Vehicle care257Select the Tyre pressure page under
the Info Menu in the Driver
Information Centre 3 115.
System status and pressure warnings
are displayed by a message
indicating the corresponding tyre in
the Driver Information Centre.
The system considers the tyre
temperature for the warnings.
Temperature dependency 3 255.
A detected low tyre pressure
condition is indicated by the control
indicator w 3 113.
If w illuminates, stop as soon as
possible and inflate the tyres as
recommended 3 293.
If w flashes for 60-90 seconds then
illuminates continuously, there is a
fault in the system. Consult a
workshop.
After inflating, some driving may be
required to update the tyre pressure
values in the Driver Information
Centre. During this time w may
illuminate.
If w illuminates at lower temperatures
and extinguishes after driving, this
could be an indicator for approaching a low tyre pressure condition. Check
tyre pressure.
Vehicle messages 3 123.
If the tyre pressure must be reduced
or increased, switch off ignition.
Only mount wheels with pressure
sensors, otherwise the tyre pressure
will not be displayed and w
illuminates continuously.
A spare wheel or temporary spare
wheel is not equipped with pressure
sensors. The tyre pressure
monitoring system is not operational
for these tyres. Control indicator w
illuminates. For the further three
tyres, the system remains
operational.The use of commercially-available liquid tyre repair kits can impair the
function of the system. Factory-
approved repair kits can be used.
Operating electronic devices or being
close to facilities using similar wave
frequencies could disrupt the tyre
pressure monitoring system.
Each time the tyres are replaced, tyre pressure monitoring system sensors
must be dismounted and serviced.
For the screwed sensor, replace
valve core and sealing ring. For the
clipped sensor, replace complete
valve stem.
Vehicle loading status
Adjust tyre pressure to load condition according to the tyre information label
or tyre pressure chart 3 293, and
select the appropriate setting in the
menu Tyre Load in the Driver
Information Centre, Vehicle
Information Menu 3 115. This setting
is the reference for the tyre pressure
warnings.

258Vehicle careThe Tyre load menu only appears
when the vehicle is at a standstill and the parking brake is applied. On
vehicles with automatic transmission
the selector lever must be in P.
Midlevel display:
Select the Tyre load page under the
Vehicle Information Menu ? in the
Driver Information Centre 3 115.
Select ● Light for comfort pressure up to
three people.
● Eco for Eco pressure up to three
people.
● Max for full loading.
Uplevel display:
Select the Tyre load page under the
Options Menu in the Driver
Information Centre 3 115.
Select ● Light for comfort pressure up to
three people.
● Eco for Eco pressure up to
three people.
● Max for full loading.
Tyre pressure sensor matching
process
Each tyre pressure sensor has a
unique identification code. The
identification code must be matched
to a new wheel position after rotating the wheels or exchanging the
complete wheel set and if one or more tyre pressure sensors were replaced.
The tyre pressure sensor matching
process should also be performed
after replacing a spare wheel with a
road wheel containing the tyre
pressure sensor.
The malfunction light w and the
warning message or code should go
off at the next ignition cycle. The
sensors are matched to the wheel
positions, using a relearn tool, in the following order: left side front wheel,
right side front wheel, right side rear
wheel and left side rear wheel. The
turn signal light at the current active
position is illuminated until sensor is
matched.
Consult a workshop for service. There are two minutes to match the first
wheel position, and five minutes
overall to match all four wheel

Vehicle care259positions. If it takes longer, the
matching process stops and must be restarted.
The tyre pressure sensor matching
process is:
1. Apply the parking brake.
2. Turn the ignition on.
3. On vehicles with automatic transmission: set the selector
lever to P.
On vehicles with manual
transmission: select neutral.
4. Midlevel display: Use MENU on the turn signal
lever to select the Vehicle
Information Menu ? in the
Driver Information Centre.
Uplevel display:
Press p on the steering wheel to
open main menu page.
Select the Info page with Q or P.
Confirm with 9.
5. Select the tyre pressure menu. Midlevel display:
Uplevel display:
6. Midlevel display: Press SET/CLR to begin the
sensor matching process. A
message requesting acceptance
of the process should be
displayed.
Press SET/CLR again to confirm
the selection. The horn sounds
twice to indicate that the receiver
is in relearn mode.
Uplevel display:
Press 9 to begin the sensor
matching process. The horn
sounds twice to indicate that the receiver is in relearn mode.
7. Start with the left side front wheel.
8. Place the relearn tool against the tyre sidewall, near the valve stem.Then press the button to activate
the tyre pressure sensor. A horn
chirp confirms that the sensor
identification code has been
matched to this wheel position.
9. Proceed to the right side front wheel, and repeat the procedure
in Step 8.
10. Proceed to the right side rear wheel, and repeat the procedure
in Step 8.
11. Proceed to the left side rear wheel, and repeat the procedure
in Step 8. The horn sounds twice

Vehicle care275SunroofNever clean with solvents or abrasive
agents, fuels, aggressive media
(e.g. paint cleaner, acetone-
containing solutions etc.), acidic or
highly alkaline media or abrasive
pads. Do not apply wax or polishing
agents to the sunroof.
Wheels and tyres
Do not use high-pressure jet
cleaners.
Clean rims with a pH-neutral wheel
cleaner.
Rims are painted and can be treated
with the same agents as the body.
Paintwork damageRectify minor paintwork damage witha touch-up pen before rust forms.
Have more extensive damage or rust
areas repaired by a workshop.
Underbody Some areas of the vehicle underbody
have a PVC undercoating while other
critical areas have a durable
protective wax coating.After the underbody is washed, check
the underbody and have it waxed if
necessary.
Bitumen/rubber materials could
damage the PVC coating. Have
underbody work carried out by a
workshop.
Before and after winter, wash the
underbody and have the protective
wax coating checked.
Towing equipment Do not clean the coupling ball bar with
a steam-jet or high-pressure jet
cleaner.
Air shutter
Clean the shutter system in the front
bumper to maintain correct
functionality.
Interior care
Interior and upholstery
Only clean the vehicle interior,
including the instrument panel fascia
and panelling, with a dry cloth or
interior cleaner.Clean the leather upholstery with
clear water and a soft cloth. In case of heavy soiling, use leather care.
The instrument cluster and the
displays should only be cleaned using
a soft damp cloth. If necessary use a
weak soap solution.
Clean fabric upholstery with a
vacuum cleaner and brush. Remove
stains with an upholstery cleaner.
Clothing fabrics may not be
colourfast. This could cause visible
discolourations, especially on light-
coloured upholstery. Removable
stains and discolourations should be
cleaned as soon as possible.
Clean seat belts with lukewarm water or interior cleaner.Caution
Close Velcro fasteners as open
Velcro fasteners on clothing could damage seat upholstery.
The same applies to clothing with
sharp-edged objects, like zips or
belts or studded jeans.

Service and maintenance277Service and
maintenanceGeneral information ...................277
Service information ..................277
Recommended fluids, lubricants and parts .................................... 278
Recommended fluids and lubricants ................................ 278General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for your vehicle is available
at the workshop.
Service display 3 108.
European service intervals Maintenance of your vehicle is
required every 30,000 km or after one year, whichever occurs first, unless
otherwise indicated in the service
display.
A shorter service interval can be valid
for severe driving behaviour, e.g. for
taxis and police vehicles.
The European service intervals are
valid for the following countries:Andorra, Austria, Belgium, Bosnia-
Herzegovina, Bulgaria, Croatia,
Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany,
Greece, Greenland, Hungary,
Iceland, Ireland, Italy, Latvia,
Liechtenstein, Lithuania,
Luxembourg, Macedonia, Malta,
Monaco, Montenegro, Netherlands,
Norway, Poland, Portugal, Romania,
San Marino, Serbia, Slovakia,
Slovenia, Spain, Sweden,
Switzerland, United Kingdom.
Service display 3 108.
International service intervals
Maintenance of your vehicle is
required every 15,000 km or after one year, whichever occurs first, unless
otherwise indicated in the service
display.
Severe operating conditions exist if
one or more of the following
circumstances occur frequently: Cold
starting, stop and go operation, trailer operation, mountain driving, driving
on poor and sandy road surfaces,
increased air pollution, presence of
airborne sand and high dust content,

278Service and maintenancedriving at high altitude and large
variations of temperature. Under
these severe operating conditions,
certain service work may be required more frequently than the regular
service interval.
The international service intervals are
valid for the countries which are not
listed in the European service
intervals.
Service display 3 108.
Confirmations Confirmation of service is recorded inthe Service and warranty booklet.
The date and mileage is completed
with the stamp and signature of the
servicing workshop.
Make sure that the Service and
warranty booklet is completed
correctly as continuous proof of
service is essential if any warranty or goodwill claims are to be met, and is
also a benefit when selling the
vehicle.Service interval with remaining
engine oil life duration
The service interval is based on
several parameters depending on
usage.
The service display lets you know
when to change the engine oil.
Service display 3 108.Recommended fluids,
lubricants and parts
Recommended fluids andlubricants
Only use products that meet the
recommended specifications.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
aging control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.

306Headlight range adjustment ......137
Headlights................................... 136
Headlights when driving abroad 138
Head restraint adjustment .............8
Head restraints ............................ 46
Heated mirrors ............................. 40
Heated rear window ..................... 43
Heated steering wheel .................92
Heating .................................. 54, 56
Heating and ventilation system . 147
High beam ......................... 114, 137
High beam assist ........................114
Hill start assist ........................... 179
Horn ....................................... 14, 92
I
Identification plate .....................280
Ignition switch positions .............158
Immobiliser .......................... 38, 114
Indicators .................................... 104
Info display ................................. 121
Information displays.................... 115
Instrument cluster ......................101
Instrument panel fuse box .........249
Instrument panel illumination .....245
Instrument panel illumination control .................................... 144
Instrument panel overview ........... 10
Interior care ............................... 275
Interior lighting ............................ 144Interior lights ...................... 144, 245
Interior mirrors .............................. 40
Interruption of power supply ......171
Introduction .................................... 3
J
Jump starting ............................. 270
K Key, memorised settings ..............24
Keys ............................................. 20
Keys, locks ................................... 20
L Lane keep assist ................112, 215
Lashing eyes ............................... 81
LED headlights ...................114, 138
Lighting features .........................145
Light switch ................................ 136
Load compartment ................30, 73
Load compartment cover .............79
Load compartment fuse box ......251
Loading information .....................88
Low fuel ..................................... 113
M
Malfunction indicator light ..........111
Manual anti-dazzle ......................40
Manual mode .....................170, 175
Manual seat adjustment ...............48
Manual transmission .................. 172Manual transmission automated 173
Manual windows ..........................41
Massage ....................................... 55
Maximum speed ......................... 254
Memorised settings ......................24
Midlevel display .......................... 115
Mirror adjustment ........................... 9
Misted light covers .....................143
N New vehicle running-in ..............158
Number plate light .....................245
O
Object detection systems ...........199
Odometer ................................... 105 Oil, engine .......................... 278, 282
OnStar ........................................ 131
Outside temperature ....................95
Overrun cut-off ........................... 163
P Parking ................................ 19, 166
Parking assist ............................ 199
Parking brake ............................ 177
Parking lights ............................. 143
Particulate filter ........................... 168
Performance .............................. 287
Performing work ........................229
Pollen filter ................................. 156
Power button .............................. 159

307Power connector........................... 98
Power outlets ............................... 97
Power seat adjustment ................50
Power windows ............................ 41
Preheating ................................. 113
Puncture ..................................... 264
Q
Quickheat ................................... 155
R Radio Frequency Identification (RFID) ..................................... 303
Radio remote control ...................21
Reading lights ............................ 144
Rear floor storage cover ..............81
Rear fog light .....................114, 143
Rear seats .................................... 55
Rear storage ................................. 79
Rear view camera ...................... 208
Rear window wiper/washer .......... 94
Recommended fluids and lubricants ........................ 278, 282
Refuelling ................................... 218
Registered trademarks ...............301
Retained power off .....................160
Reversing lights .........................143
Ride control systems ..................179
Roof .............................................. 44
Roof load ...................................... 88
Roof rack ..................................... 87S
Safety belts ................................... 56
Safety net .................................... 84
Seat adjustment ............................. 7
Seat belt ........................................ 8
Seat belt reminder .....................109
Seat belts ..................................... 56
Seat heating Seat heating, front .....................54
Seat heating, rear .....................56
Seat position ................................ 47
Selector lever ..................... 169, 174
Service ............................... 156, 277
Service display .......................... 108
Service information ....................277
Side airbag system ......................62
Side blind spot alert ....................207
Sidelights .................................... 136
Side turn signal lights ................244
Software acknowledgement .......299
Software update ......................... 301
Spare wheel ............................... 267
Speed limiter....................... 115, 184
Speedometer ............................. 104
Sport mode ................................ 181
Starting and operating ................158
Starting off ................................... 17
Starting the engine ....................161
Steering ...................................... 158
Steering wheel adjustment ......9, 91Steering wheel controls ...............91
Stop-start system........................ 163
Storage ......................................... 71
Storage compartments .................71
Sunroof ........................................ 44
Sunvisor lights ........................... 145
Sun visors .................................... 43
Symbols ......................................... 4
T Tachometer ............................... 106
Tail lights ................................... 238
Three-point seat belt .................... 57
Tools .......................................... 253
Tow bar....................................... 221
Towing ................................ 221, 271
Towing another vehicle .............272
Towing equipment .....................223
Towing the vehicle .....................271
Traction Control system ............. 179
Traction Control system off......... 113
Traffic sign assistant ...........115, 211
Trailer coupling ........................... 221
Trailer stability assist .................226
Trailer towing ............................. 222
Transmission ............................... 16
Transmission display .........169, 173
Tread depth ............................... 260
Trip odometer ............................ 105
Turn and lane-change signals ...142
