Maintenance
57
(2) Remove the four screws, and then re-
move the handlebar cover.
(3) Turn the handlebars so that the left han-
dlebar grip is facing down.
(4) Loosen the locknut.
(5) Tighten or loosen the adjusting nut until
the desired amount of friction is ob-
tained.
(6) While holding the adjusting nut with a
wrench, tighten the locknut to the speci-
fied torque.
(7) Securely install the handlebar cover and
four screws in their original positions.(8) While holding the steering pole, move
the lock pin to the stowed position, and
then lower the steering pole.
EJU31289Adjusting the jet thrust nozzle angle
The angle of the jet thrust nozzle can be ad-
justed to two settings to suit operator prefer-
ence.
To adjust the jet thrust nozzle angle:
(1) Remove the two bolts, and then remove
the steering pole cover.
(2) Pull back the outer sleeve of the steering
cable joint, and then disconnect the joint
from the steering cable pivot bolt.
1Handlebar cover
1Adjusting nut
2Locknut
Tightening torque:
Locknut:
29.0 Nm (2.96 kgf-m, 21.4 ft-lb)
1
1Steering pole cover
1Steering cable joint
UF4D71E0.book Page 57 Thursday, April 23, 2015 1:48 PM

Maintenance
58
(3) Remove the steering cable pivot bolt.
(4) Select the nozzle angle, install the steer-
ing cable pivot bolt with the lock washer
in the desired position (P1 or P2) on the
steering column, and then tighten the
bolt to the specified torque.TIP:
The outermost hole in the steering column
cannot be used.
(5) Securely connect the steering cable joint
to the steering cable pivot bolt.
(6) Securely install the steering pole cover
and two bolts in their original positions.
1Steering cable pivot bolt
2Steering column
1Nozzle angles
1Nozzle angles
2Steering cable pivot bolt positions
Standard steering cable pivot bolt posi-
tion:
P2
Tightening torque:
Steering cable pivot bolt:
5.4 Nm (0.55 kgf-m, 4.0 ft-lb)
UF4D71E0.book Page 58 Thursday, April 23, 2015 1:48 PM

Maintenance
59
EJU40831Periodic maintenance chart
The periodic maintenance chart gives general guidelines for periodic maintenance. Have a
Yamaha dealer perform the checks in the following chart. However, maintenance may need
to be performed more frequently depending on your operating conditions. If you have any
questions, consult a Yamaha dealer.
This “ ” mark indicates maintenance that you may do yourself.
This “ ” mark indicates items to be checked and serviced by a Yamaha dealer.
Item OperationInitial Thereafter every
Page 10
hours50 hours100
hours200
hours
6
months12
months12
months24
months
Spark plugsCheck, clean, replace 60
Lubrication pointsLubricate 54
Intermediate
housingLubricate 61
Fuel systemCheck —
Fuel filterCheck 61
Check, replace —
Fuel tankCheck, clean —
CarburetorCheck, adjust —
Engine idling
speedCheck, adjust 62
Carburetor throttle
shaftCheck —
Bilge strainerClean —
ImpellerCheck —
Jet thrust nozzle
angleCheck, adjust —
Handlebar pivot
shaftCheck, adjust —
Steering frictionCheck, adjust —
Throttle cableCheck, adjust —
Choke cableCheck, adjust 61
BatteryCheck, charge —
Rubber couplingCheck —
Engine mountCheck —
Nuts and boltsCheck —
UF4D71E0.book Page 59 Thursday, April 23, 2015 1:48 PM

Trouble recovery
69
EJU34735Submerged watercraft
If the watercraft is submerged or flooded with
water, drain the bilge water from the engine
compartment. Then, have a Yamaha dealer
service the watercraft as soon as possible.
(1) Remove the watercraft from the water,
and then remove the hood.
(2) Turn the fuel cock knob to “OFF”.
(3) Turn the watercraft over far enough to
drain the bilge water from the engine
compartment. NOTICE: Turning the
watercraft on its side with the hood
removed could cause damage to the
steering pole. Use two people to pro-
vide enough support to make sure
that the steering pole is not damaged.
[ECJ00702]
(4) Turn the watercraft upright again.
(5) Have the watercraft serviced by a
Yamaha dealer as soon as possible.
NOTICE: Be sure to have a Yamaha
dealer inspect the watercraft. Other-
wise, serious engine damage could
result.
[ECJ00792]
UF4D71E0.book Page 69 Thursday, April 23, 2015 1:48 PM

Index
71
P
Periodic maintenance chart ..................... 59
Post-launch checks ................................. 39
Post-operation care ................................. 50
Pre-launch checks ................................... 35
Pre-operation check points ..................... 35
Pre-operation checklist ............................ 33
Primary Identification (PRI-ID) number ...... 1
R
Recommended equipment ...................... 12
Rustproofing ............................................ 55
S
Safe boating rules .................................... 14
Safety equipment check .......................... 39
Spark plugs, checking ............................. 60
Start switch .............................................. 19
Starting off ............................................... 45
Starting the engine on water .................... 41
Steering friction, adjusting ....................... 56
Steering pole ............................................ 20
Steering pole check ................................. 37
Steering system ....................................... 20
Steering system checks ........................... 36
Stern rope hole ........................................ 25
Stopping the engine ................................. 43
Stopping the watercraft ........................... 45
Storage pouch ......................................... 25
Storage pouch checks ............................. 38
Submerged watercraft ............................. 69
Switch checks .......................................... 38
T
Throttle lever ............................................ 20
Throttle lever checks ................................ 37
Tool kit ..................................................... 56
Towing the watercraft .............................. 68
Transporting ............................................. 31
Troubleshooting ....................................... 64
Troubleshooting chart .............................. 64
Turning the watercraft .............................. 43
W
Water separator ....................................... 22
Water separator check............................. 36
Watercraft characteristics ........................ 13
Watercraft control functions .................... 19
