Valve clearance .................................. 8-41
Brakes ................................................ 8-41
Checking the front and rear brake pads.................................................. 8-41
Checking the brake fluid level ............ 8-42
Brake fluid replacement ..................... 8-43
Checking the brake pedal .................. 8-43
Parking brake ..................................... 8-44
Brake light switch adjustment ............ 8-44
Cable inspection and lubrication........ 8-45
Brake pedal and accelerator pedal
lubrication ......................................... 8-45
Checking the stabilizer bushes .......... 8-46
Rear knuckle upper and lower pivot
lubrication (left and right) .................. 8-46
Steering shaft lubrication ................... 8-47
Wheel removal.................................... 8-47
Checking and tightening the bead lock .................................................. 8-48
Tire replacement ................................ 8-48
Wheel installation ............................... 8-49
Battery ................................................ 8-50
Jump-starting ..................................... 8-53 Fuse replacement ...............................8-54
Replacing a headlight bulb .................8-57
Headlight beam adjustment ...............8-59
Tail/brake light bulb replacement .......8-60
Troubleshooting ..................................8-60
Troubleshooting charts .......................8-62
CLEANING AND STORAGE ....................9-1 Cleaning................................................9-1
Storage .................................................9-2
SPECIFICATIONS..................................10-1
CONSUMER INFORMATION ................11-1 Identification number records.............11-1
INDEX ....................................................12-1
UBN57AE0.book Page 3 Tuesday, November 24, 2015 1:42 PM

8-57
8
4. Turn the key to “ ” (on) and turn on theelectrical circuit in question to check if
the device operates. If the fuse blows
again immediately, have a Yamaha dealer
check the electrical system.
5. Install the hood.EBU32670Replacing a headlight bulbIf a headlight bulb burns out, replace it as fol-
lows. 1. Remove the cover at the rear of the head- light by pulling it off. 2. Remove the headlight bulb cover by pull-
ing it off.
3. Disconnect the headlight coupler.1. Cover at the rear of the headlight
1
1. Headlight bulb cover
1
UBN57AE0.book Page 57 Tuesday, November 24, 2015 1:42 PM

8-58
8
4. Unhook the headlight bulb holder.5. Wait for the headlight bulb to cool before
touching or removing it. Remove the
burnt-out bulb by pulling it out.
6. Place a new headlight bulb into position, and then secure it with the bulb holder.
NOTICE: Do not touch the glass part of
the headlight bulb to keep it free from
oil, otherwise the transparency of the
glass, the luminosity of the bulb, and
the bulb life will be adversely affected.
Thoroughly clean off any dirt and fin-
gerprints on the headlight bulb using a
cloth moistened with alcohol or thin-
ner.
[ECB00652]
1. Headlight coupler
1. Headlight bulb holder
11
UBN57AE0.book Page 58 Tuesday, November 24, 2015 1:42 PM

8-59
8
7. Connect the headlight coupler.
8. Install the bulb cover and the cover at therear of the headlight. NOTICE: Make
sure the headlight bulb cover is se-
curely fitted over the bulb holder and
seated properly.
[ECB02210]
9. Adjust the headlight beam if necessary.
EBU32681Headlight beam adjustmentNOTICEECB00691It is advisable to have a Yamaha dealer
make this adjustment. To raise the beam, turn the headlight beam
adjusting screw in direction (a).
To lower the beam, turn the headlight beam
adjusting screw in direction (b).
1. Do not touch the glass part of the bulb.
1
1. Headlight beam adjusting screw
1
(a)
(b)
UBN57AE0.book Page 59 Tuesday, November 24, 2015 1:42 PM

10-4
10
Rim size:12 x 7.5ATFront brake:Type:
Hydraulic disc brake
Specified brake fluid: DOT 4Rear brake:Type:
Hydraulic disc brake
Specified brake fluid: DOT 4Front suspension:Type:
Double wishbone
Spring/shock absorber type: Coil spring/gas-oil damper
Wheel travel: 246 mm (9.7 in)Rear suspension:Type:Double wishbone
Spring/shock absorber type: Coil spring/gas-oil damper
Wheel travel:
269 mm (10.6 in)Electrical system:Ignition system:TCI
Charging system:
AC magneto
Battery:Model:U1-H11L
Voltage, capacity:
12 V, 28.0 AhHeadlight:Bulb type:Halogen bulbBulb voltage, wattage × quantity:Headlight:
12 V, 35.0/35.0 W × 2
Tail/brake light: 12 V, 5.0/21.0 W × 2
Neutral indicator light:
LED
Reverse indicator light: LED
Coolant temperature warning light: LED
Engine trouble warning light:
LED
Parking brake indicator light: LED
On-Command four-wheel-drive/differential gear lock
indicator: LCD
High-range indicator light: LED
Low-range indicator light:
LED
Differential gear lock indicator light: LED
UBN57AE0.book Page 4 Tuesday, November 24, 2015 1:42 PM

12-1
12
INDEX
AAccelerator pedal ......................................................... 4-12
Accelerator pedal, Pre-operation check ........................ 5-7
Air filter case/air duct check hose, cleaning ................ 8-38
Air filter element, cleaning ........................................... 8-34
Auxiliary DC jack .......................................................... 4-34
Axle boots .................................................................... 8-31BBasic guide for safe use ................................................ 7-1
Battery, Periodic maintenance .................................... 8-50
Bead lock, checking and tightening ............................ 8-48
Brake fluid level, checking ........................................... 8-42
Brake fluid, replacing ................................................... 8-43
Brake light switch, adjusting ........................................ 8-44
Brake pedal .................................................................. 4-12
Brake pedal and accelerator pedal, lubrication ........... 8-45
Brake pedal, checking ................................................. 8-43
Brakes, Periodic maintenance ..................................... 8-41
Brakes, Pre-operation check ......................................... 5-3CCable, inspecting and lubrication ................................ 8-45
Cargo bed .................................................................... 4-22
Cleaning ......................................................................... 9-1
Control cables, Pre-operation check ............................. 5-8
Coolant, Periodic maintenance ................................... 8-25
Coolant, Pre-operation check ........................................ 5-6
Coolant temperature warning light ................................ 4-4
Cup holders ................................................................. 4-21
DDifferential gear oil, Periodic maintenance .................. 8-22
Differential gear oil, Pre-operation check ...................... 5-6
Doors ........................................................................... 4-15
Driver seat position ...................................................... 4-16
Drive select lever ......................................................... 4-14
Drive select lever operation and reverse driving ............ 6-3EEngine break-in .............................................................. 6-1
Engine oil and oil filter cartridge, Periodic maintenance .............................................................. 8-14
Engine oil, Pre-operation check .................................... 5-5
Engine trouble warning light .......................................... 4-4
EPS warning light .......................................................... 4-5FFinal gear oil, Periodic maintenance ............................ 8-20
Final gear oil, Pre-operation check ................................ 5-6
Fittings and fasteners, Pre-operation check ................. 5-8
Front and rear brake pads, checking .......................... 8-41
Fuel, Pre-operation check ............................................. 5-3
Fuel tank cap ............................................................... 4-14
Fuse, replacing ............................................................ 8-54GGlove compartment ..................................................... 4-17HHeadlight beam, adjusting ........................................... 8-59
Headlight bulb, replacing ............................................. 8-57
Helmet indicator light ..................................................... 4-5
High-range indicator light .............................................. 4-2
Hood ............................................................................ 8-10
Horn switch .................................................................. 4-12
