare wheel 3 167, Wheel changing
3 165.
Control indicator w and (depending
on version) a corresponding message appears at each ignition cycle until
the tyres are inflated to the correct
tyre pressure.
Driver Information Centre 3 89.
Relearn function
After changing wheels, the tyre
pressure monitoring system needs to recalculate. The relearn process
takes up to 20 minutes of driving with
a minimum speed of 12 mph.
If problems occur during the relearn
process, control indicator w flashes
for several seconds then illuminates
continuously and (depending on
version) a warning message is
displayed in the Driver Information
Centre.
Driver Information Centre 3 89.General information
The use of tyre chains or
commercially available liquid tyre
repair kits can impair the function of
the system. Factory-approved tyre
repair kits can be used.
Tyre repair kit 3 163, Tyre chains
3 162.
Operating electronic devices or being close to facilities using similar wave
frequencies could disrupt the tyre
pressure monitoring system.
Each time the tyres are replaced, tyre
pressure monitoring system sensors
must be dismounted and serviced by
a workshop.
Tread depthCheck tread depth at regular
intervals.
Tyres should be replaced for safety
reasons at a tread depth of 2-3 mm (4 mm for winter tyres).
For safety reasons, it is
recommended that the tread depth of
the tyres on one axle should not vary
by more than 2 mm.

Vehicle care16710. Align the valve hole in the wheelcover with the tyre valve before
installing.
Install wheel nut caps.
11. Stow the replaced wheel 3 167
and the vehicle tools 3 158.
12. Check the tyre pressure of the installed tyre and the wheel nut
torque as soon as possible.
Have the defective tyre renewed or repaired as soon as possible.
Spare wheel Some vehicles are equipped with a
tyre repair kit 3 163 instead of a spare
wheel.
If mounting a spare wheel which is
different from the other wheels, this
wheel might be classified as a
temporary spare wheel and the
corresponding speed limits apply,
even though no label indicates this.
Seek the assistance of a workshop to
check the applicable speed limit.Caution
The use of a spare wheel that is smaller than the other wheels or in combination with winter tyres
could affect driveability. Have the defective tyre replaced as soon as
possible.
Depending on model variant, the
spare wheel is stored beneath the
floor or in the load compartment.
1. Attach the extension bar 2 to the
wheel wrench 1. Vehicle tools
3 158.
2. Insert the wheel wrench into the
aperture in the load compartment
floor.
3. Rotate the wheel wrench to lower the spare wheel to the floor.

198T
Tachometer ................................. 75
Tailgate ......................................... 27
Tail lights ................................... 150
Technical data ............................ 182
Temperature ................................. 89
Third row seats ............................ 41
Three-point seat belt .................... 45
Toll road stickers .......................... 31
Tools .......................................... 158
Top-Tether .................................... 54
Towing ................................ 137, 171
Towing another vehicle .............171
Towing the vehicle .....................171
Traction Control system ............. 127
Trailer coupling ........................... 137
Trailer towing ............................. 137
Transmission ......................... 16, 83
Transmission display ...........78, 121
Tread depth ............................... 161
Trip computer ......................... 89, 95
Trip odometer .............................. 75
Turn and lane-change signals ...100
Turn signal ................................... 81
Tyre chains ................................ 162
Tyre designations ......................159
Tyre pressure ............................ 159
Tyre pressure monitoring system ............................... 86, 160Tyre pressures ........................... 190
Tyre repair kit ............................. 163
U
Ultrasonic parking assist ...... 84, 130
Underseat storage .......................61
Unit of measurement ....................89
Upholstery .................................. 174
USB port ....................................... 73
Using this manual ..........................3
V Vehicle battery ........................... 145
Vehicle checks............................ 141
Vehicle data ................................ 181
Vehicle data recording and privacy ..................................... 192
Vehicle dimensions .................... 187
Vehicle Identification Number ....179
Vehicle jack ................................ 158
Vehicle security ............................ 28
Vehicle shutdown ...........80, 95, 114
Vehicle specific data ......................3
Vehicle storage ........................... 140
Vehicle tools ............................... 158
Vehicle unlocking ........................... 6
Vehicle weight ........................... 186
Ventilation ................................... 105
Volume ......................................... 89W
Warning chime.............................. 89
Warning chimes ........................... 94
Warning lights ............................... 75
Washer and wiper systems .........14
Washer fluid ............................... 144
Wheel changing .........................165
Wheel covers ............................. 162
Wheels and tyres .......................158
Windows ....................................... 31
Windscreen................................... 31 Windscreen stickers .....................31
Windscreen wiper/washer ...........70
Winter tyres ............................... 158
Wiper blade replacement ..........147
