2016 YAMAHA XMAX 400 fuse
[x] Cancel search: fusePage 6 of 92
TABLE OF CONTENTSSAFETY INFORMATION.................. 1-1
Further safe-riding points ............... 1-5
DESCRIPTION.................................. 2-1
Left view ......................................... 2-1
Right view ....................................... 2-2
Controls and instruments ............... 2-3
INSTRUMENT AND CONTROL
FUNCTIONS...................................... 3-1
Immobilizer system......................... 3-1
Main switch/steering lock............... 3-2
Indicator lights and warning
lights............................................ 3-3
Speedometer .................................. 3-5
Tachometer .................................... 3-6
Multi-function display ..................... 3-6
Anti-theft alarm (optional) ............. 3-10
Handlebar switches ...................... 3-10
Front brake lever .......................... 3-11
Rear brake lever ........................... 3-12
ABS (for ABS models) .................. 3-12
Fuel tank cap ................................ 3-13
Fuel ............................................... 3-14
Catalytic converters...................... 3-15
Seat .............................................. 3-16
Storage compartments................. 3-16
Adjusting the shock absorber
assemblies ................................ 3-18
Sidestand ..................................... 3-18
Ignition circuit cut-off system ....... 3-19FOR YOUR SAFETY –
PRE-OPERATION CHECKS............. 4-1
OPERATION AND IMPORTANT
RIDING POINTS................................ 5-1
Starting the engine .......................... 5-1
Starting off ...................................... 5-2
Acceleration and deceleration ........ 5-3
Braking ............................................ 5-3
Tips for reducing fuel
consumption ................................ 5-4
Engine break-in ............................... 5-4
Parking ............................................ 5-5
PERIODIC MAINTENANCE AND
ADJUSTMENT................................... 6-1
Owner’s tool kit ............................... 6-2
Periodic maintenance chart for the
emission control system .............. 6-3
General maintenance and
lubrication chart ........................... 6-4
Removing and installing panels ...... 6-8
Checking the spark plug ............... 6-11
Engine oil and oil filter element ..... 6-13
Final transmission oil..................... 6-15
Coolant.......................................... 6-16
Air filter elements and check
hoses and V-belt case air filter
element ...................................... 6-18
Checking the throttle grip free
play ............................................ 6-20Valve clearance............................. 6-20
Tires .............................................. 6-21
Cast wheels .................................. 6-22
Checking the front and rear brake
lever free play ............................ 6-23
Checking the front and rear brake
pads .......................................... 6-24
Checking the brake fluid level ...... 6-24
Changing the brake fluid .............. 6-26
Checking and lubricating the
cables ........................................ 6-26
Checking and lubricating the
throttle grip and cable ............... 6-26
Lubricating the front and rear
brake levers ............................... 6-27
Checking and lubricating the
centerstand and sidestand........ 6-27
Checking the front fork ................. 6-28
Checking the steering................... 6-29
Checking the wheel bearings ....... 6-29
Battery .......................................... 6-29
Replacing the fuses ...................... 6-31
Replacing a headlight bulb ........... 6-32
Tail/brake light .............................. 6-33
Front turn signal light .................... 6-33
Replacing a rear turn signal light
bulb ........................................... 6-33
Replacing the license plate light
bulb ........................................... 6-34
Auxiliary light ................................ 6-35
Troubleshooting............................ 6-35U1SDE1E0.book Page 1 Monday, September 23, 2013 3:55 PM
Page 14 of 92
DESCRIPTION
2-1
2
EAU10411
Left view
1
5
8
2
4
3
7 6
9
10
11
12
1. Headlight (page 6-32)
2. Battery (page 6-29)
3. Main fuse (page 6-31)
4. Coolant reservoir cap (page 6-16)
5. Coolant level check window (page 6-16)
6. Rear storage compartment (page 3-16)
7. V-belt case air filter element (page 6-18)
8. Shock absorber assembly spring preload adjusting ring (page 3-18)9. Air filter element (left) (page 6-18)
10.Engine oil filter element (page 6-13)
11.Sidestand (page 3-18)
12.Front brake pads (page 6-24)U1SDE1E0.book Page 1 Monday, September 23, 2013 3:55 PM
Page 15 of 92
DESCRIPTION
2-2
2
EAU10421
Right view
7
5 6 1
2
4
3
1. Grab bar (page 5-2)
2. Seat (page 3-16)
3. Fuel tank cap (page 3-13)
4. Fuses (page 6-31)
5. Centerstand (page 6-27)
6. Air filter element (right) (page 6-18)
7. Shock absorber assembly spring preload adjusting ring (page 3-18)
U1SDE1E0.book Page 2 Monday, September 23, 2013 3:55 PM
Page 74 of 92
PERIODIC MAINTENANCE AND ADJUSTMENT
6-31
6
EAUM3091
Replacing the fusesThe fuse box, which contains the fuses
for the individual circuits, is located be-
hind panel C. (See page 6-8.)TIPThe main fuse, which is in a different
and hard-to-reach location, must be
replaced by a Yamaha dealer.If a fuse for the individual circuits is
blown, replace it as follows.
1.
the electrical circuit in question.
2. Remove the blown fuse, and then
install a new fuse of the specified
amperage. WARNING! Do notuse a fuse of a higher amperage
rating than recommended to
avoid causing extensive dam-
age to the electrical system and
possibly a fire.
[EWA15132]
TIP
tool kit. Use the tongs to remove and
install a fuse.
YP400R
1. Main fuse
2. Spare main fuseZAUM1058
11
2
1. Fuse boxZAUM1036
1
1. Radiator fan fuse
2. ECU fuse
3. Backup fuse
4. Signaling system fuse
5. Headlight fuse
6. Ignition fuse
7. Spare fuse
8. Hazard fuseZAUM1037
7
1
2
3
4
5
620 10
1020
1010 1010
7.57.5
U1SDE1E0.book Page 31 Monday, September 23, 2013 3:55 PM
Page 75 of 92
PERIODIC MAINTENANCE AND ADJUSTMENT
6-32
6 YP400RA
3. Turn the key to “ON” and turn on
the electrical circuit in question to
check if the device operates.
4. If the fuse immediately blows
again, have a Yamaha dealer
check the electrical system.
EAU34242
Replacing a headlight bulbThis model is equipped with halogen
bulb headlights. If a headlight bulb
burns out, have a Yamaha dealer re-
place it and, if necessary, adjust the
headlight beam.
1. Radiator fan fuse
2. ECU fuse
3. Backup fuse
4. Signaling system fuse
5. Headlight fuse
6. Ignition fuse
7. Spare fuse
8. Hazard fuse
9. ABS control unit fuse
10.ABS motor fuse
11.ABS solenoid fuseZAUM1129
10
10
10
20
30
30
7
7
11
1
2
3
4
56
20 1020
1010 1010
7.57.5
9
10
Specified fuses:
Main fuse:
30.0 A
Ignition fuse:
10.0 A
Signaling system fuse:
10.0 A
Headlight fuse:
20.0 A
Hazard fuse:
10.0 A
Radiator fan fuse:
7.5 A
ABS control unit fuse:
YP400RA 10.0 A
ABS motor fuse:
YP400RA 30.0 A
ABS solenoid fuse:
YP400RA 20.0 A
Backup fuse:
10.0 A
U1SDE1E0.book Page 32 Monday, September 23, 2013 3:55 PM
Page 87 of 92
SPECIFICATIONS
8-3
8
Voltage, capacity:
12 V, 8.0 AhHeadlight:Bulb type:
Halogen bulbBulb voltage, wattage × quantity:Headlight:
12 V, 55.0 W × 2
Tail/brake light:
LED
Front turn signal light:
12 V, 10.0 W × 2
Rear turn signal light:
12 V, 10.0 W × 2
Auxiliary light:
LED
License plate light:
12 V, 5.0 W × 1
Meter lighting:
12 V, 2.0 W × 3
High beam indicator light:
12 V, 1.4 W × 1
Turn signal indicator light:
12 V, 1.4 W × 2
Engine trouble warning light:
12 V, 1.4 W × 1
ABS warning light:
YP400RA 12 V, 1.4 W × 1
Immobilizer system indicator light:
LEDFuses:Main fuse:
30.0 AHeadlight fuse:
20.0 A
Signaling system fuse:
10.0 A
Ignition fuse:
10.0 A
Radiator fan fuse:
7.5 A
Hazard fuse:
10.0 A
ECU fuse:
10.0 A
ABS control unit fuse:
YP400RA 10.0 A
ABS motor fuse:
YP400RA 30.0 A
ABS solenoid fuse:
YP400RA 20.0 A
Backup fuse:
10.0 A
U1SDE1E0.book Page 3 Monday, September 23, 2013 3:55 PM
Page 89 of 92
10-1
10
INDEX
AABS (for ABS models) .......................... 3-12
ABS warning light (for ABS models) ....... 3-4
Acceleration and deceleration ................ 5-3
Air filter elements and check hoses
and V-belt case air filter element ....... 6-18
Anti-theft alarm (optional) ..................... 3-10
Auxiliary light ........................................ 6-35BBattery .................................................. 6-29
Brake fluid, changing............................ 6-26
Brake fluid level, checking.................... 6-24
Brake lever, front .................................. 3-11
Brake lever, rear ................................... 3-12
Brake levers, lubricating ....................... 6-27
Braking ................................................... 5-3CCables, checking and lubricating ......... 6-26
Care ........................................................ 7-1
Catalytic converters.............................. 3-15
Centerstand and sidestand, checking
and lubricating ................................... 6-27
Coolant ................................................. 6-16DDimmer switch...................................... 3-11EEngine break-in ...................................... 5-4
Engine oil and oil filter element............. 6-13
Engine trouble warning light ................... 3-4FFinal transmission oil ............................ 6-15
Front and rear brake lever free play,
checking ............................................. 6-23
Front and rear brake pads, checking ... 6-24Front fork, checking ............................. 6-28
Front turn signal light ........................... 6-33
Fuel ...................................................... 3-14
Fuel consumption, tips for reducing ...... 5-4
Fuel tank cap........................................ 3-13
Fuses, replacing ................................... 6-31
HHandlebar switches ............................. 3-10
Hazard switch ...................................... 3-11
Headlight bulb, replacing ..................... 6-32
High beam indicator light ....................... 3-4
Horn switch .......................................... 3-11IIdentification numbers ........................... 9-1
Ignition circuit cut-off system .............. 3-19
Immobilizer system ................................ 3-1
Immobilizer system indicator light ......... 3-4
Indicator lights and warning lights ......... 3-3LLicense plate light bulb, replacing ....... 6-34MMain switch/steering lock ...................... 3-2
Maintenance and lubrication, periodic... 6-4
Maintenance, emission control
system ................................................. 6-3
Matte color, caution ............................... 7-1
Model label............................................. 9-1
Multi-function display............................. 3-6PPanels, removing and installing ............. 6-8
Parking ................................................... 5-5
Part locations ......................................... 2-1
Pass switch .......................................... 3-11
SSafe-riding points ................................... 1-5
Safety information................................... 1-1
Seat....................................................... 3-16
Shock absorber assemblies,
adjusting ............................................. 3-18
Sidestand.............................................. 3-18
Spark plug, checking ............................ 6-11
Specifications ......................................... 8-1
Speedometer .......................................... 3-5
Starting off .............................................. 5-2
Starting the engine ................................. 5-1
Start switch ........................................... 3-11
Steering, checking ................................ 6-29
Storage ................................................... 7-4
Storage compartments ......................... 3-16TTachometer............................................. 3-6
Tail/brake light ...................................... 6-33
Throttle grip and cable, checking and
lubricating ........................................... 6-26
Throttle grip free play, checking ........... 6-20
Tires ...................................................... 6-21
Tool kit .................................................... 6-2
Troubleshooting .................................... 6-35
Troubleshooting charts ......................... 6-36
Turn signal indicator lights...................... 3-3
Turn signal light bulb (rear),
replacing ............................................. 6-33
Turn signal switch ................................. 3-11VValve clearance..................................... 6-20
Vehicle identification number ................. 9-1
U1SDE1E0.book Page 1 Monday, September 23, 2013 3:55 PM
