In brief111Fixed air vents .................... 130
2 Headlight range
adjustment ......................... 110
Ultrasonic parking assist .....163
Traction control system ......156
Electronic Stability
Program ............................. 157
3 Side air vents .....................129
4 Light switch ........................ 108
Turn and lane-change
signals ................................ 111
High beam and low beam,
headlight flash ....................109
Sidelights ............................ 108
Automatic light control .......108
Exit lighting ......................... 115
Front fog lights ...................112
Rear fog light ...................... 112
High beam assist ................109
5 Instruments .......................... 89
Transmission display ............93Driver Information Centre .... 102
Trip computer ...................... 104
6 Horn ..................................... 84
Driver airbag ........................ 60
7 Remote control on
steering wheel .......................84
Cruise control .....................159
8 Windscreen wiper,
windscreen washer system ..85
Trip computer ...................... 104
9 Coin tray ............................... 72
10 Power outlet, USB slot ..........87
11 Centre air vents .................. 129
12 Storage compartment ...........72
13 Info-display .......................... 102
14 Front passenger airbag .........60
15 Storage compartment ..........72
16 Glovebox .............................. 73
17 Seat belt reminder ................. 96
Front passenger airbag
deactivation ........................... 61
18 Cupholders ........................... 7319Climate control system ....... 116
Electronic climate control
system ................................. 118
20 Cigarette lighter .................... 89
Power outlet ......................... 87
21 Gear lever, Manual
transmission ........................ 150
Manual transmission
automated ........................... 150
22 Cruise control and speed
limiter ................................. 159
Manual transmission
automated,
Winter and Laden modes ....152
Idle speed control ...............136
Stop-start system ................136
ECO mode .......................... 133
23 Ignition switch with
steering wheel lock ............134
24 Steering column controls .....84
25 Steering wheel adjustment ..84
26 Bonnet release lever ..........176
27 Auxiliary heater ...................123

Instruments and controls99Lane departure warning 3 167.
Electronic Stability Program b flashes or illuminates yellow.
Illuminates briefly when the ignition is
switched on.
Flashing during driving
The system is actively engaged.
Engine output may be reduced and the vehicle may be braked
automatically to a small degree
3 157.
Illuminates during driving The system is unavailable.
May illuminate together with control
indicator A 3 97. A corresponding
message also appears in the Driver Information Centre 3 102.
ESP® Plus
3 157, Traction Control
system 3 156.
Electronic Stability Program
off
Ø illuminates green.If ESP ®Plus
has been deactivated with
Ø on the instrument panel, control
indicator Ø illuminates and a
corresponding message appears in
the Driver Information Centre 3 102.
ESP® Plus
3 157, Traction Control
system 3 156.
Engine coolant temperature
W illuminates red.
Illuminates briefly when the ignition is
switched on.
Illuminates when the engine is
running
If W illuminates (possibly in
combination with control indicator
C ), stop vehicle and switch off
engine.Caution
Coolant temperature too high.
Check coolant level 3 178.
If there is sufficient coolant, consult a workshop.
Preheating
! illuminates yellow.
Preheating is activated. Only
activates when outside temperature
is low.
AdBlue Õ illuminates yellow.
AdBlue level is low. Refill AdBlue as
soon as possible, to avoid prevention
of engine starts.
Illuminates together with control
indicator A to indicate a system
failure or as a warning that engine starting may not be possible after a
certain distance. Seek the assistance
of a workshop immediately.
A corresponding message appears in the Driver Information Centre 3 102.
AdBlue 3 143.
Tyre pressure monitoring system
w illuminates or flashes yellow.
Illuminates briefly when the ignition is switched on.

132Driving and operatingDriving and
operatingDriving hints ............................... 133
Driving economically ...............133
Control of the vehicle ...............133
Steering ................................... 133
Starting and operating ...............134
New vehicle running-in ............134
Ignition switch positions ...........134
Starting the engine ..................135
Idle speed control ....................136
Overrun cut-off ........................ 136
Stop-start system ....................136
Parking .................................... 139
Air suspension ......................... 140
Engine exhaust .......................... 142
Diesel particle filter ..................142
Catalytic converter ...................142
AdBlue ..................................... 143
Manual transmission ..................150
Manual transmission automa‐ ted .............................................. 150
Transmission display ...............150
Starting the engine ..................151
Selector lever .......................... 151Manual mode........................... 152
Electronic driving programmes 152
Fault ........................................ 153
Interruption of power supply ....154
Brakes ........................................ 154
Antilock brake system .............154
Parking brake .......................... 155
Brake assist ............................. 156
Hill start assist ......................... 156
Ride control systems .................156
Traction Control system ..........156
Electronic stability program .....157
Limited-slip rear axle ...............159
Driver assistance systems .........159
Cruise control .......................... 159
Speed limiter ........................... 163
Parking assist .......................... 163
Rear view camera ...................165
Lane departure warning ..........167
Fuel ............................................ 168
Fuel for diesel engines ............168
Refuelling ................................ 169
Fuel consumption - CO 2-
Emissions ............................... 170
Trailer hitch ................................ 171
General information .................171
Driving characteristics and towing tips .............................. 171
Trailer towing ........................... 171Towing equipment ...................172
Trailer stability assist ...............172
Auxiliary features .......................172
Power take-off ......................... 172

156Driving and operatingBrake assistIf the brake pedal is depressed
quickly and forcefully, maximum
brake force is automatically applied
(full braking).
Maintain steady pressure on the
brake pedal for as long as full braking
is required. Maximum brake force is
automatically reduced when the
brake pedal is released.
Brake assist is not available during an
Autostop. Stop-start system 3 136.
Hill start assist
The system helps prevent unintended movement when driving away on
inclines.
When releasing the brake pedal after
stopping on an incline (with the
selector lever in a forward gear or
reverse gear), the brakes remain on
for a further two seconds. The brakes
release automatically as soon as the
vehicle begins to accelerate.Caution
The Hill start assist cannot
completely prevent vehicle
movement in all situations
(extremely steep gradients, etc.).
If necessary, depress the brake
pedal to prevent the vehicle from
rolling forwards or backwards.
The Hill start assist is not active
during an Autostop. Stop-start system 3 136.
Ride control systems
Traction Control system The Traction Control system (TC) is a
component part of the Electronic
Stability Program (ESP® Plus
) which
improves driving stability when
necessary, regardless of the type of
road surface or tyre grip, by
preventing the drive wheels from
spinning.
As soon as the drive wheels starts to spin, engine output is reduced and
the wheel spinning the most is braked
individually. This considerably
improves the driving stability of the
vehicle on slippery road surfaces.
TC is operational as soon as the
ignition is switched on and control
indicator b extinguishes in the
instrument cluster. A corresponding message also appears in the Driver
Information Centre 3 102.
When TC is active b flashes.

Driving and operating1579Warning
Do not let this special safety
feature tempt you into taking risks
when driving.
Adapt speed to the road
conditions.
Control indicator b 3 99.
Trailer stability assist (TSA) 3 172.
Enhanced Traction function
If necessary, in the event of soft
ground, mud or snow-covered road
surfaces, the Traction control system
(TC) can be deactivated to enhance
traction:
Press Ø on the instrument panel.
Control indicator Ø illuminates in the
instrument cluster and a
corresponding message appears in
the Driver Information Centre 3 102.
When vehicle speed reaches 50 km/h, the system switches
automatically from Enhanced
Traction function to TC operation.
Control indicator Ø extinguishes in
the instrument cluster.
TC is reactivated by pressing Ø
again. Control indicator Ø
extinguishes.
TC is also reactivated the next time
the ignition is switched on.
Fault
If the system detects a fault, control indicator b 3 99 illuminates together
with A 3 97 in the instrument cluster
and a corresponding message
appears in the Driver Information
Centre 3 102.
The Traction control system (TC) is
not operational. Have the cause of the fault remedied by a workshop.
Vehicle messages 3 103.
Electronic stability program
The Electronic Stability Program
(ESP® Plus
) improves driving stability
when necessary, regardless of the
type of road surface or tyre grip. It also
prevents the drive wheels from
spinning.

158Driving and operatingAs soon as the vehicle starts to
swerve (understeer/oversteer),
engine output is reduced and the wheels are braked individually. This
considerably improves the driving
stability of the vehicle on slippery road
surfaces.
ESP® Plus
is operational as soon as
the ignition is switched on and control
indicator b extinguishes in the
instrument cluster. A corresponding
message also appears in the Driver
Information Centre 3 102.
When ESP® Plus
comes into action b
flashes.9 Warning
Do not let this special safety
feature tempt you into taking risks
when driving.
Adapt speed to the road
conditions.
Control indicator b 3 99.
Trailer stability assist (TSA) 3 172.
Enhanced Traction function
If necessary, in the event of soft
ground, mud or snow-covered road
surfaces, ESP® Plus
can be
deactivated to enhance traction:
Press Ø on the instrument panel.
Control indicator Ø illuminates in the
instrument cluster and a
corresponding message appears in
the Driver Information Centre 3 102.
When vehicle speed reaches
50 km/h, the system switches
automatically from Enhanced
Traction function to ESP® Plus
operation. Control indicator Ø
extinguishes in the instrument cluster.
ESP® Plus
is reactivated by pressing
Ø again. Control indicator Ø
extinguishes.
ESP® Plus
is also reactivated the next
time the ignition is switched on.

Driving and operating159Engine Drag Torque ControlThe engine drag torque control
system is an integral feature of
ESP® Plus
. When downshifting under
slippery road conditions, the engine
speed and torque increases to help
prevent locking of the drive wheels
during sudden deceleration.
Fault
If the system detects a fault, control indicator b 3 99 illuminates together
with A 3 97 in the instrument cluster
and a corresponding message
appears in the Driver Information
Centre 3 102.
The Electronic Stability Program
(ESP® Plus
) is not operational. Have
the cause of the fault remedied by a
workshop.
Vehicle messages 3 103.
Limited-slip rear axle
Rear-wheel drive vehicles may be
equipped with an automatic locking
rear differential which automatically controls the torque transmitted toeach rear wheel, enhancing traction
in the event of soft ground, mud or
snow-covered road surfaces.9 Warning
Do not let this special safety
feature tempt you into taking risks
when driving.
Adapt speed to the road
conditions.
When vehicle speed reaches
30 km/h, or once the rear wheels
return to surfaces with normal grip,
e.g. paved roads, the system
automatically deactivates,
sometimes accompanied by a noise
(with no consequence to vehicle
behaviour).
The system can also be deactivated
manually once normal grip conditions have resumed by briefly releasing the
accelerator.
Driver assistance
systems9 Warning
Driver assistance systems are
developed to support the driver
and not to replace the driver's
attention.
The driver accepts full
responsibility when driving the
vehicle.
When using driver assistance
systems, always take care
regarding the current traffic
situation.
Cruise control
The cruise control can store and
maintain speeds of 30 km/h and
above. Deviations from the stored
speeds may occur when driving uphill or downhill. The stored speed will
flash in the Driver Information Centre
3 102.

253Changing tyre and wheel size ...203
Charging system .......................... 97
Child locks ................................... 28
Child restraint installation locations ................................... 65
Child restraints.............................. 63
Child restraint systems ................63
Cigarette lighter ........................... 89
Cleaning the vehicle ...................217
Climate control ............................. 16
Climate control systems .............116
Clock ............................................ 87
Coat hooks ................................... 73
Collision damage repair ..............250
Control indicators.......................... 93
Control of the vehicle .................133
Controls ........................................ 84
Convex shape .............................. 36
Coolant ....................................... 178
Coolant and antifreeze ...............222
Coolant heater ............................ 123
Cornering light ....................111, 187
Coupling ball bar ........................172
Cruise control ....................101, 159
Cupholders .................................. 73
D
Danger, Warnings and Cautions ...4
Dashboard .................................... 10
Daytime running lights ...............110Declaration of conformity ............248
DEF ............................................ 143
Demisting and defrosting ..............16
Diesel exhaust fluid ....................143
Diesel fuel ................................... 168
Diesel fuel filter .......................... 183
Diesel fuel system bleeding .......183
Diesel particle filter ....................142
Door locks..................................... 23
Door open .................................. 101
Doors ............................................ 28
DPF (diesel particle filter) ...........142
Drink holders ................................ 73
Driver assistance systems ..........159
Driver Information Centre ...........102
Driving characteristics and towing tips .............................. 171
Driving economically................... 133
Driving hints ................................ 133
E ECO mode .................................. 133
ecoScoring.................................. 104
Electric adjustment ......................36
Electrical accessories ...................87
Electrical system......................... 194
Electronic climate control system 118
Electronic driving programmes ..152
Electronic Stability Program 99,
157, 172Electronic Stability Program off ...99
Emergency exit .......................39, 41
End-of-life vehicle recovery .......176
Engine compartment fuse box ...195
Engine coolant ........................... 178
Engine coolant temperature ........99
Engine coolant temperature gauge ....................................... 91
Engine data ............................... 227
Engine Drag Torque Control ......157
Engine exhaust .......................... 142
Engine identification ...................225
Engine oil ...........177, 222, 226, 245
Engine oil additives ....................222
Engine oil level monitor ................92
Engine oil pressure ....................100
Engine oil viscosity grades .........222
Enhanced Traction function....... ................................ 156, 157, 159
Event data recorders ..................250
Exhaust gases ............................ 142
Exit lighting ................................ 115
Exterior care .............................. 217
Exterior light ............................... 101
Exterior lighting ....................14, 108
Exterior mirrors ............................. 36
F Fault ........................................... 153
Fire extinguisher ........................... 80
