2017.5 OPEL KARL stop start

In brief111Central locking system ..........23
Power windows .....................31
2 Exterior mirrors .....................29
3 Cruise control .....................124
Speed limiter ...................... 125
Heated steering wheel ..........61
4 Turn and lane-change
signals, headlight flash,
low beam and high beam ......95
Exit lighting ........................... 97
Parking lights ........................ 96
5 Side air vents ...................... 105
6 Instruments .......................... 65
7 Driver Information Centre ...... 77
8 Steering wheel controls .......61
9 Windscreen wiper,
windscreen washer
system, rear window
wiper, rear window washer
system ................................... 62
10 Centre air vents .................. 105
11 Hazard warning flashers ......94
12 Info-Display ........................... 8213Anti-theft alarm system
status LED ........................... 28
14 Infotainment system
15 Glovebox .............................. 53
16 Climate control system .......... 99
17 AUX input, USB input
18 Selector lever, manual
transmission ....................... 115
Selector lever, manual
transmission automated ......116
19 Seat heating .......................... 38
20 Parking brake ......................120
21 Ignition switch with
steering wheel lock ............109
22 Horn ..................................... 62
Driver airbag ........................ 44
23 Bonnet release lever ..........139
24 Steering wheel adjustment ..61
25 Fuse box ............................ 154
26 Traction Control system .....121
City mode ............................ 123
Stop-start system ................111
Fuel selector ......................... 67
Lane departure warning .....128Electronic Stability Control . 122
27 Light switch .......................... 93
Headlight range
adjustment ........................... 94
Front fog light ........................ 95
Rear fog light ........................ 95
Brightness of instrument
panel illumination ..................96

In brief131Central locking system ..........23
Power windows .....................31
2 Exterior mirrors .....................29
3 Cruise control .....................124
Speed limiter ...................... 125
Heated steering wheel ..........61
4 Turn and lane-change
signals, headlight flash,
low beam and high beam ......95
Exit lighting ........................... 97
Parking lights ........................ 96
5 Side air vents ...................... 105
6 Instruments .......................... 65
7 Driver Information Centre ...... 77
8 Steering wheel controls .......61
9 Windscreen wiper,
windscreen washer
system, rear window
wiper, rear window washer
system ................................... 62
10 Centre air vents .................. 105
11 Hazard warning flashers ......94
12 Info-Display ........................... 8213Anti-theft alarm system
status LED ........................... 28
14 Infotainment system
15 Glovebox .............................. 53
16 Climate control system .......... 99
17 AUX input, USB input
18 Selector lever, manual
transmission ....................... 115
Selector lever, manual
transmission automated ......116
19 Seat heating .......................... 38
20 Parking brake ......................120
21 Ignition switch with
steering wheel lock ............109
22 Horn ..................................... 62
Driver airbag ........................ 44
23 Bonnet release lever ..........139
24 Steering wheel adjustment ..61
25 Fuse box ............................ 154
26 Traction Control system .....121
City mode ............................ 123
Stop-start system ................111
Fuel selector ......................... 67
Lane departure warning .....128Electronic Stability Control . 122
27 Light switch .......................... 93
Headlight range
adjustment ........................... 94
Front fog light ........................ 95
Rear fog light ........................ 95
Brightness of instrument
panel illumination ..................96

In brief19Starting the engine 3 110.Stop-start system
If the vehicle is at a low speed or at a
standstill and certain conditions are
fulfilled, activate an Autostop as
follows:
Vehicles with manual transmission: ● Depress the clutch pedal.
● Engage neutral gear.
● Release the clutch pedal.
An Autostop is indicated by the
needle at the AUTOSTOP position in
the tachometer.
To restart the engine, depress the clutch pedal again.
Vehicles with manual transmission
automated:
If the vehicle is at a standstill with the
brake pedal depressed, Autostop is
activated automatically, indicated by
the needle at the AUTOSTOP position in the tachometer.
Release the brake pedal or move
selector lever out of D to restart the
engine.
Stop-start system 3 111.

38Seats, restraintsBackrest inclination
Pull lever, adjust inclination and
release lever. Allow the backrest to
engage audibly.
Seat height
Lever pumping motion
up:seat higherdown:seat lowerHeating
Activate seat heating by pressing ß
for the respective front seat.
The LED in the button illuminates to
indicate activation.
Pressing ß once more deactivates
seat heating.
Seat heating is operational when
engine is running.
During an Autostop, seat heating is
also operational.
Stop-start system 3 111.

62Instruments and controlsThe grip areas of the steering wheel
are heated quicker and to a higher
temperature than the other areas.
Heating is operational when the
engine is running and during an
Autostop.
Stop-start system 3 111.
Horn
Press j.
Windscreen wiper/washer
Windscreen wiperHI:fastLO:slowE:interval wipingOFF:off
For a single wipe when the
windscreen wiper is off, press the
lever down to position 2.
Do not use if the windscreen is frozen.
Switch off in car washes.
Windscreen washer
Pull lever. Washer fluid is sprayed
onto the windscreen and the wiper
wipes a few times.
Washer fluid 3 142

Instruments and controls65Power outlets
A 12 Volt power outlet is located in the
centre console.
Do not exceed the maximum power
consumption of 120 watts.
With ignition off, the power outlet is
deactivated. Additionally, the power outlet is deactivated in the event of
low vehicle battery voltage.
Electrical accessories that are
connected must comply with the
electromagnetic compatibility
requirements laid down in
DIN VDE 40 839.
Do not connect any current-delivering accessories, e.g. electrical charging
devices or batteries.
Do not damage the outlet by using
unsuitable plugs.
Stop-start system 3 111.
Cigarette lighter The cigarette lighter may be located
in the centre console.
Press in cigarette lighter. It switches
off automatically once the element is
glowing. Pull out lighter.
AshtraysCaution
To be used only for ash and not for combustible rubbish.
The portable ashtray can be placed inthe cupholders.
Warning lights, gauges
and indicators
Instrument cluster
The needles of the instruments briefly
rotate to the end position when the
engine is being switched on.
Speedometer
Indicates vehicle speed.

Instruments and controls73The front passenger airbag is
deactivated 3 46.9 Danger
Risk of fatal injury for a child using
a child restraint system together
with activated front passenger
airbag.
Risk of fatal injury for an adult
person with deactivated front
passenger airbag.
Charging system
p illuminates red.
Illuminates when the ignition is
switched on and extinguishes shortly
after the engine starts.
Illuminates when the engine is
running
Stop, switch off engine. Vehicle
battery is not charging. Engine
cooling may be interrupted. The
brake servo unit may cease to be
effective. Seek the assistance of a
workshop.
Malfunction indicator light
Z illuminates or flashes yellow.
Illuminates when the ignition is
switched on and extinguishes shortly
after the engine starts.
Illuminates when the engine is
running
Fault in the emission control system. The permitted emission limits may be exceeded. Seek the assistance of a
workshop immediately.
Flashes when the engine is
running
Fault that could lead to catalytic converter damage. Ease up on the
accelerator until the flashing stops.
Seek the assistance of a workshop
immediately.
Service vehicle soon
g illuminates yellow.
Additionally, a warning code is
displayed in the Driver Information
Centre.
The vehicle requires a service.Seek the assistance of a workshop. Vehicle messages 3 83.
Brake and clutch system
R illuminates red.
The brake and clutch fluid level is too low, when manual parking brake is
not applied 3 142.9 Warning
Stop. Do not continue your
journey. Consult a workshop.
Illuminates when the manual parking
brake is applied and ignition is
switched on 3 120.
Operate pedal - illuminates or flashes yellow.
Illuminates
Clutch pedal must be depressed to
start the engine in Autostop mode.
Stop-start system 3 111.

Instruments and controls75Flashes
The system is actively engaged.
Engine output may be reduced and
the vehicle may be braked
automatically to a small degree.
Illuminates
A fault in the system is present. A
warning code appears in the Driver
Information Centre. Continued driving is possible. The system is not
operational. Driving stability,
however, may deteriorate depending on road surface conditions.
Have the cause of the fault remedied
by a workshop.
Electronic Stability Control 3 122,
Traction Control system 3 121.
Traction Control system off
k illuminates yellow.
The system is deactivated.
Engine coolant temperature
W illuminates red.Illuminates when the engine is
running
Stop, switch off engine.Caution
Coolant temperature too high.
Check coolant level 3 141.
If there is sufficient coolant, consult a workshop.
Tyre pressure monitoring system
w illuminates or flashes yellow.
Illuminates
Tyre pressure loss. Stop immediately
and check tyre pressure.
Flashes
Fault in system or tyre without
pressure sensor mounted ( e.g. spare
wheel). After 60-90 seconds the
control indicator illuminates
continuously. Consult a workshop.
Tyre pressure monitoring system
3 158.
Engine oil pressure
I illuminates red.
Illuminates when the ignition is
switched on and extinguishes shortly
after the engine starts.
Illuminates when the engine is
runningCaution
Engine lubrication may be
interrupted. This may result in
damage to the engine and/or
locking of the drive wheels.
1. Depress the clutch.
2. Set selector lever to neutral.
3. Move out of the flow of traffic as quickly as possible without
impeding other vehicles.
4. Switch off the ignition.
