2016 YAMAHA XVS950CU engine

Motorcycle care and stora ge
7-2
7
off any
deter gent resi due usin g
plenty of water, as it is harmful
to plastic parts.
 Do not use any harsh chemical
prod ucts on plastic parts. Be
sure to avoi d usin g cloths or
spon ges which have b een in
contact with stron g or a brasive
cleanin g prod ucts, solvent or
thinner, fuel ( gasoline), rust re-
movers or inhi bitors, brake flui d,
antifreeze or electrolyte.
 Do not use hi gh-pressure wash-
ers or steam-jet cleaners since
they cause water seepag e and
d eterioration in the followin g ar-
eas: seals (of wheel an d swin g-
arm bearin gs, fork an d b rakes),
electric components (couplers,
connectors, instruments,
switches an d li ghts), breather
hoses an d vents.
 For motorcycles equippe d with
a win dshiel d: Do not use stron g
cleaners or har d spon ges as
they will cause dullin g or
sc r

atchin g. Some cleanin g
compoun ds for plastic may
leave scratches on the win d- shiel
d. Test the pro duct on a
small hi dden part of the win d-
shiel d to make sure that it does
not leave any marks. If the win d-
shiel d is scratche d, use a quality
plastic polishin g compoun d af-
ter washing .
After normal useRemove dirt with warm water, a mild
detergent, and a soft, clean sponge,
and then rinse thoroughly with clean
water. Use a toothbrush or bottlebrush
for hard-to-reach areas. Stubborn dirt
and insects will come off more easily if
the area is covered with a wet cloth for
a few minutes before cleaning.
After riding in the rain, near the sea oron salt-sprayed roadsSince sea salt or salt sprayed on roads
during winter are extremely corrosive
in combination with water, carry out
the following steps after each ride in
the rain, near the sea or on salt-
sprayed roads.
TIPSalt sprayed on roads in the winter
may remain well into spring.1. Clean the motorcycle with cold
water and a mild detergent, after
the engine has cooled down.
NOTICE: Do not use warm wa-
ter since it increases the corro-
sive action of the salt.
[ECA10792]
2. After drying the motorcycle, apply a corrosion protection spray on all
metal, including chrome- and
nickel-plated, surfaces to prevent
corrosion.
After cleanin g
1. Dry the motorcycle with a chamois or an absorbing cloth.
2. Use a chrome polish to shine chrome, aluminum and stainless-
steel parts, including the exhaust
system. (Even the thermally in-
duced discoloring of stainless-
steel exhaust systems can be re-
moved through polishing.)
U2DEE1E0.book Page 2 Friday, September 4, 2015 4:52 PM

Motorcycle care and stora ge
7-3
7 3. To prevent corrosion, it is recom-
mended to apply a corrosion pro-
tection spray on all metal,
including chrome- and nickel-plat-
ed, surfaces.
4. Use spray oil as a universal clean- er to remove any remaining dirt.
5. Touch up minor paint damage caused by stones, etc.
6. Wax all painted and chrome-plat- ed surfaces. Avoid combination
cleaner waxes, many of which
contain abrasives that may mar
the paint or protective finish.
7. Let the motorcycle dry completely before storing or covering it.
WARNING
EWA11132
Contaminants on the brakes or tires
can cause loss of control.  Make sure that there is no oil or
wax on the brakes or tires.
 If necessary, clean the brake
d iscs an d b rake linin gs with a
re gular brake disc cleaner or
acetone, an d wash the tires with
warm water an d a mil d d eter-
g ent. Before ri din g at hi gher speed
s, test the motorcycle’s
b rakin g performance an d cor-
nerin g b ehavior.
NOTICE
ECA10951
 Apply spray oil an d wax spar-
in gly an d make sure to wipe off
any excess.
 Never apply oil or wax to the
drive belt.
 Never apply oil or wax to any
rubber an d plastic parts, but
treat them with a suitab le care
prod uct.
 Avoi d usin g a brasive polishin g
compoun ds as they will wear
away the paint.TIP Consult a Yamaha dealer for ad-
vice on what products to use.
 Washing, rainy weather or humid
climates can cause the headlight
lens to fog. Turning the headlight
on for a short period of time will
help remove the moisture from the
lens.
EAU26283
Stora geShort-term
Always store your motorcycle in a cool,
dry place and, if necessary, protect it
against dust with a porous cover. Be
sure the engine and the exhaust sys-
tem are cool before covering the mo-
torcycle.NOTICE
ECA10811
 Storin g the motorcycle in a
poorly ventilate d room or cover-
in g it with a tarp, while it is still
wet, will allow water an d humi d-
ity to seep in and cause rust.
 To prevent corrosion, avoi d
d amp cellars, sta bles (b ecause
of the presence of ammonia)
an d areas where stron g chemi-
cals are store d.Lon g-term
Before storing your motorcycle for sev-
eral months: 1. Follow all the instructions in the “Care” section of this chapter.
U2DEE1E0.book Page 3 Friday, September 4, 2015 4:52 PM

Motorcycle care and stora ge
7-4
7
2. Fill up the fuel tank and add fuel
stabilizer (if available) to prevent
the fuel tank from rusting and the
fuel from deteriorating.
3. Perform the following steps to protect the cylinders, piston rings,
etc. from corrosion.a. Remove the spark plug caps and spark plugs.
b. Pour a teaspoonful of engine oil into each spark plug bore.
c. Install the spark plug caps onto the spark plugs, and then
place the spark plugs on the
cylinder head so that the elec-
trodes are grounded. (This will
limit sparking during the next
step.)
d. Turn the engine over several times with the starter. (This will
coat the cylinder walls with oil.)
WARNING! To prevent dam-
a g e or injury from sparkin g,
make sure to groun d the
spark plu g electro des while
turning the en gine over.
[EWA10952]
e. Remove the spark plug caps
from the spark plugs, and then
install the spark plugs and the
spark plug caps.
4. Lubricate all control cables and the pivoting points of all levers and
pedals as well as of the side-
stand/centerstand.
5. Check and, if necessary, correct the tire air pressure, and then lift
the motorcycle so that both of its
wheels are off the ground. Alterna-
tively, turn the wheels a little every
month in order to prevent the tires
from becoming degraded in one
spot.
6. Cover the muffler outlet with a plastic bag to prevent moisture
from entering it.
7. Remove the battery and fully charge it. Store it in a cool, dry
place and charge it once a month.
Do not store the battery in an ex-
cessively cold or warm place [less
than 0 °C (30°F) or more than 30
°C (90°F)]. For more information
on storing the battery, see page
6-25.
TIPMake any necessary repairs before
storing the motorcycle.
U2DEE1E0.book Page 4 Friday, September 4, 2015 4:52 PM

Specifications
8-1
8
Dimensions:Overall length:2290 mm (90.2 in)
Overall width:
830 mm (32.7 in)
Overall height: 1120 mm (44.1 in)
Seat height: 690 mm (27.2 in)
Wheelbase:
1570 mm (61.8 in)
Ground clearance: 130 mm (5.12 in)
Minimum turning radius: 3.3 m (10.83 ft)Wei ght:Curb weight:
For non-ABS models 247 kg (545 lb)
For ABS models 251 kg (553 lb)Engine:Combustion cycle:
4-stroke
Cooling system:
Air cooled
Valve train: SOHC
Cylinder arrangement: V-type
Number of cylinders:
2-cylinder
Displacement: 942 cm³
Bore × stroke:
85.0 × 83.0 mm (3.35 × 3.27 in) Compression ratio:
9.0 : 1
Starting system: Electric starter
Lubrication system:
Wet sump
Engine oil:Recommended brand:
YAMALUBE
SAE viscosity grades:
10W-40
Recommended engine oil grade: API service SG type or higher, JASO
standard MA
Engine oil quantity: Oil change:
3.70 L (3.91 US qt, 3.26 Imp.qt)
With oil filter removal: 4.00 L (4.23 US qt, 3.52 Imp.qt)Air filter:Air filter element:
Oil-coated paper elementFuel:Recommended fuel:Regular unleaded gasoline (Gasohol [E10]
acceptable)
Fuel tank capacity: 12 L (3.2 US gal, 2.6 Imp.gal)
Fuel reserve amount:
2.8 L (0.74 US gal, 0.62 Imp.gal)Fuel injection:Throttle body:ID mark: 1TP1 01
Spark plu g(s):Manufacturer/model:
NGK/CPR7EA-9
Spark plug gap:
0.8–0.9 mm (0.031–0.035 in)Clutch:Clutch type:Wet, multiple-discDrivetrain:Primary reduction ratio:1.674 (72/43)
Final drive: Belt
Secondary reduction ratio:
2.333 (70/30)
Transmission type: Constant mesh 5-speed
Gear ratio: 1st: 3.067 (46/15)
2nd: 2.063 (33/16)
3rd:
1.579 (30/19)
4th: 1.259 (34/27)
5th: 1.042 (25/24)Chassis:Frame type:Double cradle
Caster angle: 29.0 °
U2DEE1E0.book Page 1 Friday, September 4, 2015 4:52 PM

Specifications
8-3
8
Neutral indicator light:LED
High beam indicator light: LED
Oil level warning light:
LED
Turn signal indicator light: LED
Fuel level warning light: LED
Engine trouble warning light:
LED
ABS warning light: For ABS models LED
Immobilizer system indicator light: LEDFuse(s):Main fuse:40.0 A
Headlight fuse: 20.0 A
Signaling system fuse:
7.5 A
Ignition fuse: 15.0 A
Parking lighting fuse: 15.0 A
Fuel injection system fuse:
10.0 A
ABS control unit fuse: For ABS models 7.5 A
ABS motor fuse: For ABS models 30.0 A ABS solenoid fuse:
For ABS models 15.0 A
Backup fuse: 7.5 A
U2DEE1E0.book Page 3 Friday, September 4, 2015 4:52 PM

Consumer information
9-1
9
EAU53562
Id entification num bersRecord the vehicle identification num-
ber, engine serial number, and the
model label information in the spaces
provided below. These identification
numbers are needed when registering
the vehicle with the authorities in your
area and when ordering spare parts
from a Yamaha dealer.
VEHICLE IDENTIFICATION NUMBER:
ENGINE SERIAL NUMBER:
MODEL LABEL INFORMATION:
EAU26401
Vehicle i dentification num ber
The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.TIPThe vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in your
area.
EAU26442
En gine serial num ber
The engine serial number is stamped
into the crankcase.
EAU26471
Mo del la bel
1. Vehicle identification number
1
1. Engine serial number
1. Model label
1
1
U2DEE1E0.book Page 1 Friday, September 4, 2015 4:52 PM

10-1
10
Index
AABS (for ABS models) .......................... 3-11
ABS warning light (for ABS models) ....... 3-4
Air filter element, replacing ................... 6-13
Auxiliary light bulb, replacing ............... 6-30BBattery .................................................. 6-25
Brake and clutch levers, checking and
lubricating........................................... 6-23
Brake and shift pedals, checking and lubricating........................................... 6-22
Brake fluid, changing............................ 6-20
Brake fluid level, checking.................... 6-19
Brake lever............................................ 3-10
Brake lever free play, checking ............ 6-17
Brake light switches ............................. 6-18
Brake pedal .......................................... 3-10
Brake/tail light....................................... 6-31CCables, checking and lubricating ......... 6-21
Care ........................................................ 7-1
Catalytic converter ............................... 3-14
Clutch lever............................................. 3-9
Clutch lever free play, adjusting ........... 6-16DDimmer switch........................................ 3-8
Drive belt slack ..................................... 6-21EEngine break-in ...................................... 5-3
Engine oil and oil filter cartridge ........... 6-10
Engine serial number .............................. 9-1
Engine stop switch ................................. 3-8
Engine trouble warning light ................... 3-4
FFront and rear brake pads, checking ... 6-18
Front fork, checking ............................. 6-24
Fuel ...................................................... 3-12
Fuel consumption, tips for reducing ...... 5-3
Fuel level warning light........................... 3-4
Fuel tank breather/overflow hose ........ 3-14
Fuel tank cap........................................ 3-12
Fuses, replacing ................................... 6-27HHandlebar switches ............................... 3-8
Hazard switch ........................................ 3-9
Headlight bulb, replacing ..................... 6-29
High beam indicator light ....................... 3-3
Horn switch ............................................ 3-8IIdentification numbers ........................... 9-1
Ignition circuit cut-off system .............. 3-18
Immobilizer system ................................ 3-1
Immobilizer system indicator light ......... 3-5
Indicator lights and warning lights ......... 3-3LLicense plate light ................................ 6-32MMain switch ............................................ 3-2
Maintenance and lubrication, periodic... 6-4
Maintenance, emission control
system ................................................. 6-3
Matte color, caution ............................... 7-1
Model label............................................. 9-1
Multi-function meter unit ........................ 3-5NNeutral indicator light ............................. 3-3
OOil level warning light .............................. 3-3PPanel, removing and installing ................ 6-8
Parking.................................................... 5-4
Part locations.......................................... 2-1
Pass switch............................................. 3-8RRESET switch ......................................... 3-9
Rider seat.............................................. 3-15SSafety information................................... 1-1
SELECT switch ....................................... 3-9
Shifting.................................................... 5-2
Shift pedal............................................. 3-10
Shock absorber assemblies,
adjusting ............................................. 3-16
Sidestand.............................................. 3-17
Sidestand, checking and
lubricating ........................................... 6-23
Spark plugs, checking ............................ 6-8
Specifications ......................................... 8-1
Starting the engine ................................. 5-1
Start switch ............................................. 3-8
Steering, checking ................................ 6-25
Steering lock ......................................... 3-15
Storage ................................................... 7-3
Supporting the motorcycle ................... 6-32
Swingarm pivots, lubricating ................ 6-24TThrottle grip and cable, checking and lubricating ........................................... 6-22
Throttle grip free play, checking ........... 6-13
Tires ...................................................... 6-14
U2DEE1E0.book Page 1 Friday, September 4, 2015 4:52 PM
